Ezviz CS-X5S-16H User manual

SK

COPYRIGHT © Hangzhou EZVIZ Software Co., Ltd.. ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou EZVIZ Software Co.,
Ltd. (hereinafter referred to as “EZVIZ”). This user manual (hereinafter referred to as “the Manual”) cannot be reproduced, changed,
translated, or distributed, partially or wholly, by any means, without the prior written permission of EZVIZ. Unless otherwise stipulated,
EZVIZ does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.
About this Manual
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter
are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware
updates or other reasons. Please find the latest version in the ™ website (http://www.ezvizlife.com).
Revision Record
New release – January, 2019
Trademarks Acknowledgement
™, ™, and other EZVIZ’s trademarks and logos are the properties of EZVIZ in various jurisdictions. Other trademarks
and logos mentioned below are the properties of their respective owners.
Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND
FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND ERRORS, AND EZVIZ MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT
OF THIRD PARTY. IN NO EVENT WILL EZVIZ, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,
CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS
BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ’S TOTAL LIABILITY FOR ALL DAMAGES EXCEED THE
ORIGINAL PURCHASE PRICE OF THE PRODUCT.
EZVIZ DOES NOT UNDERTAKE ANY LIABILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE AS THE RESULT OF PRODUCT INTERRUPTION
OR SERVICE TERMINATION CAUSED BY: A) IMPROPER INSTALLATION OR USAGE OTHER THAN AS REQUESTED; B) THE PROTECTION OF
NATIONAL OR PUBLIC INTERESTS; C) FORCE MAJEURE; D) YOURSELF OR THE THIRD PARTY, INCLUDING WITHOUT LIMITATION, USING ANY
THIRD PARTY’S PRODUCTS, SOFTWARE, APPLICATIONS, AND AMONG OTHERS.
REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. EZVIZ SHALL
NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK,
HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, EZVIZ WILL PROVIDE TIMELY TECHNICAL
SUPPORT IF REQUIRED.
SURVEILLANCE LAWS AND DATA PROTECTION LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION
BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. EZVIZ SHALL NOT BE LIABLE
IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THE ABOVE AND THE APPLICABLE LAW, THE LATTER PREVAILS.
Regulatory Information
FCC Information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
product generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this product does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and comply therefore with
the applicable harmonized European standards listed under the Radio Equipment Directive 2014/53/EU, the EMC
Directive 2014/30/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal
waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase
of equivalent new equipment, or dispose of it at designated collection points. For more information see: www.
recyclethis.info.
2006/66/EC and its amendment 2013/56/EU (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery
information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb),
or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point. For
more information see: www.recyclethis.info.
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
EC DECLARATION OF CONFORMITY
Hereby, Hangzhou EZVIZ Software Co.,Ltd. declares that the radio equipment type [CS-X5S-16H] is in compliance with Directive 2014/53/
EU.
The full text of the EC DECLARATION OF CONFORMITY is available at the following web link:
http://www.ezvizlife.com/declaration-of-conformity.
Safety Instruction
Due to the product shape and dimension, the name and address of the importer/manufacturer are printed on the
package.
Customer Service
For more information, please visit www.ezvizlife.com
Need help? Contact us:
Telephone: [phone]
Technical Inquires Email: [email protected]
SAVE THIS MANUAL FOR FUTURE REFERENCE

1
Basic Information
Box Contents
NVR (x1) Power Adapter (x1)
Screw Kit (x1) Mouse (x1) Quick Start Guide (x1)
For models equipped with HDD (Hard Disk Drive), the screw kit is not included.
Product View
Rear Panel Overview
RESET Hole Audio Output
For Louderspeaker (e.g.)
VGA Interface
For Monitor
LAN interface
For Router
USB Interface
For mouse
Power Input (12 V)
HDMI Interface
For Monitor
Audio Input
For Pickup
Power ButtonGrounding Terminal
Insert and hold a pin for 7s until
the LED indicator flashes in red.
The cables with dotted lines above are not included.

2
Wiring
If you want to install HDD by yourself, refer to Appendix.
1. Connect the LAN interface of NVR to that of router using network cable (suggested).
2. Connect the mouse to the USB interface of NVR.
IPC
ACCESS
For LAN For UPLINK
3. Connect NVR to the Monitor using VGA or HDMI cable.
VGA Cable (Purchase Seperately)
Monitor
Monitor
HDMI Cable (Purchase Seperately)
Choose the corresponding signal source of the Monitor according to different connections.

3
Setup
Power on
1. Connect NVR with power outlet and turn on the power button.
Power Adaptor
Power Outlet
Power Button
Use stable power supply to avoid device exception or even damage.
2. Wait until the Wizard interface appears on the Monitor and set the password (For the first time access).
It is recommended to set new password for better security.
3. Log in the NVR.
•Admin password is the verification code on the lable of the device.
•If the wizard does not appear, please check the steps above.
(Optional) Shutdown
1. In the operation interface of NVR (Monitor), go to Shutdown by Menu Shutdown and click it.
2. Click Yes.
For device protection, do not turn off or disconnect the power supply while the device is working.

4
Linkage
Link through Monitor
•Make sure that the camera and device are using the same network, wired or wireless.
•The wireless camera in its initial state can be added to the device's Wi-Fi network by the following steps.
Power on all devices before you start.
•Reset the camera if it has been connected to Wi-Fi before.
•The camera and device should be within the distance of up to 10 m (32.8 feet). Stay away from wireless device or
barriers to avoid signal decreasing.
Within 10m (32.8 ft)
1. Go to Camera Management by Menu Camera.
2. When camera is ready to connect Wi-Fi, click Search.
3. Click "+" to add linked camera.
The camera will automatically connect to the device.
LED Indicator Status
LED Indicator
LED Indicator Status
Steady Green Working Properly
Steady Red Device Exceptions or Alarm
Flashing Red Restore Factory Defaults

5
Link to EZVIZ APP
You can add your devcie to EZVIZ app for more functions.
1. Download the App in your Phone (Optional).
- Search for "EZVIZ" in the App Store/Google Play™ to download and install the app.
- Launch the App.
- Register an EZVIZ user account.
2. Add the NVR.
- Log into the EZVIZ App.
- Click “+” on the upper-right corner to go to QR code scanning interface.
- Scan the QR Code at the bottom to add the device.

6
Appendix
HDD Installation
1. Loosen six screws No.1 to 6 on the back and both sides of the device to take apart the cover.
2. Connect the data cable and power cable of NVR with HDD respectively.
Power Interface Data Interface
3. Use screws (No. 7, 9, 10, 12) or (No. 8, 9, 11, 12) to fixate the HDD.
4. Re-assemble the NVR with screws (No.1 to No. 6).

7
Allgemeine Informationen
Lieferumfang
1x NVR 1x Netzteil
1x Schraubensatz 1x Maus 1x Kurzanleitung
Bei Modellen mit HDD (Festplatte) ist der Schraubensatz nicht im Lieferumfang enthalten.
Produktansicht
Rückseite
Rücksetztaste Audioausgang
An Louderspeaker
(beispielsweise)
VGA-Anschluss
An Monitor
LAN-Anschluss
An Router
USB-Port
An Maus
Stromversorgungseingang
(12 V)
HDMI-Port
An Monitor
Audioeingang
An Mikrofon
Ein/Aus-TasteErdungsanschluss
Halten Sie die Rücksetztaste für 7 Sekunden
mit einem Stift gedrückt, bis die LED-Anzeige
rot blinkt.
Die durch gestrichelte Linien dargestellten Kabel sind nicht im Lieferumfang enthalten.

8
Anschlüsse
Möchten Sie die Festplatte selbst einbauen, dann informieren Sie sich darüber im Anhang.
1. Verbinden Sie die Netzwerkschnittstelle des NVR über Netzwerkkabel (empfohlen) mit der des Routers.
2. Schließen Sie die Maus am USB-Port des NVR an.
IPC
ACCESS
An LAN An UPLINK
3. Schließen Sie den NVR über VGA- oder HDMI-Kabel am Monitor an.
VGA-Kabel (nicht mitgeliefert)
Monitor
Monitor
HDMI-Kabel (nicht mitgeliefert)
Wählen Sie je nach Verbindungsart die entsprechende Signalquelle für den Monitors.

9
Einrichtung
Einschalten
1. Schließen Sie den NVR an einer geeigneten Steckdose an und schalten Sie ihn ein.
Netzteil
Steckdose
Ein/Aus-Taste
Verwenden Sie ein stabiles Netzteil, um Ausnahmen oder Schäden am Gerät zu vermeiden.
2. Warten Sie, bis der Assistent auf dem Monitor angezeigt wird und stellen Sie das Passwort ein
(bei erstmaligem Zugriff).
Wir empfehlen, ein neues Passwort einzustellen, um die Sicherheit zu erhöhen.
3. Melden Sie sich beim NVR an.
•Das Administrator-Passwort ist der Verifizierungscode auf dem Typenschild des Geräts.
•Falls der Assistent nicht angezeigt wird, überprüfen Sie die obigen Schritte.
(Optional) Herunterfahren
1. Navigieren Sie im Betriebsmenü des NVR (Monitor) zu Shutdown (Herunterfahren), indem Sie zu
Menu (Menü) Shutdown (Herunterfahren) gehen und die Funktion anklicken.
2. Klicken Sie auf Yes (Ja).
Schalten Sie zum Schutz des Geräts die Stromversorgung nicht ab, während das Gerät arbeitet.

10
Verbindung
Verbindung über Monitor
•Vergewissern Sie sich, dass die Kamera und das Gerät das gleiche Netzwerk verwenden, kabelgebunden oder drahtlos.
•Die Funkkamera kann im Ausgangszustand durch folgende Schritte dem WLAN-Netzwerk des Geräts hinzugefügt werden.
Schalten Sie alle Geräte ein, bevor Sie starten.
•Setzen Sie die Kamera zurück, wenn sie zuvor mit dem WLAN verbunden war.
•Die Kamera und das Gerät müssen sich in einem Abstand von bis zu 10 m voneinander befinden. Halten Sie sich von
Drahtlosgeräten oder Barrieren fern, um einen Signalabfall zu vermeiden.
Innerhalb von 10 m
1. Navigieren Sie zu Camera Management (Kameraverwaltung) über Menu (Menü) Camera
(Kamera).
2. Wenn die Kamera bereit ist, sich mit dem WLAN zu verbinden, klicken Sie auf Search (Suche).
3. Klicken Sie auf „+“, um die verbundene Kamera hinzuzufügen.
Die Kamera verbindet sich automatisch mit dem Gerät.
LED-Anzeigestatus
LED-
Betriebsanzeige
LED-Anzeigestatus
Leuchtet grün Ordnungsgemäßer Betrieb
Leuchtet rot Geräteausnahme oder Alarm
Blinkt rot Rücksetzung zu den
Werkseinstellungen

11
Verknüpfung mit EZVIZ-App
Sie können Ihr Gerät zur EZVIZ-App hinzufügen, um weitere Funktionen zu erhalten.
1. Laden Sie die App auf Ihr Smartphone herunter (optional).
- Suchen Sie „EZVIZ“ im App Store oder bei Google Play™, um die App herunterzuladen und zu
installieren.
- Starten Sie die App.
- Registrieren Sie ein EZVIZ-Benutzerkonto.
2. Fügen Sie den NVR hinzu.
- Melden Sie sich bei der EZVIZ-App an.
- Klicken Sie oben rechts auf „+“, um in das Scanmenü des QR-Codes zu gelangen.
- Scannen Sie den nachstehenden QR-Code, um das Gerät hinzuzufügen.

12
Anhang
HDD-Installation
1. Lösen Sie die sechs Schrauben 1 bis 6 auf der Rückseite und auf beiden Seiten des Geräts, um das
Gehäuse zu öffnen.
2. Schließen Sie das Datenkabel und das Netzkabel des NVR an der Festplatte an.
Stromanschluss Datenanschluss
3. Befestigen Sie die Festplatte mit den Schrauben (Nr. 7, 9, 10, 12) oder (Nr. 8, 9, 11, 12).
4. Montieren Sie den NVR wieder mit den Schrauben 1 bis 6.

13
Información básica
Contenido de la caja
1 grabadora de vídeo de red (NVR) 1 adaptador de corriente
1 Juego de tornillos 1 ratón 1 Guía de inicio rápido
En modelos equipados con unidad de disco duro, el juego de tornillos no se incluye.
Vista del producto
Descripción del panel posterior
Orificio RESTAURAR Salida de audio
Para altavoces (p. ej.)
Conexión VGA
Para monitor
Conector LAN
Para enrutador
Conexión USB
Para ratón
Entrada de
alimentación (12 V)
Conexión HDMI
Para monitor
Entrada de audio
Para fonocaptor
Botón de encendidoConexión a tierra
Inserte un pin y manténgalo durante 7 s hasta
que el indicador led se vuelva rojo.
Los cables representados por las líneas de puntos en la figura precedente no están incluidos.

14
Cableado
Si desea instalar la unidad de disco duro usted mismo, consulte el Apéndice.
1. Conecte la interfaz LAN del NVR a la del enrutador utilizando el cable de red (sugerencia).
2. Conecte el ratón a la conexión USB de la NVR.
IPC
ACCESS
Para LAN Para UPLINK
3. Conecte la NVR al monitor mediante un cable VGA o HDMI.
Cable VGA (se adquiere por separado)
Monitor
Monitor
Cable HDMI
(se adquiere por separado)
Elija la fuente de señal correspondiente del monitor según las diferentes conexiones.

15
Instalación
Encendido
1. Conecte el NVR a una toma de corriente y active el botón de encendido.
Adaptador de
corriente
Toma de corriente
Botón de encendido
Use una fuente de alimentación estable para evitar excepciones del dispositivo e incluso daños.
2. Espere hasta que el asistente de instalación aparezca en el monitor y establezca la contraseña
(durante el primer acceso).
Para una mayor seguridad, se recomienda establecer una nueva contraseña.
3. Inicie sesión en el NVR.
•La contraseña de administrador es el código de verificación en la etiqueta del dispositivo.
•Si el asistente no aparece, compruebe los pasos anteriores.
(Opcional) Apagado
1. En la interfaz de funcionamiento del NVR (monitor), vaya a Shutdown (Apagado) en Menu (Menú)
Shutdown (Apagado) y haga clic.
2. Haga clic en Yes (Sí).
Para proteger el dispositivo, no apague ni desconecte la fuente de alimentación mientras el dispositivo esté en
funcionamiento.

16
Vinculación
Vincular mediante monitor
•Asegúrese de que la cámara y el dispositivo estén utilizando la misma red, por cable o inalámbrica.
•La cámara inalámbrica en su estado inicial puede añadirse a la red Wi-Fi del dispositivo mediante los siguientes pasos.
Encienda todos los dispositivos antes de empezar.
•Reinicie la cámara si se ha conectado antes al Wi-Fi.
•La cámara y el dispositivo deben encontrarse a una distancia inferior a 10 m. Manténgase alejado de otros dispositivos
inalámbricos y evite barreras para no interferir en la señal.
A menos de 10 m
1. Entre en Camera Management (Administración de cámaras) a través del Menu (Menú)
Camera (Cámara).
2. Cuando la cámara esté lista para conectarse al Wi-Fi, haga clic sobre Search (Buscar).
3. Haga clic sobre "+" para agregar la cámara vinculada.
La cámara se conectará automáticamente al dispositivo.
Estado del indicador LED
Indicador LED
Estado del indicador LED
Verde fijo funciona correctamente
Rojo sólido Excepción o alarma del dispositivo
Parpadeo rojo restauración de los valores de
fábrica
