FARM-MAXX FTL Series User manual

FARM-MAXX
FTL –SERIES
FTL-36G, FTL-48G, FTL-60G
OPERATOR'S
MANUAL
UNI-MAXX GLOBAL, LLC
PO BOX 8
WILSON, NC 27894

Congratulation for purchasing your new FARM-MAXX rotary tiller!
This tiller has been designed and manufactured following all safety and quality requirements needed
for a safe and satisfactory use over time.
A careful reading of this manual will permit you to familiarize with your new equipment, and will
provide you all the tools needed to use it safely.
A proper maintenance and knowledge of the safety rules of use will allow to obtain the
best performance and a long service life of the machine.
The Safety Alert Symbol used throughout this manual and on safety
decals of the machine indicates the presence of potential hazard to the
operator. When you see this symbol, be alert and carefully read the
message that follows it.
The Safety Alert Symbol is used in conjunction with following Signal Words, according to the
degree of possible injuries that may result operating the implement:
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury,
and includes hazards that are exposed when guards are removed. It may also be used to alert
against unsafe practices.
CAUTION
Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate
injury. It may also be used to alert against unsafe practices.
IMPORTANT
Indicates instructions or procedures that, if not observed, can cause damage to equipment or
environment.
NOTE
Indicates helpful information.
READ, UNDERSTAND, and FOLLOW the safety messages following the Safety Alert Symbol and
Signal Words. Failure to comply with safety messages could result in serious bodily injury or death.

TABLE OF CONTENTS
1. ABOUT THIS MANUAL...................................................................
1
2. INTRODUCTION...............................................................................
1
2.1. TILLER IDENTIFICATION................................................................................................................
1
2.2. INTENDED
USE....................................................................................................................................
1
2.3. MAIN PARTS
DESCRIPTION..........................................................................................................
2
2.4. TILLER
SPECIFICATION...................................................................................................................
3
3. SAFETY...............................................................................................
4
3.1. GENERAL SAFETY INSTRUCTIONS.............................................................................................
4
3.2. EQUIPMENT SAFETY INSTRUCTIONS.......................................................................................
5
3.3. OPERATING SAFETY INSTRUCTIONS........................................................................................
6
3.4. TRANSPORTING SAFETY INSTRUCTIONS...............................................................................
7
3.5. MAINTENANCE SAFETY INSTRUCTIONS.................................................................................
8
3.6. STORAGE SAFETY
INSTRUCTIONS..............................................................................................
8
3.7. SAFETY LABELS..................................................................................................................................
9
SAFETY LABELS POSITION AND DESCRIPTION...........................................................
9
4. SET-UP................................................................................................
1
0
4.1. LOWER HITCHES POSITIONING..................................................................................................
11
4.2. CONNECTING TO THE
TRACTOR.................................................................................................
12
4.3. DRIVELINE INSTALLATION...........................................................................................................
12
DRIVELINE LENGTH CHECK.................................................................................................
12
4.4. TRACTOR-TILLER STABILITY.......................................................................................................
14
5. OPERATING.......................................................................................
1
4
5.1. START
UP................................................................................................................................................
14
5.2. OPERATING INSTRUCTIONS..........................................................................................................
15
5.3. ADJUSTMENTS.....................................................................................................................................
16
LOWER CLEVISES
ADJUSTMENT.........................................................................................
16
FRICTION CLUTCH
ADJUSTMENT.......................................................................................
17

SKIDS ADJUSTMENT.................................................................................................................
18
REAR BOARD ADJUSTMENT..................................................................................................
19
5.4. STOPPING AND DISCONNECTION...............................................................................................
19
5.5. TRASPORTING.....................................................................................................................................
.
20
6. MAINTENANCE.................................................................................
2
1
6.1. BLADES REPLACEMENT..................................................................................................................
21
6.2. GEARBOX LUBRICATION.................................................................................................................
22
6.3. SIDE CASE LUBRICATION................................................................................................................
23
6.4. BEARING HOUSING LUBRICATION.............................................................................................
24
6.5. DRIVESHAFT MAINTENANCE.......................................................................................................
24
7. STORAGE...........................................................................................
2
6
8. SCRAPPING.......................................................................................
2
6
9. TROUBLESHOOTING......................................................................
2
7
10. TORQUE VALUES TABLE..............................................................
2
9

FTL Series Rotary Tillers
1
1. ABOUT THIS MANUAL
The operator must read the manual for a correct understanding of the hazards that may present
when operating the tiller, as well as for obtain optimum performance from the machine.
The manual is part of the machine, it must be kept in good condition and remain with the machine
even in case of resale, until its demolition. In case of loss or damage, request a new copy to the
Manufacturer or your Dealer.
The information, descriptions and illustrations in this manual describes the state of the product at
the time of its publication, and may not reflect the product in the future.
The Manufacturer reserve the right to make design improvements or changes in specifications
without incurring in any obligation to install them on units previously sold.
Text, illustrations and drawings of this manual cannot be disclosed or transmitted, in whole or in
part, to third parties without the written permission of the Manufacturer. All rights are reserved.
2. INTRODUCTION
2.1. TILLER IDENTIFICATION
Each tiller has a plate for unique identification. Any request for assistance or information regarding
the machine must be directed to the Manufacturer or Dealer always referring to the model and serial
number as shown on the nameplate affixed to the machine:
2.2. INTENDED USE
The FTL-series tillers are designed to be used uniquely for horticultural, agricultural, or commercial
applications, to till soil for seedbed and planting preparation.
They are designed to be mounted on tractors equipped with hydraulic lift and universal three point
hitch that can support the implement weight, and driven by the power of the tractor through the
PTO driveshaft.
The tractors used to operate the U-series tillers must have the following requirements:

FTL Series Rotary Tillers
2
Hitch Category: 3-point Cat. I standard
PTO: 540 RPM, 6-spline, 1 3/8 Z6
Horsepower: tiller FTL-36G 15-25 HP
tiller FTL-48G 20-30 HP
tiller FTL-60G 25-40 HP
DANGER
Any use of the machine other than the intended use is non-intended use, and is to be considered as
unauthorized and dangerous. The manufacturer assumes no liability for damage resulting from non-
intended use.
2.3. MAIN PARTS DESCRIPTION
1. Tiller deck
2. Clevis (lower hitch)
3. Lower hitch pin
4. Upper hitch pin
5. Top mast
6. Implement input connection (tiller
PTO)
7. Gearbox
8. Side transmission case
9. Rear board
10. Rotor shaft
11. Tine
12. Parking stand
13. Skid
14. Cardan driveshaft
15. PTO shield
NOTE
Unless otherwise indicated, images shown in this manual refer to the tiller FTL-60G.

FTL Series Rotary Tillers
3
2.4. TILLER SPECIFICATIONS
TILLER MODEL
FTL-36G
FTL-48G
FTL-60G
Overall dimensions
mm
1035 x 805 x 600
1340 x 805 x 600
1645 x 805 x 600
Tilling width
in
33.5''
45.6''
58.2''
cm
85.09
115.82
147.83
Recommended
Tractor HP range
HP
15-25
20-35
25-40
3-point Hitch type
-
Cat. I,
compat. Quick
Hitch I cat. ASAE
Cat. I,
compat. Quick
Hitch I cat. ASAE
Cat. I,
compat. Quick
Hitch I cat. ASAE
Frame off-set
in
-
4''
-
Number of Flanges on
Rotor
No.
4
6
7
Number of tines per
Flange
No.
24
36
42
PTO Input speed
rpm
540
540
540
Rotor Shaft Speed
rpm
@540
245
242
242
Standard Tine
Construction
-
curved
curved
curved
Transmission type
-
gear
gear
gear
Max Working depth
cm
16.51
16.51
16.51
Rotor tube diameter
mm
70
70
70
Rotor Swing Diameter
mm
375
375
375
Driveline safety device
-
slip clutch
slip clutch
slip clutch
Weight (driveline
excluded)
lbs
337
397
441
Kg.
153
181
200

FTL Series Rotary Tillers
4
3. SAFETY
Proper use of equipment, a strict observance of the safety messages listed below and application of
all reasonable practices to avoid any risks, prevents accidents or injury, allows the machine working
better and longer, and minimize the failures. The manufacturer assumes no liability for any damage
resulting from not applying the behavioral rules indicated into the manual.
3.1. GENERAL SAFETY INSTRUCTION
DANGER
The machine must be used only by authorized and well trained operators. The operator must have
read and understood the instructions of this manual, it must make adequate preparation for the
proper use of the machine and must hold a driving license. In case of doubt about the use of the
machine and/or the interpretation of this manual, the operator must contact the Manufacturer or
the Dealer.
WARNING
The manual must always remain with the machine. In case of loss or damage, request a new copy
to the Manufacturer or your Dealer.
WARNING
Follow strictly the rules prescribed by the safety pictograms applied to the machine.
WARNING
Be sure that all safety pictograms are legible. If pictograms are worn, they must be replaced with
others obtained from the Manufacturer, and placed in the position indicated by this manual.
DANGER
Before using the machine, make sure that all safety devices are installed and in good working
conditions. In case of damages of shields, replace them immediately.
DANGER
Is absolutely forbidden to remove or alter safety devices.
DANGER
Before starting, and during operation of the tiller, make sure there are no people or animals in the
operation area: the machine can project material from the back, with risks of serious injury or death.
DANGER
Pay maximum attention to avoid any accidental contact with rotating parts of the machine.
DANGER
During operation, adjustment, maintenance, repairing or transportation of the machine, the operator
must always use appropriate Personal Protective Equipment (PPE).
DANGER
Do not operate the implement while wearing loose fitting clothing that can give rise to entanglement
in parts of the machine.
DANGER

FTL Series Rotary Tillers
5
Do not operate the implement when tired, not in good condition or under the influence of alcohol or
drugs.
CAUTION
If the use of the machine is required at night or in conditions of reduced visibility, use the lighting
system of the tractor and possibly an auxiliary lighting system.
3.2. EQUIPMENT SAFETY INSTRUCTIONS
WARNING
Use the tiller for its intended purpose only. Improper use can damage the tiller and cause serious
injury to persons, animals, or death.
DANGER
The machine should be used by a single operator driving the tractor.
WARNING
Any unauthorized modification of the machine may cause problems in safety and relieves the
Manufacturer from any liability for damages or injuries that may result to operators, third parties
and objects.
WARNING
Before using the machine, familiarize yourself with its controls and its working capacity.
WARNING
Do not leave the tiller unattended with tractor engine running.
WARNING
Do not operate tiller on too muddy, sandy or rocky soils.
WARNING
Keep the machine clean from debris and foreign objects which may damage functioning or cause
injury.
WARNING
Do not use the machine if the category of the connecting pins of the tiller does not match that of
the tractor hitch system.
WARNING
Do not use the machine with missing bolts, screws, pins or safety pins.
WARNING
Never use the machine to transport or lift people, animals or objects.
WARNING
Make certain, by adding front ballast, that at least 20% of the total weight (tractor, implement and
ballast) is on the front axle of the tractor, to ensure stability.
WARNING

FTL Series Rotary Tillers
6
Before engaging the tractor PTO, make sure the tractor PTO speed is set as required for the tiller
(540 rpm). Do not over speed PTO or machine breakage may result.
DANGER
Do not operate the tiller if the driveshaft is damaged. The driveshaft could be subject to breakage
during operation, causing serious injury or death. Remove the driveshaft and replace it with an
undamaged.
3.3. OPERATING SAFETY INSTRUCTIONS
WARNING
Before using the machine, be sure to have cleared the operating area from obstacles (stones,
branches, debris, etc...). Mark all the obstacles that cannot be eliminated (e.g. by means flags).
DANGER
Never engage the tractor PTO in the presence of people close to the driveshaft. The body, hair or
clothing of a person can get caught in rotating parts, causing serious injury or death.
DANGER
Before engaging the PTO and during all operations, make sure that no person or animal is in
immediate area of action of the machine. Never use the tiller if people are in his working area.
DANGER
It's absolutely forbidden to stand near the tiller with moving parts.
WARNING
The operator must operate tiller lifting/lowering only from the driving seat of the tractor. Do not
perform lifting maneuvers on side or behind the tractor.
WARNING
Before making changes in direction, turns or going in reverse, slightly lift the tiller from the ground
after disengaging the power take-off, to avoid damage to the machine.
DANGER
In presence of steep slopes (greater than 15 degrees) the tilling action may cause instability of the
tractor, with risk of tipping and consequent serious injury or death hazard. Consult the manual for
the tractor to determine the maximum slope that the tractor is able to deal with.
DANGER
Always disengage the PTO before raising the tiller, and never engage the PTO with the tiller in the
raised position. The machine might throw objects at high speed, causing serious injury or death.
WARNING
Never leave the driver's seat when the tractor is turned on. Before leaving the tractor, lower the
tiller to the ground, disengage the PTO, insert the parking brake, stop engine and remove the key
from the control panel.
DANGER

FTL Series Rotary Tillers
7
The PTO shields of tractor and implement side, the driveshaft shielding and the driveshaft retaining
chains must be properly installed and in good condition, to avoid risk of entanglement with serious
injury or death.
DANGER
Before engaging the PTO of the tractor, always make sure that the drive shaft is mounted in the
correct direction, and that its clamping elements are properly connected both to tractor side and to
tiller side.
WARNING
Stop operating immediately if blades strike a foreign object. Repair all damage and make certain
rotor and blades are in good condition before resuming operation.
WARNING
Always disengage the tractor PTO when the driveshaft exceed an angle of 10 degrees up or down
while operating. An excessive angle with driveshaft rotating can break the driveshaft and cause
flying projectiles.
CAUTION
Avoid clutch's overheating caused by too long or frequent slipping of the clutch, since it can damage
the clutch components. Before checking slip clutch, make sure it has cooled. Clutch could be
extremely hot and cause severe burn.
CAUTION
Prolonged use of the tiller can cause overheating of the gearbox. Do not touch the gearbox during
use and immediately after, it could be extremely hot and cause severe burn.
WARNING
All adjustment operations on the tiller must be performed by qualified and trained operators, with
the tractor engine off, the PTO disengaged, the tiller lowered to the ground or on security stands,
the ignition key off and the parking brake set.
3.4. TRANSPORTING SAFETY INSTRUCTIONS
WARNING
Before transporting, determine the stopping characteristics of the tractor and implement.
WARNING
Transport only at speeds where you can maintain control of the equipment.
WARNING
When driving on roads, the implement must be in transport position adequately raised from the road
surface, with tractor lifting hydraulics locked so that the tiller cannot be lowered accidentally.
DANGER
The implement may be wider than the tractor. Pay attention during transporting to persons, animals
or obstacles exposed.

FTL Series Rotary Tillers
8
WARNING
When turning, use extreme care and reduce tractor speed.
WARNING
Do not operate the tractor with weak or faulty brakes or worn tires.
CAUTION
Always use tractor lighting system and auxiliary lighting system for an adequate warning to operators
of other vehicles, especially when transporting at night or in conditions of reduced visibility.
DANGER
In case of tiller lifting, make sure that the lifting device chosen is suitable to perform the operation
safely, and use only the lifting points prescribed on tiller.
3.5. MAINTENANCE SAFETY INSTRUCTIONS
WARNING
All maintenance and repairing operations must be performed by qualified and trained operators,
with the tractor engine off, the PTO disengaged, the tiller lowered to the ground or on security
stands, the ignition key off and the parking brake set.
WARNING
Perform repairs and replacements necessary to the machine using only original spare parts provided
by the manufacturer or your dealer.
DANGER
Perform maintenance operations always using appropriate Personal Protective Equipment (protective
eye glasses, hard hat, hearing protection, safety shoes, overall and work gloves, filter mask).
CAUTION
Before any maintenance operation, make sure that the parts which may become hot during use
(friction clutch, gear box...) have cooled.
WARN4435G
Do not perform repairs that you do not know. Always follow the manual instructions and in case of
doubt contact the Manufacturer or your dealer.
DANGER
Do not swallow fuels or lubricants. In case of accidental contact with eyes, rinse well with water and
consult a doctor.
3.6. STORAGE SAFETY INSTRUCTIONS
WARNING
Never leave the tractor unattended with the tiller in lifted position. Accidental operation of lifting
lever or a hydraulic failure may cause sudden drop of unit with injury or death by crushing.
DANGER

FTL Series Rotary Tillers
9
Following operation, or before unhooking the tiller, stop the tractor, set the brakes, disengage the
PTO, lower the attached tiller to the ground, shut off the engine, remove the ignition key and wait
for all moving parts to stop.
WARNING
Make sure all parked machines are on a hard, level surface and engage all safety devices.
CAUTION
Place support blocks under tiller as needed to prevent unit from tipping over onto a child and/or an
adult. A tiller that tips over can result in injury or death.
CAUTION
Store the unit in an area away from human activity.
3.7. SAFETY LABELS
The safety labels applied on the machine give fundamental information for using the machine safely.
Make sure safety labels are in good conditions. If pictograms are worn, they must be replaced with
others obtained from the manufacturer and placed in the position indicated by this manual.
Make sure the safety labels are legible. If necessary, wipe them by a cloth, with soap and water.
SAFETY LABELS POSITION AND DESCRIPTION

FTL Series Rotary Tillers
10
1
Rotating Tines Hazard.
2
Rotating Driveline Hazard.
3
General Safety Instructions.
4
Operate only with 540 rpm PTO.
4. SET UP
The tiller is delivered fully assembled and equipped with a driveshaft with torque limiter (clutch
discs) and related operating manual.
When the machine is delivered, check that there is no damage to the tiller or driveshaft. In case of
damage or missing parts immediately notify the manufacturer or your dealer.
4.1. LOWER HITCHES POSITIONING
The U-series tillers are designed to be mounted on tractors equipped with:

FTL Series Rotary Tillers
11
3-point Hitch Category I (ISO 730 standard);
Quick Hitch Category I (ASABE Standard).
The position of the lower hitches must be adjusted accordingly.
If the tractor is equipped with a Quick Hitch Category I (ASABE Standard), verify that the lower
clevises show the pins oriented up (see figure), so that the distance between upper and the lower
pins is 15'' (381 mm), as required from the standard.
If this not occurs, proceed as follows for each of the two clevises::
remove the U-bolt and the clevis from the square tube;
invert the clevis orientation and reposition it on the square tube at distance of 13 7/16'' from the
center of tiller PTO. At the end of the operation the lower clevises should be positioned
symmetrically respect to tiller PTO, at distance of 26 7/8'' (683 mm);
re-tighten the U-bolt, referring to the tightening table of this manual.
If the tractor is equipped with a 3-point Hitch Category I (ISO 730 standard), verify that the lower
clevises show the pins oriented down (opposite than figure above), so that the distance between
upper and the lower pins is 18'' (460 mm approx), as required from the standard.
If this not occurs, proceed as follows for each of the two clevises:
remove the U-bolt and the clevis from the square tube;
invert the clevis orientation and reposition it on the square tube at distance of 13 7/16'' from the
center of tiller PTO. At the end of the operation the lower clevises should be positioned
symmetrically respect to tiller PTO, at distance of 26 7/8'' (683 mm);
re-tighten the U-bolt, referring to the tightening table of this manual;

FTL Series Rotary Tillers
12
remove from upper and lower pins the bushings provided for coupling with Quick Hitch, through
the extraction of elastic pins. Replace the elastic pins when finished. Store the bushings for
possible future use.
4.2. CONNECTING TO THE TRACTOR
To connect the tiller to the tractor the operator must do the following:
drive the tractor in reverse, up to align the rear lifting arms to lower hitches of the tiller in parking;
set the tractor's parking brake, stop engine, remove the ignition key and get off the tractor;
connect the lifting arms of the tractor to the lower hitches of the tiller, through the use of the pins
and the relative safety split pins;
raise the tiller until PTOs of tractor and machine are at the same height, then adjust the 3-point
top link so that the front of the machine is leveled to the back (the axis of the tiller PTO must be
parallel to the ground), in order to limit stress transmitted to the tiller through the cardan shaft;
make sure that left side of the tiller is leveled with the right, by adjusting the tractor lifting arms,
then lock the arms to prevent swinging that could compromise the stability of tractor and machine;
finally adjust the parking stand, placing it at the highest point by means of the related elastic pin.
4.3. DRIVELINE INSTALLATION
Before installing the driveshaft, the operator must read the manuals of driveshaft and tractor,
checking in particular that rpm and direction of rotation of the tractor PTO match those of the tiller.
If the direction of rotation of the PTO tractor does not match that of the tiller, contact the
manufacturer or your dealer.
To connect the driveshaft to the tractor and implement, the operator must:
park tractor and tiller on a flat surface, with parking brake set, engine off, and ignition key
removed;
check that safety devices of driveshaft, tiller and tractor are in good condition, otherwise provide
for their replacement;
remove the PTO shield of the tiller through the fixing screws;
position the driveshaft with clutch turned towards the implement side;
insert the clutch hub on the tiller PTO, then ensure its tightening onto shaft through its
fastener;
replace the PTO shield of the tiller through the fixing screws;
insert the driveshaft yoke on the tractor PTO, then ensure its tightening onto shaft through its
fastener;
hook to the tractor and tiller the two retaining chains of the the driveline shielding, to prevent
shielding rotation during functioning of the machine.
DRIVELINE LENGTH CHECK
Before operating the tiller, ensure that the size of driveshaft is adequate. The driveshaft supplied
with the machine has a standard length, therefore it may need an adaptation of the length,
depending of the tractor which the tiller is combined.
The length of the driveshaft must be such to:

FTL Series Rotary Tillers
13
avoid bottom out of the transmission tubes, when the driveshaft is in compressed position (when
tiller is raised up off the ground);
ensure an overlapping of the transmission tubes enough to transmit the torque required, when
the driveshaft is in max extension (when tiller is in its lowest position in the ground).
When the driveshaft is at its minimum length (max compressed position), there must be at least a
2 cm of distance between the ends of each transmission tube and the yokes side.
When the driveshaft is at its maximum operational extension, there must be an overlap between the
tubes profiles of 15 cm at least.
A driveshaft too long may cause structural damages to the tractor and machine. If the driveshaft is
too long, it may be adapted by removing it and shortening the tubes according to the instructions
provided by the manufacturer in its use and maintenance manual.
A driveshaft too short can cause disengage of the tubes during operation, with severe hazard for
the operator and structural damage to the tractor and machine. If the driveshaft is too short, it must
be replaced with a longer one. In this case contact the manufacturer or your dealer.
IMPORTANT
before operating the tiller the first time, make sure that the driveshaft is lubricated in accordance
with how indicated in the instruction booklet;
before operating the tiller the first time, and after long periods of inactivity, make sure that the
driveline clutch has run a short "run in" in accordance with what indicated in the instruction manual
of the manufacturer, removing the possible oxidation of the components that may compromise
the correct slipping during the usage (see also section "Maintenance");

FTL Series Rotary Tillers
14
always engage the tractor PTO at low rpm to minimize the effect of the peak torque on the
driveline and the machine.
4.4. TRACTOR-TILLER STABILITY
The weight of the machine modifies the stability of the system tractor-tiller, resulting in loss of
steering control and braking.
The front axle of the tractor should always loaded with at least 20% of the overall weight of the
system tractor-tiller.
CAUTION
Check the lifting capacity and stability of the tractor and, if necessary, applying the front ballast. To
determine the appropriate characteristics of the ballast, refer to the manual of the tractor.
5. OPERATING
Before operate the tiller, make sure you have read and understood the operating manuals of the
tiller, tractor and PTO shaft, and followed what is described in the section "Set Up".
DANGER
During operation, adjustment, maintenance, repairing or transportation of the machine, the operator
must always use appropriate Personal Protective Equipment (PPE).
Before starting work, ensure that all machine guards are in good conditions and fully functional.
During operation, the machine can throw material from the back: prevent people and animals to
approach the operational area.
5.1. START UP
Before the start up and before each use, perform the following pre-operation inspections and service
of the implement:
check that the tiller has not damaged functional parts and has all mechanical parts in good
condition. Repair and / or replace the damaged parts;
check that the tiller has no missing parts (pins, safety pins, plugs oil ...). Restore the missing
parts;
check that all guards and safety devices have no damages and are properly positioned. Repair
and / or replace the damaged shieldings, restore the correct position;
verify that the PTO driveshaft is properly installed (see section: Connection of the drive shaft);
check that the driveshaft clutch is in good condition, and that its components are not subject to
"sticking" (see section: Maintenance / Driveline);
check the presence of lubricant in all greasing points of the tiller (driveshaft, supports...) (see
sect. Maintenance / Driveline and Maintenance / Support rotor);
check for oil leaks from the gearbox or the transmission side cover. Identify the reason of loss,
then repair and / or replace the damaged components;
check the correct oil level in the gearbox and in transmission side box (see section maintenance);

FTL Series Rotary Tillers
15
check that blades are not excessively worn and the relating hardware is correctly tightened (see
sect. Maintenance);
check that all the tiller hardware is properly tightened. Refer to the tightening table in the manual
for proper torque values;
check that all safety dacals are correctly positioned, in good condition and legible. Replace any
damaged decals;
check that there is no constraints that may prevent the movement of equipment. Remove any
constraint.
Before the start up and before each use, make the following checks on the operating area identified
for tillage:
check that area is clear of foreign objects (rocks, branches or debris). Remove any obstacle and
visibly highlight obstacles that cannot be eliminated (e.g. by means flags);
make sure in the working area exposed there are no people or animals;
make sure the soil to be worked is not too grassy, muddy, sandy or rocky.
WARNING
Before conducting the above inspections and service, make sure the tractor engine is off, all rotation
parts are completely stopped and the tractor is in park with the parking brake engaged. Make sure
the tiller is resting on the ground or securely blocked up and the tractor lifting hydraulics locked.
Once all the checks above have been done, start tractor and the tiller as follows:
start the tractor and engage the tractor PTO at low rpm, making sure that the tiller is NOT in the
raised position but close to the ground, then increase speed engine until to 540 rpm;
lower the tiller on the ground and simultaneously start driving the tractor at low speed.
Subsequently increase the ground speed depending on ground conditions;
If the environmental temperature is very cold , it's recommended to wait a few minutes with the
PTO of the tractor at low rate before lowering the tiller completely on the ground;
drive for a while operating the tiller, then stop the tractor to check the quality of the work
performed. If you need to get off the tractor, lift the tiller just out of the ground, reduce engine
speed and disengage PTO, set the parking brake, stop engine and remove the ignition key;
If the working depth and/or soil texture are not as desired, correct them by adjusting the skids
and/or the rear cover (see section Adjustments).
5.2. OPERATING INSTRUCTIONS
During operations:/ OPERATE ACCORDING TO FOLLOWING INTRUCTION
always keep the tractor engine at rpm rate ensuring to the tiller the right power required for the
use;
always keep a tractor speed adequate to conditions of the soil to be worked (from 2 to 10 km / h
approx.). Reduce speed in the case of hard or stony soils;
choose a driving pattern that provides the maximum pass length and minimizes turning;
when working in the hills, if you can do "climbing" in the sense of the slope, in any case do not
work along the hillsides, making the steps from top to bottom to reduce the terrace Where
possible always try to «work up» the slope. If this is not possible avoid hoeing along the contours
of the hill and hoe up and down the slope to avoid a terracing effect;

FTL Series Rotary Tillers
16
always perform changes and reverse of direction with PTO disengaged and the tiller slightly lifted
from the ground to avoid damage to the machine;
periodically check for foreign objects wrapped around the rotor shaft and remove them, after
disengaging PTO, turning off tractor engine, and removing ignition key;
if the blades strike a foreign object, or in case of prolonged intervention of the clutch due to an
object wedged into the rotor, stop operating immediately, idle the engine speed and disengage
the PTO. Wait for stopping of all rotating parts, then raise the implement and proceed to removing
the object, after stopped the tractor, set the parking brake, stopped engine and removed the
ignition key. Repair any damages immediately, and make sure rotor and blades are in good
condition before restarting operation;
avoid friction clutch overheating caused by too long or too frequent slipping of the clutch, since
this can damage the friction plates and clutch parts.
Typical problems that may occur operating the tiller are described into Troubleshooting section,
together with their solutions.
5.3. ADJUSTMENTS
WARNING
All adjustment operations must be performed with the tractor engine off, the PTO disengaged, the
tiller lowered to the ground or on security stands, the parking brake set and the ignition key off.
LOWER CLEVISES ADJUSTMENT
It is possible to adjust the lower hitch position loosening the bolts 1 (see picture) and sliding the
clevis 2. Tighten the bolts after making any adjustment required.
FRICTION CLUTCH ADJUSTMENT
The PTO driveshaft and friction clutch are designed to transmit adequate power to the tiller.
1
1
2
