FAME Explorer 2.10 User manual

ENGLISH
Important safety instructions! Please read before connection!
DANGER! (Electrical shock due to high voltages in the device)
The housing must not be removed! There are no parts to be maintained in the device.
Inside the unit there are components which are under high electrical voltage.
Before each use, check the device for damage or the absence of components, protective
devices or housing parts. If this is the case, the device must not be used!
Leave maintenance and repair work to a qualified service workshop or contact your
dealer. In the case of a malfunction of the device, operation must also be stopped
immediately until the device has been repaired by a specialist!
DANGER! (Electric shock due to short circuit)
Modifications to the power cord or plug are prohibited. If the power cord is damaged in any
way, it must be replaced immediately with an original spare part from the manufacturer.
Always make sure that the grounding of the device is maintained. Use only the supplied
power cords and always maintain the side grounded contacts. Make sure that the sockets
used have a properly functioning protective earth.
Failure to do so may result in fire or death due to electric shock!
DANGER! (For babies and children)
Dispose of or store any packaging material properly! Packaging material must be kept out
of the reach of babies and children due to the risk of suffocation.
Ensure that children never use the appliance unattended! In addition, make sure that
children do not remove (small) parts from the device, as they could suffocate by swallowing
parts!
DANGER! (Hearing damage)
Professional speaker systems are able to generate harmful sound levels. Even the influence
of seemingly harmless sound levels over a longer period of time can lead to permanent
damage to the hearing (from approx. 95 dBA SPL).
Therefore, always wear professional hearing protection (earplugs or capsule ear protectors)
during operation!
Hint! (Fire hazard due to overheating)
The maximum permissible ambient temperature of this device is 40°C.
Ensure that the unit is placed in a well-ventilated location away from direct heat sources,
naked flames, combustible materials, and liquids. A minimum distance of 1 m is required.
Do not tape or cover the ventilation slots of the unit, or insert objects into the unit.

ENGLISH
Hint! (Operating conditions)
In advance, it must be clarified with the manufacturer whether the device is also suitable
for outdoor use.
Always keep a minimum distance of 20 cm from walls or other structural objects.
Never expose the device to direct rain, moisture or liquids, as this can lead to damage.
Vibrations, dust or sunlight can also cause damage, avoid them!
Hint! (Power supply)
It is essential that you check that the device voltage matches your local mains voltage. It
is highly recommended that you fuse your mains socket with a residual current circuit
breaker (FI).
If you do not use your device for a longer period of time or carry out maintenance work,
disconnect the device from the mains in order to minimize danger. The same applies to
storm conditions such as thunderstorms, floods, etc.
Hint! (Fuses)
Replace fuses only with IEC127 type (5x20mm) and the correct rating to ensure optimum
performance! It is forbidden to use short-circuited fuses or to bridge the fuse holder.
Fuses may only be replaced by qualified personnel.
Hint! (Condensation)
To avoid condensation in the unit, the unit should adapt to the ambient temperature
before commissioning.
Hint! (Unwanted odours)
A new product can sometimes lead to unwanted odours. This reaction is normal and
disappears after a few minutes.
Hint! (Possible damage due to magnetic fields)
Speakers cause a static magnetic field. Ensure sufficient distance from equipment that
may be affected.

ENGLISH
Symbols on device and packaging:
The lightning flash symbol warns the user of uninsulated voltages and the risk of
electric shock.
The exclamation mark symbol draws the user’s attention to important maintains and
operating instructions in the manual.
The lightning warns you of dangerous voltage accessible from the outside. A connection
to any terminal marked with this symbol may only be made with a ready-made cable
that complies with the manufacturer's recommendations or with cables installed by
qualified personnel.
This symbol warns of hot surfaces. To avoid burns - DO NOT touch!
Only suitable for indoor use.
Read the manual
Please read and follow the warnings and recommendations carefully to ensure safe
and trouble-free use.

ENGLISH
Installation:
Be sure to check the unit for damage before use. Use the original packaging or a suitable
transport or storage packaging to protect the product from dust, moisture, etc. when not in use.
During assembly, suitable protective equipment (in particular head protection, gloves and safety
shoes) must be worn and only suitable climbing aids (ladders, scaffolding, etc.) must be used.
The responsibility for this lies solely with the installation company.
The installation may only be carried out by experts and only at mounting points with sufficient
load-bearing capacity, if necessary taking construction requirements into account. The fixing
material (screws, dowels, etc.) specified by the manufacturer in the assembly instructions must
be used. Screw connections must be secured against loosening by suitable measures.
Fixed or mobile installations shall be protected against falling by two independently acting
devices. Loose additional parts or parts which come loose must be able to be caught by suitable
devices. National regulations must be observed when using fasteners and fixing elements as well
as slings. With regard to the dimensioning of the securing devices, possible dynamic loads
(jerking forces) must also be taken into account.
ATTENTION! (Inspection measures)
After installation, check the suspension of the system consisting of bracket and
loudspeaker for secure fastening. The operator of loudspeaker systems (stationary or
mobile) is obliged to regularly inspect all system components or have them inspected in
accordance with the relevant national regulations and to have any damage repaired
immediately. Furthermore, we urgently recommend detailed documentation of all
inspection measures in test books or similar.
ATTENTION! (Load capacity)
When loudspeakers are longer or permanently used outdoors, wind loads, snow and ice
loads as well as thermal influences must be taken into account for the stability and load-
bearing capacity of structures and surfaces.
In particular, the load-bearing points of flown systems should be dimensioned with
sufficient safety reserves. The national regulations must be observed.
WARNING! (Risk of injury from overturning)
Improper installation can cause considerable injury and damage!
During transport and installation, ensure that only aids specified by the manufacturer
(e.g. trolleys, stands, tripods, brackets, etc.) are used and always follow the
manufacturer's instructions!

ENGLISH
Hint! (Special measures)
Special measures may also be required to prevent spectators from behaving dangerously.
Tripods must not be set up in escape and rescue routes. When installing in traffic routes,
the required width of the paths and proper blocking and marking must be ensured. When
setting up and setting down
a special hazard. Suitable aids must be used for this purpose.
The national regulations must be observed.
Using this device with sinusoidal, square-wave or other measuring signals at higher
levels will cause serious damage to the device!

ENGLISH
Congratulations on your new Fame Explorer 2.10!
Thank you for choosing a Fame product. Through efficient development and economical
production, Fame enables high quality products at a fantastic price.
Please read the instruction manual carefully to learn about all the features of this
product and keep it for future use.
Have fun with your new product!
Your Fame Team
Guarantee:
The current general terms and guarantee conditions
of the Music Store professional GmbH apply.
You can view it at: www.musicstore.de
If you have any questions or suggestions,
please contact us:
Music Store professional GmbH
Istanbulstr. 22-26
51103 Cologne
Managing Director: Michael Sauer
WEEE-Reg.-No. DE 41617453
Tel: [phone]
Fax: [phone]
[e-mail]
Intended use:
The product Fame Explorer 2.10 is optimized for use with music and speech signals. The device
may only be used for this purpose and in accordance with the operating instructions. Other
purposes as well as operation under other operating conditions are expressly not intended and can
lead to damage to property or personal injury! No liability is assumed for damage resulting from
improper use.
It must be ensured that the device is operated exclusively by trained and competent users who are
in full possession of their mental, physical and sensory abilities. The use of other persons is
expressly only permitted at the request of a person responsible for their safety, who instructs or
supervises the use.
Content
Quantity
Subwoofer
1
Satellite
2
Manual
1
Power cable
1
Speaker Cable
2
Scope of delivery:

ENGLISH
Set up:
All connections of the device should be made before switching on. Only use high-quality and
undamaged cables that are as short as possible for the connections.
Configuration of the audio input connector
CH1 –CH4
XLR/jack (6,35mm) –jack combo, balanced

ENGLISH
CH5 –CH6
RCA/Cinch –Mono/Stereo (6,35mm)
CH7 –CH8
AUX, 3,5mm Stereo-Jack

ENGLISH
Connections and controls:

ENGLISH
No.
Designation
No.
Designation
1
Setup Switch
Left: Stereo-Mode
Right: Mono-Mode
12
Echo
Control for setting the echo effect
2
CH1 –CH4 Input
XLR/Jack (6,35mm) mono balance
Input
13
Delay
Control for setting the delay effect
3
CH1 –CH4 Level –Control
Volume control for the
individual inputs
14
Subwoofer Volume Control
Control for adjusting the volume of the
subwoofer
4
CH1 –CH4 MIC/Line Select Switch
to adjust the input level:
LINE: for audio devices with line
output
MIC: for microphone
15
Master Volume Control
Volume control for the overall volume
5
CH1 –CH4 Tone Control
Those switches allow you to adjust the
tone effect, boost the low and high
frequency once reduce midrange.
16
POWER/LIMIT LED
LED shines blue: The system is
connected and switched on.
LED shines red: Lights when the
signal level is too high or a current
overload is detected.
6
CH5-CH6 Input
RCA/Cinch
Mono/Stereo (6,35mm)
17
Monitor Output
For connection to a stereo monitor system
7
CH6 –CH6 Level –Control
Volume control for the
individual inputs
18
Speaker LED
This two-color LED indicates the status of
each speaker output:
Green - active speaker output
Red - inactive speaker output
8
CH7 –CH8 Input
3,5mm Stereo-jack socket for
connecting MP3 or CD players,
tablets, smartphones and PCs or
Bluetooth-function
19
L/R Speaker Output
for included satellite speakers
9
Bluetooth Control
Pressing a key activates the pairing
mode. The LED flashes during pairing
and lights up constantly when a
connection is established.
To reset a connection, press the key
again.
20
Power switch
10
Bluetooth LED Display
LED off: Bluetooth function
switched off
permanent lights: Bluetooth
function activated
LED flashes: Pairing mode
21
Fuse
T3.15AL/250V
11
Switch CH7-CH8
Switch to select AUX input or
Bluetooth function
22
Power Outlet

ENGLISH
Operation:
The Fame Explorer 2.10 can be operated in stereo mode as well as in mono mode. The setting is
done via the setup switch (1) on the back of the subwoofer.
Stereo mode
In stereo mode both outputs are active and the two satellite speakers are split to be used as a
2.1 sound system.

ENGLISH
Mono mode
In mono mode, only the left output is active and the two satellite speakers are connected
together to concentrate their power on one output. Mono mode includes either a compact mono
setup (A) or the standard mono setup (B).

ENGLISH
Notice:
Please note that the tripods are not included in the scope of delivery, but must be
purchased as an option. The Explorer Tripod SET from Fame (item number PAH0021771-000)
is recommended as a suitable tripod.

ENGLISH
Technical data:
Model
Explorer 2.10
Type
Subwoofer
Satellite
Quantity
1
2
Power Output
250 Watt RMS
Mono-Mode:
60 Watt RMS
Stereo-Mode:
120 Watt RMS
Subwoofer
10“
Satellite
WF: 4,75“
TW: 1“
Power Output Total
350 Watt RMS
Fuse
T3.15AL/250V
Frequency fange
50 Hz –160 Hz
155 Hz –20 kHz
System frequency
50 Hz –20 kHz, +/-3 dB
Limiter
Soft Limit
Input
XLR/Jack-Combo, RCA/Cinch,
3,5mm Stereo-Jack
Output
TS Stereo Monitor Output
Bluetooth-function
Yes
Power connect
IEC
Power supply
220-240 VAC –50/60 Hz
Max. SPL
123 dB
Mono-Mode:
125 dB
Stereo-Mode:
130 dB
Material
Plastic
Dimensions (H x W x D)
458 x 350 x 407 mm
227 x 140 x 155 mm
Weight
14 kg
4 kg
Colour
Black

ENGLISH
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
Cleaning:
The ventilation grilles of the unit must be cleaned regularly from impurities such as dust and dirt.
Switch off the unit before cleaning and disconnect mains operated units from the mains supply.
Use a lint-free, damp cloth for cleaning. Never use alcohol or solvents for cleaning!
Do not open the device. The device does not contain any assemblies or components that can be
replaced or maintained by the user.
In case of damage, do not put the device into operation under any circumstances. Service work
or repairs may only be carried out by qualified service personnel, in particular in the following
cases:
Objects or liquids have penetrated into the device.
The unit does not operate as normal.
The unit has been dropped or the cabinet has been damaged.
Symptom
Troubleshooting
No function
Check the network connection and the fuse
No sound from loudspeaker, but
power LED lights up
Check the cable connections at the inputs and
outputs
The speaker or XLR cables may be defective.
Please replace them

ENGLISH
Environmental protection:
The company MUSIC STORE professional GmbH always strives to reduce the burden of packaging
to a minimum. The use of environmentally friendly and recyclable materials is of fundamental
importance to us. Please dispose of and recycle the packaging components after use properly.
Disposal of packaging:
Ensure that paper packaging, plastic materials, etc. are separately recycled. Observe the
corresponding disposal instructions on the packaging.
Disposal of batteries:
Batteries do not belong in the garbage! Please keep batteries in accordance with the
official collection points or disposal stations in accordance with the specifications.
Disposal of your old device:
Do not dispose of the device with household waste! This device is subject to the WEEE
Directive (Waste Electrical and Electronic Equipment) in its currently valid version.
The device will be disposed of by an approved waste disposal company or your local waste
disposal office. The regulations valid in your country must be observed!
Manufacturer: MUSIC STORE professional GmbH,
Istanbulstraße 22-26,
51103 Cologne, Germany

ENGLISH
MS ID: PAH0021649-000
09/2021
Notes
