FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A
BW500 / BW750
Trailer Sprayer
OPERATION AND
MAINTENANCE
MANUAL
March 2018
Original

FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A

FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A
FOREWARD............................................................................................................................. 5
Pre-Delivery .......................................................................................................................... 7
Delivery ................................................................................................................................ 8
After-Sale .............................................................................................................................. 9
Owner Register ................................................................................................................... 10
SAFETY................................................................................................................................... 11
Recognize Safety Information ............................................................................................ 11
Understand Signal Words ................................................................................................... 11
Follow Safety Instructions .................................................................................................. 11
Prepare for Emergencies .....................................................................................................12
Wear Protective Clothing .................................................................................................... 12
Protect Against Noise ......................................................................................................... 12
Practice Safe Maintenance.................................................................................................. 12
Support Raised Equipment ................................................................................................. 13
Avoid Heating Near Pressurized Fluid Lines ..................................................................... 13
Avoid High-Pressure Fluids................................................................................................ 13
Inspect Lift Circuit Hoses ................................................................................................... 14
Store Attachments Safely .................................................................................................... 14
Service Tires Safely ............................................................................................................ 14
Dispose of Waste Properly ................................................................................................. 15
Handle Agricultural Chemicals Safely ............................................................................... 15
Handle Chemical Products Safely ...................................................................................... 16
Operate Safely ..................................................................................................................... 17
Use Safety Lights and Devices ........................................................................................... 17
Keep Riders Off Machine ................................................................................................... 17
Observe Maximum Transport Speed .................................................................................. 18
EC Compliance Notification............................................................................................... 18
Use a Signal Person ............................................................................................................19
Use a Safety Chain .............................................................................................................. 19
Tow Loads Safely ............................................................................................................... 19
Avoid Overhead Power Lines............................................................................................. 20
Prepare for Transport ..........................................................................................................20
Transport Safely .................................................................................................................. 21
Park Safely .......................................................................................................................... 21
Parked Jack Position ........................................................................................................... 21
Replace Safety Signs .......................................................................................................... 22
Safety Sign Locations ......................................................................................................... 23
Reflective Decal Locations ................................................................................................. 28
Safety Features.................................................................................................................... 29
PREPARING MACHINE ...................................................................................................... 30
Use Tractor Operator's Manual ........................................................................................... 30
Pre-Operation Checklist ...................................................................................................... 30
Checking and Lubricating Machine.................................................................................... 31
Checking Tire Pressure....................................................................................................... 31
Sprayer Setup And Assembly ............................................................................................. 31

FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A
Implement Driveline (PTO Drive Pumps Only .................................................................. 32
Hitching Sprayer To Tractor ............................................................................................... 33
ATTACHING AND DETACHING ...................................................................................... 35
Attach Machine Safely ........................................................................................................ 35
Making Proper Hose Connections ...................................................................................... 35
.Attach Safety Chain to Tractor .......................................................................................... 37
Attach Warning Light Plug ................................................................................................. 37
Connect Rate Controller or Sprayer System Wiring .......................................................... 37
Detach Machine from Tractor ............................................................................................. 38
TRANSPORTING .................................................................................................................. 39
Using Warning Lights ......................................................................................................... 40
Keep Riders Off Machine ................................................................................................... 40
HYDRAULIC DRIVE PUMP (OPTIONAL) ...................................................................... 42
TeeJet Controller (Standard) ............................................................................................... 42
Raven Rate Controller (Optional): ...................................................................................... 43
Hydraulic Hose Connections - Boom Control .................................................................... 43
EF & EFT Boom Hydraulic Hose Connections .................................................................. 43
EFT Boom Electrical Connections ..................................................................................... 44
HC Boom Hydraulic Hose and Electrical Connections ...................................................... 44
HC Boom Electrical Connections ....................................................................................... 44
Sprayer Accessories............................................................................................................ 45
Unhitching Sprayer From Tractor....................................................................................... 45
Sprayer Accessories ............................................................................................................46
Foam Marker Switch Box ................................................................................................... 46
Fence Line Kit .................................................................................................................... 46
In-Cab Electric 50 Gallon Rinse System ............................................................................ 46
Operation ............................................................................................................................ 47
New Operator Or Owner..................................................................................................... 47
Break-In .............................................................................................................................. 48
Pre-Operation Checklist...................................................................................................... 48
Measuring Travel Speed ..................................................................................................... 49
Adjust Ground Speed .......................................................................................................... 50
Spraying Solutions Other Than Water ................................................................................ 50
Tip Selection ....................................................................................................................... 50
Hydraulic System ................................................................................................................ 51
Sprayer Controls ................................................................................................................. 51
Triple Electric Control ........................................................................................................ 51
Optional Automatic Rate Controller................................................................................... 52
Self Cleaning Filter (Optional) ........................................................................................... 55
Filling The Product Tank .................................................................................................... 56
Fill Through Top Lid (Standard Configuration) ................................................................. 56
Filling With Transfer Pump................................................................................................ 56
If Equipped With Manual Control Rinse System: .............................................................. 56
If Equipped With Electric Control Rinse System: .............................................................. 57
Filling With Sprayer Pump ................................................................................................. 57
If Equipped With Manual Control Rinse System: .............................................................. 57

FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A
If Equipped With Electric Control Rinse System: .............................................................. 57
With Manual Control Rinse System: .................................................................................. 58
With Electric Control Rinse System: .................................................................................. 58
Priming The Sprayer ........................................................................................................... 58
Priming The Sprayer Equipped With A RAVEN Rate Controller ..................................... 59
TeeJet Electric Control System ........................................................................................... 60
Raven Rate Control System (Optional) .............................................................................. 60
Tank Tie Down Straps ........................................................................................................ 61
VALVE SETTING INSTRUCTIONS .................................................................................. 62
TANK SYSTEMS ................................................................................................................... 63
Chemical Inductor (Optional) ............................................................................................. 63
Hand Rinse Gun for Chemical Inductor (Optional) ............................................................ 65
Standard System ................................................................................................................. 65
Optional Electric System .................................................................................................... 66
Hand Rinse Tank ................................................................................................................67
External Sight Gauge .......................................................................................................... 67
Rinse Tank Flush System (Optional) .................................................................................. 68
Manual Control System ...................................................................................................... 68
Electric Control System ...................................................................................................... 70
Cleaning The Sprayer ......................................................................................................... 72
Long Term Shutdown ......................................................................................................... 73
Electric Control Rinse System ............................................................................................ 74
Long Term Shutdown ......................................................................................................... 75
Cleaning Your Sprayer Manually ....................................................................................... 75
HYDRAULIC BOOM OPERATION ................................................................................... 76
EF & EFT Boom ................................................................................................................. 76
EFT Boom ........................................................................................................................... 76
HC Boom ............................................................................................................................ 77
Service And Maintenance ................................................................................................... 78
LUBRICATION AND MAINTENANCE ............................................................................ 79
Lubricating and Maintaining Machine Safely .................................................................... 79
Grease ................................................................................................................................. 79
Alternative and Synthetic Lubricants ................................................................................. 79
Lubricant Storage................................................................................................................ 80
Lubrication and Maintenance Intervals .............................................................................. 80
LUBRICATION POINTS ...................................................................................................... 81
Weekly Lubrication Interval ............................................................................................... 81
Boom Tower Slides (HC Boom Only) ............................................................................... 84
200 Hour Lubrication Interval ............................................................................................ 84
GENERAL MAINTENANCE ............................................................................................... 85
Tire Pressure ....................................................................................................................... 85
Filters .................................................................................................................................. 85
Sprayer Tips ........................................................................................................................ 86
Storing and Winterizing ...................................................................................................... 86

FAST Global Solutions, Inc. FAST™ BW500 / BW750 Trailer Sprayer Made in U.S.A
Chemical Inductor ............................................................................................................... 87
Foam Marker ....................................................................................................................... 87
Cleaning the outside of the sprayer..................................................................................... 87
Boom Adjustments ............................................................................................................. 87
EF & EFT Boom Only ........................................................................................................ 89
Boom Wing Assembly Alignment ...................................................................................... 89
Boom Breakaways .............................................................................................................. 90
SERVICE ................................................................................................................................. 91
Practice Safe Maintenance .................................................................................................. 91
Work in Clean Area ............................................................................................................ 91
Service Machines Safely ..................................................................................................... 91
Support Machine Properly .................................................................................................. 92
Avoid High-Pressure Fluids ................................................................................................ 92
Replace Hydraulic Hoses.................................................................................................... 93
Tightening Hardware .......................................................................................................... 93
Metric Bolt and Screw Torque Values ............................................................................... 94
Unified Inch Bolt and Screw Torque Values ...................................................................... 95
Face Seal Fittings Assembly and Installation—All Pressure Applications ........................ 96
SAE Face Seal and O-Ring Stud End Fitting Torque Chart—Standard Pressures ............ 96
Preparing for Storage ..........................................................................................................97
Removing from Storage...................................................................................................... 97
SERVICE RECORD .............................................................................................................. 98
TROUBLESHOOTING ......................................................................................................... 99
Hydraulic Fitting Torque .................................................................................................. 102
Mechanical Specifications ................................................................................................ 102
RAVEN CONSOLE CALIBRATION ................................................................................ 103
OPTIONAL ACCESSORIES.............................................................................................. 104
Fence Line Kit(s) .............................................................................................................. 104
Manual Fence Row Nozzle Operation: ............................................................................. 104
Electric Fence Row Nozzle Operation: ............................................................................ 104

Warranty
Page 1
WARRANTY REGISTRATION FORM
Limited Warranty
FAST AG Solutions warrants to the buyer that the new machinery is free from defects in material and work-
manship.
This warranty is only effective as to any new machinery which has not been altered, changed, repaired or
treated since its delivery to the buyer, other than by FAST AG Solutions or its authorized dealers or employ-
ees, and does not apply to accessories, attachments, tools or parts, sold or operated with the new machinery,
if they have not been manufactured by FAST AG Solutions.
FAST AG Solutions shall only be liable for defects in the materials or workmanship attributable to faulty mate-
rial or bad workmanship that can be proved by the buyer, and specifically excludes liability for repairs arising
as a result of normal wear and tear of the new machinery or in any other manner whatsoever, and without lim-
iting the generality of the foregoing, excludes application or installation of parts not completed in accordance
with this operator’s manual, specifications, or printed instructions.
Written notice shall be given by registered mail, to the Manufacturer within seven (7) days after the defect shall
have become apparent or the repairs shall have become necessary, addressed as follows:
FAST AG Solutions
4130 Commerce Boulevard
Windom, MN 56101
This warranty shall expire one (1) year after the date of delivery of the new machinery.
If these conditions are fulfilled, FAST AG Solutions shall at its own cost and at its own option either repair or
replace any defective parts provided that the buyer shall be responsible for all expenses incurred as a result of
repairs, labor, parts, transportation or any other work, unless FAST AG Solutions has authorized such
expenses in advance.
The warranty shall not extend to any repairs, changes, alterations, or replacements made to the new equip-
ment other than by FAST AG Solutions or its authorized dealers or employees.
This warranty extends only to the original owner of the new equipment.
Rubber parts (including tires, hoses, grommets) are not warranted.
This warranty is limited to the terms stated herein and is in lieu of any other warranties whether express or
implied, and without limiting the generality of the foregoing, excluded all warranties, express or implied or con-
ditions whether statutory or otherwise as to quality and fitness for any purpose of the new equipment. the Man-
ufacturer disclaims all liability for incidental or consequential damages.
This Sprayer is subject to design changes and FAST AG Solutions shall not be required to retrofit or exchange
items on previously sold units except at its own option.
Warranty void if not registered.
Warranty

Warranty Registration
Page 2
WARRANTY REGISTRATION FORM
FAST BW500 / BW750 TRAILER SPRAYER
Warranty Registration Form & Inspection Report
Warranty Registration
This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery.
DEALER INSPECTION REPORT SAFETY
____All Fasteners Tight ____ Safety Chain Installed
____Wheel Bolts Torqued ____ All Guards Installed
____Hydraulic Hoses and Fittings Free and Tight ____ All Safety Signs Installed
____Boom Hoses and Fittings Free and Tight ____ Reflectors, SMV and Lights Clean
____Wheel Drive Turns Freely ____ Review Operating and
____Lubricate Machine Safety Instructions
____Check Tire Pressure
____Frame and Wings Level
____Monitors and Controllers Function
____Wiring Harness Connected
I have thoroughly instructed the buyer on the above described equipment which review included the Operator’s
Manual content, equipment care, adjustments, safe operation and applicable warranty policy.
Date_____________________
Dealer’s Rep. Signature___________________________________________________
The above equipment and Operator’s Manual have been received by me and I have been thoroughly instructed
as to care, adjustments, safe operation and applicable warranty policy.
Date_____________________
Owner’s Signature________________________________________________________
White - FAST
Yellow - Dealer
Pink - Customer
Customer Name
Address
City State Zip
Phone
Dealer Name
Address
City State Zip
Sprayer Model
Serial Number
Delivery Date

Warranty Registration
Page 3
WARRANTY REGISTRATION FORM
FAST BW500 / BW750 TRAILER SPRAYER
SPRAYER APPLICATOR SERIAL NUMBER
__________________________________
DATE PURCHASED ______________/_____/__________
TANK SIZE _____________________
BOOM LENGTH___________________________________
PUMP MANUFACTURER:
(CIRCLE ONE)
ACE 150 Belt Driven ACE FMC150

Warranty Registration
Page 4
WARRANTY REGISTRATION FORM

Page 5
FOREWARD
FOREWARD
READ THIS MANUAL carefully to learn how to operate and service your machine cor-
rectly. Failure to do so could result in personal injury or equipment damage. This manual
and safety signs on your machine may also be available in other languages.
THIS MANUAL SHOULD BE CONSIDERED a permanent part of your machine and
should remain with the machine when you sell it.
MEASUREMENTS in this manual are given in both metric and customary U.S. unit
equivalents. Use only correct replacement parts and fasteners. Metric and inch fasteners
may require a specific metric or inch wrench.
RIGHT-HAND AND LEFT-HAND sides are determined by facing in direction implement
will travel when going forward.
WRITE PRODUCT IDENTIFICATION NUMBERS (P.I.N.) in Specification section. Accu-
rately record all numbers to help in tracing machine should it be stolen. Your dealer also
needs these numbers when you order parts. File identification numbers in a safe place
off machine.
BEFORE DELIVERING THIS MACHINE, your dealer performed a pre-delivery inspec-
tion.

Page 6
FOREWARD
THIS SPRAYER IS DESIGNED SOLELY for use in customary agricultural or similar
operations for the purpose of applying crop protection chemicals (“INTENDED USE”).
Use in any other way is considered as contrary to the intended use. The manufacturer
accepts no liability for damage or injury resulting from this misuse, and these risks must
be borne solely by the user. Compliance with and strict adherence to the conditions of
operation, service and repair as specified by the manufacturer also constitute essential
elements for the intended use.
THIS SPRAYER SHOULD BE OPERATED, serviced and repaired only by persons famil-
iar with all its particular characteristics and acquainted with the relevant safety rules
(accident prevention). The accident prevention regulations, all other generally recog-
nized regulations on safety and occupational medicine and the road traffic regulations
must be observed at all times. Any arbitrary modifications carried out on this SPRAYER
will relieve the manufacturer of all liability for any resulting damage or injury.
WARRANTY is provided as part of FAST's support program for customers who operate
and maintain their equipment as described in this manual. Warranty is explained on war-
ranty certificate which you should have received from your dealer.
This warranty provides you assurance that FAST will back its products where defects
appear within warranty period. In some circumstances, by FAST also provides field
improvements, often without charge to customer, even if product is out of warranty.
Should equipment be abused, or modified to change its performance beyond original fac-
tory specifications, warranty will become void and field improvements may be denied.
Setting fuel delivery above specifications or otherwise overpowering machines will result
in such action.
TIRE MANUFACTURER'S warranty applicable to your machine may not apply outside
U.S.
If you are not the original owner of this machine, it is in your interest to contact your local
FAST dealer to inform them of this unit's serial number. This will help FAST notify you of
any issues or product improvements.

Pre-Delivery
Page 7
FOREWARD
Pre-Delivery
After machine has been completely assembled, inspect to be sure it is in good running
order before delivering to customer. The following checklist is a reminder of points to
inspect. Check off each item as it is found satisfactory or after proper adjustment is
made.
□NO parts on the unit have been damaged in shipment. Check for such things as
dents and loose or missing parts; correct or replace components as required.
□SMV emblem installed; protective shipping tape removed from reflectors and lights
are installed.
□All grease fittings have been lubricated. (See LUBRICATION AND MAINTENANCE
section in this manual.)
□Inspect to be sure all nuts have been tightened to proper torque and all cotter pins
spread.
□Tires are properly inflated. Tighten wheel bolts to specified torque.
□Adjust axles per customer’s wheel spacing request.
□Warning lights are properly installed and operational.
□Make sure all customer-ordered attachments have been installed or are available
for delivery.
□Any parts scratched in shipment have been touched up with paint.
□Remove all shipping decals.
□Rotating PTO shields turn freely.
□Verify correct nozzle spacing.
□As applicable, the cylinders. hoses and fittings are NOT damaged, leaking or
loosely connected.
□This machine has been thoroughly checked and to the best of my knowledge is
ready for delivery to the customer.
Signed: _________________________
Date: _________________________

Delivery
Page 8
FOREWARD
Delivery
At the time machine is delivered, following checklist is a reminder of information which
should be conveyed directly to the customer. Check off each item as it is fully explained
to customer.
□Tell customer to use proper tools.
□Explain to customer that life expectancy of this or any other machine depends on
regular lubrication as directed in operator's manual.
□Give operator's manual to customer and explain all operating adjustments.
□Make customer aware of all safety precautions that must be followed while using
this machine.
□When machine is transported on a road or highway at night or during day, acces-
sory lights and devices should be used for adequate warning to operators of other
vehicles. In this regard, tell customer to check local governmental regulations.
□To the best of my knowledge, this machine has been delivered ready for field use
and customer has been fully informed as to proper care and operation.
Signed: _________________________
Date: ________________________

After-Sale
Page 9
FOREWARD
After-Sale
The following is a suggested list of items to be checked at a dealer-customer mutually
agreeable time during the first operating season.
□Check with customer as to performance of machine. Make certain proper operating
adjustments are understood.
□If possible, operate machine to see that it is functioning properly.
□Acquaint customer with any special attachment which will help do a better job.
□Go over entire machine for loose or missing hardware.
□Check for broken or damaged parts.
□Ask customer if recommended periodic lubrication has been performed.
□Review operator's manual with customer and stress importance of proper lubrica-
tion and safety precautions.
Signed: _________________________
Date: _________________________

Owner Register
Page 10
FOREWARD
Owner Register
Name Model Number
Post Office P.I.N. Number
County State Date Purchased

Recognize Safety Information
Page 11
SAFETY
SAFETY
Recognize Safety Information
This is a safety-alert symbol. When you
see this symbol on your machine or in this
manual, be alert to the potential for per-
sonal injury.
Follow recommended precautions and
safe operating practices.
Understand Signal Words
A signal word—DANGER, WARNING, or
CAUTION—is used with the safety-alert
symbol. DANGER identifies the most seri-
ous hazards.
DANGER or WARNING safety signs are
located near specific hazards. General
precautions are listed on CAUTION safety
signs. CAUTION also calls attention to
safety messages in this manual.
Follow Safety Instructions
Carefully read all safety messages in this
manual and on your machine safety signs.
Keep safety signs in good condition.
Replace missing or damaged safety signs.
Be sure new equipment components and
repair parts include the current safety
signs. Replacement safety signs are avail-
able from your FAST dealer.
There can be additional safety information
contained on parts and components
sourced from suppliers that is not repro-
duced in this operator's manual.
Learn how to operate the machine and
how to use controls properly. Do not let
anyone operate without instruction.
Keep your machine in proper working con-
dition. Unauthorized modifications to the
machine may impair the function and/or
safety and affect machine life.
If you do not understand any part of this
manual and need assistance, contact your
FAST dealer.

Prepare for Emergencies
Page 12
SAFETY
Prepare for Emergencies
Be prepared if a fire starts.
Keep a first aid kit and fire extinguisher
handy.
Keep emergency numbers for poison con-
trol center, doctors, ambulance service,
hospital, and fire department near your
telephone.
Wear Protective Clothing
Wear close fitting clothing and safety
equipment appropriate to the job.
Operating equipment safely requires the
full attention of the operator. Do not wear
radio or music headphones while operat-
ing machine.
Protect Against Noise
Prolonged exposure to loud noise can
cause impairment or loss of hearing.
Wear a suitable hearing protective device
such as earmuffs or earplugs to protect
against objectionable or uncomfortable
loud noises.
Practice Safe Maintenance
Understand service procedure before
doing work. Keep area clean and dry.
Never lubricate, service, or adjust machine
while it is moving. Keep hands, feet, and
clothing from power-driven parts. Disen-
gage all power and operate controls to
relieve pressure. Lower equipment to the

Support Raised Equipment
Page 13
SAFETY
ground. Stop the engine. Remove the key.
Allow machine to cool.
Securely support any machine elements
that must be raised for service work.
Keep all parts in good condition and prop-
erly installed. Fix damage immediately.
Replace worn or broken parts. Remove
any buildup of grease, oil, or debris.
On self-propelled equipment, disconnect
battery ground cable (-) before making
adjustments on electrical systems or weld-
ing on machine.
On towed implements, disconnect wiring
harnesses from tractor before servicing
electrical system components or welding
on machine.
Support Raised Equipment
Always use a safety support when working
on, under, or around machine. Transport/
Service locks can be used for this pur-
pose.
Shut off tractor engine and remove key
when working on machine.
If air has been allowed to enter hydraulic
hoses or cylinders, bleed hydraulic system
before use. If there is a failure in hydraulic
system, unsupported raised equipment
could suddenly lower, causing serious per-
sonal injury or death.
If support is not available, completely
lower wings and frame, relieve hydraulic
pressure and disconnect hoses from trac-
tor.
Avoid Heating Near Pressurized Fluid
Lines
Flammable spray can be generated by
heating near pressurized fluid lines, result-
ing in severe burns to yourself and
bystanders. Do not heat by welding, sol-
dering, or using a torch near pressurized
fluid lines or other flammable materials.
Pressurized lines can accidentally burst
when heat goes beyond the immediate
flame area.
Avoid High-Pressure Fluids
Inspect hydraulic hoses periodically – at
least once per year – for leakage, kinking,
cuts, cracks, abrasion, blisters, corrosion,
exposed wire braid or any other signs of
wear or damage.
Replace worn or damaged hose assem-
blies immediately with FAST approved
replacement parts.
Escaping fluid under pressure can pene-
trate the skin causing serious injury.
Avoid the hazard by relieving pressure
before disconnecting hydraulic or other

Inspect Lift Circuit Hoses
Page 14
SAFETY
lines. Tighten all connections before
applying pressure.
Search for leaks with a piece of cardboard.
Protect hands and body from high-pres-
sure fluids.
If an accident occurs, see a doctor imme-
diately. Any fluid injected into the skin
must be surgically removed within a few
hours or gangrene may result. Doctors
unfamiliar with this type of injury should
reference a knowledgeable medical
source.
Inspect Lift Circuit Hoses
Avoid serious injury or death while working
under a raised implement.
Hydraulic hoses between the lift cylinders
and hydraulic lock-up valves should be
inspected frequently for leakage, kinking,
cuts, cracks, abrasion, blisters, corrosion,
exposed wire braid or any other signs of
wear or damage. Worn or damaged hose
assemblies can fail during use and should
be replaced immediately. See your FAST
dealer for replacement hoses.
Store Attachments Safely
Stored attachments such as dual wheels
can fall and cause serious injury or death.
Securely store attachments and imple-
ments to prevent falling. Keep playing chil-
dren and bystanders away from storage
area.
Service Tires Safely
CAUTION: Explosive separation
of a tire and rim parts can cause
serious injury or death.
Do not attempt to mount a tire unless you
have the proper equipment and experi-
ence to perform the job.
