Fagor 5HA-196 X - REV 7-10 Installation guide

5HA-196 X
5HA-200 LX
5HA-200 RX
24” MULTI-FUNCTION OVENS
24” FOUR À CONVECTION
24” HORNO DE CONVECCIÓN
NOTE: To avoid accident, injury, or damage, please read these instructions carefully before installing or operating the appliance.
NOTE: Veuillez lire ces instructions attentivement a fin d’éviter accidents et dommages.
NOTA: Por favor, lea este manual de instrucciones atentamente para evitar posibles daños o accidentes.
INSTALLATION USE & CARE INSTRUCTIONS
GUIDE D’UTILISATION ET D’ENTRETIEN
MANUAL DE INSTRUCCIONES Y MANTENIMIENTO

OVENS
CONTENTS
THANK YOU
1. IMPORTANT SAFETY NOTICES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.1. Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2. Installation and Electrical Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3. USING THE OVEN AND PRACTICAL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1. Before using the oven for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2. Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.3. Operating the oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.4. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5. Practical advice and cooking table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4. OVEN CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1. Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1.1. Oven Exterior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.1.2. Oven Interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1.3. Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1.4. Side Supports .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2. Replacing the interior light bulb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5. TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
6. ENERGY-SAVING TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
7. STOP/START DIGITAL TIMER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
7.1. Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2. Timer Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3. Safety Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.4. Timer Beeping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

5
THANK YOU
Congratulations!
You are now the proud owner of a FAGOR oven and we would like to thank you
for the condence you have placed in us.
FAGOR offers a complete range of high quality and eco-friendly products that are
designed to work hard while consuming less.
We strive to bring energy efciency to the forefront with products that consis-
tently deliver on that promise.
FAGOR’s complete appliance range offers a wide selection of cooktops, range
hoods, dishwashers, washing machines, and refrigerators that you can combine
with your new oven.
Before using your oven for the rst time, we recommend you read user manual
carefully.You will nd information you will need to make the most of new FAGOR
oven. Please pay special attention to the safety advice, as well as use & care
guidelines contained in this manual.
At the same time, we recommend you keep this manual in a safe place. If you
pass the appliance on to another person, please be sure to enclose the manual.
Thank you,
FAGOR America Inc.

6
1. IMPORTANT SAFETY
INSTRUCTIONS
When properly cared for, your new Fagor oven has been designed to be a safe,
reliable appliance. Read all instructions carefully before using this oven. These
precautions will reduce the risk of burns, electric shock, re and injuries.
When operating this appliance, basic safety precautions must be followed,
including the following:
• This appliance must be properly installed and grounded by a qualied
technician. See electric preparation and connection instructions in the
Installation Instructions.
• This appliance should only be serviced by an authorized service technician.
Contact the nearest authorized service center for inspection, repair or
adjustment.
• Do not repair or replace any part of the oven unless specically
recommended. Refer service to an authorized service center.
• Do not operate this appliance if it is not working properly or if it has been
damaged, until an authorized technician by Fagor has inspected it.
• Install or locate this appliance only in accordance with the Installation
Instructions.
• Use this oven only as intended by the manufacturer. If you have any
questions, contact the manufacturer.
• Do not cover or block any openings on this appliance.
• Use this appliance only for its intended use as described in this manual. Do
not use corrosive chemicals, vapors, or nonfood products in this appliance.
This type of oven is specically designed to heat or cook in a residential
environment. It is not designed for industrial or laboratory use. The use of
corrosive chemicals in heating or cleaning will damage the appliance.
• In the event that personal clothing or hair catches re, DROP AND ROLL
IMMEDIATELY to extinguish ames.
• This oven is intended for residential use only. It is not approved for outdoor
use.
• Do not line the oven bottom with any type of foil, liners or cookware because
permanent damage will occur to the oven bottom.

7
• Do not allow children to use this appliance unless closely supervised by an
adult. Children and pets should not be left alone or unattended in the area
where the appliance is in use. Never allow children to sit or stand on any part
of the oven.
• Do not store items of interest to children above the oven. If children should
climb onto the appliance to reach these items, they could be seriously
injured.
To reduce the risk of re in the oven cavity:
1. Do not store ammable materials in or near the oven.
2. Do not use water on a grease re. Smother re or use a dry chemical or
foam-type extinguisher.
3. Have a re extinguisher readily available and highly visible next to any
cooking appliance. Be sure you know how to use it.
4. Do not overcook food. Carefully attend oven if paper, plastic or other
combustible materials are placed inside the oven.
5. Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils or food in the cavity when not being used.
6. If materials inside the oven should ignite, keep oven door closed. Turn oven
off and disconnect the circuit at the circuit breaker box.
7. Do not block any vent openings.
8. Be sure the blower fan runs when the oven is in operation. If the fan does
not operate, do not use the oven. Call an authorized service center.
9. Never use the oven to warm or heat a room. This can damage the oven
parts.
10. For personal safety, wear proper clothing. Loose tting garments or
garments with hanging sleeves should never be worn while using this
appliance.

8
SAFETY PRECAUTIONS
• Tie long hair so that it doesn’t hang loose near the oven cavity.
• The heating elements may be hot even though they are dark in color. Interior
surfaces of an oven become hot enough to cause serious burns.
• During and after use, do not press or let clothing or other ammable
materials contact the heating elements or the interior surfaces of the oven
until they have had sufcient time to cool.
• The trim on the top and sides of the oven door may become hot enough to
cause burns.
• Use care when opening the door. Open the door slightly to let hot air or
steam escape before removing or replacing food.
• Do not heat unopened food containers. Buildup of pressure may cause the
container to burst and result in injury.
• Always place oven racks in desired location while the oven is cool. If a
rack must be moved while the oven is hot, do not let potholder contact the
heating elements.
• Use only dry potholders. Moist or damp potholders on hot surfaces may
result in burns from steam. Do not let potholders touch hot heating elements.
Do not use a towel or other bulky cloth material.

20
43/50
”
23
5/16
”
22”
21
13/16
”
min.
2327/64”
013/16”
235/8”(with induction cooktop installation above)
231/2”(without induction cooktop installation)
MINIMUM COUNTERTOP CLEARANCE
REQUIREMENT:
0
13/16
”
2327/64”
23
5/16
”
2043/50”
21
13/16
”
min.
22”
237/32”
231/2”
9
1. Cut the plastic lm covering the entire package.
2. Carefully remove all the oven’s protective elements: top cover, edge
protection and polystyrene base.
1. The measurements of the Cabinet unit in which
the oven is to be mounted must coincide with
those indicated in the diagrams, depending on
whether the unit is wall-mounted or installed
below a counter top.
-Figure 1-
2. INSTALLATION AND ASSEMBLY
UNPACKING
INSTALLATION & ELECTRICAL CONNECTION
24” Multi-Function Wall Oven 5HA-196 X
2.1
2.2
a

10
IMPORTANT:
- The measurements of the gure 1 or 2 must be taken into consideration to
properly mount the oven.
- Once the oven is placed in the space, fasten it to the cabinet with the 2
supplied screws in the positions marked “A”.
- Do not hang from the door when it is opened.
Side Swing 24” Multi-Function Oven 5HA-200 LX 5HA-200 RX
b
