QUICK START GUIDE: 3FE-8112
Dear Customer,
This Quick Start Guide is enclosed with detailed washing
machine operating instructions. Before using the appliance
carefully read the Operang Instrucons, especially
guidelines for safe use.
Before plugging the washing machine into the mains, remove
the safety packaging and ensure the machine is level. Do not
start the washing machine before it is properly set up.
Only wash delicate fabrics, synthetics, wool using designated
programs. Such fabrics should only be washed in the maximum
load sizes recommended (see page 2.).
The correct washing machine operation extends its lifetime
so make sure the drum seal is dry (leave the door ajar after
washing). Do not clean the washing machine with harsh or
abrasive detergents.
Preparing to wash1
Empty pockets
Close all zips and button up duvet covers.
Wash delicate and small items in a protective mesh
laundry bag.
Open the door of the washing machine by gripping the
door and the door handle on the inside of the door.
Insert the sorted clothes into the washing machine:
Cotton — max full drum.
Synthetics — max ½ of the drum.
Silk, wool — max 1/3 of the drum.
Close the door, press rmly against the seal.
Add detergent2
Open the detergent drawer. Pull the handle.
Pour the recommended dose of washing detergent into
the appropriate compartment of the detergent drawer.
Add fabric conditioner to the appropriate compartment
if required.
MAIN WASH detergent.
Fabric softener or other special care liquids.
PREWASH detergent.
Program selecons3
Set the programme selector knob to the desired
programme.
Customize the programme to your needs — you
can change the temperature, spin speed, or enable
additional features.
Select additional functions. The additional functions
are described on the control panel and in the “Table
of Wash Programmes” (see page 2) .
Select START4
Close the appliance door.
Set the programme selector dial to the desired
programme (see page 2).
Select additional functions or wash cycle
parameters as required – according to your needs.
Select time remaining ranging from 1 to 23 hours.
Then press the START/ PAUSE button
End of the wash5
Your machine will stop by itself as soon as the
programme you have selected nishes.
“- -” will ash on the electronic display.
You can open the machine’s door and
Remove the laundry.
Leave the door of your machine open to allow the
inner part of your machine to dry.
Switch the programme dial to STOP position.
Unplug your machine.
Turn the water tap off.
1. Electronic Display
2. Programme Dial
3. Upper Tray
4. Detergent Drawer
5. Drum
6. Pump Filter Cover
7. Temperature button
8. Spin Button
9. Time Remaining
8+9. Child Lock
IO-WMS-1616 (EN) 11.2019./1
7 8 9
8 + 9

ITEM Programme
name
The
default
tempera-
ture
[°C]
Max. spin
speed
[RPM]
Max.
load
[kg] Delay End
Addional funcons available Detergent drawer
Prewash Main wash Fabric
soener
Time
[h:min]
Energy
con-
sump-
on
[wh]
Water
con-
sump-
on
[l]
Number
of rinses Type of laundry
1Coon 60 Very dirty, cotton and ax textiles. (Underwear, linen, tablecloth, towel (maximum 3,5 kg),
bedclothes, etc.)
2Coon 40 Dirty cotton and ax textiles. (Underwear, linen, tablecloth, towel (maximum 3,5 kg),
bedclothes, etc.)
3Pre-Wash Dirty cotton and ax textiles. (Underwear, linen, tablecloth, towel (maximum 3,5 kg),
bedclothes, etc.)
4 Eco 20 Less dirty, cotton and linen textiles. (Underwear, bedsheet, tablecloth, towel (max.2,0 kg)
bedcloth, etc.)
5EASY
CARE
Very dirty or synthetic-mixed textiles. (Nylon socks, shirts, blouses, synthetic-including
trousers etc.)
6WOOL Woollen laundries with machine wash labels.
7RINSING Provides an additional rinse to any type of laundry after the washing cycle.
8ALLERGY
SAFE Baby laundry
9Spin/Drain
You can use this program for any type of laundry if you want an additional rinsing step after
the washing cycle./ You can use the drain program to drain the water accumulated inside the
machine (adding or removing laundry). To enable the drain program, turn the program knob
to the spin/drain program. After you select “spin cancelled” using the auxiliary function key,
the program will start to run.
10 SENSITIVE/
HAND WASH
Laundry recommended for hand wash or sensitive laundry.
Outdoor
Clothing Outdoor Clothing
11
Mixed Dirty cotton, synthetics, colour and ax textiles can be washed together. 12
Jeans / Dark
Garments
Black and dark items made of cotton, mixed bre or jeans. Wash inside out., Jeans often
contains excess dye and may run during the rst few washes. Wash light and dark coloured
items separately.
13
DAILY 60
min. Dirty cotton, coloured and linen textiles washed at 60°C in 60 minutes.
14
Rapid 15 min. In a short time of 15 minutes, Lightly soiled, cotton, colored and linen textiles your can wash. 15
Standard programmes for washing cotton fabrics at 60 °C and 40 °C. These programmes are suitable for washing normally soiled cotton fabrics.
These are the most effective programmes for washing these type of fabrics, taking into account the total energy and water consumption.
* Real water temperature may differ from the declared wash cycle temperature.
Above mentioned time is an estimate and may differ from actual wash cycle time, depending on temperature, water pressure, load size, etc.
The time is automatically updated during wash cycle. Displaying the same time for an extended period or abrupt changes are normal.
NOTE:
NOTE:
Use detergent or fabric softener if necessary, Detergent required, without which washing will be ineffective. Do not use detergent or fabric softener
TABLE OF WASH PROGRAMMES: 3FE-8112
04:00 52 2
03:55 43 2
02:44 90 3
01:36 42 2
01:50 50 2
00:43 48 3
00:30 50 3
03:31 92 4
00:17 -- -
01:30 95 3
01:20 49 2
01:33 48 2
01:36 62 3
01:00 37 1
00:15 32 1
6300
1100
1800
1800
6300
800
100
2680
60
300
330
310
360
900
130
60° 8.0
40° 8.0
60° 8.0
20° 4.0
40° 3.5
30° 2.5
cold
water 8.0
60° 4.0
8.0
30° 2.5
30° 3.5
40° 3.5
30° 3.5
60° 4.0
30° 2.0
cold
water
1200
1200
1200
1200
1000
800
1200
800
1200
800
800
800
800
1200
800
