FAME EZ Wireless User manual

ENGLISH
Important safety instructions! Please read before connection!
DANGER! (Electrical shock due to high voltages in the device)
The housing must not be removed! There are no parts to be maintained in the device.
Inside the unit there are components which are under high electrical voltage.
Before each use, check the device for damage or the absence of components, protective
devices or housing parts. If this is the case, the device must not be used!
Leave maintenance and repair work to a qualified service workshop or contact your
dealer. In the case of a malfunction of the device, operation must also be stopped
immediately until the device has been repaired by a specialist!
DANGER! (Electric shock due to short circuit)
Modifications to the power cord or plug are prohibited. If the power cord is damaged in any
way, it must be replaced immediately with an original spare part from the manufacturer.
Always make sure that the grounding of the device is maintained. Use only the supplied
power cords and always maintain the side grounded contacts. Make sure that the sockets
used have a properly functioning protective earth.
Failure to do so may result in fire or death due to electric shock!
DANGER! (For babies and children)
Dispose of or store any packaging material properly! Packaging material must be kept out
of the reach of babies and children due to the risk of suffocation.
Ensure that children never use the appliance unattended! In addition, make sure that
children do not remove (small) parts from the device, as they could suffocate by swallowing
parts!
DANGER! (Hearing damage)
Amplifier units are able to generate harmful sound levels. Even the influence of seemingly
harmless sound levels over a longer period of time can lead to permanent damage to the
hearing (from approx. 95 dBA SPL).
Therefore, always wear professional hearing protection (earplugs or capsule ear protectors)
during operation!
Hint! (Fire hazard due to overheating)
The maximum permissible ambient temperature of this device is 40°C.
Ensure that the unit is placed in a well-ventilated location away from direct heat sources,
naked flames, combustible materials, and liquids. A minimum distance of 1 m is required.

ENGLISH
Hint! (Operating conditions)
In advance, it must be clarified with the manufacturer whether the device is also suitable
for outdoor use.
Never expose the device to direct rain, moisture or liquids, as this can lead to damage.
Vibrations, dust or sunlight can also cause damage, avoid them!
Hint! (Power supply)
It is essential that you check that the device voltage matches your local mains voltage. It
is highly recommended that you fuse your mains socket with a residual current circuit
breaker (FI).
If you do not use your device for a longer period of time or carry out maintenance work,
disconnect the device from the mains in order to minimize danger. The same applies to
storm conditions such as thunderstorms, floods, etc.
Hint! (Condensation)
To avoid condensation in the unit, the unit should adapt to the ambient temperature
before commissioning.
Hint! (Unwanted odours)
A new product can sometimes lead to unwanted odours. This reaction is normal and
disappears after a few minutes.

ENGLISH
Symbols on device and packaging:
The lightning flash symbol warns the user of uninsulated voltages and the risk of
electric shock.
The exclamation mark symbol draws the user’s attention to important maintains and
operating instructions in the manual.
The lightning warns you of dangerous voltage accessible from the outside. A connection
to any terminal marked with this symbol may only be made with a ready-made cable
that complies with the manufacturer's recommendations or with cables installed by
qualified personnel.
This symbol warns of hot surfaces. To avoid burns - DO NOT touch!
Only suitable for indoor use.
Read the manual
Please read and follow the warnings and recommendations carefully to ensure safe
and trouble-free use.
Installation:
Be sure to check the unit for damage before use. Use the original packaging or a suitable
transport or storage packaging to protect the product from dust, moisture, etc. when not in use.

ENGLISH
Congratulations on your new Fame EZ Wireless!
Thank you for choosing a Fame product. Through efficient development and economical
production, Fame enables high quality products at a fantastic price.
Please read the instruction manual carefully to learn about all the features of this
product and keep it for future use.
Have fun with your new product!
Your Fame Team
Guarantee:
The current general terms and guarantee conditions
of the Music Store professional GmbH apply.
You can view it at: www.musicstore.de
If you have any questions or suggestions, please
contact us:
Music Store professional GmbH
Istanbulstr. 22-26
51103 Cologne
Managing Director: Michael Sauer
WEEE-Reg.-No. DE 41617453
Tel: [phone]
Fax: [phone]
[e-mail]
Intended use:
The product Fame EZ Wireless XLR-plug-on transmitter system is designed as a XLR plug-
on transmitter and receiver intended for wireless transmission of audio signals. The device may
only be used for this purpose and in accordance with the operating instructions. Other purposes
as well as operation under other operating conditions are expressly not intended and can lead to
damage to property or personal injury! No liability is assumed for damage resulting from
improper use.
It must be ensured that the device is operated exclusively by trained and competent users who
are in full possession of their mental, physical and sensory abilities. The use of other persons is
expressly only permitted at the request of a person responsible for their safety, who instructs or
supervises the use.
Content
Quantity
XLR Plug-on Transmitter 1
XLR Plug-on Receiver 1
USB Charging Cable 1
Manual 1
Scope of delivery:

ENGLISH
Set up:
All connections of the device should be made before switching on. Only use high-quality and
undamaged cables that are as short as possible for the connections.
Configuration of the 3-pin XLR connector

ENGLISH
Connections and controls:
No.
Designation
No.
Designation
1
3-pin XLR connector
(transmitter: XLR socket)
(receiver: XLR plug)
5
ID button
2
Indicator (orange)
6
Micro USB power recharging jack
3
ID channel indicator and power
level indicator
7
Release button, push to disconnect
from microphone
4
Power button

ENGLISH
Operation:
1. First, switch on the receiver and transmitter by pressing and holding the on/off switch of both
units.
2. When the orange indicator flashes, both units must be paired together. To do so, press and
hold the ID channel display buttons of both units for about 5 to 7 seconds. The pairing of both
units is completed when both ID channel indicators light up in the same color and the orange
indicator turns off.
3. Then connect the transmitter to your microphone or instrument and the receiver to an
amplifier or mixer.
Notes
If the pairing of both devices did not work successfully, switch the transmitter off and
then on again. Now perform the pairing procedure (step 2) again.
If there is any noise during transmission, simply press the ID channel display button on
the transmitter to select another channel. The receiver will automatically change the
channel.
The 4 colors - red, green, blue and purple - of the ID indicators refer to the 4 different
channels.

ENGLISH
Technical data:
Model
Fame EZ Wireless
Transmitter
Receiver
Power
Rechargeable 3,7 V / 450
mAH Li battery
Rechargeable 3,7 V / 360
mAH Li battery
Audio interface
XLR female
XLR male
Channel
4 GHF channel
Frequency
5,729 GHz to 5,820 GHz
Transmission power
> 7 dBm
Receiver sensitivity
< -81 dBm
Signal Noise Ratio
140 dB
Sound quality
24 bit/48 KHz
Delay
5,6 ms
Distortion
-100dB
Max. input signal
amplitude
500 mV
Max. transmission
distance
35m (no obstacles)
Battery Life 4h (after complete charge)
Recharging time
< 2h
Colour
Black
Black
Dimensions
(L x W x H)
30,5 x 30,5 x 98,8 mm
30,5 x 30,5 x 97,5 mm
Weight
0,060 kg
0,057 kg

ENGLISH
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsure, contact the
manufacturer, the dealer or the corresponding specialist personnel. Never open the device on
your own!
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
Display
Description
Charge level indicator lights up
Battery charge status > 30%
Charge level indicator flashes slowly
Battery charge status < 30%
Charge level indicator flashes
quickly
Battery charge status < 15%
Charge level indicator flashes every
5 seconds
Battery charge status < 5%, unit switches
off automatically afterwards
Display
Description
Pairing indicator flashes orange
Pairing running
Pairing indicator off
Pairing successfully completed
Charge level indicator flashes green
Charging running
Charge level indicator lights up
green
Charging completed

ENGLISH
Cleaning:
The ventilation grilles of the unit must be cleaned regularly from impurities such as dust and dirt.
Switch off the unit before cleaning and disconnect mains operated units from the mains supply.
Use a lint-free, damp cloth for cleaning. Never use alcohol or solvents for cleaning!
Do not open the device. The device does not contain any assemblies or components that can be
replaced or maintained by the user.
In case of damage, do not put the device into operation under any circumstances. Service work
or repairs may only be carried out by qualified service personnel, in particular in the following
cases:
Objects or liquids have penetrated into the device.
The unit does not operate as normal.
The unit has been dropped or the cabinet has been damaged.
Environmental protection:
The company MUSIC STORE professional GmbH always strives to reduce the burden of packaging
to a minimum. The use of environmentally friendly and recyclable materials is of fundamental
importance to us. Please dispose of and recycle the packaging components after use properly.
Disposal of packaging:
Ensure that paper packaging, plastic materials, etc. are separately recycled. Observe the
corresponding disposal instructions on the packaging.
Disposal of batteries:
Batteries do not belong in the garbage! Please keep batteries in accordance with the
official collection points or disposal stations in accordance with the specifications.
Disposal of your old device:
Do not dispose of the device with household waste! This device is subject to the WEEE
Directive (Waste Electrical and Electronic Equipment) in its currently valid version.
The device will be disposed of by an approved waste disposal company or your local waste
disposal office. The regulations valid in your country must be observed!
Manufacturer: MUSIC STORE professional GmbH,
Istanbulstraße 22-26,
51103 Cologne, Germany

ENGLISH
MS ID:
PAH0021442-000
10/2019
Notes
