Fast Mover FMT6800 Series User manual

Fast Mover Tools
FMT6800 SERIES
Additional Information
The FMT6800 series should provide years of trouble free service,
however, to ensure maximum benefit from your machine it should be
treated with care, kept dry, cleaned, and electrically tested on a regular
basis. Any worn or damaged parts should be replaced immediately. To
assist we have provided a list of the main spares available to order.
All parts may be ordered through your local distributor.
The full range of Infrared products can be found on
www.fastmovertoolsuk.com
This product conforms to EU Directive 2002/96/EC.
This appliance bears the symbol of the crossed waste bin. This
indicates that, at the end of its useful life,it must not be disposed
of as domestic waste, but must be taken to a collection center for
waste electrical and electronic equipment. It is the user's
responsibility to dispose of this appliance through the
appropriate channels at the end of its useful life. Failure to do so
may incur the penalties established by laws governing waste
disposal.
FMT6800 SERIES
Hand Held & Static Short wave
Paint Drying Systems
The HLP1000 Series consists of the following models.
FMT6800 - Hand Held Heater/Dryer
FMT6800S - Hand Held Heater/Dryer + 5Part Stand
FMT6800T - 2 x Hand Held Heater/Dryers + 5Part Stand
FMT6900-TIMER- 0/60Min Timer for HLP1000S/HLP1000T models
only
Fast Mover Tools Ltd
Unit 1, Frenchs Avenue
Dunstable, Bedfordshire, LU6 1BH, UK
Tel: [phone]
Fax: [phone]
www.fastmovertoolsuk.com
Email - [e-mail]
Part No.
Description
415790
LAMP REFLECTOR
415795
END REFLECTOR
991511
GUARD
410059
ON/OFF SWITCH
64241072
1KW 220/240V GOLD POWERSLIM QUARTZ LAMP
64121033
1kW 110/120V POWERSLIM QUARTZ LAMP
410061
TIMER PLUG

USER INFORMATION
This model has been designed and developed to assist with any number of
small drying processes, and is ideal for spot repairs, engine drying, adhesive
stripe removal, drying filler, primer, or just preheating prior to spraying.
It may be used as a stand-alone system, when fitted to the slide and lock bracket
on the separately available 5 Piece lightweight stand, or as a source of instant
direct heat, when used as a hand held. A mechanical timer is also available to
help ensure correct drying times.
Fitted with the powerful 1KW Gold Powerslim short wave infrared lamp - instant
direct heat can be directed wherever and whenever it may be required.
To ensure long lamp life do not drop or subject the fitting to large amounts of
vibration when lamp is lit.
Assembly Instructions
The FMT6800 Hand held unit has been packed with a separate handle and
lamp ready for attachment and fitting to the heater. Please leave the lamp in
transit packing until ready to fit.
Place the fitting lamp down with the cable and switch at the bottom of the
cassette on a flat surface. The handle should be attached to the main unit by
means of the bolt supplied, ensuring the spacer provided is fitted between the
two fixing posts of the heater. Please ensure the star washer is fitted under the
head of the bolt, then fully tighten to secure, the pre made hole in the grip of the
handle should be at the bottom of heater. If correct fitted you will be able to tilt
the body of the heater in a downward direction only with the cable and switch
at the bottom.
Lamp Fitting
Remove the first two screws from one end of an end reflector, this will release
the guard and expose one of the lamp terminal end posts. Now remove the end
reflector from the opposite end of the cassette, exposing the other lamp
terminal. Release the nuts on the exposed terminal end posts just enough to
allow the fork terminals of the lamp leads to be pushed under the washer and
nut provided. Carefully remove the lamp from its packing, holding it by the
porcelain end caps only, taking care not to handle the quartz glass. Now
carefully insert the end caps of the lamp under the spring retaining clips of the
heater. The fork terminals on each end of the lamp should now be inserted
under the washer/nuts of the lamp end posts and tightened to make a good
connection. The lamp leads should then be tucked away around the space at
each end of the heater. Now replace the end reflectors and grill to complete the
assembly.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR YOUR SOCKET OUTLET
THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND
DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK
IF THE CUT OFF PLUG IS INSERTED INTO ANY 13 AMP SOCKET.
If a new plug is to be fitted please observe the wiring code as shown below. If
in any doubt please consult a qualified electrician.
WARNING: THIS APPLIANCE MUST BE EARTHED.
The wires in this mains lead are coloured in accordance with the following code-
Green and Yellow - Earth Blue - Neutral Brown - Live
As the colours of the wire in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as
follows.
The wire which is coloured GREEN AND YELLOW must be connected to the
terminal in the plug which is marked with the letter E or by the Earth symbol or
coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal in the plug
which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal in the
plug which is marked with the letter L or coloured RED.
SAFETY TIPS
Please check rating label to ensure correct VOLTAGE before connection to any
main supply.
When used with a stand please observe a Static Safety Distance of 500mm
(20inches) between the heater and any object .
Always unplug before removing any cover or guard, also before cleaning or
maintenance is carried out.
IF YOUR HEATER / DRYER IS NOT FITTED WITH A TIMER - IT SHOULD NEVER
BE LEFT UNATTENDED DURING THE DRYING PROCESS
THIS MODEL IS AVAILABLE IN 1KW -110-120V AND
1KW –220-240V
PLEASE CHECK VOLTAGE LABEL PRIOR TO USE
