Fanimation ISLANDER FP320 1 Series User manual

ISLANDER®CEILING FAN
MODEL #FP320**1
Español p. 21
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-567-2055, 8 a.m.-5 p.m., EST, Monday-Friday.
Date Code Purchase Date Net Weight 19.00 lbs (8.62 kgs)
For best and quickest service please provide date code. You can find the date code on the carton
or top of fan housing.
ATTACH YOUR RECEIPT HERE AND REGISTER YOUR FAN AT FANIMATION.COM
READ AND SAVE THESE INSTRUCTIONS

Important Safety Instructions
WARNING: To avoid fire, shock and serious personal injury, follow these instructions.
1. Read your owner’s manual and safety information before installing your new fan. Review the accompanying assembly diagrams.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent power
from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a warning device, such
as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan. Always turn off the power to the ceiling fan before
servicing.
4. Do not insert anything into the fan blades while the fan is operating.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions
1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring, and do not operate fan without blades.
2. All wiring and installation procedures must satisfy National Electrical Codes (ANSI/ NFPA 70) and Local Codes. The ceiling fan
must be grounded as a precaution against possible electrical shock. Electrical installation should be made or approved by a licensed
electrician.
3. The fan base must be securely mounted and capable of reliably supporting at least 35 lbs. See page 5 of owner’s manual for
support requirements. Consult a qualified electrician if in doubt.
4. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent accidental contact with the fan blades.
5. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not have adequate electrical
knowledge or experience, have your fan installed by licensed electrician.
WARNING: This product is designed to use only those parts supplied with this product and/or accessories designated specifically for
use with this product. Using parts and/or accessories not designated for use with this product could result in personal injury or property
damage.
WARNING: To reduce the risk of personal injury, do not bend the blade bracket (flange or blade holder) when installing the brackets,
balancing the blades, or cleaning the fan. Do not insert foreign objects in between rotating fan blades.
WARNING: To Reduce The Risk Of Fire Or Electric Shock. Do Not Use This Fan With Any Solid-State Speed Control Device.
WARNING: To Reduce The Risk Of Electric Shock. Disconnect The Electrical Supply Circuit To The Fan Before Installing Light Kit.
Suitable for use in damp locations.6.
6. The appliance is not intended for use by young children or infirm persons without supervision. Young children should be supervised to
ensure that they do not play with the appliance.
7. For supply connections, if the conductor of a fan is identified as a grounded conductor, then it should be connected to a grounded
conductor power supply. If the conductor of a fan is identified as an ungrounded conductor, then it should be connected to an ungrounded
conductor power supply. If the conductor of a fan is identified for equipment grounding, then it should be connected to an
equipmengrounding conductor.

1. LIMITED LIFETIME MOTOR WARRANTY - If any part of your fan motor fails, due to a defect in materials or workmanship during the
lifetime of the original purchaser, Fanimation will provide the replacement part free of charge, when the defective fan is returned
to our national service center. Proof of purchase is required. Customer shall be responsible for all costs incurred in the removal or
reinstallation and shipping of the product for repairs or replacement.
2. ONE YEAR MOTOR LABOR WARRANTY - If your fan motor fails at any time within one year from the original purchase, due to
defects in materials or workmanship, labor to repair the motor will be provided free of charge at our national service center. Purchaser will
be responsible for labor charges after this one-year period. Customer shall be responsible for all costs incurred in the removal or
reinstallation and shipping of the product for repairs or replacement.
3. If any other part of your fan fails at any time within one year after original purchase, due to a defect in materials or workmanship, we
will repair, or replace, at our option, the defective part free of charge for parts and labor performed at our national service center.
4. Because of varying climate conditions, this warranty does not cover changes in the finish, including rusting, pitting, corroding,
tarnishing, or peeling.
5. This warranty is void and does not apply to damage from improper installation, neglect, accident, misuse, exposure to extremes of
heat or humidity, or as a result of any modification to the original product.
6. All costs of removal and reinstallation of the fan are the sole responsibility of the owner of the fan and not the store that sold the fan or
Fanimation.
7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty.
8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must accompany
authorized returns and must be sent freight prepaid to Fanimation. The fan to be returned must be properly packed to avoid
damage in transit; Fanimation will not be responsible for any damage resulting from improper packaging.
9. It is understood that any repair or replacement is the exclusive remedy available from Fanimation. There is no other expressed or
implied warranty. Fanimation hereby disclaims any and all implied warranties, including, but not limited to those of merchantability and
fitness for a particular purpose to the extent permitted by law. Some states do not allow limitations on implied warranties. Fanimation will
not be liable for incidental, consequential, or special damages arising out of or in conjunction with product use or performance, except as
may otherwise be accorded by law. This warranty gives you special legal rights and you may also have other rights that vary from state to
state.
10. A certain amount of wobble is normal and should not be considered a problem or a defect.
LIMITED LIFETIME WARRANTY
Extends to the original purchaser of a Fanimation fan from an authorized Fanimation dealer/retailer only
*DAMP LOCATION CEILING FAN: If you have purchased a Damp Location Ceiling Fan, you may only use light kits marked suitable for use in damp locations.
Table of Contents
Unpacking Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Energy Efficient Use of Ceiling Fans . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical and Structural Requirements . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Assemble Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Hang Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Wire Your Ceiling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Install Your Canopy Housing . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
5
5
7
9
10
12
13
15
16
16
17
18
19
How to Assemble Your Ceiling Fan Blades . . . . . . . . . . . . . . . . . . . . . . .
How to Operate Your Ceiling Fan - Pull Chain . . . . . . . . . . . . . . . . . . . . .
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How to Clean Your Ceiling Fan Blades . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exploded-View Illustration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tools Needed for Assembly
(Not Included) Materials
WARNING
Before assembling your ceiling fan, refer to section on
proper method of wiring your fan (page 10). If you feel you
do not have enough wiring knowledge or experience, have
your fan installed by a licensed electrician.
This manual is designed to make it as easy as possible for you to assemble,
install, operate and maintain your ceiling fan
• One Phillips head screwdriver
• One ¼˝ blade screwdriver
• One stepladder
• One wire stripper
Wiring outlet box and box connectors must be of type
required by local code. The minimum wire would be a 3-
conductor (2-wire with ground) of the following size:
nstalled ire ength ire i e
p to ft
ft
Unpacking Instructions
1. Check to see that you have received the following parts:
NOTE: If you are uncertain of part description, refer to exploded view illustration.
WARNING
Do not install or use fan if any part is damaged or missing. This product is designed to use only those parts supplied with
this product and/or any accessories designated specifically for use with this product by Fanimation. Substitution of parts
or accessories not designated for use with this product by Fanimation could result in personal injury or property damage.
Contact your retail store for missing or damaged parts.
For your convenience, check-off each step. As each step is completed, place a check mark. This will ensure that all steps have been
completed and will be helpful in finding your place should you be interrupted.
4
Blade Holders
- Side A (5)
Blade Holders
- Side B (5)
Hanger Bracket
Assembly (1)
Motor Coupling
Cover Assembly (1)
Hardware Bags
Motor Assembly (1)
Downrod/Hanger Ball Assembly (1)
– Downrod (1)
– Hanger Ball (1)
– Set Screw (1)
– Hairpin Clip (1)
– Clevis Pin (1)
– Pin (1)
3/16"-24 x 3/8"
Screws
(11)
Ceiling Canopy (1)
Wire Connectors
(4)
5/32˝
Threaded Rods
(2)
5/32˝
Lockwashers
(2)
Knurled Knobs
(2)
Fan Fob
(1)
Pull Chain Coupler
(1)
10-32 x 1/2˝
Screws
(11)
NOTE: Place the parts from the loose parts bags in a small
container to keep them from being lost. If any parts are
missing, contact your local retailer.

Ceiling fan performance and energy savings rely
heavily on the proper installation and use of the
ceiling fan. Here are a few tips to ensure efficient
product performance.
Using the Ceiling Fan Year Round
Summer Season: Use the ceiling fan in the
counterclockwise direction. The airflow produced by
the ceiling fan creates a wind-chill effect, making you
“feel” cooler. Select a fan speed that provides a
comfortable breeze, lower speeds consume less
energy.
Winter Season: Reverse the motor and operate the
ceiling fan at low speed in the clockwise direction.
This produces a gentle updraft, which forces warm air
near the ceiling down into the occupied space.
Remember to adjust your thermostat when using your
ceiling fan-additional energy and dollar savings could
be realized with this simple step!
Choosing the Appropriate Mounting Location
Ceiling fans should be installed, or mounted, in the middle
of the room and at least 7 feet from floor to the blade and
18 inches from wall to the blade. If ceiling height allows,
install the fan 8 - 9 feet from floor to the blade for optimal
airflow. Consult your Fanimation Retailer for optional
mounting accessories.
Turn Off When Not in the Room
Ceiling fans cool people, not rooms. If the room is
unoccupied, turn off the ceiling fan to save energy.
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 HZ, 15 Amp Circuit.
Electrical code requires use of a fan-rated outlet box to
support the extra weight and motion associated with a
ceiling fan. A fan-rated box will be labeled as such and
typically supports up to a 70lb ceiling fan. Fan-Rated
Outlet Boxes vary in ratings and design. Ensure the
ratings of your ceiling fan outlet box meet the
requirements for the ceiling fan being installed. Figure
1, Figure 2 and Figure 3 depicts different structural
configurations that may be used for mounting the outlet
box.
Low profile box (Figure 1)
A 1/2-in.-deep pancake box is meant to be screwed to a
joist or block. It’s used if only one cable is coming into the
box. It is also available in a saddle-mount configuration.
Deep box (Figure 2)
A 2-1/4-in.-deep box can be attached to blocking between
joists and is roomy enough to handle more than one cable.
CEILING JOIST
CEILING OUTLET BOX
Figure 1
Figure 2
CEILING JOIST
2" x 4"
2" x 4"
CEILING OUTLET BOX
Energy Efficient Use of Ceiling Fans
Electrical and Structural Requirements
5

6
If your fan is to replace an existing light fixture, turn
electricity off at the main fuse box at this time and remove
the existing light fixture.
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned off
at the main fuse box before wiring. All wiring must be in
accordance with National and Local codes and the ceiling
fan must be properly grounded as a precaution against
possible electrical shock.
Deep box with brace (Figure 3)
Paired with a deep box, this hanger is meant to span
between two joists and takes the place of wooden blocking.
To avoid fire or shock, follow all wiring instructions
carefully. Any electrical work not described in these
instructions should be done or approved by a licensed
electrician.
Figure 3
CEILING JOIST
CEILING
OUTLET BOX
To reduce the risk of fire, electric shock, or personal injury,
mount to outlet box marked acceptable for fan support of
15.9 kg (35 lbs) or less and use mounting screws provided
with the outlet box. Most outlet boxes commonly used for
the support of luminaires are not acceptable for fan support
and may need to be replaced, consult a qualified electrician
if in doubt.
Do not operate this fan with a variable (Rheostat) wall
controller or dimmer switch. Doing so could result in
damage to the ceiling fan’s remote control unit.
Electrical and Structural Requirements (Continued)
WARNING
WARNING
WARNING
WARNING

7
How to Assemble Your Ceiling Fan
1. Prior to assembly, set aside and save the hardware
bag(s) packed in the packing.
2. Remove the hanger ball by loosening the setscrew
in the hanger ball until the ball falls freely down the
downrod (Figure 1). Remove the pin from the downrod,
then remove the hanger ball. Retain the pin and
hanger ball for reinstallation in Step 6.
3. The fan comes with blue, black, and white 80˝
wires. Separate and untwist the three wires. Route the
wires through the downrod.
Figure 1
Hanger Ball Pin
Set Screw
WARNING
It is critical that the clevis pin in the downrod support
is properly installed and the set screws and nuts are
securely tightened. Failure to do so could result in the
fan falling.
4. Loosen the two setscrews in the downrod support.
Align the clevis pin holes in the downrod with the
holes in the downrod support. Install the clevis pin
and secure with the hairpin clip. (Figure 3) Be sure to
push the straight leg of the hairpin clip through the
hole near the end of the clevis pin until the curved
portion of the hairpin clip snaps around the clevis pin.
The hairpin clip must be properly installed to prevent
the clevis pin from working loose. Pull on the downrod
to make sure the clevis pin is properly installed.
NOTE: The setscrews must be properly installed as
described above, or fan-wobble could result.
5. Route wires through opening in canopy. Position
canopy on fan shown with open side facing up.
(Figure 2)
6. Reinstall the hanger ball (Figure 2) on the downrod
as follows. Route the three 80˝ wires through the
hanger ball. Position the pin through the two holes in
the downrod and align the hanger ball so the pin is
captured in the groove in the top of the hanger ball.
Pull the hanger ball up tight against the pin. Securely
tighten the setscrew in the hanger ball. A loose
setscrew could create fan wobble.
NOTE: You will be using either the 6˝ downrod
supplied with your fan or an optional downrod
purchased seperately.
Figure 2
Set
Screw
Ceiling
Canopy Pin
Downrod

8
How to Assemble Your Ceiling Fan (Continued)
Figure 3
8. Slide the motor coupling cover down until it touches
the top of the motor.
9. The fan comes with blue, black, and white leads.
Before installing fan, measure up approximately 6-9
inches above top of downrod/hanger ball assembly.
Cut off excess wire and strip back insulation ½˝ from
end of wire.
10. You have now completed the assembly of your
new ceiling fan. You can now proceed with the
hanging and the electrical wiring of your fan.
Ceiling
Canopy
Motor Coupling
Cover
Hairpin Clip
Downrod
Support
Downrod/Hanger
Ball Assembly
Clevis Pin
Set Screw
WARNING
To reduce the risk of personal injury, do not bend the
blade holders when installing, balancing the blades or
cleaning the fan. Do not insert foreign objects in
between the rotating blades.
CAUTION
All set screws must be checked, and retightened where
necessary before installation.
7. While pulling up on the hanger ball, securely tighten
the two 3/16-24 x 3/8˝ setscrews in the downrod
support. (Figure 3)

9
How to Hang Your Ceiling Fan
Floor
Ceiling
No
less than
7 ft
Figure 1
Figure 2
Figure 3
Outlet Box
Outlet Box
Hanger
Bracket
Hanger
Bracket
Screw (2)
Supplied with
Outlet Box
Tab
Downrod/Hanger
Ball Assembly
WARNING
To avoid possible electrical shock, be sure electricity is
turned off at the main fuse box before hanging.
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
WARNING
The fan must be hung with at least 7´ of clearance from
floor to blades (Figure 1)
WARNING
The outlet box must be securely anchored and capable
of withstanding a load of at least 50 lbs. Hanger bracket
must seat fi rmly against outlet box. If the outlet box is
recessed, remove wallboard until bracket contacts box.
If bracket and/or outlet box are not securely attached,
the fan could wobble or fall.
CAUTION
Do not connect fan blades until the fan is completely
installed. Hanging fan with blades connected may
result in damage to the fan blades.
1. Securely attach the hanger bracket to the outlet box
using the outlet box screws and washers supplied with
the outlet box. (Figure 2)
NOTE: Outlet box screws pass through slotted holes
of the hanger bracket. (Figure 2)
2. Pull the electric wires in the outlet box down
through the opening in the hanger bracket and bend
wires up and out of the way so that the hanger ball will
easily fit into the hanger bracket.
3. Carefully lift the fan and seat the downrod/hanger
ball assembly onto the hanger bracket that was just
attached to the outlet box (Figure 3). Be sure the
groove in the ball is lined up with tab on the hanger
bracket. (Figure 2)
WARNING
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
To avoid possible shock, do not pinch wires between
the hanger ball assembly and the hanger bracket.

10
1. Connect the green grounding lead from the
downrod and the green grounding lead from the
hanger bracket to the supply grounding conductor
(this may be a bare wire or wire with green colored
insulation). Securely connect wires with wire
connector. Securely connect the white fan motor wire
to the white supply (neutral) wire using wire connector.
Securely connect the black fan motor wire and blue
wire to the black supply wire using wire connector.
(Figure 2A)
2. After connections have been made, taking care not
to pinch the wires and put the white and green leads
to one side and the black leads towards the other side,
the connection should be turned upward and carefully
push leads into the outlet box. The wires should be
spread apart with the grounded conductor and the
equipment-grounding conductor on one side of the
outlet box and the ungrounded conductor on the other
side. (Figure 3A)
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
Option A
NOTE: If you feel that you do not have enough
electrical wiring knowledge or experience, have your
fan installed by a licensed electrician.
How to Wire Your Ceiling Fan
WARNING
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring.
(Figure 1)
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors except for the ground wire. Do not operate
fan until the blades are in place. Noise and motor
damage could result.
Wire Connectors
HARDWARE USED:
X 3
Figure 1
Figure 2A
Main Fuse Box
Green Wire
from Supply
(Ground)
Green Wire
from Hanger
Bracket (Ground)
Green Wire
from Hanger
Ball (Ground)
White Wire
from Supply Listed
Outlet Box
White Wire
from Fan
Household
Supply
Black Wire
from Supply
Blue Wire
from Fan
Black Wire
from Fan
Figure 3A
Green Wire
from Supply
(Ground)
Green Wire
from Hanger
Bracket (Ground)
Green Wire
from Hanger
Ball (Ground)
White Wire
from Supply Listed
Outlet Box
White Wire
from Fan
Household
Supply
Black Wire
from Supply
Blue Wire
from Fan
Black Wire
from Fan

11
How to Wire Your Ceiling Fan (Continued)
Figure 2B
Green Wire
from Supply
(Ground)
Green Wire
from Hanger
Bracket (Ground)
Green Wire
from Hanger
Ball (Ground)
White Wire
from Supply
White Wire
from Fan
Listed
Outlet Box
Household
Supply
Blue Wire
from Fan
Black Wire
from Fan
Black Wire
from Supply
Red Wire
from Supply
1. Connect the green grounding lead from the
downrod and the green grounding lead from the
hanger bracket to the supply grounding conductor
(this may be a bare wire or wire with green colored
insulation). Securely connect wires with wire
connector. Securely connect the white fan motor wire
to the white supply (neutral) wire using wire connector.
Securely connect the black fan motor wire to the black
supply wire using wire connector. Securely connect
the blue fan motor wire to the red supply wire using
wire connector. (Figure 2B)
Option B - with a red wire available
NOTE: If you feel that you do not have enough
electrical wiring knowledge or experience, have your
fan installed by a licensed electrician.
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors except for the ground wire. Do not operate
fan until the blades are in place. Noise and motor
damage could result.
2. After connections have been made, taking care not
to pinch the wires and put the white and green leads
to one side and the black leads towards the other side,
the connection should be turned upward and carefully
push leads into the outlet box. The wires should be
spread apart with the grounded conductor and the
equipment-grounding conductor on one side of the
outlet box and the ungrounded conductor on the other
side. (Figure 3B)
Figure 3B
Green Wire
from Supply
(Ground)
Green Wire
from Hanger
Bracket (Ground)
Green Wire
from Hanger
Ball (Ground)
White Wire
from Supply
White Wire
from Fan
Listed
Outlet Box
Household
Supply
Blue Wire
from Fan
Black Wire
from Fan
Black Wire
from Supply
Red Wire
from Supply
Wire Connectors
HARDWARE USED:
X 4

12
Figure 1
How to Install Your Canopy Housing
Figure 2
NOTE: Supply wires
and fan wires omitted
for clarity.
NOTE: This step is applicable after the neccessary
wiring is completed.
WARNING
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the canopy
housing and not pinched between the housing and the
ceiling.
1. Screw in two threaded rods into the hanger bracket.
(Figure 1)
NOTE: The threaded rods in the hanger bracket
serves as guides for easier installation.
2. Securely attach the canopy housing to the hanger
bracket using the external lockwashers and knurled
knobs supplied with your fan. (Figure 2)
Lockwashers (2)
Knurled Knobs (2)
X 2
X 2
X 2
HARDWARE USED:
5/32˝
Threaded Rods
5/32˝
Lockwashers
Knurled Knobs
Threaded Rods (2)

13
You will find the fan blade set packed in its own carton and the blade holders and hardware bag in the upper foam
packing in the fan box. The hardware bag for the blade holders consists of 10 screws and a Phillips head screwdriver.
1. Lay side “A” of the blade holder on a flat surface
with the inside of the blade holder facing up. This is
the side with the threaded posts and pitched foot.
(Figure 1)
2. Position the palm leaf, or the woven bamboo blade,
or the wicker blade over the blade holder with the
threaded posts showing. Make sure the bottom edge
of the blade is fully seated against the blade holder.
3. Place side “B” of the blade holder on top of the
blade, positioning the holes over the threaded posts.
4. With a philips screwdriver, thread both screws into
the posts but do not fully tighten.
5. Prior to final tightening, position the centerline of the
blade holder with the center of the end of the blade.
NOTE: Optional Wood blades and Blades Holders,
Canvas blades and The Ococee™ kayak oar blades
are available for this assembly.
X 10
3/16”-24 x 3/8”
Screws
HARDWARE USED:
How to Assemble Your Ceiling Fan Blades
Side A
Fan Blade
Side B
Do not connect fan blades until the fan is completely
installed. Installing the fan with blades assembled
may result in damage to the fan blades.
INSTALLATION NOTE
Attach the Blades to the Rubber Flywheel using the
holes marked #5 for 5-blade application. For 4-blade
application, use the holes marked #4.
INSTALLATION NOTE
Flywheel
Blade Holder
Screw
(2 per blade holder)
Figure 2
6. Tighten both screws to secure the blade. (Figure 1)
7. Attach blade holders to the bottom of the rubber
flywheel using the 10-32 x ½˝ Flywheel Screws.
8. Make sure the screws securing the blade holders
to the flywheel are tight and that the blade holders
are properly seated on the flywheel. (Figure 2) X 10
10–32 x 1/2˝
Screws
HARDWARE USED:
Figure 1

14
How to Assemble Your Ceiling Fan Blades (Continued)
Figure 3
9. Install the fan fob and pull chain coupler. (Figure 3)
10. Restore Power and your fan is now wired to be
turned on and off from the fan pull chain speed control.
X 1Fan Fob
HARDWARE USED:
Fan Fob
Pull Chain Coupler
X 1Pull Chain Coupler

15
How to Operate Your Ceiling Fan - Pull Chain
1. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box. (Figure 1)
WARNING
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not operate
fan until the blades are in place. Noise and fan damage
could result.
Main Fuse Box
Speed Control
Pull Chain
Reverse
Switch
Figure 1
Figure 2
2. Check the operation of the fan by gently pulling on
the fan fob. (Figure 2)
Fan Pull Chain Operating Sequence
1st Pull High
2nd Pull Medium
3rd Pull Low
4th Pull Off
3. If airflow is desired in the opposite direction, turn the
fan off and wait for the blades to stop turning. Slide the
reverse switch on the switch cup assembly to the
opposite position and turn fan on again. (Figure 2)
Reverse Switch Information
Season Rotation Direction Switch Position
Summer Counterclockwise Down
Winter Clockwise Up

Periodic cleaning of your new ceiling fan is the only
maintenance necessary.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the finish.
Abrasive cleaning agents are not required and should be
avoided to prevent damage to finish.
Periodic light dusting of the blades is recommended.
A feather duster will work best.
Avoid using water, cleansers, or harsh rags, which
can warp and ruin the blades.
CAUTION
Do not use solvents when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of electrical shock.
How to Clean Your Ceiling Fan Blades
Maintenance
16

Parts List
Model FP320**1
** Insert FINISH CODES (Refer to fan model number located on downrod support)
Before discarding packaging materials, be certain all parts have been removed.
Ref. # Description Part #
1 Hanger Bracket Assembly APG610BL
3 Ceiling Canopy PG165**
Hardware Bag Containing:
HDWFP320**
4 5/32˝-32 Threaded Rods (2)
5 5/32˝External Lockwasher (2)
6 Knurled Knobs (2)
13 10–32 x ½˝Flywheel Screws (11)
14 Wire Connectors (4)
19 Pull Chain Coupler
20 Fan Fob
2Downrod/Hanger Ball Assembly Containing:
ADR1-6**
7 Downrod
8 Clevis Pin
9 Hairpin Clip
10 Motor Assembly
11 Switch Cup Housing Assembly AP3245**
12 Wiring Harness AP3230**
15 Cover Blade Holders (Set of 5) AP3220**
16 Blade Holders (Set of 5) AP3210**
Blade Mounting Hardware Bag Containing: BMH5**
17 3/16˝-24 x 3/8˝ Phillips Screws (11 pc)
18 Motor Coupling Cover Assembly APPYJ1401**
How To Order Parts
When ordering repair parts, always give the
following information:
• Fan Model Number
• Part Number
• Part Description
• Date Code
Contact [email protected] or
call 1.888.567.2055 for repair parts.
17
AMA320**1

NOTE: The illustration shown is not to scale or its actual configuration may vary.
Product/parts are subject to change without notice.
Islander
®
Model FP320**1
Exploded-View Illustration
16
15
17
9
8
10
11
12
13
7
6
4
5
18
3
14
2
1
Ground Wire
(Green)
Ground Wire
(Green)
19
20
18

WARNING
For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan.
Troubleshooting
Trouble Probable Cause Suggested Remedy
1. FAN WILL NOT START.
1. Fuse or circuit breaker blown.
2. Loose power line connections to the fan, or loose
switch wire connections in the switch housing.
3. Reversing switch in neutral position.
1. Check main and branch circuit fuses or circuit
breakers.
2. Check line wire connections to fan and switch wire
connections in the switch housings.
CAUTION: Make sure main power is turned off !
3. Make sure reversing switch position is all the way to
one side.
2. FAN SOUNDS NOISY.
1. Blades not attached to fan.
2. Loose screws in motor housing.
3. Screws securing fan blade holders to motor flywheel
are loose.
4. Wire connectors inside housing rattling.
5. Motor noise caused by solid state variable speed
control.
6. Screws holding blades to blade holders are loose.
7. Lower housing support set screw loose.
1. Attach blades to fan before operating.
2. Check to make sure all screws in motor housing are
snug (not over-tight).
3. Check to make sure the screws which attach the fan
blade holders to the motor flywheel are tight.
4. Check to make sure wire connectors in switch
housing are not rattling against each other or against
the interior wall of the switch housing.
CAUTION: Make sure main power is turned off !
5. Some fan motors are sensitive to signals from
solid-state variable speed controls. Solid-state controls
are not recommended, choose an alternative control
method.
6. Tighten screws securely.
7. Tighten set screw securely.
3. FAN WOBBLES
EXCESSIVELY.
1. Setscrew in downrod support is loose.
2. Setscrew in downrod/hanger ball assembly is loose.
3. Screws securing fan blade holders to motor hub are
loose.
4. Blade holders not seated properly.
5. Hanger bracket and/or ceiling outlet box is not
securely fastened.
6. Fan blades out of balance.
1. Tighten both setscrews securely in downrod support.
2. Tighten the setscrew in the downrod/hanger ball
assembly.
3. Check to be sure screws which attach the fan blade
holders to the flywheel are tight.
4. Check to be sure the fan blade holders seat firmly
and uniformly to the surface of the motor housing. If
holders are seated incorrectly, loosen the screws and
retighten.
5. Tighten the hanger bracket screws to the outlet box,
and secure outlet box.
6. Interchanging position of fan blades can redistribute
the weight and result in a smoother operation. For
example, exchange blades in positions 1 and 3 or 1 and
4. If this does not improve wobble, exchange 2 and 3 or
2 and 4.
4. NOT ENOUGH AIR
MOVEMENT.
1. If possible, consider using a longer downrod (not
included, you can buy the longer downrod from
fanimation.com).
19

2021/05 V.01
Copyright 2021 Fanimation
10983 Bennett Parkway
Zionsville, IN 46077
Phone: [phone]
Outside U.S.: 317-733-4113
FAX: [phone]
FANIMATION.COM
