Grizzly T32713 User manual

For questions or help with this product contact Tech Support at [phone] or [e-mail]
MODEL T32713
NEGATIVE PRESSURE GAUGE
KIT FOR G0860/G0861/G0862
DUST COLLECTORS
INSTRUCTIONS
COPYRIGHT © AUGUST, 2021 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
(FOR MODELS MFD. SINCE 08/21) #CS22017 PRINTED IN TAIWAN
Introduction
The Model T32713 Negative Pressure Gauge Kit
can be installed on the Model G0860, G0861, and
G0862 dust collectors to indicate when to clean or
replace the canister filter.
V1.08.21
To reduce your risk of
serious injury, read this
entire manual BEFORE
using machine.
Figure 1. Model T32713 Negative Pressure
Gauge Kit.
Box Contents (Figure 2) Qty
A. Pressure Gauge Assembly ......................... 1
B. Clear Tube 1⁄2" x 24" ................................... 1
C. Hose Clamps 1⁄2" ........................................ 2
D. 90º T-Fitting 1⁄2" x 11⁄2" x 11⁄2" ...................... 1
E. Dust Hose 11⁄2" x 43⁄4" ................................. 1
F. Hose Clamps 11⁄2" ...................................... 2
Inventory
ABC
D E F
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
Figure 2. Inventory.
Installation
Use the following steps to assemble the Model
T32713 and attach it to your Model G0860,
G0861, or G0862 dust collector.
Items Needed Qty
Wrenches or Sockets 10mm ............................ 2
Phillips Head Screwdriver #2 ............................ 1
Wear safety glasses during
the entire setup process!

-2- Model T32713 (Mfd. Since 08/21)
To install negative pressure gauge:
1. DISCONNECT DUST COLLECTOR FROM
POWER!
2. Place (2) 1⁄2" hose clamps around clear tube,
then slide one end of tube over port on back
of pressure gauge (see Figure 3).
4. Place (2) 11⁄2" hose clamps around dust
hose, then slide one end of hose over (1) 11⁄2"
port on T-fitting (see Figure 5).
5. Remove (2) flange nuts from hex bolts on
pressure gauge assembly (see Figure 6).
6. Spread jaws of pressure gauge mount just
enough to slide mount over support leg near
magnetic switch, as shown in Figure 6.
3. Slide other end of clear tube over 1⁄2" port on
T-fitting (see Figure 4).
Figure 4. Clear tube placed over T-fitting port.
Clear Tube
T-Fitting
1⁄2" Port
Figure 5. Dust hose placed over T-fitting port.
T-Fitting
Hose Clamp
Dust Hose
Figure 6. Pressure gauge mount placed on
support leg (G0861 shown).
Support Leg
Hex Bolt
(1 of 2)
Pressure
Gauge
Mount
Note: Position of pressure gauge mount
on support leg will differ from machine to
machine. Place mount near port on intake
barrel where pressure gauge will be visible
during operations.
Figure 3. Clear tube placed over pressure gauge
port.
Hose Clamp
Clear Tube
Pressure Gauge
Assembly

Model T32713 (Mfd. Since 08/21) -3-
7. Loosen hose clamp securing vacuum hose to
intake barrel port and remove hose from port
(see Figure 7).
8. Slide other end of dust hose from Step 4 over
intake barrel port (see Figure 8).
9. Slide vacuum hose over other port on T-fitting
(see Figure 8).
10. Adjust and orient hoses and clear tube as
needed to eliminate any kinks, then tighten
all (5) hose clamps to secure connections.
11. Slide pressure gauge mount to position where
it is easy to read, and secure in place with (2)
flange nuts removed in Step 5.
12. Connect dust collector to power.
Figure 7. Vacuum hose attached to intake barrel
port.
Vacuum
Hose
Intake Barrel
Port
Figure 8. Dust hose placed over intake barrel
port and vacuum hose over T-fitting port.
13. Cover intake dust ports and turn dust collec-
tor ON. Pressure gauge should indicate at
least 200mmAq or 2kPa.
— If gauge indicates at least 200mmAq or
2kPa, negative pressure kit has been
installed correctly and filter is operating
efficiently.
— If gauge indicates less than 200mmAq
or 2kPa, confirm all hose and tube con-
nections are tight and there are no kinks
that disrupt air flow. If gauge still indicates
less than 200mmAq, refer to Reading
Pressure Gauge to service filter as
required.
Reading Pressure Gauge
The Model G0860, G0861, and G0862 use a
handle and internal paddles to remove the dust
buildup from the filter. The negative pressure
gauge will help determine when a more thorough
cleaning is needed and whether the filter should
be replaced.
If the operating pressure on the pressure gauge
drops below 200mmAq or 2kPa (see Figure 9),
remove and clean the filter, as described in the
Owner's Manual.
If the operating pressure drops below 150mmAq
or 1.5kPa, and cleaning does not improve perfor-
mance, replace the filter.
Figure 9. Pressure gauge values.
Dust Hose
T-Fitting
Intake Barrel
Port
Vacuum Hose

-4- Model T32713 (Mfd. Since 08/21)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
9
12
7
1
3
6
8
4
5
11
5
2
9
10
T32713 Parts Breakdown & List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 PT32713001 PRESSURE GAUGE MOUNT 7 PT32713007 CLEAR TUBE 1/2" X 24"
2 PT32713002 T-FITTING 90-DEG 1/2" X 1-1/2" X 1-1/2" 8 PT32713008 BUTTON HD CAP SCR 1/4-20 X 1/2
3 PT32713003 NEGATIVE PRESSURE GAUGE 9 PT32713009 HOSE CLAMP 1-1/2"
4 PT32713004 HEX BOLT 1/4-20 X 2-1/2 10 PT32713010 DUST HOSE 1-1/2" X 4-3/4"
5 PT32713005 HOSE CLAMP 1/2" 11 PT32713011 FOAM 35 X 95 X 3MM
6 PT32713006 FLANGE NUT 1/4-20 12 PT32713012 TOUCH-UP PAI NT, GRI ZZLY GREEN
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call [phone] or visit our online parts store at www.grizzly.com to check for availability.
