FableKids MILA User manual

Car Seat
Please read the instructions carefully before use and keep for future reference.
Thank you for choosing FableKids.
“MILA”
Original User Manual –FableKids Car Seat

Dear Parents,
Thank you for purchasing our product. Please read the operating
instructions carefully before using the product for the first time. If
you give the product to a third party, this manual must be handed
over with it. Keep the instruction manual for future reference. The
drawings in this manual may not match the physical objects. Please
refer to the physical objects.
“MILA” Car Seat
Configuration
Stroller / pushchair
Original User Manual –FableKids Car Seat

1. Important Safety Information
2. Product Overview
3. Instructions for use
4. Adjustments
5. Installation
6. Place your child in the restraint
7. Take your child out of restraint
8. The traveling note
9. Note for user
10. Cleaning and washing note
11. Environmentally friendly disposal
Table of Contents
9
8
7
7
1
2
3
4
5
6
7
Original User Manual –FableKids Car Seat

Warning! Extreme Danger
•Do not use a rear-facing car seat on front
passenger seat where a passenger side
airbag is fitted. Airbag inflates rapidly and
can throw a rear-facing child restraint into
seat back with a great force, which can
injure child.
WARNING
IMPORTANT: Read these instructions carefully before use and keep them
for future reference. Your child’s safety may be affected if you do not follow
these instructions. Failure to follow these warnings and the instructions
could result in serious injury or death.
1. Important Safety Information
1
Original User Manual –FableKids Car Seat
•No child restraint can guarantee absolute protection from injury in every crash. However, to
ensure that your child gets all the protection designed into the restraint, please red and follow
this instructions exactly.
Warning! Failure to follow each of the following instructions can result in your child striking the
vehicle’ s interior during a sudden stop or crash.
1. Only suitable if the approved vehicles are fitted a 3-point safety belts with retractor approved
to UN/ECE Regulation No.16 or other equivalent standards.
2. Rigid items and plastic parts of a child restraint system must be so located and installed that
they are not liable, during everyday use of the vehicle, to become trapped by a moveable
seat or in a door of the vehicle.
3. This rear-facing child restraint system can not be used in seating positions where there is an
airbag installed.
4. Take care that the straps, holding the restraint to the vehicle, shall be as tight as possible.
Make sure that the straps, restraining the child should be adjusted to the child's body and the
straps should not be twisted.
5. It is important that the lap part of the harness belt system is worn lowdown, so that the pelvis
is firmly engaged.
6. The child restraint system MUST BE CHANGED after it has been suffered from a violent
impact in an accident.

Original User Manual –FableKids Car Seat
2. Product Overview
A. Carrying handle
B. Hook button for installation in stroller
C. Handle adjustment buttom
D. Belt hook
E. Shoulder strap lots
F. Harness adjuster
F
A
C
B
D
2
E

3. Instructions for use
Original User Manual –FableKids Car Seat
1. This child restraint is designed for use by children whose weight 13kg or less and whose
heights are 26 inches (66cm)or less.
2. This child restraint is only used rear-facing position and can not be used forward-facing
position.
•For maximum protection, the center rear seat position is recommended for the safest position
in most vehicles for installing a child restraint. Only when the seat is provided with a3-point
adult belt.
•All seat cover on the restraint are removable for cleaning. And you can simply blot the desired
area with a damp sponge and cool water.
•Your child restraint should not be purchased or sold as a_ secondhand item. It is
recommended not to use child restraint older than 6 years as the protection in an accident
may be rediced.
3

4. Adjustments
Original User Manual –FableKids Car Seat
Handle adjustments
•Face the restraint: push the red button on each side of handle, rotate and release red button
to desired position until hearing a “click” , There are four positions available. See the picture.
Harness adjustment
•This car seat has 2 sets of slots.
•Select the suitable slots according to
child’s physique.
•To change the harness strap
position, undo the harness strap
from the seat buckle, come out from
belt slots on the back of car seat and
re-thread them throng the desired
slots.
•Reconnect the straps to seat buckle.
•IMPORTANT: Before lifting car seat, place handle in “ locked” upright carrying position.
4

5. Installation
Original User Manual –FableKids Car Seat
Please refer to graphic above for installation.
1. Place car seat REAR-FACING on vehicle seat.
2. Thread vehicle lap belt through car seat SLOTS and buckle belt.
•NOTE: Vehicle shoulder belt must not be place through car seats slots.
3. Pull front to back and left to right to check for secure installation.
•NOTE: Vehicle MUST be on level ground and child in car seat when leveling.
5

6. Place your child in the restraint
Original User Manual –FableKids Car Seat
1. See the graphic in D from step 1-step 5. for installing your child restraint on car seat.
2. Press the red release button on buckle, unfasten the buckle connector 1 & 2.
3. Lift up the harness straps and lay them flat on the back of restraint.
4. Place your child in restraint.
•Note: Do not place your child in a sleeping bag, blanket or other bulky wrapping before
putting child in the restraint. The shoulder straps will not fit snugly, and the child won’ t be
safe.
5. Put the harness straps on each side of child’ s shoulder.
•Remark: A newborn baby will need extra support around the head and body. Please don’ t
remove the cushion if you are going to use it of your newborn baby or baby less than 7
months.
•PS: the cushion is alternative item, please asking sell agent regarding to this extra selection.
6. Join the two buckle connectors, passing the left “1” under the right “2” ,and inserting them
both into the buckle until you hear a “click” signifying the buckle is locked.
7. Pull the harness adjuster lock to the position you desired.
8. Check that harness straps are snug with just enough room to insert one finger between
child's Chest and harness straps.
•Note: check that the buckle is secured by attempting to pull the above and below part to
remove the connectors. 6

7. Take your child out of Restraint then remove the
restraint out of vehicle
Original User Manual –FableKids Car Seat
1. Press the red release button on buckle, unfasten the buckle connector 1&2.
2. Lift up the harness straps and lay them flat on the back of restraint.
3. Take your child out of restraint.
4. Unbuckle the vehicle seatbelt.
5. Pull out the vehicle seat belt through the seat belt hooks in the restraint.
6. Removethe restraint out of vehicle.
•Please take care that the child restraint system should be kept away from the sunlight. Some
parts of the child restraint system may become too hot for child s skin.
•Do not leave the child unattended in child restraint system and in the car.
•While travelling it is recommended that any luggage or other objects liable to cause injuries in
the event of a collision shall be properly secured.
•Please note that the Child restraint system never should be used without cover.
•The seat cover should never be replaced with any other cover than the one recommended by
the manufacturer. The cover constitutes an integral part of the restraint performance.
•Do not use your child restraint in vehicle seats with lap belts only.
•Your child restraint should be securely belted to the vehicle, even when unoccupied. Because
in a crash an unsecured restraint may injure other occupants.
•Please take a rest in each two hours if you are traveling with baby in vehicles with car seat
•Please check the car seat condition if you are going to long traveling with child
•Please put all the edge staff into trunk if you are going to travel with baby, because those
items might hurt baby during unstable road travel conditions.
•Please always check the car seat before you placing baby into it.
•Please contact with sold agent if anything break. DON T TRY TO FIX UP CAR SEATBY
YOURSELF.IT MIGHT BE DAMAGE FORLATER USED WITHOUT CERTAIN FIS KNOWLEDGE
8. The traveling note
9. Note for user
•Please remove child out of car as first priority when accident happens.
•Don’ t look after child when they were crying during the driving.
•Please always check buckle hole before buckle up.
•Please keep car seat outreach of child when itis not used.
•Please keep outreach of PE bag from child after unpack of car seat.
•Don’ t placing car seat on any seat content AIRBAG.
•Do not after or modify your restraint. Only the manufacturer or agent must do repairs. 7

10. Cleaning and washing note
Original User Manual –FableKids Car Seat
•For quickly cleanups, simply blot the desired area with a mild soap solution using a damp
sponge and cool water, if necessary, can be hand wash.
•Clean up your car seat shell with mild solution soap and cool water. Never use “household
detergents” :they can weaken plastic.
•Harness straps are only surface washable with mild soap anc damp cloth.
•Don’ t use wash machine to wash.
•Don’ t use hot water to wash
8

11. Environmentally friendly disposal
Warning Danger of suffocation! Packaging material is
dangerous for children. Never let children play with packaging
material.
11.1 Disposal and packaging
The packaging of your unit consists of materials that are
necessary to guarantee effective protection during transport.
These materials are fully recyclable and therefore reduce the
environmental impact. Dispose of the packaging in a bin for
recyclable materials.
11.2 Disposal of old equipment
Old appliances must be disposed of in accordance with the guidelines
and regulations of the local waste disposal authority. Check with your
local administration for the address of the nearest recycling center and
deliver your appliance there.
The symbol of the crossed-out dustbin on a Waste electrical or
electronic equipment indicates that it must not be disposed of with
household waste at the end of its life. Collection points for waste
electrical and electronic equipment are available free of charge in your
area. You can obtain the addresses from your city or local government.
You can find out about other return options created by us on our
website
www.fable-kids.com
The separate collection of Waste electrical or electronic equipment is
intended to enable the reuse, recycling or other forms of recovery of
Waste electrical or electronic equipment and to avoid the negative
consequences of disposal on the environment and human health.
9
