Fast 9553P User manual

9553P / 9573P – 60' - 100'
3PT SPRAYER
OWNER’S MANUAL

820103 9553P / 9573P – 60' - 100' 3PT Sprayer 2023-11-30

Table of Contents 3PT Sprayer 9553P / 9573P Page 3
Table of Contents
Section
Page
Table of Contents...................................................................................................................................................3
Warranty Registraon............................................................................................................................................9
Warranty Inspecon Report ......................................................................................................................................9
Inspecons ..........................................................................................................................................................11
Pre-Delivery .............................................................................................................................................................11
Delivery ...................................................................................................................................................................12
Aer-Sale.................................................................................................................................................................13
Serial Number Locaon........................................................................................................................................ 14
Owner Register....................................................................................................................................................15
Foreword to the Owner ....................................................................................................................................... 16
INTRODUCTION ................................................................................................................................................... 18
Machine Components .............................................................................................................................................19
Fence Row Nozzles...................................................................................................................................................20
Boom Auto-Leveling ................................................................................................................................................20
Boom Auto-Height...................................................................................................................................................20
SAFETY................................................................................................................................................................. 21
Safety Alert Symbols and Signal Words...................................................................................................................21
General Safety.........................................................................................................................................................22
Prepare for Emergencies.....................................................................................................................................22
Wear Protecve Clothing ....................................................................................................................................22
Protect Against Noise..........................................................................................................................................22
Pracce Safe Maintenance..................................................................................................................................22
Support Raised Equipment .................................................................................................................................23
Avoid Heang Near Pressurized Fluid Lines........................................................................................................23
Avoid High-Pressure Fluids..................................................................................................................................23
Inspect Li Circuit Hoses.....................................................................................................................................24
Store Aachments Safely....................................................................................................................................24
Electrical..............................................................................................................................................................24
Service Tires Safely..............................................................................................................................................24
Dispose of Waste Properly..................................................................................................................................25
Handle Agricultural Chemicals Safely..................................................................................................................25
Reduce risk of exposure and injury:....................................................................................................................25
Handle Chemical Products Safely........................................................................................................................26
Operate Hydraulics Safely ...................................................................................................................................26

Table of Contents 3PT Sprayer 9553P / 9573P Page 4
Use Safety Lights and Devices.............................................................................................................................27
Keep Riders O Machine.....................................................................................................................................27
Observe Maximum Transport Speed ..................................................................................................................27
EC Compliance Nocaon.................................................................................................................................28
Use a Signal Person.............................................................................................................................................28
Tow Loads Safely .................................................................................................................................................28
Avoid Overhead Power Lines ..............................................................................................................................29
Prepare for Transport..........................................................................................................................................29
Transport Safely ..................................................................................................................................................30
Chemical Safety.......................................................................................................................................................30
Personal Protecon.............................................................................................................................................30
Diluon................................................................................................................................................................31
Storage ................................................................................................................................................................31
Replace Safety Signs................................................................................................................................................32
Wing....................................................................................................................................................................32
Main Frame.........................................................................................................................................................34
Tanks and Plaorm..............................................................................................................................................36
Safety Features........................................................................................................................................................37
Sign-O Form ..........................................................................................................................................................38
SPECIFICATIONS ................................................................................................................................................... 39
Tractor Power, Size Recommendaon .....................................................................................................................39
Hydraulic System Requirements..............................................................................................................................39
Machine Dimensions & Specicaons.....................................................................................................................39
PREPARING THE MACHINE ...................................................................................................................................40
Use the Tractor Operator’s Manual.........................................................................................................................40
Break-In ...................................................................................................................................................................40
Pre-Operaon Checklist...........................................................................................................................................41
CONTROLS ...........................................................................................................................................................42
Spray Circuit Controller ...........................................................................................................................................42
Chemical Circuit Controls ........................................................................................................................................42
Boom Funcon Control Box .....................................................................................................................................42
CONTROLLER INSTALLATION ................................................................................................................................ 44
Spray Circuit Controller ...........................................................................................................................................44
Boom Funcon Control Box .....................................................................................................................................44
Foam Marker Switch (Oponal) ..............................................................................................................................44
ATTACHING and DETACHING ................................................................................................................................ 45
Aach the Machine Safely.......................................................................................................................................45
Aach the Machine to the Tractor ..........................................................................................................................45

Table of Contents 3PT Sprayer 9553P / 9573P Page 5
Aach Warning Light Plug.......................................................................................................................................45
Connect Rate Controller or Nutrient Applicator System Wiring ..............................................................................46
Make Proper Hose Connecons...............................................................................................................................46
SCV Idencaon Chart...........................................................................................................................................47
TRANSPORTING ................................................................................................................................................... 48
Following Safe Transport Procedures ......................................................................................................................48
Preparing the Machine for Transport......................................................................................................................48
Fold Toolbar for Transport...................................................................................................................................48
Transport Notes and Checks ...............................................................................................................................49
Transporng the Machine .......................................................................................................................................49
Using Warning Lights ..........................................................................................................................................49
Keep Riders O the Machine ..............................................................................................................................49
Cauon for All Machines .........................................................................................................................................50
Unfolding/Extending the Boom...............................................................................................................................50
HYDRAULIC FLOW ................................................................................................................................................52
Regulang Hydraulic Flow to the Pump ..................................................................................................................52
Load Sensing Closed Center System (LS Closed) .................................................................................................52
Pressure Compensang Closed-Center System (PC Closed) ...............................................................................52
Open Center System (Open) ...............................................................................................................................53
Tractor SCV Funcons..............................................................................................................................................54
SPRAYER CALIBRATION ........................................................................................................................................55
Set Engine RPM .......................................................................................................................................................55
Controller Calibraon ..............................................................................................................................................55
Nozzle Calibraon ...................................................................................................................................................55
Machine Yard Calibraon........................................................................................................................................56
Ground Speed Calibraon .......................................................................................................................................56
Area Coverage.....................................................................................................................................................57
Field Calibraon ......................................................................................................................................................57
ADJUST GROUND SPEED ......................................................................................................................................60
For broadcast spraying............................................................................................................................................60
For row crop spraying..............................................................................................................................................60
PREPARING THE LIQUID SYSTEM..........................................................................................................................61
Clean Strainer Filter.................................................................................................................................................61
FILLING THE TANK ................................................................................................................................................62
Filling the Product Tank...........................................................................................................................................62

Table of Contents 3PT Sprayer 9553P / 9573P Page 6
Filling Fresh Water Rinse Tank.................................................................................................................................62
CHEMICAL EDUCTOR............................................................................................................................................ 63
Before Operaon.....................................................................................................................................................63
Rinsing the Hopper..................................................................................................................................................63
Start-Up ...................................................................................................................................................................64
Pouring Chemical into the Hopper...........................................................................................................................64
Shutdown ................................................................................................................................................................65
Maintenance ...........................................................................................................................................................66
General Cleaning.................................................................................................................................................66
Daily Maintenance ..............................................................................................................................................66
Yearly Maintenance ............................................................................................................................................66
FIELD OPERATION ................................................................................................................................................67
Operaon Procedure ...............................................................................................................................................68
LUBRICATION & MAINTENANCE........................................................................................................................... 70
Lubricang and Maintaining the Machine Safely ...................................................................................................70
Lubricant Storage ....................................................................................................................................................70
Grease .....................................................................................................................................................................70
Greases for Air Temperature Ranges...................................................................................................................70
Alternave and Synthec Lubricants ..................................................................................................................70
Lubricaon and Maintenance Intervals...................................................................................................................71
Each 10 hours or Daily.........................................................................................................................................71
Each 50 Hours or Weekly ....................................................................................................................................72
Before and Aer Each Season.............................................................................................................................72
As Required .........................................................................................................................................................72
Cleaning...................................................................................................................................................................73
Filters ..................................................................................................................................................................73
Main Tank............................................................................................................................................................74
SERVICE ...............................................................................................................................................................75
Pracce Safe Maintenance......................................................................................................................................75
Work in a Clean Area...............................................................................................................................................75
Service Machines Safely ..........................................................................................................................................75
Support the Machine Properly ................................................................................................................................76
Avoid High-Pressure Fluids ......................................................................................................................................76
Prevenng Hydraulic System Contaminaon ..........................................................................................................76
Replace Hydraulic Hoses .........................................................................................................................................77
Tightening Hardware ..............................................................................................................................................77
Breakaway Tension..................................................................................................................................................77

Table of Contents 3PT Sprayer 9553P / 9573P Page 7
Aligning Booms .......................................................................................................................................................78
PREPARING FOR STORAGE ................................................................................................................................... 79
Removing from Storage...........................................................................................................................................79
TROUBLESHOOTING............................................................................................................................................. 80
TIGHTENING HARDWARE.....................................................................................................................................82
Metric Bolt and Screw Torque Values ......................................................................................................................82
Unied Inch Bolt and Screw Torque Values .............................................................................................................83
Face Seal Fings Assembly & Installaon - All Pressure Applicaons ....................................................................84
Face Seal O-Ring to Stud End Installaon ...........................................................................................................84
Face Seal Adjustable Stud End O-Ring Installaon..............................................................................................84
Face Seal Straight Stud End O-Ring Installaon ..................................................................................................84
Fing Installaon ...............................................................................................................................................84
Assembly Torque.................................................................................................................................................84
SAE Face Seal and O-Ring Stud End Fing Torque Chart ........................................................................................85

Table of Contents 3PT Sprayer 9553P / 9573P Page 8
Limited Warranty
Fast Ag Solutions warrants to the buyer that the new machinery is free from defects in material
and workmanship.
This warranty is only effective as to any new machinery which has not been altered, changed,
repaired or treated since its delivery to the buyer, other than by Fast Ag Solutions or its authorized
dealers or employees, and does not apply to accessories, attachments, tools or parts, sold or
operated with the new machinery, if they have not been manufactured by Fast Ag Solutions.
Fast Ag Solutions shall only be liable for defects in the materials or workmanship attributable to
faulty material or bad workmanship that can be proved by the buyer, and specifically excludes
liability for repairs arising as a result of normal wear and tear of the new machinery or in any other
manner whatsoever, and without limiting the generality of the foregoing, excludes application or
installation of parts not completed in accordance with this Operator’s Manual, specifications, or
printed instructions.
Written notice shall be given by registered mail, to the Manufacturer within seven (7) days after
the defect shall have become apparent or the repairs shall have become necessary, addressed
as follows:
Fast Ag Solutions
4130 Commerce Boulevard
Windom, MN 56101
This warranty shall expire one (1) year after the date of delivery of the new machinery.
If these conditions are fulfilled, Fast Ag Solutions shall at its own cost and at its own option either
repair or replace any defective parts provided that the buyer shall be responsible for all expenses
incurred as a result of repairs, labor, parts, transportation or any other work, unless Fast Ag
Solutions has authorized such expenses in advance.
The warranty shall not extend to any repairs, changes, alterations, or replacements made to the
new equipment other than by Fast Ag Solutions or its authorized dealers or employees.
This warranty extends only to the original owner of the new equipment.
Rubber parts (including tires, hoses, grommets) are not warranted.
This warranty is limited to the terms stated herein and is in lieu of any other warranties whether
express or implied, and without limiting the generality of the foregoing, excluded all warranties,
express or implied or conditions whether statutory or otherwise as to quality and fitness for any
purpose of the new equipment. The Manufacturer disclaims all liability for incidental or
consequential damages.
This 3PT Sprayer is subject to design changes and Fast Ag Solutions shall not be required to
retrofit or exchange items on previously sold units except at its own option.
Warranty void if not registered.

Warranty Registration 3PT Sprayer 9553P / 9573P Page 9
FAST
3PT SPRAYER
Warranty Registration
This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery.
Customer Name
Address
City
State
Zip
Phone
Dealer Name
Address
City
State
Zip
Sprayer Model
Serial Number
Delivery Date
Warranty Inspection Report
DEALER INSPECTION REPORT
SAFETY
____All Fasteners Tight
____ Safety Chain Installed
____Wheel Bolts Torqued
____ All Guards Installed
____Hydraulic Hoses and Fittings Free and Tight
____ All Safety Signs Installed
____Fertilizer Hoses and Fittings Free and Tight
____ Reflectors, SMV, and Lights Clean
____Wheel Drive Turns Freely
____ Review Operating and
____Lubricate Machine
____ Safety Instructions
____Check Tire Pressure
____Frame and Wings Level
____Monitors and Controllers Function
____Wiring Harness Connected
I have thoroughly instructed the buyer on the above-described equipment which review included the Operator’s Manual
content, equipment care, adjustments, safe operation, and applicable warranty policy.
Date_____________________
Dealer’s Rep. Signature___________________________________________________
The above equipment and Operator’s Manual have been received by me, and I have been thoroughly instructed as to
care, adjustments, safe operation, and applicable warranty policy.
Date_____________________
Owner’s Signature________________________________________________________
White - FAST
Yellow - Dealer
Pink – Customer

3PT Sprayer 9553P / 9573P Page 10
FAST 9553P / 9573P Series Sprayer
SPRAYER SERIAL NUMBER _______________________________
DATE PURCHASED ______________/_____/__________
TANK SIZE (CIRCLE ONE) 500 Gal. 750 Gal.
NUMBER OF ROW UNITS ___________________________________
PUMP MANUFACTURER:
(CIRCLE ONE)
ACE FMCSC-205F-HYD-304
ACE 255F-304 WET SEAL
ACE 255F-304 PWM WET SEAL
HYPRO 9306C-HM1C

Inspections 3PT Sprayer 9553P / 9573P Page 11
Inspections
Pre-Delivery
After the machine has been completely assembled, inspect it to be sure it is in good running order
before delivering it to the customer. Ensure each item is found satisfactory or proper adjustment
to the item(s) is made.
The following checklist is a reminder of points to inspect. It is neither an exclusive nor an
exhaustive list of points to inspect. See the Warranty Inspection Report for a formal list.
oSMV emblem is installed, protective shipping tape is removed from reflectors, and lights
are installed.
oAll grease fittings are lubricated (see LUBRICATION and MAINTENANCE section in this
Manual.)
oInspect to be sure all nuts are tightened to proper torque and all cotter pins are spread.
oThe tires are properly inflated (see SPECIFICATIONS).
oWheel bolts are tightened to their specified torque(s).
oFertilizer row units are properly adjusted.
oWarning lights are properly installed and operational.
oAll customer-ordered attachments are installed or are available for delivery.
oAny parts scratched in shipment are touched up with paint.
oAll shipping decals are removed.
oTransport pins are inserted in the transport holes.
This machine has been thoroughly checked and to the best of my knowledge is ready for delivery
to the customer.
Signed: _________________________
Date: _________________________

Inspections 3PT Sprayer 9553P / 9573P Page 12
Delivery
The following checklist is a reminder of information which should be conveyed directly to the
customer at the time the machine is delivered.
Check off each item as it is fully relayed to the customer.
oTell the customer to use proper tools.
oExplain to the customer that the life expectancy of this or any other machine depends on
regular lubrication as directed in Operator's Manual.
oMake the customer aware of all safety precautions that must be followed while using this
machine.
oWhen the machine is transported on a road or highway at night or during the day,
accessory lights and devices should be used for adequate warning to Operators of other
vehicles. For this matter, tell the customer to check local governmental regulations.
oGive the Operator's Manual to the customer and explain all operating adjustments.
To the best of my knowledge, this machine has been delivered ready for field use, and the
customer has been fully informed as to its proper care and operation.
Signed: _________________________
Date: ________________________

Inspections 3PT Sprayer 9553P / 9573P Page 13
After-Sale
The following is a suggested list of items to be checked at a dealer-customer mutually agreeable
time during the first operating season.
oCheck with the customer as to performance of machine. Make certain proper operating
adjustments are understood.
oIf possible, operate the machine to see that it is functioning properly.
oAcquaint the customer with any special attachment which will help do a better job.
oGo over the entire machine for loose or missing hardware.
oCheck for broken or damaged parts.
oAsk the customer if recommended periodic lubrication has been performed.
oReview the Operator's Manual with the customer and stress the importance of proper
lubrication and safety precautions.
Signed: _________________________
Date: _________________________

Serial Number Location 3PT Sprayer 9553P / 9573P Page 14
Serial Number Location
Always give your dealer the Serial Number of your 3PT Sprayer when ordering parts or requesting
service or other information.
The Serial Number is on a tag attached to the 3PT Carrier. Please mark the number in the spaces
provided in this Manual for easy reference.

Owner Register 3PT Sprayer 9553P / 9573P Page 15
Owner Register
Model Number
Serial Number
Name
Address
County
State
Date Purchased
Name
Address
County
State
Date Purchased
Name
Address
County
State
Date Purchased
Name
Address
County
State
Date Purchased

Foreword to the Owner 3PT Sprayer 9553P / 9573P Page 16
Foreword to the Owner
Congratulations on your choice of an 3PT Sprayer to complement your agricultural operation!
READ THIS MANUAL carefully to learn how to operate and service your machine correctly. Failure
to do so could result in personal injury or equipment damage. This Manual and safety signs on
your machine may also be available in other languages.
THIS MANUAL SHOULD BE CONSIDERED a permanent part of your machine and should
remain with the machine when you sell it.
MEASUREMENTS in this Manual are given in both metric and customary U.S. unit equivalents.
Use only correct replacement parts and fasteners. Metric and inch fasteners may require a
specific metric or inch wrench.
RIGHT-HAND AND LEFT-HAND sides are determined by facing in direction that the implement
will travel when going forward.
WRITE SERIAL NUMBER of the machine in the Specification section and in the Owner Register.
Accurately record all numbers to help in tracing your machine should it be stolen. Your dealer also
needs these numbers when you order parts. File identification numbers in a safe place off-
machine.
BEFORE DELIVERING THIS MACHINE, your dealer performed a pre-delivery inspection.
THIS 3PT SPRAYER IS DESIGNED SOLELY for use in customary agricultural or similar
operations for the purpose of applying chemical to row crops (“Intended Use”). Use in any other

Foreword to the Owner 3PT Sprayer 9553P / 9573P Page 17
way is considered as contrary to the Intended Use. The manufacturer accepts no liability for
damage or injury resulting from this misuse, and these risks must be borne solely by the user.
Compliance with and strict adherence to the conditions of operation, service, and repair as
specified by the manufacturer also constitute essential elements for the Intended Use.
THIS 3PT SPRAYER SHOULD BE OPERATED, serviced, and repaired only by persons familiar
with all its particular characteristics and acquainted with the relevant safety rules (Accident
Prevention). The Accident Prevention regulations, all other generally recognized regulations on
safety and occupational medicine and the road traffic regulations must be observed at all times.
Any arbitrary modifications carried out on this 3PT Sprayer will relieve the manufacturer of all
liability for any resulting damage or injury.
THIS DOCUMENT outlines the specific design and performance requirements for the use of a
Fast Ag Solutions 3PT Sprayer assembly. The word “must” in this document indicates a
mandatory requirement. The use of “should” indicates a recommendation of that which is advised
but not required.
WARRANTY is provided as part of Fast Ag Solutions' support program for customers who operate
and maintain their equipment as described in this Manual. The warranty is explained on the
warranty certificate which you should have received from your dealer.
This warranty provides you with assurance that Fast Ag Solutions will back its products where
defects appear within the warranty period. In some circumstances, Fast Ag Solutions also
provides field improvements, often without charge to the customer, even if the product is out of
warranty. Should equipment be abused or modified to change its performance beyond original
factory specifications, the warranty will become void and field improvements may be denied.
TIRE MANUFACTURER'S warranty applicable to your machine may not apply outside U.S.
If you are not the original owner of this machine, it is in your interest to contact your local Fast Ag
Solutions dealer to inform them of this unit's serial number. This will help Fast Ag Solutions notify
you of any issues or product improvements.

INTRODUCTION
INTRODUCTION 3PT Sprayer 9553P / 9573P Page 18
INTRODUCTION
Read this Manual carefully
before operating your FAST
equipment. The information
presented will prepare you
to safely operate and service
your machine.
All Operators are required to read this
Manual carefully and be acquainted with all
the operating and adjustment procedures
before attempting to operate. Failure to
follow the information in this Manual and on
decals may result in personal injury or
equipment damage.
This Manual should be considered a
permanent part of this equipment and should
remain with the equipment when you sell it.
Replacement manuals can be obtained from
your Fast Ag Solutions dealer.
This equipment has been engineered and
manufactured to provide dependable and
satisfactory use. Like all mechanical
products, it will require cleaning and upkeep.
Inspect your equipment before putting it into
service. Your authorized Fast Ag Solutions
dealer has trained mechanics, genuine FAST
service parts, and the necessary tools and
equipment when service is needed. Use only
genuine FAST parts for service or repairs.
Substitute parts will void the warranty and
may not meet standards for safe and
satisfactory operation.
Warranty is provided as part of Fast Ag
Solutions’ support program for customers
who operate and maintain their equipment as
described in this Manual. The warranty is
explained on the warranty certificate you
should have received from your dealer. This
warranty provides you with the assurance
that Fast Ag Solutions will back its products
where defects appear within the warranty
period. Should the equipment be abused or
modified to change its performance beyond
the original factory specifications, the
warranty will become void.
These instructions have been compiled from
field experience and engineering data. Some
information may be general in nature due to
unknown and varying operating conditions.
However, through experience and these
instructions, you should be able to develop
procedures suitable to your particular
situation.
The illustrations and data used in this Manual
were current at the time of printing. However,
due to possible in-line production changes,
your machine may vary slightly in detail. We
reserve the right to redesign and change the
machines as necessary without notification.
Figure 1: Orientation is viewed from behind the
machine

INTRODUCTION
INTRODUCTION 3PT Sprayer 9553P / 9573P Page 19
Machine Components
This 3PT boom sprayer is meant to distribute
chemicals over a wide area. The system is
pressurized by a hydraulic pump that
provides flow for tank agitation, tank rinsing,
and boom pressure.
A 5-gallon rinse tank is mounted on the side
of the carrier. Optional foam markers are
available and mount on the carrier frame.
A solenoid to each boom controls the flow to
the wings, and a butterfly valve and flow
sensor maintain the system pressure.
Nozzles along the wings distribute the
chemical solution over the field. A screen in
the line next to the pump and after the
solenoids removes contaminants from the
system. The chemical system controller is
mounted in the tractor cab for easy
operation.
The booms attach to and are suspended
from the back of the frame. The inner booms
(B) swing rearward at right angles to the
frame for field operation. The outer booms
(C) pivot up and out for field operation. The
wing breakaways (D) swing back if they hit
an obstruction.
The boom position controller mounts in the
cab for easy operation.
A. Main Tank
B. Rinse Tank
C. Hand Wash Tank
D. Inner Boom
E. Outer Boom
F. Breakaway Boom
G. Boom Section Valves
H. Boom Controller
I. Chemical Controller (optional)

INTRODUCTION
INTRODUCTION 3PT Sprayer 9553P / 9573P Page 20
Fence Row Nozzles
Fence Row Nozzles are equipped to provide
coverage next to a fence or at the edge of a
field. Open the inline valve when spraying
next to a fence and turn it off when in the
field.
Figure 2: Standard manual fence row nozzle
Figure 3: Electric shutoff fence row nozzle
Boom Auto-Leveling
A Norac Auto Leveling System (optional) is
mounted on the back of the frame. It is
integrated into the hydraulic system to keep
the booms level.
Boom Auto-Height
The sprayer can be equipped with an "Auto
height" control system. The control valve is
mounted on the back of the frame and
connects into the hydraulic system to keep
the booms at a preset height.
