Fanimation Enigma FP2120 Series User manual

Product Specifications subject to change
The Enigma®
FP2120 Series
SPECIFICATION SHEET

A
7´ min
Floor
Ceiling
Blade Sweep
60˝
Net Hanging Weight: 29 lbs
6½˝dia
18° Blade Pitch
10˝
Copyright 2008 Fanimation, Inc. 2008/05
The Enigma®Fan Assembly – FP2120¾¾
10983 Bennett Parkway
Zionsville, IN 46077
Toll Free [phone]
FAX [phone]
Outside U.S. call [phone]
Visit Our Website www.fanimation.com
Dimensions shown in inches
*Minimum Pole Lengths for Sloped Ceilings
Degrees / Pitch Minimum Pole
Length
Blade Tip to
Ceiling Dimension
18° / 4 - 12 pitch 12˝(DR1-12_) 6½˝
27°- 30° /
6 - 12 to 7 - 12 18˝(DR1-18_) 4½˝
Distance from Ceiling
to Bottom of Fan A
Fan w/6˝downrod 18½˝
Fan w/12˝downrod 24½˝
Fan w/18˝downrod 30½˝
Fan w/24˝downrod 36½˝
Fan w/36˝downrod 48½˝
Fan w/48˝downrod 60½˝
Fan w/60˝downrod 72½˝
Fan w/72˝downrod 84½˝
INSTALLATION REQUIREMENTS:
Ceiling fan is to be secured to a structural member such as a ceiling joist and must be capable of withstanding a load of
at least 50 pounds. A lag bolt must pass through the junction box and into the wood member above.
ELECTRICAL REQUIREMENTS:
Ceiling fan requires a grounded electrical supply line of 120 volts AC, 60 Hz, 15 amp circuit. 220 VAC, 50 Hz version is
available.
FAN SPEEDS:
3-speed, non-reversing. High - 180 rpm; Med - 120 rpm; Low - 60 rpm
CONTROL OPTIONS:
The hand-held remote control (C4T) and canopy-style receiver (RECAN34) are included. This is a push-button control
with frequency code settings located on both the transmitter and the receiver units. Each push button unit will consist of
3 separate speeds, down light controls, and off button. Optional controls are: C1 or C2 wall controls; C25 wall control (to
be used in conjunction with fan receiver). Installation and operating instructions provided with each control.
LIGHTING OPTION:
Single, built-in downlight socket, bulb not included, use only PAR 30 short-neck Halogen Bulb with a maximum of 75
watts.
DOWNROD OPTIONS:
The Enigma®fan comes with a 1˝Dia. x 6˝(DR1-6) downrod. Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝,
60˝, and 72˝. The Enigma®fan can be mounted on a sloped ceiling up to *30°. Most sloped ceiling installations require
a downrod longer than the standard 6˝downrod. Optional sloped ceiling ball kits (SCB1-52) are available for up to 52°.
Call tech support for more information
DAMP LOCATION:
Fan is rated for Damp Location usage.
Available Finishes
MG Metro Gray
WA Metro Gray with
Walnut Wood Blade
**Custom Finishes are available
by special order only. Contact
tech support for more information
