The Andover™
FP5220 Series
SPECIFICATION SHEET
Product Specifications Subject To Change

Copyright 2007 Fanimation, Inc. 2007/12
The Andover™Fan Assembly – FP5220¾¾
Dimensions shown in inches
10983 Bennett Parkway
Zionsville, IN 46077
Toll Free [phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
Fan Assembly - FP5220¾¾
Distance from Ceiling to Blade Edge
(with 6˝DR) 10.3˝
Blade Sweep / Pitch 54˝/ 14°
Down Light Diameter 12˝
Canopy Diameter 6½˝
Net Hanging Weight: (with Light Kit) 31¼ lbs
INSTALLATION REQUIREMENTS:
Ceiling fan attaches to electrical junction box securely anchored and capable of withstanding a load of at least 50 lbs.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit.
MOTOR SPECS:
188 x 20 motor is designed for optimal performance with this fan.
FAN SPEEDS:
3 fan speeds with reversing switch (on top of the motor). High – 145 rpm; Med – 105 rpm; Low – 70 rpm
CONTROL OPTIONS:
The hand-held remote control (C24) with canopy receiver (RECFP5220) is included. Push button remote control will
consist of 3 separate fan speeds, infinite light levels, and off position. Reversing switch located on fan housing. Optional
wall control (C25) is available (to be used in conjunction with fan receiver).
LIGHTING OPTIONS:
The 3-bulb (40 watt max candelabra bulbs - not included) downlight fixture is included with this fan assembly. Maximum
downlight wattage not to exceed 120 watts.
DOWNROD OPTIONS:
The Andover™fan comes with a 1˝Dia. x 6˝(DR1-6) & 12˝(DR1-12) downrods and decorative downrod sleeve.
Optional downrods are available in 18”, 24”, 36”, 48”, 60”, and 72”. For installations requiring a longer downrod, a downrod
coupler is available. The Andover™fan can be mounted on a sloped ceiling up to 30°. Most sloped ceiling installations
require a downrod longer than the standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up
to 52°. Call tech support for more information.
BLADE SETS:
A set of 5 reversible (cherry/walnut) wood blades are included. Not recommended for Damp Location.
DAMP LOCATION:
Fan not rated for Damp Location usage.
Available Finishes
OB Oil-Rubbed Bronze with Amber Glass
PW Pewter with Opal/Frosted Glass
Distance from Ceiling to
Bottom of Downlight
Fan w/6˝downrod 18˝
Fan w/12˝downrod 24˝
Fan w/18˝downrod 30˝
Fan w/24˝downrod 36˝
Fan w/36˝downrod 48˝
Fan w/48˝downrod 60˝
Fan w/60˝downrod 72˝
Fan w/72˝downrod 84˝
