Fast Mover FMT18-2 Installation and operation manual

T: [phone] F: [phone] E: sales@fastmovertoolsuk com
FMT18-2
Air Bru h Compre or 1/6HP
Product Informa"on Guide
F T18-2_Product Instructions 08/09/2014 13:46 Page 1

Tool Use
This mini air compressor is ideal for use with
airbrushes with a setup of 0.2 to 1.0mm.
Features and Functions
- Air Pressure Gauge, Air Filter, Adjustable
Pressure.
- Oil Free Piston.
- Instant pressure.
- Thermally Protected.
- Low noise: 62dB.
- Auto Stop and Start Function.
FMT18-2 Part & In truc"on
Fa t Mover Tool Ltd
T: 01582 661993 F: 01582 667100 E: ale @fa tmovertool uk.com
W: www.fa tmovertool uk.com
2
Speci ication
Type Single Cylinder Piston Compressor
Power 1/6HP
Air Outlet 1/8”
Speed 1450RP
Air Flow 20-23L/min
Auto Stop 4BAR/57PSI
Auto Re-Start 3BAR/43PSI
Pressure Adjustment 0-4BAR
Net Weight 3.6kg
Dimensions 275 x 140 x 220mm
Operation Instructions
- Be ore using this compressor, amiliarise yoursel with it’s design and operation, examine
page 5 to assist you in this.
- Always place the compressor in a convenient position in relation to your work area. Do not pull or
place the airline under strain as this can cause damage and will impede your progress.
- The Standard outlet thread size on this tool is 1/8” BSP. If you need to fit an alternative size
airline connection you will require an adaptor, speak to your stockist for more information.
- Only use compatible Air Hoses to obtain the best working performance, it is recommended that
PTFE tape is used on all connections.
- Connect airline and airbrush before switching the compressor on. The pressure supply is instant
and the gauge will show maximum pressure straight away. You can adjust the working pressure
with the pressure adjustor.
- ake sure that the Auto-Stop function is working as it should. Before starting work allow
compressor to reach maximum pressure. If the Auto-Stop does not work, switch off and check the
pressure gauge. If it falls rapidly then there is an air leak, check all connections and try again.
IMPORTANT
Please read through this Manual carefully before using the FMT18-2
Thi tool mu t only be u ed within the parameter outlined in thi
manual. All u er of the equipment hould be trained in any ri k
a ociated with thi tool
F T18-2_Product Instructions 08/09/2014 13:46 Page 2

- The compressors working pressure is the figure indicated on the pressure gauge when a tool is in
use. This figure will differ with each different airbrush used. An airbrush with a larger nozzle will
use more air than one with a smaller nozzle. Always check the air requirements of any tool before
using it for the first time.
- The bottom of the regulator filter is a water release valve, use this at any time to release any
moisture build-up.
General Sa ety Instructions
- Users must choose the correct air compressor, with suitable air flow and pressure, for the tool and
work requirement.
- Before connecting the compressor, check the main voltage is compatible with the compressor
motor.
- This compressor has suction pad feet. These are design to stop the compressor from sliding
around on a flat, level surface only and are NOT intended for using on angled or vertical surfaces.
- Follow all HSE guidelines on electrical tools and their use as well as your own Electrical Health &
Safety Policy. Always use an earthed electrical supply.
- Switch off compressor before disconnecting airbrush.
- Never leave your compressor exposed to dust, acids vapors, explosive or flammable gases, rain,
sun, fog or snow.
- Ensure all air hoses cannot be twisted, pinched or damaged.
- The compressor cylinder head warms up whilst in use and stays hot after use. Take extreme care
when handling compressor.
- Turn off compressor when not in use or connected to airbrush
- The vacuum pump must be used in a well ventilated environment in temperatures between 5 and
40oC.
- Before moving compressor, disconnect it from the plug socket. NEVER carry it by the power lead.
- DO NOT use this appliance with wet hands or your feet.
- DO NOT allow children to use or play with this tool.
- DO NOT open or tamper with any part of this compressor. Repairs can and must only be carried
out by an authorised service centre.
- Always spray in a well ventilated area.
Electrical Sa ety Instructions
The owner and/or the operator MUST read, understand and comply all points listed below.
- You UST check all electrical products, before use, to ensure that they are safe.
- You UST inspect plugs, sockets, power leads and any other connectors for wear or damage.
- You UST have any worn or damaged plugs, sockets and power leads replaced immediately
upon discovery.
- You UST ensure that the risk of electric shock is minimised by the installation of appropriate
safety devices.
- A Residual Current Circuit Breaker (RCCB) should be incorporated in the main distribution board.
- If no RCCB is fitted, use of a Residual Current Device (RCD) is strongly recommended. If you are
unsure, speak to a qualified electrician and have an RCCB fitted if necessary.
- RCDs are available from most electrical retailers.
- The Electricity at Work Act 1989 requires that all portable electrical appliances, if used on
business premises, to be tested by a qualified electrician, using a Portable Appliance Tester
(PAT), at least once a year.
- The Health & Safety at Work Act 1974 makes owners of electrical appliances responsible for the
safe condition of those appliances and the safety of the appliance operators. If in any doubt about
electrical safety, seek advice from the governing body or independent electrical training providers.
- Ensure that the insulation on all cables and on the appliance are safe and intact before
connecting it to the power supply.
3
Plea e keep thi manual for future reference
Fa t Mover Tool Ltd
Unit 1 French Avenue, Dun table, Bedford hire, LU6 1BH
W: www.fa tmovertool uk.com
F T18-2_Product Instructions 08/09/2014 13:46 Page 3

FMT18-2 Part & In truc"on
Fa t Mover Tool Ltd
T: 01582 661993 F: 01582 667100 E: ale @fa tmovertool uk.com
W: www.fa tmovertool uk.com
4
- Ensure that cables are always protected against short circuit and overload.
- Regularly inspect power supply cables and plugs for wear or damage and check all connections
to ensure that none is loose or damaged.
- Ensure that the voltage rating of the compressor matches your power supply and that the plug is
fitted with the correct fuse.
- Do not yank the plug from the socket as can cause damage to both plug and socket. Any
damage to plugs or sockets is potentially lethal.
- Never carry any electrical tool by it’s power lead.
- If you are using an extension reel, ensure that it is fully unwound and that an RCD is fitted. A
minimum cable core of 1.5mm2is recommended although a core of 2.5mm2will ensure that heavy
loads can be handled. Your extension reel needs to be marked for outdoor use if working outside.
- When the ASTA/BS approved UK 3 pin plug is damaged, cut the cable close to the plug and
dispose of the it safely. Fit a new plug according to the following instructions;
1: Connect the GREEN/YELLOW earth wire to the earth terminal
‘E’.
2: Connect the BROWN live wire to the live terminal ‘L’.
3: Connect the BLUE neutral wire to the neutral terminal ‘N’.
4: After wiring, check that there are no bare wires, that all wires
have been correctly connected, that the cable outer insulation
extends beyond the cable restraint and that the restraint is tight.
The plug fitted to this compressor is fitted with a 13amp fuse.
Double insulated products, which are always marked with this symbol are fitted with live
(brown) and neutral (blue) wires only. To rewire, connect the wires as indicated above but DO NOT
connect either wire to the earth terminal.
F T18-2_Product Instructions 08/09/2014 13:46 Page 4

5
Plea e keep thi manual for future reference
Fa t Mover Tool Ltd
Unit 1 French Avenue, Dun table, Bedford hire, LU6 1BH
W: www.fa tmovertool uk.com
Your Compressor at a Glance
A: Power Plug (non-UK shown)
B: Power Switch
C: Handle
D: Pressure Regulator
E: Pressure Gauge
F: 1/8” Air Outlet
G: Air Filter
Regulator/Filter Operating Instructions
- This is an in-line, low pressure regulator with a 100PSI gauge and
moisture trap. The regulator gives user control over operating
pressure as will suppling clean, dry and regulated are. This
regulator must only be used within the perimeters set out below
Operation
- The gauge (A) reflects the working pressure of the air tool.
- To adjust the working pressure, pull the twist grip (B) up and turn
clockwise to increase pressure and anti-clockwise to decrease it.
- Once the correct pressure is obtained, push to dial down to fix it.
- To release any build-up of moisture, push the release button (C).
A
C
B
F T18-2_Product Instructions 08/09/2014 13:46 Page 5

FMT18-2 Part & In truc"on
Fa t Mover Tool Ltd
T: 01582 661993 F: 01582 667100 E: ale @fa tmovertool uk.com
W: www.fa tmovertool uk.com
6
Ref. Code Description Q’ty
1 F T18-2/1 Power Switch 1
2 F T18-2/2 Front Cover 1
3 F T18-2/3 Wire & Plug (Non-UK Shown) 1
4 F T18-2/4 Condenser 1
5 F T18-2/5 Rear Body 1
6 F T18-2/6 Screw 4
7 F T18-2/7 otor 1
8 F T18-2/8 Bearing 1
9 F T18-2/9 Rotary otor 1
10 F T18-2/10 Bearing 1
11 F T18-2/11 Rubber Pad 4
12 F T18-2/12 Front Cover 1
13 F T18-2/13 O-Ring 1
14 F T18-2/14 Cylinder Block 1
15 F T18-2/15 O-Ring 1
16 F T18-2/16 Gasket 1
17 F T18-2/17 Pressure Switch 1
18 F T18-2/18 Handle 1
19 F T18-2/19 Screw 4
20 F T18-2/20 Cylinder Head 1
21 F T18-2/21 Connector 1
22 F T18-2/22 Filter Valve 1
23 F T18-2/23 Connector 1
24 F T18-2/24 Counterweight 1
25 F T18-2/25 Bearing 1
Ref. Code Description Q’ty
26 F T18-2/26 Link 1
27 F T18-2/27 Snap Ring 1
28 F T18-2/28 Compression Ring 1
29 F T18-2/29 Block 1
30 F T18-2/30 Valve Plate 1
31 F T18-2/31 Screw 1
32 F T18-2/32 Cylinder 1
33 F T18-2/33 Front Cover 1
Parts Diagram
75mm ini Air Operated Sander
F T18-2_Product Instructions 08/09/2014 13:46 Page 6

7
Plea e keep thi manual for future reference
Fa t Mover Tool Ltd
Unit 1 French Avenue, Dun table, Bedford hire, LU6 1BH
W: www.fa tmovertool uk.com
Warranty
We hope that you will be very happy with your purchase. If you do have a problem with your tool,
you have the added peace of mind of a 6month warranty, which comes into date from the date of
purchase (proof of purchase required).
Scope o Warranty
- The warranty will cover you from all faults cause by defective components or poor workmanship.
- Tools sent outside the EU are not covered by this warranty.
- Product must be returned to us, the warranty does not cover cost of carriage.
- If the product is no longer in manufacture, it will be replaced with a tool of equivalent or higher
specification.
What is not covered
- Normal wear and tear caused by use in accordance with the operating instructions.
- Replacement of any provided accessories, such as Backing Pads, Airline Connections, Air
Fittings, Blades, Spanners, etc.
- Accidental damage, faults caused by negligent use or care, neglect, misuse or careless operation,
handling and storage of the product.
- odification of, or change of, any part of this product in any way.
- Faults caused by use of non compatible accessories.
- Tool seizure caused by insufficient oiling.
- Faults caused by incorrect installation.
- Repairs or alterations carried out by non-approved parties.
- Traced of water or rust inside tool - this shows that a properly working air filter has not been used.
Validity
- This warranty is valid for 6 months after date of purchase.
- Warranty is rendered invalid if;
- Tool is taken apart for any reason without our consent.
- Tool is not oiled daily.
- Air supply line is not used with a properly working air filter.
- A warranty claim will not be accepted without an official proof of purchase from your supplier.
Use ul Links
F T18-2 Product Page
www.fastmovertoolsuk.com/F T18-2
View the latest information and
download the latest product manual.
ain Website
www.fastmovertoolsuk.com
You can view all our current
range here as well as
download offers and product
technical information.
F T18-2_Product Instructions 08/09/2014 13:46 Page 7

FMT18-2 Part & In truc"on
Fa t Mover Tool Ltd
T: 01582 661993 F: 01582 667100 E: ale @fa tmovertool uk.com
W: www.fa tmovertool uk.com
8
Waste Electronic and Electrical Equipment (WEEE) Regulations
Dispose of this equipment in accordance with WEEE Regulations
This item should not be put in household waste bins. Ask for a list of authorised
commercial electrical disposal organisations.
Fast over Tools care for the environment, please dispose of packaging in a responsible
way.
Declaration o Con ormity
We declare that the equipment detail below, to the best of our knowledge and
ability, complies with the following Directive.
achinery Directive - 2006/42/EC and amending Directives
Restriction of the Use of certain Hazardous Substances in Electrical and Electronic Equipment
(RoHS) - 2002/95/EC
Equipment Description 1/6HP ini Air Compressor
Part Code F T18-2
Distributed in the EU by Fast over Tools Ltd
Address Unit 1 Frenchs Avenue
Dunstable
Bedfordshire
LU6 1BH
United Kingdom
The following Transposed Harmonised Standards have been applied in the
design and construction of this equipment:
BS EN 1012-1:2012 Compressors and vacuum pumps. Safety requirements.
Air Compressors
BS EN 60204-1:2006 a1:2009 Safety of machinery. Electrical equipment of machines.
General requirements
BS EN 61000-6-1:2007 Electromagnetic compatibility (E C). Generic standards.
Immunity for residential, commercial and light-industrial
environments
BS EN 61000-6-3:2007+A1:2011 Electromagnetic compatibility (E C). Generic standards.
Emission standard for residential, commercial and
light-industrial environments
The manufacturer and the distributor, stated above, hold the Technical Construction File for this
equipment.
Signed on behalf of the distributor
(the responsible person) …………………………………………
Name: Brian offitt
Position: Director
Date and Place: 20/03/2014, Dunstable, UK
F T18-2_Product Instructions 08/09/2014 13:46 Page 8
