Farr Gold Series Installation and operating instructions

Gold Series
Dust
Collector
Gold Series
Dust
Collector
Installation,
Operation and
Maintenance
Installation,
Operation and
Maintenance
Farr Air Pollution Control
PO Box 9080 / 3501 North Airport Road
Jonesboro, Arkansas 72401
1-800-479-6801
1-800-222-6891 Fax
wwwfarr.com/apc
Customer:Customer:
Location:Location:
Job #:
Local Rep:
Rep. Phone #:
Document #C-1000-21 Rev. D

TABLE OF CONTENTS
INTRODUCTION .......................................................................................................................................................5
SECTION 100-SAFETY PRECAUTIONS ...............................................................................................................5
SECTION 100-SAFETY PRECAUTIONS ...............................................................................................................6
100.1 UNDERSTAND SIGNAL WORDS AND SYMBOLS ..............................................................................................6
100.2 WARNING DECALS AND GUARDS ..................................................................................................................6
100.3 LOCK-OUT/TAG-OUT REQUIREMENTS............................................................................................................7
SECTION 200-RECEIVING YOUR EQUIPMENT................................................................................................8
200.1 THE PURCHASER’S RESPONSIBILITY .............................................................................................................8
200.2 SYSTEM COMPONENTS ..................................................................................................................................8
200.3 HOW YOUR EQUIPMENT IS SHIPPED .............................................................................................................9
200.4 UNCRATING AND INSPECTION ........................................................................................................................9
200.5 UNDERSTAND YOUR SERIAL PLATE...............................................................................................................9
SECTION 300-INSTALLATION OF YOUR EQUIPMENT................................................................................10
TABLE 300.1: GOLD SERIES ASSEMBLY TOOLS ....................................................................................................10
SECTION 310-ASSEMBLING YOUR GOLD SERIES........................................................................................11
310.1 HARDWARE...................................................................................................................................................11
310.2 HOPPERS......................................................................................................................................................11
310.3 SUPPORT LEGS AND BRACES ......................................................................................................................11
310.4 HOPPER/SUPPORT STRUCTURE ASSEMBLY ...............................................................................................11
310.5 FILTER MODULE ...........................................................................................................................................11
310.6 DISCHARGE ACCESSORIES ..........................................................................................................................12
310.7 DRUM KIT/SLIDE GATE.................................................................................................................................13
310.8 PLATFORM/LADDER......................................................................................................................................13
SECTION 320-ATTACHING DUCT WORK TO YOUR GOLD SERIES.........................................................14
320.1 INLET DUCT DESIGN.....................................................................................................................................15
320.2 INLET FLANGES.............................................................................................................................................16
320.3 REMOTE MOUNT FAN DISCHARGES ............................................................................................................16
320.4 TOP MOUNT FAN DISCHARGES....................................................................................................................16
320.5 DISCHARGE HOPPER FLANGE......................................................................................................................16
SECTION 330-FIELD UTILITY CONNECTIONS ..............................................................................................17
330.1 MOTOR CONNECTIONS.................................................................................................................................18
330.2 TIMER CONTROL...........................................................................................................................................19
330.3 SOLENOIDS ...................................................................................................................................................19
330.4 DIFFERENTIAL PRESSURE (DP) CONNECTIONS..........................................................................................21
330.5 COMPRESSED AIR CONNECTION .................................................................................................................21
330.6 SPRINKLER CONNECTIONS ..........................................................................................................................23
SECTION 340-EXPLOSION VENTS .....................................................................................................................25
340.1 IMPORTANT NOTE CONCERNING EXPLOSION VENTS:.................................................................................25
340.2 GENERAL EXPLOSION VENT GUIDELINES....................................................................................................25
340.3 EXPLOSIVE DUSTS .......................................................................................................................................26
340.4 EXPLOSION VENTS OPERATION ...................................................................................................................26
340.5 RETURN OF FILTERED AIR TO THE BUILDING ..............................................................................................26
340.6 LOCATION OF VENTS AND VENTED EQUIPMENT..........................................................................................26
340.7 SYSTEM DUCTING ON COMBUSTIBLE DUSTS ..............................................................................................27
340.8 IGNITION SOURCES ......................................................................................................................................27
340.9 VENT DISCHARGE DUCTS ............................................................................................................................27
340.10 VENT INSPECTION AND MAINTENANCE ......................................................................................................27
SECTION 350-FILTER INSTALLATION/REPLACEMENT.............................................................................28
2
SECTION 360-PRECOATING OF FILTERS .......................................................................................................29

SECTION 400-OPERATION OF YOUR EQUIPMENT ......................................................................................31
400.1 SYSTEM OPERATION ....................................................................................................................................31
400.2 FILTER CLEANING.........................................................................................................................................32
400.3 CLEANING SYSTEM COMPONENTS ..............................................................................................................33
400.4 DWYER DCT1000 AUTOMATIC TIMER CONTROLLER .................................................................................34
400.5 NCC DT-10 (DETERMINATOR) AUTOMATIC TIMER CONTROLLER.............................................................37
400.6 GOYEN T-4 AND P-4 AUTOMATIC TIMER CONTROLLER .............................................................................41
400.7 FAN OPERATION ...........................................................................................................................................44
400.8 STARTUP PROCEDURE .................................................................................................................................49
400.9 SHUTDOWN PROCEDURE ..............................................................................................................................50
400.10 RECOMMENDED TIMER SETTINGS .............................................................................................................50
SECTION 500-PREVENTIVE MAINTENANCE AND TROUBLESHOOTING..............................................51
500.1 FILTER ELEMENTS ........................................................................................................................................51
500.2 HOPPER ........................................................................................................................................................51
500.3 FAN MOTOR LUBRICATION ...........................................................................................................................51
500.4 SOLENOID AND DIAPHRAGM VALVES ...........................................................................................................51
500.5 AUTOMATIC TIMER CONTROL (IF EQUIPPED)...............................................................................................52
500.6 CLEANING AND REPAIR ................................................................................................................................52
500.7 INSPECTION LOG ..........................................................................................................................................52
500.8 SUGGESTED PREVENTATIVE MAINTENANCE SCHEDULE.............................................................................54
SECTION 510-TROUBLESHOOTING GUIDE....................................................................................................55
SECTION 600-DEFINITIONS.................................................................................................................................68
3
SECTION 700- REPLACEMENT PARTS LIST...................................................................................................71

GOLD SERIES ACCESSORIES
Following is a list of common accessories to Gold Series collectors that are not covered in this manual. If
your collector includes any of the accessories, the documentation title and/or number will be listed beside
the accessory. The documentation will be included with this manual submittal.
Fan __________________________________________________
Fan Silencer __________________________________________________
SMF Kit __________________________________________________
Automatic Timer
Controller __________________________________________________
Motor Starter __________________________________________________
Air Lock __________________________________________________
Screw Conveyor __________________________________________________
Dust Level Indicator __________________________________________________
High Hopper Level
Probe __________________________________________________
Support Structure __________________________________________________
Determinator Remote
Display Panel __________________________________________________
Thermocouple __________________________________________________
Magnehelic Gage __________________________________________________
Photohelic Gage __________________________________________________
Flow Meter __________________________________________________
Compressed Air
Pressure Transducer __________________________________________________
Emissions Monitor __________________________________________________
4

INTRODUCTION
Congratulations on your selection of Farr Air Pollution Control equipment! As the owner/operator of this
equipment you have an important responsibility to see that it is operated and maintained in a safe
manner. The unit will require moderate attention to keep it in good operating condition. This manual has
been prepared to aid you in that effort. Throughout this manual, reference may be made to various
components, which may or may not be part of your particular system. They are included in the interest of
fully describing typical systems with all available options.
This manual covers the installation, operation and maintenance of the Gold Series Dust Collector. This is
a piece of air cleaning equipment that is used to eliminate dust contaminants from the environment
making the facility or plant a healthier and safer work place. This unit has been assembled using only
quality materials and labor. This machine has been checked to make sure that it is operational for you at
the time of installation.
Prior to installing your equipment, thoroughly read and understand this manual. Locate all parts and
ensure that nothing is missing, suffered shipping damage or has been damaged during unloading.
Familiarize yourself with each component of your system and its function using the contents of this
manual as a guide. Refer to any local codes or ordinances relating to equipment of this type. They may
affect the method or procedure used to install your system.
DO NOT DISCARD THIS MANUAL!
It contains information which when properly used will insure proper operation, continued
high performance, and a long work life to your unit.
5

SECTION 100-SAFETY PRECAUTIONS
Farr relies on the skills and expertise of its customer and any consulting engineers and/or installing
contractors hired by that customer to properly design and install the dust collection system of which Farr
equipment is a part. It is the responsibility of the end user of this equipment to take the necessary
precautions to minimize the inherent risks associated with combustible dust.1Refer to Section 340 of this
manual if you have an explosive dust. Read this manual thoroughly and comply with the precautionary
statements relative to worker safety. Precautions must be taken to ensure that all electrical/air
connections and regulation devices are installed and operating properly.
100.1 Understand Signal Words and Symbols
The symbols shown below appear on the equipment to alert you of potential hazards. When you see
these symbols you must read, understand, and heed the information that accompanies them.
mi
100.2 Warning Decals and Guards
This piece of equipment contains several warning decals located in many different locations. It is the
owner/operator's responsibility to maintain the integrity of these decals and to ensure that all operators of
the equipment are aware of them and understand their meaning. Replacement decals are available free
of charge from your Farr Service Representative, or by calling Farr direct at 1-800-479-6801. Part
numbers for these decals are listed in the spare parts list in section 700.
This piece of equipment may contain one or more safety guards to protect the operator(s) from injury. It
is the owner/operator's responsibility to maintain the integrity of these guards and ensure that they are in
place when the equipment is in operation.
WARNING!
DO NOT attempt to operate or maintain this piece of equipment until you have read and thoroughly
understood all of the safety information contained in this manual. All such information must be taken
seriously. This piece of equipment contains moving parts and potential pinch points, which can cause
serious injury or death. If you do not understand anything in this manual, seek assistance from your
supervisor before operating this equipment. DO NOT attempt to operate this equipment with out factory-
installed guards. Replace damaged guards.
6
1See NFPA 654 Standard for the Prevention of Fire and Dust Explosions from the Manufacturing, Processing, and
handling of Combustible Particulate Solids. And NFPA 68 Guide for Venting of Deflagrations.
Indicates an imminently
hazardous situation, which, if not
avoided may result in death or
serious injury
Indicates a potentially
hazardous situation, which
may, if not avoided, result in
nor or moderate injury and
or property damage.
Indicates a potential hazardous
situation, which, if not avoided,
could result in death or serious
injury.
Indicates the presence of an
electrical power source,
which could result in death,
personal and /or property
damage.

Identifies equipment
wi
Indicates the hazard of being
trapped inside a dust collector. If
the main fan is activated the
collector door would be sucked
shut. The door would be very
difficult to open against the
negative pressure generated by
the fan.
Marks the location of an
explosion relief vent. In
the event of an explosion
in the dust collector
there is a potential for
damage to personal
property, injury, and /or
death.
SEE SECTION 340
Identifies hazards associated with
rotating machinery.
Identifies hazards associated with
belt and chain drives.
Identifies hazards associated with
compressed air sources.
that will start
thout warning.
Identifies hazards associated with equipment
that are considered confined spaces.
100.3 Lock-out/Tag-out Requirements
Control of this equipment must be in accordance with OSHA Standard 1910.147 “Control of Hazardous
Energy (Lock-out/Tag-out)”. This standard “requires employers to establish a program and utilize
procedures for affixing appropriate lock-out/tag-out devices to energy isolating devices and to otherwise
disable machines or equipment to prevent unexpected energizing, start-up or release of stored energy in
order to prevent injury to employees”.
For further information on Lock-out/Tag-out requirements, see your company’s Safety Director or refer to
OSHA Standard 1910.147.
Before inspecting or servicing this equipment perform an approved Lock-out/Tag-out procedure
on the electrical service, the compressed air (or other gas) supply or any other energy source.
7

8
SECTION 200-RECEIVING YOUR EQUIPMENT
200.1 The Purchaser’s Responsibility
A visual inspection of your equipment should be performed before it is removed from the truck. Dents,
scratches and other damage should be noted and photographed. The structural integrity of the housing
will be adversely affected by large dents. Farr should immediately be notified of any structural damage to
your equipment. It is the purchaser’s responsibility to file shortage reports and damage claims
with the carrier and your Farr representative. The carrier is responsible for any damage to the
equipment while it is in transit unless specific arrangements are made otherwise.
The Gold Series dust collector is shipped disassembled and must be reassembled by installation
personnel. Unit assembly, with the exception of the electrical and air connections, can usually be
accomplished by anyone with a basic understanding of common hand tools.
Besides a common set of hand tools, a crane, fork-lift and/or chain-fall will be required to position the fan
and motor on top of the unit clean-air plenum and lift heavier components into position.
Farr must rely on the skill and expertise of its customers and the customer's installation
contractor to ensure that all electrical connections are made correctly and air connections and
regulation devices are installed and operating properly.
200.2 System Components
Your Gold Series dust collection system may consist of one or all of the following components:
13. Discharge Drum(s)
1. Filter Module
14. Manual Cleaning Control
2. Hopper Section(s)
15. Automatic Timer Control
3. Fan
16. Fan silencer
4. Support Legs
5. Cross Braces
6. Assembly Hardware
7. Motor Starter
8. Maintenance Platform
9. Maintenance Ladder
10. Rotary Airlock
11. Screw Conveyor(s)
12. Slide Gate Kit(s)
Remote Mount
Fan
Access Platfor
m
Rotar
y
Airlock Filter Module –
Cartridges are factory
installed. Hardware is
located inside inlet
Ho
pp
er
Su
pp
ort Le
g
s
Figure 200.2 Gold Series Shipment

200.3 How Your Equipment Is Shipped
It is Farr’s goal to ship our products as economically and practically as possible. In order to save our
customers shipping costs, it is our goal to load your collector on as few trucks as necessary. The number
and size of trucks required to transport your collector will depend solely on the size of your unit. The
trucks are loaded to minimize damage to the collector while loading, shipping, and unloading. Typically,
your collector will ship with the hopper, plenum, support structure, fan and other accessories
disassembled. These items will be loaded on the trucks separately and placed on pallets for easy
unloading. A fork-truck or crane may be needed to unload your collector depending on the size of the
unit. All assembly hardware will be located in a box that will be placed in the inlet of the plenum
section of your collector. A picture of a typical collector loaded on a flat bed trailer is shown in Figure
200.2
200.4 Uncrating and Inspection
Each Gold Series dust collector is normally shipped on two or more skids. One skid contains the filter
module section. A second skid contains the hopper section and other skids will contain fans, support legs,
safety monitoring filters, airlocks and custom accessories. Typically, the filter cartridges, control box
and any other user installed components are shipped inside the cartridge area of the bin-vent
section.
Use extreme care when handling the unit and components. Careless handling can damage delicate
parts or affect assembly alignments. Compare the number of items received against the carrier's Bill of
Lading. The project drawing has a listing of all loose components shipped with the job. A copy of this
drawing is included with this manual submittal and can also be found in the small parts box located in the
inlet of the collector. Inspect all items for apparent damage. Immediately report any shortages or
obvious damage to the carrier and to your local Farr Representative or call Farr at 1-800-479-6801.
When all skids are completely unpacked, check all items received against the material list on the project
drawing and or the packing list (if any) sent with the shipment. Further inspect the unit and components
for hidden damage. Again, report any shortages or damage to the carrier and to your local Farr
Representative.
Do not return any damaged components without first contacting your Farr Representative to
obtain Returned Goods Authorization (RGA). Carefully inspect all packing material so that small
parts are not inadvertently discarded.
200.5 Understand Your Serial Plate
Once you receive your equipment, it will be important to have the collector’s part, model, and order
numbers. This information will be helpful when calling customer service or finding original equipment
supplied with the collector. This information should be found on a silver plate above the door on your
collector. You should write this information in this book for easy access. Here is what your serial plate will
show.
Part Number – This will link the unit to the prints and
engineering documents associated with your unit.
Model – This tells us what style unit you purchased.
Product – This information will identify what model of
Farr dust collector you own. Gold Series should be
printed in this area.
Serial Number – This number will provide all of the
same information (part numbers, size, and model) and
will also provide the sold to and ship to addresses. It will also provide all of the accessories sold with the
unit, and the best source of information for ordering replacement parts.
Ship Date – This will identify when and where the collector was manufactured and when it shipped. This
information will aid in tracking order information.
9
Figure 200.5 Serial Plate
JONESBORO, AR U.S.A.
www.camfilfarr.com/apc
FAX: [phone]
TEL: [phone]
PART NO.
SER NO.
MODEL
L-68494

SECTION 300-INSTALLATION OF YOUR EQUIPMENT
Table 300.1: Gold Series Assembly Tools
The following items may be required to install your equipment depending on configuration and installation
requirements:
Only trained, authorized personnel should be permitted to service or maintain electrical or safety
components. It is the buyers/installers responsibility to ensure that all applicable electrical and
safety codes are met.
DESCRIPTION INTENDED USE
1 SAE Socket Set General tightening of fasteners
2 Common Screwdriver Electrical connections
3 Phillips Screwdriver Electrical connections
4 Electric Drill or Impact Wrench Installation of self-tapping screws and fasteners
5 Hammer Drill Anchoring to floor
6 Masonry Bit Anchoring to floor
7 Hammer Installing anchors
8 Pliers General use
9 Wire Cutters Electrical connections
10 Wire Nuts Electrical connections
11 Electrical Tape Electrical connections
12 Extension Cord General use
13 Conduit Electrical connections
14 ¾” or larger black iron pipe or equivalent Compressed air connections
15 Fittings for items 13 & 14 Compressed air and electrical connections
16 Thread Sealant Compressed air connections
17 Alignment Punch Aligning holes
18 Forklift or Overhead Hoist Moving and positioning components
19 Electrical Cable (3 PH 230/460 VAC 10 HP) Fan electrical connections
20 Electrical Cable (1 PH 120/240 VAC) Control and lighting electrical connections
21 Wedge anchors or equivalent suitable for the application Anchoring to floor
22 230/460VAC, 3 Ph, 60Hz Electric Motor Starter *Ventilation Fan * (If not supplied with unit)
23 Transit or Carpenters Level Leveling Unit
10

SECTION 310-ASSEMBLING YOUR GOLD
SERIES
310.1 Hardware
Refer to Figure 310.1 for typical assembly points of a
standard collector. Refer to the General Dimension
drawings for specifics, such as item part numbers, inlet
and outlet locations, foundation dimensions and
accessories.
Locate the cartons containing the installation hardware.
The cartons will be labeled with the part number and are
normally located inside the inlet. The carton containing
the hardware to be used for the support legs and cross
braces will be labeled “hardware kit for structural
support”. The carton(s) to be used to bolt the bin-vent to
the hopper(s) will contain 3/8-16 thread cutter screws and
roll(s) of gray rope caulk. Separate the hardware for ease
of location during assembly.
310.2 Hoppers
Locate the hopper(s) and support legs. Remove the
hopper(s) from the skid(s) and place on a flat, level
surface. Note: GS24 and smaller units will ship with the
support legs, cross braces and hopper(s) pre-assembled.
If your collector includes multiple hoppers place them in
the correct configuration as shown on the General
Dimensions drawing. Using a tape measure or string line,
square the hopper(s) as necessary. Bolt the hopper(s)
together using the corner support brackets and hardware
as shown on Figure 310.2.
310.3 Support Legs and Braces
Refer to Figure 310.2 for general assembly and your
support structure drawing for specific parts. Locate the
support legs and bolt them to the corner support
brackets. Locate the cross braces and bolt them to the support legs. If your collector contains knee
braces, bolt one end to the support leg and the other end to the corner support bracket. Note: Do not
tighten any of the bolts until all bolts have been started.
310.4 Hopper/Support Structure Assembly
Lift the completed hopper/support structure assembly with a forklift or chain hoist and carefully overturn
into an upright position. Note: The slots for lifting in the corner support brackets –Figure 310.2.
Move the assembly into final position. Ensure that inspection panels or optional device connections are
in the desired orientation. Note: On GS6, 10 & 20 collectors, the bin-vent to hopper(s) bolt-holes are
not symmetrical. Turn the hopper/support structure assembly so that when the “Match Line”
label(s) on the hopper(s) line up with the “Match Line” label(s) on the bin-vent, the collector is in
the desired orientation. The “Match Line” labels do not have to line up perfectly; they are intended
only for general hopper to bin-vent orientation –Figure 310.3.
Level the hopper flange(s) with a transit or carpenter’s level. Grout the support leg bases as necessary.
Anchor the support legs to the floor using appropriate concrete anchors (by installing contractor).
310.5 Filter Module
11
If your collector is equipped with a top-mounted fan, locate the fan mount panel and clean the area
around the fan flange that will be in contact with the rope caulk. If your collector is equipped with a remote
Figure 310.1
FAN
(FIELD INSTALL)
FILTER MODULE
INLET
SUPPORT
LEG
HOPPER
CROSS
BRACE
SLIDE GATE
DRUM LID
DRUM
FAN MOUNT
PANEL

mount fan, remove the upper side panel from the side you intend to make your fan duct flanged
connection. Remove any old rope caulk that did not come off with the upper side panel.
Clean the fan flange and apply rope caulk, ensuring a continuous seal.
If you have a top mount fan, lift the fan onto the filter module roof. Bolt the fan to the fan mount panel
using the hardware included –Figure 310.1. If you have a remote mount fan refer to section 320 (Remote
mount fan discharges) for further instructions.
Remove any dirt or other accumulation from the hopper flange. Line the hopper flange with rope caulk as
indicated in Figure 310.3. Ensure that there is a continuous seal on the flange.
Lift the filter module, using the lifting lugs provided and approved lifting equipment – Figure 310.3. Failure
to connect lifting cable to all (4) lifting lugs may result in damage to the collector. On larger collectors,
adequate cable length or a spreader bar is required to prevent damage to the collector.
Clean the filter module flange and set onto the hopper flange, taking care not to damage the flanges or
rope caulk. Ensure that the orientation of the collector is as desired for your installation. Note: On GS6,
10 & 20 collectors ensure that the “Match Line” label(s) on the filter module, line up with the
“Match Line” label(s) on the hopper(s) - Figure 310.3.
Attach the filter module to the hopper, using 3/8-16 thread cutter screws – Figure 310.3. Use a drift or
alignment pin to align holes as necessary. Insert bolts into each of the four corners without tightening
them. Insert the bolts from the corners to the center of the collector. Note: Do not tighten bolts when
starting to align hopper. Wait until all bolts have been started before tightening. Keep most of the
weight on the crane or forklift supporting the filter module. This will allow you to move and adjust the filter
module as necessary.
310.6 Discharge Accessories
Locate the hopper discharge accessory supplied with your collector. This will be a drum kit/slide gate,
rotary airlock or screw conveyor. Install the accessory to the hopper discharge flange(s) using the
General Dimensions drawing and Section 320 as a guide.
12
CORNER SUPPORT
BRACKET 5/8 BOLT
5/8 FLAT WASHER
5/8 LOCK WASHER
5/8 NUT
FIGURE 310.2
(GS 32 SHOWN)
5/8" BOLT, FLAT WASHER
(2 SIDES), LOCK WASHER &
NUT (TYP ALL CONNECTIONS)
SLOT FOR
LIFTING
KNEE BRACE

310.7 Drum Kit/Slide Gate
Figure 310.3
(GS6 shown)
3/8-16 THREAD
CUTTER SCREW
"MATCH LINE"
LABEL
~
~
UPPER SIDE
PANEL
LOWER SIDE
PANEL
LIFTING LUG
FULL MODULE
(4 CARTRIDGES)
HALF MODULE
(2 CARTRIDGES)
ROPE CAULK
Clean and apply rope caulk to the top
surface of the slide gate flange. Bolt
the slide gate to the hopper
discharge flange; making sure that
the slide gate is oriented so that
there is no interference when the
handle is pulled out. Fasten one end
of the flexible hose to the slide gate
collar with a hose clamp. Slip the
other end of the flexible hose over
the collar of the drum lid and fasten
with a hose clamp. If you have a
positive pressure drum kit, slip the
drum ring over the top of the drum.
Slide the ring down far enough so
that when the (4) clamps are
secured, the drum lid gasket seals
tightly against the top surface of the
drum. Tighten the drum ring screw. If
you have a negative pressure drum
kit, place the drum lid on top of the
drum with the gasket surface
contacting the top surface of the
drum. – Figure 310.7.
310.8 Platform/Ladder
If equipped, lift the platform assembly
into position and install using the
hardware provided. Lift and install
the access ladder using the
hardware provided. Refer to the
Platform/Ladder assembly drawing
and General Dimensions drawing for specific instructions. It may be necessary to cut
the ladder to the exact length. Note: The installing contractor must brace the ladder properly.
13
Drum lid
Hose clamp
Flexible hose
55 GAL
Drum
55 GAL
Drum
Attach to discharge
flange on hopper. Hose clamp
Slide gate
Hose clamp
Flexible hose
Hose clamp
Drum lid
Slide gate
Drum latch ring
Negative
Pressure
Drum kit
Positive
Pressure
Drum kit
Figure 310.7

SECTION 320-ATTACHING DUCT WORK TO YOUR GOLD SERIES
This section covers flange details and design guidelines for ducting to your Gold Series dust collector.
The following figures show the different sizes of inlet and outlet flanges.
14
24"
24"
3 SPA @
6" = 18" 4-1/8"
4-1/8"
26-1/4"
1-1/8"1-1/8"
26-1/4"
3 SPA @
6" = 18"
60"
24"
9 SPA @ 6" = 54" 4-1/8"1-1/8"
62-1/4"
3 SPA @
6" = 18"
26-1/4"
4-1/8"
96"
24"
15 SPA @ 6" = 90"
90"
1-1/8"
3/8-16 UNC
3/8-16 UNC3/8-16 UNC
Figure 320.1
SINGLE MODULE INLET
Figure 320.2
DOUBLE MODULE INLET
Figure 320.3
TRIPLE MODULE INLET
22"
1"
6 SPA @4" =24"
SIDE OUTLET FLANGE
Figure 320.4
10 SPA @ 4" = 40"
3/8-16 UNC
38"
3/8-16 UNC
22"
6 SPA @4" =24"
(HALF PANEL)
SIDE OUTLET FLANGE
Figure 320.5
3 @4"
= 12"
3-1/2" 3-1/2"
17"1"

320.1 Inlet Duct Design
When you run ducting to your collector, it is important to follow these guidelines.
1. The straight length of duct entering the inlet should be a minimum of 2 duct diameters.
2. The transition angle from the duct to the inlet flange should be a minimum of 45°.
In figure 320.8, the “RECOMMENDED” design shows a vertical section of duct, a 90° elbow and a
horizontal length of a least 2 duct diameters before entering the inlet. The air direction will cause the
dust to be evenly distributed to the filters. In the “NOT RECOMMENDED” design, the duct enters the
inlet at an angle. The air direction will force dust already in the hopper (previously pulsed off the
filters), to be re-entrained into the air stream.
In figure 320.9, the “RECOMMENDED” design shows a straight section of duct that is at least 2 duct
diameters long, before entering the inlet. The air direction will cause the dust to be evenly distributed
to all of the filters in the collector. In the “NOT RECOMMENDED” design, the duct is not long enough
to allow the air to straighten out before entering the inlet. The air direction will force the dust to one
side of the collector, resulting in uneven dust loading on the filters.
15
38"
2"
Figure 320.6
TOP OUTLET FLANGE
(FULL PANEL)
40"
9 SPA @ 4" =36"
3/8-16 UNC
2"
1"
38"
40"
9 SPA @ 4" = 36"
38"
2"
Figure 320.7
TOP OUTLET FLANGE
(HALF PANEL)
19"
3-1/2"
3-1/2"
3 @ 4"
= 12"
3/8-16 UNC
17" 1"
2"
DUCT
DIA. DUCT
DIA.
TRANSITION
INLET DUST
PARTICLES
DUST
PARTICLES
RECOMMENDED NOT RECOMMENDED
Figure 320.8 - Side View
60°MIN.
TRANSITION
SLOPE
DUCT LENGTH
MIN 2X DIAMETER

320.2 Inlet Flanges
Depending on the size and orientation of your Gold Series collector, the inlet will have one or more of
three inlet designs. These inlets are configured and classified with the number of modules that the
collector uses to support the inlet plenum. Larger collectors may have more than one inlet plenum
and vary in the size of the inlet. Figures 320.1, 320.2 and 320.3 show dimensions of the one, two, and
three module inlets respectively. When attaching ductwork to these flanges always be sure to caulk or
place gasket material between the duct and collector before bolting them together.
320.3 Remote Mount Fan Discharges
Remote mount fans, provided by Farr, will be ducted to the collector by removing an upper panel and
attaching the ductwork to the frame of the Gold Series dust collector. The ductwork will be attached to
the flange details on Figures 320.4-320.7. These dimensions are the bolt patterns for the panel and
frames. Either the side panels, on the upper section of the dust collector, or top panels can be
removed. Figure 320.4, is the bolt pattern for the full sized side panel, while Figure 320.5, is for the
half sized side panel. Figure 320.6 and 320.7 are for the full and half sized top panels respectively.
When attaching ductwork to these flanges, always be sure to caulk or place gasket between the duct
and collector before bolting them together.
320.4 Top Mount Fan Discharges
Top mount fans, provided by Farr, are field mounted on the top of the Gold Series collector. All Farr
provided fans will have a fan damper supplied with the fan. When attaching ductwork to this flange,
always be sure to caulk or place gasket between the duct and damper outlet before bolting them
together.
320.5 Discharge Hopper Flange
Accessories will be attached to the hopper discharge flange. See your General dimensions drawing for
the dimensions for your flange.
16
DUCT DIA. DUCT DIA.
DUST
PARTICLES
GS 16 SHOWN
INLET DUST
PARTICLES
RECOMMENDED NOT RECOMMENDED
TRANSITION
Figure 320.9 - Top View
TRANSITION
SLOPE
60°MIN.
DUCT LENGTH
MIN 2X DIAMETER

SECTION 330-FIELD UTILITY CONNECTIONS
17
120/1/50-60 VAC
TIMER
AIR CONSUMPTION
(SEE TABLE 330.3)
Figure 330.1
(Field Utility Connections)
GROUND
HIGH DP
JUMPER
LOW DP
90 PSI (MIN)
COMPRESSED
AIR (1" NPT)
SOLENOID TO
DIAPHRAGM VALVE
CONNECT TO MAGNEHELIC GAGE
IF YOU DO NOT HAVE AIRLINE
CONNECTIONS ON YOUR TIMER
1/4" OD PNEUMATIC TUBE
ELECT. WIRE
1" NPT AIR LINE
HOT
(1 PER SOLENOID)
COMMON

330.1 Motor Connections
WARNING! Failure to perform an approved Lock-out/Tag-out procedure may result in a sudden
release of energy resulting in property damage, personal injury or death! Ensure that the circuit
you are working with is off before you make these or any other electrical connections. Serious
injury may result if you do not take proper safety precautions!
Farr can supply the fan, motor starter, and rotary air locks (or other discharge devices) for our dust
collectors. However, the customer or Farr representative may elect to supply the fan and other
accessories. It is imperative that all equipment installed complies with your local electrical code. Check
your paper work and information plates to determine electrical specifications for your equipment.
Mount the motor starter enclosure in a convenient location for operation. Use the enclosure as a template
for marking and drilling mounting holes. Possible locations include a support leg or plant wall near the
collector.
Run conduit and wiring (supplied by others) from the motor starter to the fan motor and from the power
source to the motor starter. The wiring diagram for the motor will be either on the motor or inside the
motor junction box. Connect the wiring from the motor starter to the fan and from the power source to the
motor starter. A qualified electrician should only make these connections.
18
230 V 208 V
Camfil Farr P/N SIZE P/N PANEL BK Camfil Farr P/N SIZE P/N PANEL BK HP HP AMPS AB P/N AMPS AB P/N
207267201 207267401 1.5 1.5
207267202 207267402 2 2
207267203 207267403 3 3
207267204 207267404 5 NA 16 AB100C16L10
207267205 207267405 7.5 523 AB100C23L10
207267206 207267406 10 7.5 30 AB100C30L10 12-37 193-EA1HC
207267207 207267407 15 10 43 AB100C43L10 14-45 193-EA1JD
207267208 207267408 20 15 60 AB100C60L10
207267209 207267409 25 20 72 AB100C72L10
207267210 207267410 30 25 85 AB100C85L10
460V
207267211 207267411 1.5 1.6 - 5
207267212 207267412 2 1.6 - 5
207267213 207267413 3 3.7-12
207267214 207267414 5 3.7-12
207267215 207267415 7.5 12 AB100C12B10 12-32
207267216 207267416 10 16 AB100C16B10 12-32
207267217 207267417 15 23 AB100C23B10 12-32
207267218 207267418 20 30 AB100C30B10 12-37
207267219 207267419 25 37 AB100C37B10 12-37
207267220 207267420 30 43 AB100C43B10 14-45 193-EA1JD
207267221 207267421 40 60 AB100C60B10 26 - 85
207267222 207267422 50 72 AB100C72B10 26 - 85
207267223 207267423 60 85 AB100C85B10 26 - 85
AB - Allen Bradley
26 - 85 193-EA1KE
AB100C09B10
AB100C12L10
193-EA1FB
CONTACTOR RELAY
MOTOR LOAD SPECIFICATIONS
3.7-1212
12X12X6 A12P12HFA1212CH
NEMA 12
ENCLOSURE
NEMA 4
ENCLOSURE
193-EA1FB
193-EA1GB
12X12X6 A1212CHNF A12P12
16X12X8 A16148CHNF CP1612
12-32
193-EA1HC
193-EA1KE
193-EA1EB
16X14X8 HFA16148CH A16P14
16X14X8 HFA16148CH A16P14
12X12X6 HFA1212CH A12P12
Camfil Farr Motor Starters
193-EA1GB
12X12X6 A1212CHNF A12P12
9
16X12X8 A16148CHNF CP1612
Table 330.1.1

330.2 Timer Control
This discussion refers to standard equipment that uses 120/220 VAC, single phase, 50/60 Hz power.
Refer to your General Dimensions drawing to confirm the electrical requirements of your equipment.
Connection instructions are the same regardless of the voltage source. Refer to the documentation
attached to this manual and the timer control box for further information regarding the installation of your
specific control.
If equipped, mount the Automatic Timer Control on a wall or stand close to the collector. It is important to
mount the timer near the collector so that you can monitor the performance. Keep in mind that both
pressure gage and electrical connections need to be made to the timer control. Note: Do not mount the
timer control to the dust collector! Vibration from the pulsejets may damage the sensitive
electronic equipment.
330.3 Solenoids
To wire your solenoids, follow Figures 330.1 and 330.3.1. Each solenoid will have two wires attached –
one specific for the numbered row of cartridges and a second wire that will be attached to all of the
solenoids (called the Common). The Common is factory pre-wired on the solenoids, therefore only one
connection will need to be made. Once the solenoid has been wired, the corresponding wires will then be
attached to the control board as shown in Figure 330.3.2. The Common will share a terminal with the L2
terminal (120 volt “return” power line). Note: The Controllers will have a separate Common
connection terminal on the board; this terminal is internally connected to the L2 power terminal
and has the same effect as wiring into the L2. Connect the first wire (other than the Common) from a
solenoid on a row of cartridges, to the corresponding numbered terminal on your control board. Once this
is done for all of the rows, you can connect the L1 and L2 Terminals (L1 is “Hot”, L-2 is “Return”) to your
120-volt power source. For more information on the diaphragm and solenoids see the attached
specification sheets.
19
Common Wire internally pre-wired
Attach Numbered Wire from
Controller to corresponding
solenoid
Attach Common Wire to either
end of the pre-wired common
terminals
Figure 330.3.1 – Solenoid Wiring Diagram
Figure 330.3.2 - Controller Wiring Diagram
L1 L2 1 2 3 54 6 117 8 10912 13 14 15 16
LOAD/SOLENOID COMMON
115
VAC
SOLENOID
VALVES

Table 330.3.1 shows the number of solenoids and automatic timer controller outputs for the standard
Gold Series models. For GS2 through GS60 models, there are at least as many timer outputs as there
are solenoids. Each timer output connects to an individual solenoid. For GS72 through GS120 models,
there are more solenoids than timer outputs. These models also have two headers (compressed air
reservoirs). If your collector is one of these models, you must connect some of the timer outputs to two
solenoids. When you connect a timer output to two solenoids, make sure the solenoids are connected to
diaphragm valves on different headers, as shown in Figure 330.3.3.
20
Figure 330.3.3 - DOUBLE UP TIMER OUTPUTS
AIR LINE
1/4" OD
TUBE
SOLENOID BOX
ELECTRICAL
TIMER
DIAPHRAGM
SOLENOID
TIMER OUTPUT
HEADER HEADER
GS2 2 6 10 10 N
GS4 4 6 10 10 N
GS6 6 6 10 10 N
GS8 4 6 10 10 N
GS10 5 6 10 10 N
GS12 6 6 10 10 N
GS16L 8 10 10 10 N
GS16 SQ 4 10 10 10 N
GS20 5 10 10 10 N
GS24 6 10 10 10 N
GS32 8 10 10 10 N
GS36 12 22 20 20 N
GS48 16 22 20 20 N
GS60 20 22 20 20 N
GS72 24 22 20 20 Y
GS84 28 22 20 20 Y
GS96 32 22 20 20 Y
GS108 36 22 20 20 Y
GS120 40 22 20 20 Y
No. of Timer Out
p
uts Double
Timer
out
p
uts
GOLD SERIES TIMER REQUIREMENTS
Table 330.3.1
Model
Designation
No. of
Solenoids/
Dia
p
hra
g
ms DeterminatorDwyer T4 & P4
