Ozito MACK-300 User manual

0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
AIRBRUSH & MINI
COMPRESSOR KIT
3L 105W
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 220–240V ~ 50Hz
Power: 105W
Tank Capacity: 3L
No Load Speed: 1,400/min
Max. Pressure: 4bar (58psi)
Auto Cut-In Pressure: 3bar (43.5psi)
Flow Rate: 15L/min
Weight: 5.32kg
MACK-300
STANDARD EQUIPMENT
IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
3 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 36 months from
the original date of purchase. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: valve adapters
and accessories.
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benefits provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major
failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the
failure does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suffered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer
service helpline above.
ozito.com.au
3L Mini Air Compressor
Airbrush
1.8m Air Hose, Airbrush Holder &
Spanner
Paint Cup & 2 x Paint Pots
0320

ONLINE MANUAL
Scan this QR Code with
your mobile device to take
you to the online manual.
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
Connecting The Airbrush To The Compressor
1. Attach one end of the air hose
to the compressor air outlet.
2. Attach the other end of the air
hose to the airbrush air inlet.
Installing A Paint Pot To The Airbrush
1. Attach the lid with the intake nozzle
securely to the paint pot.
2. Push the intake nozzle securely into
the paint inlet of the airbrush.
Note: Alternatively the paint cup can also
be attached for small paint jobs. To avoid
accidental spillage, do not ll the paint cup
more than 60% and adjust the cup position
as required.
Hanging Hook
The provided hanging hook can be used to rest the airbrush if you
need to pause midway through airbrushing.
1. Attach the hanging hook to a wall using 2 screws (not supplied).
2. Place the airbrush on the hanging
hook when not in use.
1. Safety Relief Valve
2. On/O󰀨 Switch
3. Pressure Regulator Dial
4. Air Outlet
5. Pressure Gauge
6. Moisture Trap
7. Rubber Feet
8. Drain Valve
9. Air Tank
10.Motor
11. Carry Handle
MINI AIR COMPRESSOR
AIRBRUSH
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
12.Nozzle Cap
13.Tip Protector
14.Paint Regulator Screw
15.Variable Trigger
16.Barrel Housing
17.Air Inlet
18.Paint Inlet
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
11
12 13 14 15 16
1
5
4
3
6
7
2
9
10
18 17
8
WARNING! ENSURE THE TOOL IS TURNED OFF
AND DISCONNECTED FROM THE POWER SUPPLY
BEFORE PERFORMING ANY OF THE FOLLOWING
OPERATIONS.

Thinning Paints
Surface preparation and proper paint thinning are the two most
important steps for best results. Ensure all surfaces are free of dust,
dirt and grease.
The airbrush kit comes with a spare
paint pot and lid that can be used for
mixing or thinning the paint until the
desired colour and viscosity is achieved.
Follow the paint manufacturer’s guide
for thinning and mixing ratios. Use
the appropriate thinning agent for paints.
Water based paints can be thinned using water.
1. Before mixing any paint or thinners, work out how much of each
substance is needed.
2. Pour the required amount of
paint into the paint pot.
3. Pour the necessary amount of
thinner into the paint pot.
4. Thoroughly mix the paint and thinning
agent in the paint pot and then attach
the lid securely.
Note: Refer to the troubleshooting section if there are issues with the
paint spread.
Variable Trigger
1. Press and hold the variable trigger down.
This allows air to start owing through the
airbrush.
2. Pull the variable trigger backwards to
allow paint to be sprayed.
Note: The further back the variable
trigger is pulled, the more paint is
sprayed out of the airbrush.
3. Release the variable paint trigger to stop spraying.
Paint Regulator Screw
The paint regulator screw is a stop that holds the variable trigger
backwards. This allows a set amount of paint to be sprayed when the
trigger is depressed.
1. Loosen the regulator screw entirely for
full control over the amount of paint
sprayed.
2. Tighten the regulator screw until the
desired amount of paint is ejected
when the trigger is pressed down.
Note: Always test spray on a scrap piece of material every time an
adjustment is made to the settings.
Paint Pot Vent Hole
The paint pot lid with the intake nozzle
has a vent hole which allows air into
the pot. This enables uid to ow into
the airbrush. Ensure it is clean and not
blocked.
Nozzle Cap
Push the cap over the nozzle of the airbrush
when not in use to protect it.
Note: Avoid rotating the nozzle cap when
removing it, as this may unscrew the nozzle.
2. PAINT PREPARATION 3. AIRBRUSH
OPERATION
PAINT
THINNER
WARNING! THE AIRBRUSH CANNOT BE USED WITH
MATERIALS CONTAINING ABRASIVE SUBSTANCES,
GLAZES, CAUSTIC AND/OR ALKALINE
SUBSTANCES.

Starting The Air Compressor
1. Press the on/o󰀨 switch to the ‘I’
position to start the compressor.
Note: The air compressor is designed to
turn o󰀨 at 4bar and turn on when the air
pressure drops to 3bar.
2. To stop the unit, press the on/o󰀨 switch to the ‘0’ position.
WARNING! COMPRESSED AIR IS DANGEROUS.
NEVER POINT THE AIR OUTLET OF CONNECTED
ACCESSORIES AT ANY PART OF YOUR BODY OR
OTHER PEOPLE AND ANIMALS.
Checking The Safety Relief Valve
The safety relief valve has been set for the highest permitted
pressure of the tank. It is prohibited to adjust the safety relief valve or
to remove its seal. Check that the safety relief valve is in working
order before every use.
WARNING! WEAR SAFETY GLASSES AND EAR
PROTECTION. KEEP YOUR FACE AWAY FROM THE
SAFETY VALVE WHEN CARRYING OUT THIS CHECK.
AIR WILL BE DISCHARGED AT HIGH PRESSURE.
DO NOT USE THE COMPRESSOR IF THE SAFETY
VALVE DOES NOT WORK AS DESCRIBED.
1. Turn the compressor on and let it run
until the switch o󰀨 pressure (4bar) is
reached.
2. Hold the ring on the safety relief
valve and pull it outwards. Air
should discharge from the valve.
3. When the ring on the safety relief valve is released, the air
discharge should stop.
Adjusting The Pressure
The airbrush has an operating pressure between 1-4bar. The
compressor pressure needs to be adjusted to suit this before
operating the airbrush.
The correct air pressure between this operating range will produce an
even spray pattern with little to no splatter.
1. Once the air compressor is switched
on, the pressure gauge will show the
regulated air pressure.
2. Lift the pressure regulator dial to
unlock it.
3. Perform a test spray onto a
scrap piece of material and
rotate the pressure regulator
dial until the desired setting
is achieved. Turning the dial
clockwise will increase the air
pressure, whilst turning it anti-
clockwise will decrease the air
pressure.
4. Keep adjusting the pressure regulator
dial until an even spray pattern with
little to no paint splatter is achieved.
5. Once the desired pressure is set,
press the regulator dial down and
twist it clockwise slightly to lock it in
position.
4. COMPRESSOR CONTROLS
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
a.
b.
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²
I
0
I
0
WARNING! THE POWER SUPPLY FOR THIS
PRODUCT SHOULD BE PROTECTED BY A
RESIDUAL CURRENT DEVICE (RATED AT 30mA OR
LESS).
WARNING! HOUSING SURFACE MAY GET HOT
DURING USE. DO NOT TOUCH THE HOUSING WHEN
HOT, ONLY HANDLE USING THE CARRY HANDLE
PROVIDED.

Painting Tips
1. Start spraying just before the start of the paint area and end just
after to ensure a consistent spray on the edges. Mask o󰀨 any
areas that you don’t want painted.
2. Move the spray gun along the surface at a steady pace whilst
maintaining the distance and angle to ensure an even coverage.
3. Overlap each pass over the paint area to achieve an even coating.
4. Airbrushing also has a range of techniques to obtain di󰀨erent
e󰀨ects. Below are some basic e󰀨ects which can be achieved by
varying the painting motion and distance from the workpiece.
Varying The Distance
Positioning the airbrush close
to the workpiece will produce a
small dense spray pattern.
Moving the airbrush further away
from the workpiece produces a
wide, faint pattern.
Angling The Airbrush
Holding the airbrush at an angle
to the workpiece produces a fan
shaped spray.
MACK-300
5. AIRBRUSHING TECHNIQUE 6. TROUBLESHOOTING
WARNING! THE AIRBRUSH MUST BE CLEANED
AFTER EACH USE TO PREVENT IT GETTING
CLOGGED. PLEASE REFER TO THE MAINTENANCE
SECTION. FAILURE TO CLEAN IT AFTER USE WILL
VOID THE WARRANTY.
Symptom Possible Cause Suggested Solution
The
compressor is
overheating
The air vents may be
obstructed, restricting
air ow.
Ensure the air vents are
free from obstructions.
Little or no
material ow Nozzle may be clogged. Clean the nozzle
Paint pot vent hole may
be blocked Clean the paint pot lid
Paint too thick Follow directions for
thinning the paint.
Spray pattern
is heavy in the
middle
Nozzle clogged Clean the nozzle
Not enough atomising
pressure
Increase the air
pressure by adjusting
the pressure regulator
dial
Spray pattern
is too wide and
misty Too much atomising
pressure
Decrease the air
pressure by adjusting
the pressure regulator
dial
Spray jet
pulsates
Material in paint pot
running out Rell the paint
Nozzle clogged Clean or replace the
nozzle
Material is too thick Follow directions for
thinning the paint.
Pattern runs or
sags Applying too much
material
Pull the variable trigger
back less or increase
movement speed of the
airbrush
Too much over
spray Gun too far from spray
object
Hold the airbrush closer
to workpiece
Too much atomising
pressure
Decrease the air
pressure by adjusting
the pressure regulator
dial
Pattern is very
light & splotchy Moving the airbrush too
fast
Pull the variable trigger
back further or decrease
movement speed of the
airbrush

Cleaning The Airbrush
Follow the procedure below when changing between di󰀨erent paints
and spray materials.
1. Remove the paint pot from the
airbrush, then empty and remove any
remaining paint.
2. Fill the paint pot with the appropriate
solvent; water for water based paints
and the appropriate cleaning solution
for oil based paints.
Note: Read the cleaning instructions provided by the paint
manufacturer to determine the appropriate cleaning solvent.
WARNING! ALWAYS READ AND FOLLOW THE
MANUFACTURER’S INSTRUCTIONS FOR HANDLING
AND USE OF THE SOLVENTS. SOME SOLVENTS
MAY BE TOXIC AND APPROPRIATE SAFETY
MEASURES MUST BE STRICTLY FOLLOWED TO
AVOID SAFETY HAZARDS.
WARNING! KEEP THE TOOL AWAY FROM CHILDREN.
SMALL PARTS ON THE TOOL CAN BE SWALLOWED
AND POSE A SERIOUS SAFETY HAZARD.
3. Re-attach the paint pot to the airbrush.
4. Switch on the air compressor
and spray the solvent through
the airbrush onto a scrap
piece of material.
5. Repeat steps 2-4 until the
solvent sprayed out of the
airbrush runs clear.
6. Switch o󰀨 the air compressor, remove
the paint pot and rinse it out with the
appropriate solvent.
Note: Do not pour solvent or contaminated water down the drain as
doing so could pollute our water system. Always dispose of waste
material in an appropriate and responsible manner. Always refer to
paint manufacturer’s guide for correct disposal methods.
Cleaning The Airbrush for Storage
Perform the procedure below when you have nished airbrushing
before putting the tool away.
1. Remove the barrel housing and needle lock.
2. Disassemble the tip protector and nozzle with the supplied spanner.
Clean these parts with the appropriate solvent.
3. Pull the needle through the front of the airbrush. Clean the needle
with the appropriate solvent.
WARNING! THE NEEDLE IS VERY SHARP. BE
CAREFUL NOT TO INJURE YOURSELF.
WARNING! DO NOT DAMAGE THE NEEDLE AS
THIS WILL AFFECT THE PERFORMANCE OF THE
AIRBRUSH AND QUALITY OF THE OUTPUT.
4. Remove and clean the rest of the barrel parts.
5. Once the parts are dry and clean of paint, reassemble the airbrush
and replace the nozzle cap before storing.
Note: When re-assembling, attach the remaining barrel parts, the tip
protector and nozzle rst, then push the needle into the barrel from
the rear until the sharp end is ush with the nozzle. There is a hole
in the stem of the trigger; the needle should pass through this during
re-assembly.
General Cleaning & Maintenance
1. We recommend that you clean the appliance immediately after you
use it.
2. Keep the safety devices free of dirt and dust as much as possible.
Wipe the equipment with a clean cloth.
3. Clean the appliance regularly with a damp cloth and some soft
soap. Do not use cleaning agents or solvents; these may be
aggressive to the plastic parts in the appliance. Ensure that no
water can get into the interior of the appliance.
MAINTENANCE
WARNING! BEFORE CLEANING THE TOOL OR
CARRYING OUT ANY MAINTENANCE PROCEDURE,
MAKE SURE THAT IT IS DISCONNECTED FROM
THE POWER SUPPLY TO PREVENT ACCIDENTAL
STARTING.
WARNING! IT IS ESSENTIAL TO CLEAN THE
AIRBRUSH THOROUGHLY AFTER EACH USE.
DRIED PAINT CAN CAUSE BLOCKAGES THAT WILL
PREVENT THE TOOL FROM WORKING. FAILURE
TO CLEAN THE TOOL AFTER EACH USE WILL VOID
THE WARRANTY.
I
0

Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check
with your local council authority for recycling advice.
Recycling packaging reduces the need for landll and raw
materials. Reuse of recycled material decreases pollution in
the environment. Please recycle packaging where facilities
exist. Check with your local council authority for recycling
advice.
DESCRIPTION OF SYMBOLS
CARING FOR THE ENVIRONMENT
SPARE PARTS
Draining The Compressor Tank
Air in the compressor tank causes water to accumulate. This must be
drained o󰀨 frequently to prevent corrosion and damage to the unit.
This should be performed after each use and prior to the next
use.
1. With the compressor turned
o󰀨, point the airbrush nozzle
away from people and pull the
trigger to release any leftover
compressed air in the tank.
2. Once no more air is released
from the airbrush nozzle,
unscrew the plug from the
drain valve to release any
water from the tank.
3. Allow the tank to drain completely before replacing the drain valve
plug.
Note: Ensure the drain valve plug is replaced correctly and tightened
fully before using the air compressor again.
WARNING! RELEASE ALL AIR PRESSURE FROM
THE TANK BEFORE OPENING THE DRAIN VALVE.
TAKE CARE WHEN DISCHARGING AIR THROUGH
THE AIR OUTLETS. THE DISCHARGED AIR CAN
CAUSE DUST, STONES, OR ANY OTHER FOREIGN
PARTICLES TO BE BLOWN THROUGH THE AIR AT
HIGH PRESSURE.
Storage
Pull the mains plug out of the socket, switch o󰀨 the tool and make
sure that it is secured in such a way that it cannot be started up again
by any unauthorised person.
Store the tool in a dry location which is not accessible to unauthorised
persons.
Supply Cords
If replacement of the supply cord is necessary, this has to be done by
the manufacturer or his agent in order to avoid a safety hazard.
Note: Ozito Industries will not be responsible for any damage or
injuries caused by the repair of the tool by an unauthorised person or
by mishandling of the tool.
Wear eye, ear & breathing
protection
Pressure rating
Warning
Regulatory Compliance Mark
(RCM)
Do not expose to rain
VVolts Hz
W
Hertz
~
n0
/min
Alternating Current Watts
No load speed
Revolutions or reciprocations
per minute
barL/min Litres per minute
Read Instruction Manual
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito Customer Service:
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
0
25
50
75
100
125
150
0
(1)00
(3)00
(5)00
(7)00
(9)00
2
46
8
10
Lb/in²
(PSI)
kPA
(BAR)
PRESSUREGAUGE
kg/cm²

WARNING! When using mains-powered tools, basic safety precautions, including the
following, should always be followed to reduce risk of re, electric shock, personal injury and
material damage.
Read the whole manual carefully and make sure you know how to switch the tool o󰀨 in an emergency,
before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The charger has been designed for 230V and 240V only. Always check that the power supply corresponds
to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand.
If the replacement of the supply cord is necessary, this has to be done by the manufacturer or his agent in
order to avoid a safety hazard.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect the
extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged or defective.
When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead
not suitable for the power input of the tool or which is damaged or defective may result in a risk of re and
electric shock.
The power supply for this products charger should be protected by a residual current device (rated at
30mA or less). A residual current device reduces the risk of electric shock.
WARNING! The appliance is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction.
Young children should be supervised to ensure that they do not play with the appliance.
• The tool must be used only for its prescribed purpose. Any use other than those mentioned in this
Manual will be considered a case of misuse. The user and not the manufacturer shall be liable for any
damage or injury resulting from such cases of misuse.
• NEVER under any circumstances aim the Air brush at another person or animal.
• In the event of an injury occurring, seek medical advice immediately.
• The spray gun must not be used for spraying ammable paints and solvents with a ash point of less
than 21ºC.
• Be certain to read all the labels on the containers of paint or other materials to be sprayed. Closely
follow all safety instructions. Use a respirator mask if there is a chance that you might otherwise inhale
the spray material. Carefully check the e󰀨ectiveness of any respirator mask you intend using.
• Always ensure there is adequate ventilation when spraying.
• The use of ear protection is recommended.
• Eye protection should be used to keep hazardous vapours and liquids out of eyes.
• Always wear a face mask when spraying.
• Always read the paint manufacturers thinning instructions before using.
• Always keep the spray nozzle in place during use. Never allow the spray to come in direct contact with
the skin.
• To reduce the risk of re or explosion, never spray ammable liquids in a conned area. If sparks come
into contact with petrol vapours or solvents, they may ignite the vapours and cause a re or explosion.
• Never immerse the airbrush or air compressor in liquid.
• NEVER spray near a naked ame, including an appliance pilot light.
• NEVER smoke whilst spraying.
• NEVER allow children to operate or play with the air brush or compressor.
• Always remove the plug from the mains socket before making any cleaning, adjustments or performing
maintenance.
• After every use ensure you clean your air brush thoroughly.
• NEVER use the air brush or compressor outside when it is raining.
• Protect the plug and the power cable from heat, oil or sharp edges.
• If damaged, The power cable must be replaced by a qualied electrician.
• The electrical connection must always be made in a dry area. Make sure that electrical connections
are protected from inundations.
• Before using the compressor, always inspect it visually. Do not use the compressor if it is cracked and/
or damaged. If the compressor is damaged, contact Ozito customer service.
• Always use the handle to move the compressor.
• Never let the compressor come into contact with water or other liquids, as the appliance is live, this
could cause electrocution or short-circuits. Never use the appliance with bare feet, wet hands or wet
feet.
• Never pull on the power cable to disconnect the plug from the power outlet or to move the compressor.
• Do not leave unattended and operating.
• The compressed air produced by the compressor cannot not be used for pharmaceutical, food or
medical purposes or to ll the air bottles of scuba divers.
• Do not cover the air inlets on the compressor or the compressor at any time.
• Compressors and lines may reach high temperatures during operation. Avoid contact! Risk of burns!
Allow hot parts to cool before handling or servicing.
• Keep the compressor at least 300mm from the nearest wall to ensure adequate ventilation for cooling
purposes.
• Protect the air hose and cord set from damage. Inspect for weak or worn spots regularly and replace
if necessary.
• Always switch o󰀨 the compressor before switching o󰀨 the power or removing the power plug.
• After using the compressor, switch o󰀨 the on/o󰀨 button, disconnect the power supply and release any
remaining pressure.
• Do not attempt to remove any part of the machine whilst it is under pressure.
• Check the maximum pressure rating of any tools or accessories that you intend to use with the
compressor. The output pressure of the air from the compressor must be regulated so that it never
exceeds the rated pressure of the tool or accessory.
• Do not attempt to block the air outlet with any part of your body or object.
• Drain the moisture from the tank after use. It will help prevent corrosion.
• Always refer to the paint manufacturers guide for correct disposal methods.
• The tool must be used only for its prescribed purpose. Any use other than those mentioned in this
Manual will be considered a case of misuse. The user and not the manufacturer shall be liable for any
damage or injury resulting from such cases of misuse.
• The manufacturer shall not be liable for any changes made to the tool nor for any damage resulting
from such changes.
• Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The
following hazards may arise in connection with the tool’s construction and design:
• Damage to the lungs if an e󰀨ective breathing mask is not worn.
• Damage to hearing if e󰀨ective earmu󰀨s are not worn.
• Damage to the eyes if e󰀨ective safety goggles or shield are not worn.
WARNING! In the event that an air line is cut or broken, the air supply must be
turned o󰀨 at the compressor. A broken air line which is not supported is extremely
dangerous and can whip around very quickly, both with the capability of striking people,
and blowing foreign particles into the air.
• Do not attempt to catch the air line but immediately keep bystanders well clear and turn o󰀨 the air
supply to the hose, turn o󰀨 the compressor at the On / O󰀨 button, and then remove the hose from the
compressor.
• Do not aim the airbrush at the air compressor.
• Always check safety release valve before use.
AIR COMPRESSOR SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool” in the warnings
refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you to
lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the
risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase
the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use a power tool while you are tired or under the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools may result in serious personal injury.
b.Use personal protective equipment. Always wear eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the o󰀨-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct power
tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and o󰀨. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool before
making any adjustments, changing accessories, or storing power tools. Such preventive safety
measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool. Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any
other condition that may a󰀨ect the power tool’s operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for
operations di󰀨erent from those intended could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
