FCW DYNA TWC 901 User manual

MODEL
•DYNA TWC 901
•DYNA TWC 902
Operating Manual
(Owner’s Manual)
IMPORTANT: Read these instructions before installing, operating, or servicing this system.
First Edition Manual No. ET001

-1 -
DYNA TWC 901、902 Operating Manual
CONTENTS
SYMBOL LEGEND---------------------------------------------------------------------------------------------------2
STATEMENT OF WARRANTY------------------------------------------------------------------------------------3
1.0 GENERAL INFORMATION-------------------------------------------------------------------------------4
1.01 Notes, Cautions and Warnings------------------------------------------------------------------------4
1.02 Important Safety Precautions--------------------------------------------------------------------------4
1.03 Transporting methods-----------------------------------------------------------------------------------6
2.0 INSTALLATION RECOMMENDATION----------------------------------------------------------------7
3.0 OPERATOR CONTROLS---------------------------------------------------------------------------------8
4.0 SPECIFICATIONS------------------------------------------------------------------------------------------9
5.0 PARTS LIST--------------------------------------------------------------------------------------------------9
6.0 REMARK-----------------------------------------------------------------------------------------------------12

-2 -
DYNA TWC 901、902 Operating Manual
SYMBOL LEGEND
AAmperage
Stick (SMAW)
VVoltage
Pulse Current Function
(GTAW)
Hz Hertz (frequency)
tSpot Time (GTAW)
SEC Seconds
Remote outputs control
(Panel/Remote)
%Percent
Remote Function
DC (Direct Current)
Arc Control (SMAW)
AC (Alternating Current)
t
2Gas Post-Flow Time
2T (GTAW)
t1Gas Pre-Flow Time
4T (GTAW)
VRD Voltage Reduction
Device Circuit
Repeat Function (GTAW)
—Negative
Spot Function (GTAW)
+Positive
High Frequency Starting
(GTAW)
Gas Input
Lift Start （GTAW）
Gas Output

-3 -
DYNA TWC 901、902 Operating Manual
STATEMENT OF WARRANTY
LIMITED WARRANTY: "FCW" warrants to customers of its authorized distributors hereafter "FCW" that its products will be free
of defects in workmanship or material. Should any failure to conform to this warranty appear within the time period applicable to
the FCW products as stated below, FCW shall, upon notification thereof and substantiation that the product has been stored,
installed, operated, and maintained in accordance with FCW’s specifications, instructions, recommendations and recognized
standard industry practice, and not subject to misuse, repair, neglect, alteration, or accident, correct such defects by suitable
repair or replacement, at FCW ‘s sole option, of any components or parts of the product determined by FCW to be defective.
The FCW COMPANY MAKESNO OTHER WARRANTY,EXPRESS OR IMPLIED. THIS WARRANTY IS EXCLUSIVE AND IN
LIEU OF ALL OTHERS, INCLUDING, BUT NOT LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR
ANY PARTICULARPURPOSE.
LIMITATION OF LIABILITY: FCW shall not under any circumstances be liable for special, indirect or consequential damages,
such as, but not limited to, lost profits and business interruption. The remedies of the Purchaser set forth herein are exclusive
and the liability of FCW with respect to any contract, or anything done in connection therewith such as the performance or
breach thereof, or from the manufacture, sale, delivery, resale, or use of any goods covered by or furnished by FCW whether
arising out of contract, negligence, strict tort, or under any warranty, or otherwise, shall not, except as expressly provided herein,
exceed the price of the goods upon which such liability is based. No employee, agent, or representative of FCW is authorized to
change this warranty in any way or grant any other warranty.
PURCHASER'S RIGHTS UNDER THIS WARRANTY ARE VOID IF REPLACEMENT PARTS OR ACCESSORIES ARE USED
WHICH IN FCW’S SOLE JUDGEMENT MAY IMPAIR THE SAFETY ORPERFORMANCE OF ANY FCW PRODUCT.
PURCHASER'S RIGHTS UNDER THIS WARRANTY ARE VOID IF THE PRODUCT IS SOLD TO PURCHASER BY
NON-AUTHORIZED PERSONS.
The warranty is effective for the time stated below beginning on the date that the authorized distributor delivers the products to
the Purchaser. Notwith standing the foregoing, in no event shall the warranty period extend more than the time stated plus one
year from the date FCW delivered the product to the authorized distributor.
POWER SUPPLIES POWER SUPPLIES & WIRE FEEDERS
MAIN POWER MAGNETICS (STATIC& ROTATING) 1YEAR
ORIGINAL MAIN POWER RECTIFIER 1YEAR
POWER SWITCHING SEMI-CONDUCTORS & CONTROL PC BOARD 1YEAR
ALL OTHER CIRCUITS AND COMPONENTS INCLUDING 1YEAR
BUT NOT LIMITED TO, CONTACTORS, RELAYS,
SOLENOIDS, PUMPS, SWITCHES, MOTORS
Warranty repairs or replacement claims under this limited warranty must be submitted to FCW by an authorized FCWrepair
facility within thirty (30) days of purchaser’s notice of any Warranty Claim. No transportation costs of any kind will be paid under
this warranty. Transportation charges to send products to an authorized warranty repair facility shall be the responsibility of the
Purchaser. All returned goods shall be at the Purchaser’s risk and expense. This warranty supersedes all previous FCW
warranties.

-4 -
DYNA TWC 901、902 Operating Manual
1.0 GENERAL INFORMATION
1.01 Notes,Cautions and Warnings
Throughout this manual, notes, cautions, and warnings are used to highlight important information. These
highlights are categorized as follows:
NOTE
An operation, procedure, or background information which requires additional emphasis or is helpful in
efficient operation of the system.
CAUTION
A procedure which, if not properly followed, may cause damage to the equipment.
WARNING
A procedure which, if not properly followed, may cause injury to the operator or others in the operating area.
1.02 Important Safety Precautions
WARNING
OPERATION AND MAINTENANCE OF ARC WELDING EQUIPMENT CAN BE DANGEROUS AND
HAZARDOUS TO YOUR HEALTH.
To prevent possible injury, read, understand and follow all warnings, safety precautions and instructions
before using the equipment. Call 86-21-69171135 or your local distributor if you have any questions.
GASES AND FUMES
Gases and fumes produced during the Arc welding or cutting process can be dangerous and hazardous to
your health.
lKeep all fumes and gases from the breathing area. Keep your head out of the welding fume plume.
lUse an air-supplied respirator if ventilation is not adequate to remove all fumes and gases.
lThe kinds of fumes and gases from the arc welding/cutting depend on the kind of metal being used,
coatings on the metal, and the different processes. You must be very careful when cutting or welding
any metals which may contain one or more of the following:
Antimony Arsenic Barium Beryllium Cadmium Chromium Cobalt Copper Lead
ManganeseMercury Nickel Selenium Silver Vanadium
lAlways read the Material Safety Data Sheets (MSDS) that should be supplied with the material you
are using. These MSDSs will give you the information regarding the kind and amount of fumes and
gases that may be dangerous to your health.
lUse special equipment, such as water or down draft welding/cutting tables, to capture fumes and
gases.
lDo not use the welding torch in an area where combustible or explosive gases or materials are
located.
lPhosgene, a toxic gas, is generated from the vapors of chlorinated solvents and cleansers. Remove
all sources of these vapors.

-5 -
DYNA TWC 901、902 Operating Manual
ELECTRIC SHOCK
Electric Shock can injure or kill. The arc welding process uses and produces high voltage electrical energy.
This electric energy can cause severe or fatal shock to the operator or others in the workplace.
lNever touch any parts that are electrically “live” or “hot.”
lWear dry gloves and clothing. Insulate yourself from the work piece or other parts of the welding
circuit.
lRepair or replace all worn or damaged parts.
lExtra care must be taken when the workplace is moist or damp.
lInstall and maintain equipment according to NEC code, refer to relative standards
lDisconnect power source before performing any service or repairs.
lRead and follow all the instructions in the Operating Manual.
FIRE AND EXPLOSION
Fire and explosion can be caused by hot slag, sparks, or the arc weld.
lBe sure there is no combustible or flammable material in the workplace. Any material that cannot be
removed must be protected.
lVentilate all flammable or explosive vapors from the workplace.
lDo not cut or weld on containers that may have held combustibles.
lProvide a fire watch when working in an area where fire hazards may exist.
lHydrogen gas may be formed and trapped under aluminum workpieces when they are cut
underwater, or while using a water table. Donot cut aluminum alloys underwater or on a water table
unless the hydrogen gas can be eliminated or dissipated. Trapped hydrogen gas that is ignited will
cause an explosion.
NOISE
Noise can cause permanent hearing loss. Arc welding/cutting processes can cause noise levels to exceed
safe limits. You must protect your ears from loud noise to prevent permanent loss of hearing.
lTo protect your hearing from loud noise, wear protective ear plugs and/ or ear muffs. Protect others
in the workplace.
lNoise levels should be measured to be sure the decibels (sound) do not exceed safe levels.
ARC WELDING RAYS
Arc Welding/ Cutting Rays can injure your eyes and burn your skin. The arc welding/cutting process produces
very bright ultra violet and infra red light. These arc rays will damage your eyes and burn your skin if you are
not properly protected.
lTo protect your eyes, always wear a welding helmet or shield. Also always wear safety glasses with
side shields, goggles or other protective eye wear.
lWear welding gloves and suitable clothing to protect your skin from the arc rays and sparks.
lKeep helmet and safety glasses in good condition. Replace lenses when cracked, chipped or dirty.
lProtect others in the work area from the arc rays. Use protective booths, screens or shields.

-6 -
DYNA TWC 901、902 Operating Manual
1.03 Transporting methods
These units are equipped with a handle for carrying purposes.
WARNING: ELECTRIC SHOCK can kill.
DO NOT TOUCHlive electrical parts. Disconnect input power conductors from de-energized supply
line before moving the welding power source.
WARNING: FALLING EQUIPMENT can cause serious personal injury and
equipment damage.
lLift unit with handle on top of case.
lUse handcart or similar device of adequate capacity.
lIf using a fork lift vehicle, place and secure unit on a proper skid before transporting.

-7 -
DYNA TWC 901、902 Operating Manual
2.0 INSTALLATION RECOMMENDATION
Installation Environment
DYNA TWC series is designed for use in hazardous environments.
Examples of environments with increased hazardous environments are-
In locations in which freedom of movement is restricted, so that the operator is forced to perform the work
in a cramped (kneeling, sitting or lying) position with physical contact with conductive parts; In locations which
are fully or partially limited by conductive elements, and in which there is a high risk of unavoidable or
accidental contact by the operator, or in wet or damp hot locations where humidity or perspiration
considerable reduces the skin resistance of the human body and the insulation properties of accessories.
Environments with hazardous environments do not include places where electrically conductive parts in
the near vicinity of the operator, which can cause increased hazard, have been insulated.
Installation Location
Be sure to locate the welder according to the following guidelines:
lIn areas, free from moisture and dust.
lIn areas, free from oil, steam and corrosive
gases.
lIn areas, not exposed to direct sunlight or rain.
lAmbient temperature: between -10 degrees C
to 40 degrees C.
lIn areas, not subjected to abnormal vibration or
shock.
lPlace at a distance of 304.79mm or more from
walls or similar that could restrict natural airflow
for cooling.
WARNING 1
FCW advises that this equipment be electrically connected by a qualified electrician.

-8 -
DYNA TWC 901、902 Operating Manual
3.0 OPERATOR CONTROLS
Figure 1
1. Input Water Fitting—Fitting size 5/8” –18 LH female.
2. Output Water Fitting—Fitting size 5/8” –18 LH female.
3. Input Cable—3 meter.
4. Fuse
5. Water Reading
6. Main Power Switch—Switching to the ON position power source.
WARNING
When the welder is connected to the primary supply voltage, the internal electrical
components maybe at primary potential with respect to earth.

-9 -
DYNA TWC 901、902 Operating Manual
4.0 SPECIFICATIONS
MODEL TWC 901 TWC 902
Input Voltage 110V 1ph 50/60Hz 220V 1ph 50/60Hz
Input Current 3.4A1.7A
Duty Cycle (40ºC) 100% 100%
Flow 3.0L/min 3.0L/min
Pressure 0.121MPa 0.121MPa
Capacity 7Litre 7Litre
Weight 15kg 15kg
Dimensions (mm) 530*260*320mm 530*260*320mm
Table 1
5.0 PARTS LIST

-10 -
DYNA TWC 901、902 Operating Manual
Figure 2

-11 -
DYNA TWC 901、902 Operating Manual
QTY.
TWC 901 TWC 902
Sequ
ence
Name Order No
P/N: 638003999
P/N: 638004999
1LABEL In/Out TWC902 2LAU8801000 11
2LABEL WATER LEVEL TWC 801/802/901/902 2LAX8804000 11
3LABEL MAIN SWITCH TWC 801/802/901/902 2LAX8806007 11
4LABEL MANUFACTURERS RATING TWC 2LAN8808011 11
LABEL FUSE TWC 901 2LAX8806009 1
5LABEL FUSE TEC 902 2LAX8806008 1
LABEL VOLTAGE INPUT 115V 1PH 2LAM8806008 1
6LABEL VOLTAGE INPUT 220V 1PH 2LAM8800005 1
LABEL FRONT TWC 901 2LAF8802006 1
7LABEL FRONT TWC 902 2LAF8802007 1
8LABEL FCW(SMALL) 2LAS8802013 22
9LABEL WARNING 127*70 2LAW8805000 11
10 SWITCH KCD2-21 16A 4KCD221RD 11
11 BUSHING,STRAIN RELIEF PG11 4SXJPG11 11
12 HANDLE 160/200 4HDL00001 11
13 PANEL TOP FP8.040.008GJ 2FPPT8040008GJ 11
14 SCREW BLACK M4*10 5FPS8918000 16 16
15 SCREW STAINLESS STEEL M5*16 5GBTBYTM5X16 22
16 BASE TWC901/902 FP8.032.006 2FPB8032006 11
17 MOUNT NPRN JJ60 4JFT35X50 11
18 water tank 30*17*15 4WER30X17X15 11
19 BRACKET WATER TANK FP8.038.007 2FPBM8038007 11
20 HOSE FITTING(A) FP8.653.014 2AD8653014 22
21 HOSE WATER 8*13 8HPVCG8X13 1m1m
22 ADAPTORS 2ADEI0001 11
23 ADAPTORS L-PIECE 2ADEL0001 11
24 HOSE FITTING 1/8 2ADHF33X8R5002 11
25 HOSE FITTING 1/4 2ADHF8653016 11
26 HOSE CLAMP 13.5*19 2HFP8636001 33
27 HOSE CLAMP 19.5*22 2HFP8636006 11
28 MOTOR TWC802/902 4WER220V 11
29 BRACKET MOTOR FP8.038.008 2FPBS8038008 11
30 FAN D200 4WER001D200 11
31 CONDENSATOR 240*185*90 4WER001 11
32 FUSE HOLDER 4FUSH15X250XD6 11
FUSE 5A D6*30 4FUS6X30X5A 1
33 FUSE 3A D6*30 4FUS6X30X3A 1
34 HOSE WATER 13*18 8HPVCG13X18 11
35 POWER SUPPLY LINE 3*1MM 8FCWWC3X1BK 33
Remark
transformer 380-200V-110V (100A) 3EER32001 1
Table 2

-12 -
DYNA TWC 901、902 Operating Manual
6.0Remark
6.1 Water Cooler rear panels meet the plume to have good to turn on the earth grounding, by
guarantees the welder safety. When welder operation, should wear protects the mirror,
the glove, puts on protects the clothing.
6.2Ambient temperatures high when big electric current long time continuous working, the
Water Cooler has stopped because of the heat outputting, gets down until the
temperature drop only then restores.
6.3When Water Cooler do not use temporarily, its depository should maintain dryly, cleanly.
The environment relative humidity is not bigger than 85%.
6.4Storing ambient temperature is -25℃~ +55℃.
6.5When long-time does not use, every two months should electrify a time, a humidity month
of every two week should electrify use a time, by use own thermal row of tide.
