L-SERIES CLUTCHES
INSTALLATION INSTRUCTIONS
Thank you for purchasing your new L-Series Clutches. They
have been custom-made from the highest quality materials.
to the dimensions you specied. With the proper installation
and care, it will provide you with many years of beauty and
trouble-free use.
Please read all instructions before you start so you will be
familiar with the overall process.
Make sure you measure your window to ensure the clutches
and shades will t properly before beginning.
Getting Started
Remove the clutch and shade from the packaging. Keep the
packaging until you have successfully installed the clutch and
the shade.
TOOLS REQUIRED
FASTENER NOTES
For outside mount, it is best to attach the bracket to wood
studs. If this is not possible, you will need to purchase special
fasteners (see illustration below for examples).
Here are some HELPFUL TIPS:
• If you are using a special fastener, make sure it is
designed to support the weight of the clutch and shade.
Follow the fastener manufacturer’s instructions carefully.
• When drilling into drywall or plaster, use a fastener
designed for hollow wall applications (see illustration).
• When drilling into concrete, stone, brick, or tile, use
appropriate plugs, anchors, or screws (not included).
• When drilling into metal, the included screws are sufcient.
Pre-drill ¹⁄₈” holes.
Molly Bolt Hollow Wall Anchor Anchor
L-SERIES CLUTCHES
INSTALLATION INSTRUCTIONS
(for L32, L32 PLUS, L40, L40 PLUS,
and L45, L45 PLUS Clutches)
• Pencil • Power Drill with the following bits:
• Awl - ¹⁄₁₆” Drill Bit
• Tape Measure - ¹⁄₄” Hex Driver
• Level - Standard Screwdriver
• Ladder or Stepstool - Masonry Drill Bit (if drilling into
concrete or brick)

EST.1 973
EST.1 973
Idler end bracket CCO end bracket
Idler end plunger and bracket
CCO end with end pin inserted
- page 2 of 5-
STEP 4 - ADD THE END CAPS FOR A FINISHED LOOK.
Note: The end caps cannot be used on an inside mount
installation.
STEP 5 - INSTALL THE P-CLIP (HOLDDOWN).
Depress the p-clip holddown and rmly attach to the wall.
DO NOT PULL THE BEAD CHAIN TAUT, as this will prevent the
bead chain from operating smoothly.
P-clip installed
STEP 3 - SET THE LOWER LIMIT/STOP POSITION.
Lower the shade to the desired long point.
Then pinch the bead chain at this point on the front of the
clutch, and place one of the bead chain stops here.
One extra bead chain stop is provided in case a change
must be made.
pinch bead
chain here
L32 SERIES CLUTCHES
(This applies to L32 and L32 PLUS Clutches)
Mounting the Shade and Clutch
STEP 1 - INSTALLING THE BRACKETS.
Note: There are two different brackets.
The idler end bracket has a simple round hole.
The continuous chain operator (CCO/or control end) bracket
has a cross shaped hole. These brackets can be installed
on a wall, ceiling, or inside installation.
The bracket to bracket dimension is the shade cloth width
plus 1³⁄₈”. Use a level to ensure a horizontal position.
STEP 2 - INSTALLING THE SHADE.
a. Begin by installing the idler end rst.
Push the idler plunger into the idler end bracket.
b. Slip the CCO end into the bracket. While keeping the idler
end in position, lift the shade up into the bracket and
align the CCO end pin into the middle of the cross
shaped hole.
Gently slide into place.
Pull down to lock in place.
Caring for your L32 Series Clutches &
Roller shades
Your clutches and roller shades will provide you with years of
beauty and pleasure with minimal care and cleaning.
• Vacuum using a brush or dust head attachment.
• Dust lightly using a soft, clean cloth.
• Never immerse the clutches or shades in water or liquids
of any type.
1
3
2

Universal brackets
CORRECT!
transit clip in vertical position
INCORRECT!
transit clip at an angle
CORRECT!
transit clip in horizontal position
Insert CCO end
- page 3 of 5-
L40 SERIES CLUTCHES
(This applies to L40, L40 PLUS, L45 & L45 PLUS Clutches)
Mounting the Shade and Clutch
STEP 1 - INSTALLING THE BRACKETS.
The brackets are universal and can be used on either side
as well as for wall, ceiling or inside installation.
The bracket to bracket dimension is the shade cloth width
plus 1³⁄₈”. Use a level to ensure a horizontal position.
STEP 2 - INSTALLING THE SHADE.
a. Begin by installing the idler end rst.
There is a transit clip on the idler end of the shade. The
transit clip should be positioned either straight up and
down, or horizontal, in order to line up the idler plunger of
the idler end with the cross shaped hole in the bracket.
See illustrations below.
b. Once the idler end is seated, REMOVE the TRANSIT CLIP.
Save this clip as it will be reinstalled in Step 2d.
STEP 2 - INSTALLING THE SHADE (continued).
c. Slip the CCO end into the bracket.
While keeping the idler end in position, lift the shade up
into the bracket and align the CCO end pin into the
middle of the cross shaped hole.
Gently slide in place and pull down to lock in place.
STEP 3 - SET THE LOWER LIMIT/STOP POSITION.
Lower the shade to the desired long point.
Then pinch the bead chain at this point on the front of the
clutch, and place one of the bead chain stops here.
One extra bead chain stop is provided in case a change
must be made.
pinch bead
chain here
d. Remember to slip the transit clip back onto the idler end.
The transit clip locks the spring-loaded idler end of a roller
shade, so that it cannot retract. It also prevents the roller
shade from slippping out of its brackets during shipment.
1
3
2

SSS1606LSCII© 2016 Fabritec, LLC. All rights reserved.
EST.1 973
EST.1 973
- page 4 of 5-
STEP 4 - ADD THE END CAPS FOR A FINISHED LOOK.
Note: The end caps cannot be used on an inside mount
installation.
STEP 5 - INSTALL THE P-CLIP (HOLDDOWN).
Depress the p-clip holddown and rmly attach to the wall.
DO NOT PULL THE BEAD CHAIN TAUT, as this will prevent the
bead chain from operating smoothly.
Caring for your L40 and L45 Series
Clutches & Roller shades
Your clutches and roller shades will provide you with years of
beauty and pleasure with minimal care and cleaning.
• Vacuum using a brush or dust head attachment.
• Dust lightly using a soft, clean cloth.
• Never immerse the clutches or shades in water or liquids
of any type.
P-clip installed
NOTE:
Call us at 800.828.8500 if you have any questions.

fabritec, llc 7531 Coldwater Canyon Ave North Hollywood CA, 91605 t 800 828 2500 f 818 503 8360 www.fabritecgroup.net
Chain
Holddown
Idler
Bracket
(Idler end)
Bracket
Cover
Bracket
(CCO end)
Clutch
Bracket Cover
Shade
Round Hem Bar, optional
Tube
FRONT VIEW
(Room side)
- page 5 of 5-
L-SERIES CLUTCHES DETAILED DIAGRAM
IMPORTANT!
1. Please read installation instructions rst (included with hardware).
2. The brackets should be 1³₈” wider than the cloth width.
3. Install the idler end of the shade rst!
