Fanimation Edgewood TF100 Series User manual

10983 Bennett Parkway
Zionsville, IN 46077
Toll Free [phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
SPECIFICATION SHEET
Product Specifications subject to change
TF100/300/600/700/900 Series Fans
Copyright 2008 Fanimation, Inc. 2008/05
The Edgewood®Series
WET LOCATION – TF900**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 188 x 12
Blade Sweep / Pitch 50˝/ 14°
Dimension (w/4½˝DR) 13.6˝from ceiling to switch cup
11.7˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 185; Med - 125; Low - 70
Plastic Blades (set of 5) Traditional Wood style – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 18 lbs
Damp/Wet Location Usage UL Rated
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
AW – Antique White Antique White
AZ – Aged Bronze Dark Cherry
SN – Satin Nickel Light Cherry
WH – White White
WET LOCATION – TF900**
Wet Location Model
WET LOCATION – TF970**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 212 x 25
Blade Sweep / Pitch 60˝/ 16°
Dimension (w/4½˝DR) 13.6˝from ceiling to switch cup
11.7˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 155; Med - 105; Low - 45
Plastic Blades (set of 5) Brown Painted – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 32 lbs
Damp/Wet Location Usage UL Rated
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
TS – Tortoise Shell Brown, Painted
WET LOCATION – TF970**
*FAN CONTROL OPTIONS (Dry Applications Only):
Optional controls are: C1 or C2 wall controls; C4 remote control with canopy receiver.
Installation & operating instructions provided with each control.

STANDARD – TF100**
Not recommended for Damp Location
Product Specifications subject to change
Not recommended for Damp Location
Product Specifications subject to change
MEDIAN – TF300**
DECORATIVE – TF600**
DELUXE – TF700**
DECORATIVE – TF600**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 188 x 20
Blade Sweep / Pitch 52˝/ 14°
Dimension (w/4½˝DR) 13¾˝from ceiling to switch cup
11¾˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 190; Med - 115; Low - 60
Blades, Reversible (set of 5) Traditional Wood – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 21 lbs
Damp Location Usage Not Recommended
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
SN – Satin Nickel Walnut / Light Walnut
TS – Tortoise Shell Walnut / Light Walnut
WH – White White / White Oak
DELUXE – TF700**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 212 x 25
Blade Sweep / Pitch 60˝/ 16°
Dimension (w/4½˝DR) 14.6˝from ceiling to switch cup
13˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 140; Med - 90; Low - 50
Blades, Reversible (set of 5) Traditional Wood – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 29 lbs
Damp Location Usage Not Recommended
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
SN – Satin Nickel Walnut / Light Walnut
TS – Tortoise Shell Walnut / Light Walnut
WH – White White / White Oak
Decorative / Deluxe ModelsStandard / Median Models
*FAN CONTROL OPTIONS:
Optional controls are: C1 or C2 wall controls; C4 remote control with canopy receiver.
Installation & operating instructions provided with each control.
STANDARD – TF100**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 153 x 15
Blade Sweep / Pitch 52˝/ 12°
Dimension (w/4½˝DR) 13½˝from ceiling to switch cup
11½˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 175; Med - 125; Low - 65
Blades, Reversible (set of 5) Traditional Wood – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 16 lbs
Damp Location Usage Not Recommended
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
AW – Antique White Antique White / White Oak
AZ – Aged Bronze Dark Cherry / Teak
OB – Oil-Rubbed Bronze Dark Cherry / Teak
SN – Satin Nickel Walnut / Light Walnut
WH – White White / White Oak
MEDIAN – TF300**
Electrical Requirements 120 VAC, 60 Hz
Fan Motor; Energy Star Rated 188 x 12
Blade Sweep / Pitch 50˝/ 14°
Dimension (w/4½˝DR) 14˝from ceiling to switch cup
12.2˝from ceiling to blade edge
Fan Controls (*Options) Pull Chain & Reverse Switch
3 - Speed, Reversible - RPM’s High - 185; Med - 105; Low - 55
Blades, Reversible (set of 5) Traditional Wood – Included
Down Light Kit / Glass Optional – Sold Separately
Net Hanging Weight 17 lbs
Damp Location Usage Not Recommended
Available Uni-Packed Finishes
Fan / Housing Assembly Blades - Traditional
AW – Antique White Antique White / White Oak
AZ – Aged Bronze Dark Cherry / Teak
OB – Oil-Rubbed Bronze Dark Cherry / Teak
SN – Satin Nickel Walnut / Light Walnut
WH – White White / White Oak
