Fabtech Fts21052bk User manual

www.fabtechmotorsports.com 4331 EUCALYPTUS AVE. CHINO, CA. 91710

PHONE 909-597-7800 FAX 909-597-7185

2007 - 13 GM 1500 4WD – 2WD SUV REAR SYSTEM

FTS21051BK REAR AUTO RIDE COIL SPRING SYSTEM

FTS21052BK REAR Non /AUTO RIDE COIL SPRING SYSTEM

THIS INSTRUCTION SHEET COVERS THE INSTALLATION OF VEHICLES WITH AND WITHOUT AUTO RIDE

SUSPENSION. VERIFY THAT YOU HAVE THE CORRECT KIT FOR YOUR APPLICATION.

READ ALL INSTRUCTIONS THOROUGHLY FROM START TO FINISH BEFORE BEGINNING INSTALLATION!

CHECK ALL PARTS INCLUDED IN THIS KIT TO THE PARTS LIST ABOVE BEFORE BEGINNING

INSTALLATION OF THE KIT. IF ANY PIECES ARE MISSING, CONTACT FABTECH AT 909-597-7800

VEHICLES THAT WILL RECEIVE OVERSIZED TIRES SHOULD CHECK BALL JOINTS, TIE RODS ENDS AND

IDLER ARM EVERY 2500-5000 MILES FOR WEAR AND REPLACE AS NEEDED.

WARNING: FABTECH RECOMMENDS THAT YOU EXERCISE EXTREME CAUTION WHEN WORKING

WITH COIL SPRINGS TO AVOID ANY POSSIBILITY OF INJURY.

THIS KIT NOT RECOMMEND FOR 2WD SUBURBAN.

TOOL LIST: (NOT INCLUDED)

oFLOOR JACK

oJACK STANDS

oEXTERNAL COIL SPRING COMPRESSOR

oASSORTED METRIC AND S.A.E SOCKETS, & ALLEN WRENCHES

oDRILL WITH 7/16” BIT

oDIE GRINDER WITH CUT OFF WHEEL

2007 - 13 GM 1500 SUV REAR SYSTEM

FTS21051BK REAR AUTO RIDE COIL SPRING SYSTEM

FTS21052BK REAR Non /AUTO RIDE COIL SPRING SYSTEM

FTS21051BK SUV Box 4 Coil Spring Rear FTS21052BK SUV Box 4 Coil Spring Rear

"Auto Ride ONLY" "Non Auto Ride ONLY"

2 FT1599-2BK 2007 SUV Auto Ride Rear Coil 2 FT1599-4BK 2007 SUV Non Auto Ride Rear Coil

1 FT20292BK Trac Bar Bracket 1 FT20292BK Trac Bar Bracket

1 FT20307BK Trac Bar Bracket Support 1 FT20307BK Trac Bar Bracket Support

1 FT1599-2-2DBK Driver Shock Drop Bracket 1 FT1599-2-2DBK Driver Shock Drop Bracket

1 FT1599-2-2PBK Pass Shock Drop Bracket 1 FT1599-2-2PBK Pass Shock Drop Bracket

1 FT20360BK Drv. Rear Upper Link 1 FT20360BK Drv. Rear Upper Link

1 FT20361BK Pass. Rear Upper Link 1 FT20361BK Pass. Rear Upper Link

2 FT20362BK Lower Link D/P 2 FT20362BK Lower Link D/P

2 FT1599-2-4 Rear sway Bar End Link 2 FT1599-2-4 Rear sway Bar End Link

8 FT1004 Sway Bushing Half 8 FT1004 Sway Bushing Half

4 FT404739 Sway Bar Sleeve 4 FT404739 Sway Bar Sleeve

1 FT20319BK Rear Bump Stop Bracket Drv. 1 FT20319BK Rear Bump Stop Bracket Drv.

1 FT20320BK Rear Bump Stop Bracket Pass 1 FT20320BK Rear Bump Stop Bracket Pass

1 FT20349 Brake Line Bracket 1 FT20349 Brake Line Bracket

4 FT20351 Auto Ride Frt. Shock Inserts 1 FT20299 Bushing & Sleeve Kit

1 FT20299 Bushing & Sleeve Kit 1 FT20309 Hardware Kit

4 12008007100 8" Black Zip Tie 4 12008007100 8" Black Zip Tie

4 12001407100 14" Black Zip Tie 4 12001407100 14" Black Zip Tie

1 FT20309 Hardware Kit 2 FT21051i Instruction Sheet

2 FT21051i Instruction Sheet

Hardware Kit FT20309

Qty. Description Location Qty. Description Location

1 9/16"-12 x 4" Bolt Rear Trac Bar Bracket 1 5/16"-16 x 1" Bolt Rear Brake Line Drop

1 9/16"-12 C-Lock Nut 1 5/16"-16 C-Lock

2 9/16" SAE Flat Washers 2 5/16" SAE Flat Washer

2 7/16"-14 x 2 1/4" Bolt 4 3/8"-16 x 1 1/4" Bolt Bump Stop Brk.

1 7/16"-14 x 1 1/2" Bolt 4 3/8"-16 C-Locks

3 7/16"-14 C-Locks 8 3/8" SAE Flat Washer

6 7/16" SAE Flat Washer 2 1/4"-20 x 1" Bolt Auto Ride Drop Brk.

2 12mm x 1.50 x 75mm Bolt Rr Sway Bar Links @ bar 2 1/4"-20 C-Lock

2 12mm C-Lock Nut 4 1/4" SAE Flat Washer

4 ½” USS Flat Washer 8 1/4 Grease Fitting Zerc Fitting

2 9/16"-12 x 3" Bolt Rear Shock @ Drop Brkt 1 FTLube Bushing Lube

2 9/16"-12 C-Lock Nut

4 9/16" SAE Flat Washers

INSTRUCTIONS:

1. Disconnect the negative terminal on the battery. Jack up

the rear end of the truck and support the frame rails with

jack stands. NEVER WORK UNDER AN

UNSUPPORTED VEHICLE! Remove the rear tires.

2. Disconnect the sway bar end links from the frame and sway

bar, discard the endlinks, save the hardware. Remove the

bolt securing the brake line support tab to the differential

housing and save. Remove the ABS wiring from the frame

mounts on both sides. Save all the hardware. SEE PHOTO

BELOW.

3. Using a floor jack, raise the differential just enough to

slightly compress the rear shocks. Remove the bolts

securing the top of the shocks to the frame (if equipped

with the Auto Ride System, unplug the electric and air line

connections) . Remove the lower pivot bolt that attaches

the track bar to the axle bracket and save. SEE PHOTO

BELOW.

4. Lower the floor jack to release the coil springs. Remove

the coil springs from the vehicle and save the rubber upper

and lower coil insulators.

5. Support the rear axle with a floor jack and remove the

factory lower links arms. Discard the links and save the

hardware. SEE PHOTO BELOW.

6. Locate FT20319 (drv) & FT20320 (pass) Rear Bumpstop

Brackets and the supplied 3/8”x1 ¼” hardware. Place the

bump stop extension mounts onto the existing pads on the

top of the differential. Using the 3/8” bolts, washers and

C-lock nuts, secure the mount to the differential. There

should be a flat washer on each side of the bolt. Do not

fully tighten. Mark and drill the front 3/8” hole in the

bumpstop and attach using the remaining 3/8” hardware on

this new hole. Torque to 30 ft lbs. SEE PHOTO BELOW

AND ON THE NEXT PAGE.

7. Locate FT20360 (drv.) & FT20361 (pass) Rear Upper Link,

FT20362 Rear Lower Links, and FT20299 Bushing and

Sleeve Kit. Using an arbor press, press the bushings and

sleeves (use supplied bushing lube) into each end of the

links and install the supplied zerk fittings. On the upper

links, use 2ea. FT1037 bushings and a short sleeve at each

end. On the lower links, use 1ea. FT1037, 1ea. FT1006 and

a long sleeve.

8. Install the new Lower Link Arms into the factory rear axle

mounts with the factory hardware. Then attach the arm to

the frame mounts also with the factory hardware. Leave

loose at this time. SEE PHOTO BELOW.

9. Support the rear axle with a floor jack and remove the

factory upper links arms. If the rear is equipped with

Auto Ride, locate the Auto Ride sensors on both the

driver side and passenger side of the vehicle on the

upper link arms. Disconnect from the link arm and save

with the hardware. DO NOT REMOVE FROM THE

TRUCK. Discard the links and save the hardware. Install

the new Upper Link Arms into the factory rear axle mounts

with the factory hardware. (install / match the driver and

passenger links as they were removed). Then attach the

arm to the frame mounts also with the factory hardware.

Remove the Auto Ride bracket from the position sensor and

use a die grinder to remove the bottom of the bracket.

Connect the auto ride brackets to the tabs on the upper links

with the factory hardware. Leave the link arm bolts loose at

this time. SEE PHOTOS BELOW

Photo shows cutting of factory bracket

10. Locate FT20292 Trac Bar Bracket, FT20307 Trac Bar

Bracket Support, and the 7/16” & 9/16“ hardware. Position

the trac bar bracket into the factory mount on the axle and

install with the factory bolt and hardware. Leave loose.

Locate the two factory holes just forward of this mount,

Using a drill with a 7/16” bit, drill these two holes out to

7/16” (carefully bend the brake line back from the inner

hole). Position the support bracket over the two new holes

and install with the 7/16” x 2 ¼” bolts and hardware. Insert

the 9/16” x 4” bolt into the trac bar bracket and support

bracket (tighten just enough to make the bracket and

support make contact, over tightening without the trac bar

installed will collapse the bracket) Torque the 7/16” bolts to

50 lbs. SEE PHOTOS BELOW AND IN NEXT

COLUMN

11. Using a drill with a 7/16” bit, drill the hole on the new trac

bar bracket to the factory mount. Use 7/16 x 1 ½” bolt and

hardware to attach the bracket to the mount and torque to

50 lbs. SEE PHOTOS BELOW

Provided

9/16” x 4” Bolt

Factory Bolt

12. Working from the driver’s side, locate FT1599-2-2D Shock

Drop Bracket. Slide the shock mount extension into the

original frame mount and insert one of the factory shock

bolts and hardware through the original shock mount side

and hand tighten. Take one of the new sway bar links and

insert 2 bushing halves and a sleeve into each end (use the

supplied lube). Install one end of the end link into the frame

mount and insert the original bolt through the sleeve, (the

factory hole may have to be drilled out with a ½” drill

bit to align properly) securing the shock mount drop

bracket. Torque the factory bolt to 75lbs and the upper bolt

shock bolt to 85lbs. SEE PHOTOS ON NEXT PAGE.

IF YOU ARE INSTALLING DIRT LOGIC REAR SHOCKS,

YOU WILL NOT USE THE FABTECH SHOCK DROP

BRACKETS. THE DIRT LOGIC SHOCKS WILL MOUNT

DIRECTLY INTO THE FACTORY UPPER AND LOWER

SHOCK MOUNTS

13. Repeat step twelve on the passenger side of the truck.

14. Place a floor jack under the rear axle. Attach your coil

spring compressor onto the new rear coil spring and

compress the coil 1”-2”. Set the upper coil insulator on top

of the coil spring and position the top of the coil into the

frame pocket. Push the bottom of the coil spring onto the

axle pad and raise the floor jack under the axle to hold the

coil spring in position. Remove the coil spring

compressors. Repeat this with the opposite coil spring.

USE CAUTION WHEN WORKING WITH COIL

SPRING COMPRESSORS, THEY CAN BE UNDER

EXTREME LOAD. SEE PHOTOS BELOW

Factory

hardware

TRUCKS EQUIPPED WITHOUT AUTORIDE, FOLLOW

STEP FIFTEEN, SKIP STEP SIXTEEN - EIGHTEEN

TRUCKS EQUIPPED WITH AUTORIDE, FOLLOW

STEP SIXTEEN - EIGHTEEN AND SKIP STEP FIFTEEN

15. Reinstall the factory shocks onto the lower axle mounts

with the factory hardware and into the new dropped upper

mount using the supplied 9/16” x 3”. Torque to 75 lbs.SEE

PHOTO ON NEXT PAGE

16. Working from the driver’s side, electrical plug. Follow the

electrical plug to the plastic loom, carefully open the loom

and ONLY remove the ABS wires from it back

approximately 10 inches. Route the plug and line down to

the shock and plug in. SEE PHOTO BELOW

17. Remove the air line manifold from its connection point in

the rear wheel well. Bring the manifold forward just behind

the rear shock. The supply line needs to be swapped on the

manifold with the line to the driver side shock. Remove the

clips from the ends and swap the two lines. Use a drill with

a 15/64” drill bit and drill a hole into the plastic liner and

insert the manifold into it. Use two of the supplied 8” zip

ties and attach the ABS & Electrical lines to the shock

extension. Use two of the supplied 14” zip ties and attach

the ABS line to the shock ABOVE THE SHOCK

BLADDER. SEE PHOTOS

Photos above show factory routing of air lines into manifold

Factory

hardware Supplied

9/16” x 3”

Hardware

Supply line from

compressor Line to

shock

Line to

shock Supply line

from

com

ressor

Photos above show changed routing of air lines into manifold

Line to

shock Supply line

from

com

ressor

Zip Tie ABS

Lines to Shock

Mount

Passenger Side Shown above and below

Drill a 15/64”

hole to attach

manifold to

wheel well

Zip Tie ABS

Lines To Shock

Above Shock

Bladder

18. Repeat steps sixteen and seventeen on the passenger side

(there is no air line manifold on the passenger side)

RESUME INSTALL OF ALL KITS

19. Remove the 9/16” x 4” bolt from the trac bar bracket and

install the trac bar into the bracket (some trucks require

sanding the edge / flashing off of the end of the trac bar for

fitment into the new bracket). Torque to 75 lbs. SEE

PHOTO ON NEXT PAGE

Zip Tie ABS

Lines to Shock

Mount

20. Connect the bottom of the sway bar end link onto the sway

bar using the supplied 12mm-1.5 x 75 bolts, ½” large flat

washers and nylock nuts. Install the brake line extension

tab using the original bolt and the supplied 5/16” hardware.

SEE PHOTOS BELOW AN IN NEXT COLUMN.

21. Reinstall the rear tires and torque the lugs to factory

specifications. The factory torque specifications can be

found in your owner’s manual.

22. Remove the jack stands and set the truck back onto the

ground. Torque the Upper and Lower Link arm bolts to

100 ft. lbs. Check the torque on all the rest of the fasteners.

23. Check front-end alignment and set to factory specifications.

Sand / grind

down the edge

of the trac bar

for proper

clearance of the

trac bar to the

trac ba

r bracket

½” Large USS

Flat Washers

One on each

side of bushin

RETORQUE ALL NUTS, BOLTS AND LUGS AFTER 50 MILES AND PERIODICALLY THEREAFTER.

For technical assistance call: 909-597-7800

Product Warranty and Warnings-

Fabtech provides a Limited Lifetime Warranty to the original retail purchaser who owns the vehicle, on which the product was originally installed, for

defects in workmanship and materials.

The Limited Lifetime Warranty excludes the following Fabtech items; bushings, bump stops, ball joints, tie rod ends, limiting straps, cross shafts, heim

joints. These parts are subject to wear and are not considered defective when worn. They are warranted for 60 days from the date of purchase for

defects in workmanship.

Take apart shocks are considered a serviceable shock with a one year warranty on leakage only. Service seal kits are available separately for future

maintenance. All other shocks are covered under our Limited Lifetime Warranty.

Fabtech does not warrant any product for finish, alterations, modifications and/or installation contrary to Fabtech’s instructions. Alterations to the finish

of the parts including but not limited to painting, powdercoating, plating and/or welding will void all warranties. Some finish damage may occur to

parts during shipping which is considered normal and is not covered under warranty.

Fabtech products are not designed nor intended to be installed on vehicles used in race applications or for racing purposes or for similar activities. (A

“RACE” is defined as any contest between two or more vehicles, or any contest of one or more vehicle against the clock, whether or not such contest is

for a prize). This warranty does not include coverage for police or taxi vehicles, race vehicles, or vehicles used for government or commercial purposes.

Also excluded from this warranty are sales outside of the United States of America.

Installation of most suspension products will raise the center of gravity of the vehicle and will cause the vehicle to handle differently than stock. It may

increase the vehicle’s susceptibility to a rollover, on road and off road, at all speeds. Extreme care should be taken to operate the vehicle safely at all

times to prevent rollover or loss of control resulting in serious injury or death. Fabtech front end Desert Guards may impair the deployment or operation

of vehicles equipped with supplemental restraining systems/air bag systems and should not be installed if the vehicle is equipped as so.

Fabtech makes every effort to ensure suspension product compatibility with all vehicles listed in the catalog, but due to unknown auto manufacturers

production changes and/or inconstancies by the auto manufacturer, Fabtech cannot be responsible for 100% compatibility, including the fitment of tire

and wheel sizes listed. The Tire and Wheel sizes listed in Fabtech’s catalog are only a guideline for street driving with noted fender trimming. Fabtech is

not responsible for damages to the vehicle’s body or tires.

Fabtech’s obligation under this warranty is limited to the repair or replacement, at Fabtech option, of the defective product only. All costs of removal,

installation or re-installation, freight charges, incidental or consequential damages are expressly excluded from this warranty. Fabtech is not responsible

for damages and/or warranty of other vehicle parts related or non related to the installed Fabtech product. This warranty is expressly in lieu of all other

warranties expressed or implied. This warranty shall not apply to any product that has been subject to accident, negligence, alteration, abuse or misuse

as determined by Fabtech.

Fabtech suspension components must be installed as a complete system including shocks as shown in our current catalog. All warranties will become

void if Fabtech parts are combined and/or substituted with other aftermarket suspension products. Combination and/or substitution of other aftermarket

suspension parts may cause premature wear and/or product failure resulting in an accident causing injury or death. Fabtech does not warrant products not

manufactured by Fabtech.

Installation of Fabtech product may void the vehicles factory warranty; it is the consumer’s responsibility to check with their local vehicle’s dealer for

warranty disposition before the installation of the product.
