QUICK START GUIDE: 3FE-8612
Dear Customer,
This Quick Start Guide is enclosed with detailed washing
machine operating instructions.Before using the appliance
carefully read the Operating Instructions, especially
guidelines for safe use.
Before plugging the washing machine into the mains,
remove the safety packaging and ensure the machine is level.
Do not start the washing machine before it is properly
set up.
Only wash delicate fabrics, synthetics, wool using
designated programs. Such fabrics should only be washed in
the maximum load sizes recommended (see page 2.).
The correct washing machine operation extends its lifetime
so make sure the drum seal is dry (leave the door ajar after
washing). Do not clean the washing machine with harsh or
abrasive detergents.
Preparing to wash1
Empty pockets
Close all zips and button up duvet covers.
Wash delicate and small items in a protective mesh
laundry bag.
Open the door of the washing machine by gripping
the door and the door handle on the inside of the
door.
Insert the sorted clothes into the washing machine:
Cotton — max full drum.
Synthetics — max ½ of the drum.
Silk, wool — max 1/3 of the drum.
Close the door, press rmly against the seal.
Add detergent2
Open the detergent drawer. Pull the handle.
Pour the recommended dose of washing detergent
into the appropriate compartment of the detergent
drawer.
Add fabric conditioner to the appropriate
compartment if required.
MAIN WASH detergent.
Fabric softener or other special care liquids.
PREWASH detergent.
OptiDose — automatic (liquid) detergent
dispensing*
The OptiDose button is used for automated
dispensing of liquid detergent.You can choose the
detergent dose — small, medium, large — or turn o
the system.
Press and hold the OptiDose button for 3 seconds
to turn o the OptiDose option. Press and hold the
OptiDose button for 3 seconds again to turn on the
OptiDose option.
* Available on selected models
Program selections3
Set the programme selector knob to the desired
programme.
Customize the programme to your needs — you
can change the temperature, spin speed, or
enable additional features.
Select additional functions.The additional
functions are described on the control panel and
in the “Table of Wash Programmes” (see page 2) .
Select START4
Close the appliance door.
Set the programme selector dial to the desired
programme (see page 2).
Select additional functions or wash cycle
parameters as required – according to your
needs.
Select time remaining ranging from 1 to 24
hours.
Then press the START/ PAUSE button
End of the wash5
End of the wash cycle is indicated by acoustic signal
(if active).The display shows END and the door lock
indicator light goes out.
Close the water valve.
Turn washing machine o.
Unplug the appliance from the mains.
Open the door and remove laundry. Once clothes
are removed, leave the door slightly ajar to allow the
drum seal to dry before the door is closed properly.
Leave the detergent drawer compartment slightly
ajar to allow it to dry.
IO-WMS-1548 (EN) 11.2019./1
1
1. Detergent drawer
2. Drum
3. Programme selector dial
4. Control Panel / Display
5. Door handle
6. Pump lter cover
7. Time Remaining
8. Temperature button
9. Spin Button
10. Soil level
11. Rapid Wash
12. Options (Extra Rinse/Pre-wash)
8+9. Acoustic Signal On/O
11+12. Child Lock
3 4
2
5
6
1
4
7 8 9 10 11 12
8 + 9 11 + 12

TABLE OF WASH PROGRAMMES: 3FE-8612
ITEM Programme
name
The
default
tempera-
ture
[°C]
Default
spin speed
[RPM]
Max.
load
[kg] Soil level Rapid
Wash
Extra Rinse Prewash
Additional functions available Detergent drawer
Prewash Main wash Fabric
softener
Time
[h:min]
Energy
con-
sump-
tion
[wh]
Water
con-
sump-
tion
[l]
Number
of rinses Type of laundry
1
Cotton
60° 1200 8.0
Heavily soiled clothing, or an moderately soiled cotton and linen for children that requires
boiling.
2
Cotton Eco
40° 1200 8.0
Moderately or heavily soiled cotton clothes, bed linen, table linen, undergarments,
towels, linen fabrics.
3Daily 58’ 60° 1200 2.0 Full and eective washing cycle in less than 1 hour. One of the shortest washing pro-
grammes on the market.
Convenience and saving time
4 Shirts 40° 800 4.0 Dirty cotton, clothing made from synthetic fabrics or natural-synthetic fabric blends
(shirts, blouses).
5Physical
tness 30° 800 4.0 Sports wear and leisure wear with Microbre.
6Out-of-home
advertising 30° 800 4.0
Special programme for washing of outerwear, sports wear, which is often waterproof.
With this programme, you can add a hydrophobic coating to the rinse aid compartment
Increases water resistance.
7 Dark 40° 1000 4.0 Lightly soiled delicate synthetics, or synthetic and cotton blends.
8 Synthetics 40° 800 4.0 Dirty cotton, synthetics, coloured laundry, linen fabrics.
9Autoclean 90° 600 --
A special programme (no load ) that sterilises (90-95°C) and cleans the inner and outer
drum from allergens and pathogens like fungi, moulds, bacteria.
10 Rinse -- 1200 8.0 This programme is for rinsing with additives (such as anti-static or softening additives).
Reduce the spin speed when washing very delicate fabrics.
Steam Refresh -- -- --
This special program do not use water for classic washing. It only use steam to refresh
your laundry.You can easily get rid of bad odors or just make fresh again your lightly
used shirts.
11
Wool 40° 600 2.0 NOTE: Do not machine wash woollen fabrics if the cloth tag prohibits. 12
Delicate 30° 600 2.5 Very delicate fabrics, e.g. silk. 13
Express 15’ Cold
water 800 2.0
Lightly soiled, sweaty cotton and linen clothes.
NOTE: Due to the extra short wash cycle, less detergent is required compared to other
programmes.
14
Antiallergic 60° 800 4.0 The program is designed for washing clothes of people with sensitive skin, eg. for
children.
15
Standard programmes for washing cotton fabrics at 60 °C and 40 °C. These programmes are suitable for washing normally soiled cotton fab-
rics. These are the most eective programmes for washing these type of fabrics, taking into account the total energy and water consumption.
*Real water temperature may dier from the declared wash cycle temperature.
Above mentioned time is an estimate and may dier from actual wash cycle time, depending on temperature, water pressure, load
size, etc.The time is automatically updated during wash cycle. Displaying the same time for an extended period or abrupt changes are
normal.
NOTE:
NOTE:
Use detergent or fabric softener if necessary, Detergent required, without which washing will be ineec-
tive.
Do not use detergent or fabric softener
Favourites To save frequently used programme settings. 16
04:34 62 2
02:58 45 2
01:16 62 1
01:32 32 3
02:00 50 2
01:31 38 2
02:26 62 3
02:17 70 3
01:18 10 2
00:20 20 1
00:15 1 --
01:07 26 2
00:50 29 2
00:15 26 1
04:41 90 4
0,73
1,0595
1,02
0,717
0,622
0,615
0,796
1,05
1,047
0,043
0,395
0,444
0,348
0,158
2,5
58`
