Fantask EP23483BK User manual

STAND FAN
OPERATING INSTRUCTIONS
MADE IN CHINA

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic safety precautions should always be observed,
including the following:
READ ALL INSTRUCTIONS BEFORE USING
WARNING: To reduce the risk of fire, electrical shock, or injury to person:
1. The product is for household use only.
2. Connect the appliance to single-phase AC supply of the voltage specified on the rating
plate.
3. Never leave the fan unattended while it is in use. Always turn the product to the OFF
position and unplug it from the electrical outlet when not in use.
4. Extreme caution is necessary when any fan is used by or near children, invalids or
elderly person and whenever the fan is left operating and unattended.
5. Do not run cord under carpeting and do not cover cord with throw rugs, runners or
the like. Arrange cord away from traffic area and where it will not be tripped over.
6. Do not operate the fan with a damaged cord or plug, or after the fan malfunctions,
has been dropped, or damaged in any manner.
7. If the supply cord is damaged, it must be replaced by the manufacturer or its service
agent or a similarly qualified person to avoid a hazard.
8. Use the fan in a well-ventilated area. While using, distance of no less than 20cm
should be kept away from wall or corner to ensure the air intakes or exhaust openings
should not be blocked unexpectedly. The fan must not be located immediately below or
besides a curtain or the likes.
9. Do not insert or allow fingers or any other objects into grill to avoid a mechanical
danger when in use. Do not block air intakes or exhaust openings in any manner.
10. Use the fan on flat, dry floor only.
11. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
12. Children should be supervised to ensure that they do not play with the appliance.
13 .This product employs overload protection (fuse). A blown fuse indicates an overload
or short-circuit situation. If the fuse blows, unplug the product from the outlet. Replace
the fuse as per the user servicing instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to an authorized service facility
for examination and/or repair.
14. This appliance has a polarized plug (one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to defeat this safety feature.
15. When replacement of Plug, the safety Device（Fuse）is to be reinstalled or remounted

as previously installed.
FOR HOUSEHOLD USE ONLY
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
Model No.
EP23483BK
Rated Voltage & Frequency
120V AC / 60Hz
Rated Power
60W
STRUCTURE AND PARTS

ASSEMBLE INSTRUCTIONS
一．The base installation:
1. For photo one, first, we should take the locking plate away from column components.
And make the column components insert into base components.
2. Use the locking plate to tighten between column components and base components.
二．Integral installation：
1.First, unscrew the clamping screw from column components and pull the lifting pipe in
column components to the required height. such as photo two,
2.Unscrew the clamping screw on bottom of fan fuselage and insert the fuselage into
lifting pipe of column components, finally, tighten the clamping screw. Such as photo
three.

The Installation of Back Grill:
Removed the motor shaft of the fan head cover, unscrew the triangle nut. and then three
round hole on back grill push in three pillars of front shell on motor, next, tighten the
triangle nut by clockwise. Such as photo four.
The Installation of Fan blade:
Push the groove on back of big fan blade into spacer pin on motor shaft, and tighten
small fan blade by anticlockwise. Such as photo five.
The Installation of Front Grill:
Unload the screw over card buckler place on the the front grill and push the front frill into
back grill after open the card buckler.
Adjust the card buckler and tighten them by previous unload screw. Such as photo six.
INSTRUCTIONS FOR USE
Before using the fan make sure that it is on a flat and stable surface.
Damage may occur if it is placed on an incline or decline.
Set all the switches to OFF position, then insert the plug directly into a standard AC
socket-outlet. Be sure plug fits tightly into outlet.
a. OSC
If you want to enlarge blast area in your room, press the lift pole down to let it shake
head (just left and right);
To stop oscillating, just pull the lift pole out.
b. Speed setting:
There are 3 speed choices. You can select speed by pressing the button.
Press the button on to start the fan and select the fan speed level, as per the following
sequence: 1 2 3
Press the button “OFF” to turn off the fan.
Push forward the fan head up and down can adjust the air supply angle.

User Servicing Instructions：
——how to physically replace the fuse：
WARNING：If the FUSE is broken, do not try to replace it yourself, it must be
replaced by the manufacturer or its service agent to avoid a hazard, or find
your dealer direct to replace a new product.
a) Grasp plug and remove from the receptacle or other outlet device. Do not unplug by
pulling on cord.
b) Open fuse cover, slide open fuse access cover on top of attachment plug towards
blades, or push on tabs located next to the blades.
c) Remove fuse carefully, such as whether to push the fuse from the other side or turn
fuse holder over to remove fuse.
d) Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
e) Close fuse cover, Slide closed the fuse access cover on top of attachment plug or push
cover closed so that all tabs latch.
f) Risk of fire. Do not replace attachment plug. Contains a safety device (fuse) that
should not be removed. Discard product if the attachment plug is damaged.
MAINTENANCE
1. Always remove the plug from the socket-outlet and allow the fan blower to stop acting
before clean it.
2. Clean the external surfaces of the unit with a soft damp (not dripping wet) cloth.
WARNING:
Do not immerse the unit in water.
Do not use any cleaning chemicals such as detergents and abrasives.
Do not allow the interior (special for the PCB) to get wet as this could create a hazard.
3. After extended periods of use, be sure to replace the water in the tank with fresh
clean water at least weekly. Also remember to clean the filter by unscrewing the filter
and removing the filter cradle. It should be cleaned in a mild soapy solution and then left
to dry before replacing the filter.
4. When the unit is not in use, make sure that it is unplugged from the wall socket, water
is drained thoroughly and it is placed back into its original box for storage until later use.
5. In case of malfunction or doubt, do not try to repair the fan yourself, it may result in a
fire hazard or electric shock. In such cases, contact the authorized service agent or
technician.
