Faber INCA HC SS Operating and safety instructions

For recirculating installations, high
quality, heavy duty filters ensure the
removalofsmokeandodorsfromthe
kitchen. Some ductwork is required
to exhaust the unit out of the cabinet.
Charcoal Filters 6093034
The Inca HC (high capacity) power pack is perfect for the
homeowner who needs powerful ventilation, but does not want
to see a rangehood at all. This exceptionally finished power
pack installs effortlessly into your custom cabinet or hood.
high capacity insert
for custom cabinets and hoods
stainless steel finish
540 cfm
2 halogen lights
3 speed control
dishwasher safe grease filters
convertible to recirculating
top or direct rear venting
built-in mounting system
sone range: 3.5 - 6.5
6” round duct
Size/Color/Model #
29 Stainless
Inca HC SS
the high powered hideaway
°
°
°
°
°
°
°
°
°
°
°
°
BUILT-IN
standard SERIES
630002752
a
c
c
e
s
s
o
r
i
e
s
p.o. box 435 • Wayland, MA 01778 • tel: [phone] • fax: [phone] • e-mail: [e-mail] • www.faberonline.com
IncaHCcanbeused withcustomcabinetry
andhoods 30" wide andup. Chooseeither
a custom liner or our Standard Liner in
standard 30" and 36" widths.
Create a perfectly-sealed, non-combustible
perimeter around the Inca HC SS. Depth
adjustable from 18” - 21 1/2”.
Liners
Standard Liner 30 Stainless
Standard Liner 36 Stainless 620000304 620000305

6” round
duct
Side View
Cut-Out
Bottom View
Note:TheIncaHCcomesstandardinthe
top vent position. The direct rear vent
position can be achieved by rotating the
blower housing.
Dimensional Diagrams
Rev.05/04
WARNING! Productspecificationsaresubjecttochangewithoutnotification. Consulttheinstallationinstructionsbefore
you begin installing this rangehood.
Makeyourductrunas straightand short
as possible. The ductrun should not
exceed35 equivalentfeetif ductedwith
therequired minimum of 6" round duct.
Count 45º angles as 3 feet, 90º elbows
as5 feet,and90º flatelbows as 12feet.
For best results, use no more than
three 90 ° elbows. Make sure that
there is a minimum of 24" of straight
duct between elbows if more than
one is used. Do not install two
elbows together. If you must elbow
right away, do it as far away from the
hood'sexhaust openingas possible.
For more efficient airflow when
venting to the rear: Rotate the Inca
HC blower housing so that the 6”
round exhaust outlet faces the back,
ratherthan running ductwork up and
elbowing back.
Pre-Planning Your Ductwork - Important: Consult the installation instructions before you begin installing this rangehood.
Recirculating Installations
Front View
For installations where ductwork is impossible or highly impractical Charcoal Filters, which
attach to the blower assembly, absorb smoke and odors.
cabinet
ceiling
hood
cabinet
ceiling
soffit
1234567890
1
23456789
0
1234567890
vent grate
vent grate
Some ductwork must
be installed to exhaust
the rangehood back into
the kitchen, either at the
topofthecabinet or at the
face of the soffit. Aplastic
vent grate supplied with
the rangehood can be
used to cover the duct
opening. This duct work
must not terminate into a
dead air space.
6” round
