Faaborg Rehab Technic Charder MS 6000 User manual

- 0 -
MS 6000
BED SCALE
USER MANUAL
Please keep the instruction manual at hand all the time for future reference.

- 1 -
TABLE OF CONTENTS
Preface ..........................................................................................................2
General Information .....................................................................................2
Safety Instruktions........................................................................................2
Environmental ..............................................................................................3
Cleaning........................................................................................................3
Maintenance .................................................................................................3
Weighing Operation......................................................................................4
Warranty-Liability ........................................................................................4
Disposing of the Scale ..................................................................................5
Explanation of Graphic Symbols..................................................................6
EMC Guidance and Manufacturer's Declaration..........................................8
Specification ...............................................................................................13
Power Adapter Standards ...........................................................................14
Preparation for Measurements....................................................................15
Installing Weight Bridge.............................................................................17
Panel ...........................................................................................................18
Key Functions.............................................................................................18
LCD Symbol Description ...........................................................................19
Date & Time Setting Procedure..................................................................20
Normal Weighing Procedure (patient on the bed) ......................................21
Weight Tracking Procedure ........................................................................22
Using the Bed Scale....................................................................................24
Using the BMI Feature ...............................................................................25
Using the Tare Function .............................................................................26
Storing and Re-Calling PRE-TARE Weight...............................................26
Set Up your Device ....................................................................................29
Printing Function........................................................................................30
Instructions for Printing and Connecting ...................................................32
Instructions for Replacing Batteries ...........................................................33
ERROR Message........................................................................................36
Troubleshooting..........................................................................................37

- -
2
Preface
Thank you for choosing Faaborg Rehab Technic’s product. All
features of this product were designed to state of the art and are
optimized for simple and straightforward use. If you have any
queries or experience any problems not addressed in the operating
instructions, please contact your Faaborg Rehab Technic’s service
partner, or visit us on the Internet at www.faaborg-rehab.dk
General Information
We strongly recommend you use the scales on flat and hard
surface. Any soft surface, like carpet will cause inaccuracy.
Safety Instruktions
Before putting the device into use, please read with care
the information given in the Operating Instructions. They
contain important instructions for installation, proper use and
maintenance of the device.
The manufacturer shall not be liable for damages arising out of
failure to heed the following instructions:
These batteries should be kept away from small children. If swallowed,
promptly seek medical assistance.
Expected Service Life: 5 years
When using electrical components under increased safety
requirements, always comply with the appropriate regulations.
Improper installation will render the warranty null and void.
Ensure the voltage marked on the power supply unit matches
your mains power supply.
This device is designed for use indoors.
Observe the permissible ambient temperatures for use
The device meets the requirements for electromagnetic
compatibility. Do not exceed the maximum values specified in the

- -
3
applicable standards.
If you have any problem, contact your local CHARDER MEDICAL service
partner.
Environmental
All batteries contain toxic compounds; disposal of batteries
should be delegated to a competent organisation, complying
with the deposit of Poisonous Waste Regulation 1972.
Please do not incinerate batteries.
The optimum operating temperature for the scale is 5℃ to +35
℃; although it will operate at higher and lower temperatures the
scales battery life will be adversely effected.
Cleaning
We would recommend using alcohol based wipes or
similar when cleaning the scales.
Please do not use large amounts of water when cleaning
the scales as this will cause damage to the scales electronics,
you should also refrain from using corrosive liquids or high
pressure washers.
Always disconnect the scales from the mains power
supply before cleaning.
Maintenance
The scale does not require any routine maintenance.
However, we recommend checking the scale’s accuracy at
regular intervals. The regularity of these checks is dependent on
the level of use and the state of the scale. If any inaccuracies
occur, please contact your local dealer or Faaborg Rehab’s
service partner.

- -
4
Weighing Operation
Before reading detailed instructions on how to use all the weighing
functions that are built into your scale, please read the following
important guidelines:
Always be sure that the display shows `Zero` before use, if it
does not then please press the ZERO key.
The device is designed to detect when a stable weight is
achieved, the indicator will `bleep` twice to indicate a stable weight
value, your reading should be taken at this point.
Warranty-Liability
If a fault or defect is present on receipt of the unit which is
within Faaborg Rehab’s scope of responsibility, Faaborg Rehab
shall have the right to either repair the fault or supply a replacement
unit. Replaced parts shall be the property of Faaborg Rehab.
Should the fault repairs or replacement delivery not be successful,
the statutory provisions shall be valid. The period of warranty shall
be two years, beginning on the date of purchase. Please retain your
receipt as proof of purchase. Should your scale require servicing,
please contact your dealer or Faaborg Rehab’s Customer Service.
No responsibility shall be accepted for damage caused
through any of the following reasons: Unsuitable or improper
storage or use, incorrect installation or commissioning by the owner
or third parties, natural wear, changes or modifications, incorrect or
negligent handling, overuse, chemical, electrochemical or electrical
interference or humidity, unless this is attributable to negligence on
the part of Faaborg Rehab.
If operating, climatic or any other influences lead to a major
change in conditions or material quality, the treaty for perfect unit

- -
5
functioning shall be rendered null and void. If CHARDER provides
and individual warranty, this means that the unit supplied will be
free of faults for the length of the warranty period.
Disposing of the Scale
This product is not to be treated as regular household waste,
but should be handed into an electrical/electronic equipment
recycling centre.
You can obtain further details from your local council, your
municipal waste disposal company or the firm which you purchased
the product.

- -
6
Explanation of Graphic Symbols
SN-T13000001
Designation of the serial number of
every device, applied at the device.
(Number as an example)
“Please note the accompanying
documents“
or “Observe operating instructions”
Charder Electronic Co., Ltd.
No.103, Guozhong Rd., Dali Dist.,
Taichung City 412, Taiwan (R.O.C.)
Identification of manufacturer of
medical product including address
Type B applied part
Dispose of old appliances
separately from your household
waste!l!
Instead, take them to communal
collection points.

- -
7
Carefully read this operation manual
before setup and commissioning,
even if you are already familiar with
Charder scales.
Transport and storage temperature
limit indicating the upper and the
lower limit
(Transport and storage temperature
on packaging)
+60°C
-20°C

- 8 -
EMC Guidance and Manufacturer's Declaration
Guidance and manufacturer’s declaration-electromagnetic
emissions
The MEDICAL SCALE MS6000 is intended for use in the electromagnetic
environment specified below.
The customer or the user of the MEDICAL SCALE MS6000 should assure
that it is used in such an environment.
Emission test
Compliance
Electromagnetic
environment-guidance
RF emissions
CISPR 11
Group 1
The MEDICAL SCALE
MS6000 uses RF energy only
for its internal function.
Therefore, its RF emissions
are very low and are not likely
to cause any interference in
nearby electronic equipment.
RF emissions
CISPR 11
Class B
The MEDICAL SCALE
MS6000 is suitable for use in
all establishments, including
domestic establishments and
those directly connected to
the public low-voltage power
supply network that supplies
buildings used for domestic
purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations
/flicker emissions
IEC 61000-3-3
Compliance

- -
9
Guidance and manufacturer’s declaration-electromagnetic immunity
The MEDICAL SCALE MS6000 is intended for use in the electromagnetic
environment specified below.
The customer or the user of the MEDICAL SCALE MS6000 should assure that it is
used in such an environment.
Immunity test
IEC 60601 test
level
Compliance
level
Electromagnetic
environment-guidance
Electrostatic
discharge(ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood,
concrete or ceramic tile.
If floors are covered with
synthetic material, the
relative humidity should
be at least 30%
Electrical fast
transient/burst
IEC 61000-4-4
± 2kV for power
supply lines +
1kV for
input/output lines
± 2kV for power
supply lines Not
applicable
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge IEC
61000-4-5
± 1kV line(s) to
line(s) ± 2kV
line(s) to earth
± 1kV differential
mode Not
applicable
Mains power quality
should be that of a
typical commercial or
hospital environment.
Voltage Dips,
short
interruptions
and voltage
variations on
power supply
input lines IEC
61000-4-11
<5% UT(>95%
dip in UT) for 0,5
cycle 40%
UT(60% dip in
UT) for 5 cycles
70% UT(30% dip
in UT) for 25
cycles <5%
UT(>95% dip in
UT) for 5 s
<5% UT(>95%
dip in UT) for 0,5
cycle 40%
UT(60% dip in
UT) for 5 cycles
70% UT(30% dip
in UT) for 25
cycles <5%
UT(>95% dip in
UT) for 5 s
Mains power quality
should be that of a
typical commercial or
hospital environment. If
the user of the
MEDICAL SCALE
MS6000 requires
continued operation
during power mains
interruptions, it is
recommended that the
MEDICAL SCALE
MS6000 be powered
from an uninterruptible
power supply or a
battery.

- -
10
Power
frequency(50/60
Hz) magnetic
field IEC 61000-
4-8
3 A/m
3 A/m
The MEDICAL SCALE
MS6000 power
frequency magnetic
fields should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration-electromagnetic immunity
The MEDICAL SCALE MS6000 is intended for use in the electromagnetic
environment specified below.
The customer or the user of the MEDICAL SCALE MS6000 should assure that is
used in such and environment.
Immunity test
IEC 60601 test
level
Compliance
level
Electromagnetic
environment-guidance
Conducted RF
IEC 61000-4-6
3 Vrms
150 KHz to 80 MHz
3 Vrms
Portable and mobile RF
communications equipment
should be used no closer to any
part of the MEDICAL SCALE
MS6000 including cables, than
the recommended separation
distance calculated from the
equation applicable to the
frequency of the transmitter.
Recommended separation
distance:
d = 1,2 √P
d = 1,2 √P 80MHz to 800 MHz
d = 2,3 √P 800MHz to 2,5 GHz
Where P is the maximum output
power rating of the transmitter in
watts (W) according to the
transmitter manufacturer and d is
the recommended separation
distance in metres (m).

- -
11
Radiated RF
IEC 61000-4-3
3 V/m 80MHz to 2,5
GHz
3 V/m
Field strengths from fixed RF
transmitters, as determined by an
electromagnetic site surveya,
should be less than the
compliance level in each
frequency rangeb.
Interference may occur in the
vicinity of equipment marked with
the following symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures, objects and
people.
a Field strengths from fixed transmitters, such as base stations for radio
(cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically with
accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the
measured field strength in the location in which the MEDICAL SCALE MS6000
is used exceeds the applicable RF compliance level above, the MEDICAL
SCALE MS6000 should be observed to verify normal operation. If abnormal
performance is observed, additional measures my be necessary, such as re-
orienting or relocating the MEDICAL SCALE MS6000.
b Over the frequency range 150 kHz to 80 MHz, field strengths should be les than
3 V/m.

- -
12
Recommended separation distance between portable and mobile RF
communications equipment and the MEDICAL SCALE
The MEDICAL SCALE MS6000 is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled. The customer
or the user of the MEDICAL SCALE MS6000 can help prevent electromagnetic
interference by maintaining a minimum distance between portable and mobile
RF communications equipment (transmitters) and the MEDICAL SCALE
MS6000 as recommended below, according to the maximum output power of
the communications equipment.
Rated maximum output
power of transmitter
W
Separation distance according to frequency of transmitter m
150 kHz to 80 MHz
d =1,2√P
80 MHz to 800 MHz
d =1,2√P
800 MHz to 2,5 GHz
d =2,3√P
0,01
0,12
0,12
0,23
0,1
0,38
0,38
0,73
1
1,2
1,2
2,3
10
3,8
3,8
7,3
100
12
12
23
For transmitters rated at a maximum output power not listed above, the
recommended separation distance d in metres (m) can be estimated using the
equation applicable to the frequency of the transmitter, where p is the
maximum output power rating of the transmitter in watts (W) according to the
transmitter manufacturer.
NOTE1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures, objects
and people.

- -
13
Specification
Model
MS 6000
Capacity
500kg x 200g
Accuracy
±300g
Verification
according to
2009/23/EC
Class III
Weight Unit
kg
LCD Display
1.0 inch LCD display with 5 and 1/2 digits
Dimension
Whole Dimension- 109 X 7.5 X 25.5 cm
Weighing Area- 88 X 18 cm
Key
Functions
ON/OFF, ZERO, HOLD/BMI, PRINT,
PRE-TARE, CLEAR, ENTER, M1-10,
MONITOR Weight, ALARM, 0~9 KEYS
Power Supply
6-AA size batteries.
Rechargeable battery pack (optional).
12V 2A switching adaptor.
Parts
overview
Weigh bridge x 2 , connecting wire x 1 ,
DP3700 Indicator x 1 , Adaptor x 1 , User
manual x 1 , RS232 cable , Bracket set for
wall mount x 1
Operation
Temperature
5℃ ~ 35℃

- -
14
Power Adapter Standards
CAUTION: The device is only compatible with restricted power
adaptors in dashed block below.

- -
15
Preparation for Measurements
1. Hold the handle of weigh bridge
2. Place weigh bridges under bed next to the bed casters.
3. Installing weigh bridges and power on the scale before pushing
the bed on it. Please refer to installing instruction.
4. Set the unit on a stable, level surface. When the bubble
indicator is in the centre of the circle, MS6000 is leveled
correctly.
Bubble indicator: Good Wrong
All four feet must touch the surface to make sure that MS6000
does not rock.

- -
16
5. Push bed forward and move to the weigh bridges after
assembly and power on the scale.
We strongly recommend two people to operate the procedure.
Before moving bed on the weigh bridge, please turn on the
scale!!
You must make sure that the connecting cable is not caught
under the measuring foot, otherwise faulty measurements
may result.
6. Four bed casters are now placed well on weigh bridges.

- 17 -
Installing Weight Bridge
Charder Bed Scale has been properly labeled for easy assembling.
The packing also includes Weigh Bridge, connecting wire and
Indicator. Connect both the weigh bridges using Weigh Bridge
connecting wire and then connect Indicator with “Weigh Bridge – 2”.
Weigh Bridge – 1 Weigh Bridge – 2
Note: Please connect all the Pins carefully with gentle hands and
match with and push the wire connecting slot gently.
Female plug
Female plug
Male plug
female plug
Connecting wire

- 18 -
Panel
Key Functions
Key
Description
ON/OFF
To switch ON/OFF the scale
ZERO
To zero the system
M 1~10
To save 10 sets of PRE-TARE value
PRE-TARE
&
TARE
PRE-TARE function for subtraction of a
known bed weight or any other object before
weighing process.
To Tare any unwanted weight.
HOLD/BMI
To weigh the patients who are unstable and
to lock the weighing value on screen
Long press for 3 seconds to calculate the
BMI of patient
PRINT
To print out the results.

- 19 -
MONITOR
WEIGHT
For tracking the change in weight of Patient.
ALARM
To turn ON/OFF and adjust volume level of
Alarm function
CLEAR
To clear the wrong entry while entering digits.
ENTER
To confirm & apply.
0~9
Entering digits
LCD Symbol Description
Definitions
Stable symbol: To indicate that the weight is stable.
Minor weight: Weight under zero.
Zero symbols: Weight is at zero point.
Low battery: Battery need to charge or replaced.
