Overview
ThispublicationprovidesdirectionsforinstallingtheFederalSignalVi s t a ™Serieslightbarsona
vehicleroof.
Unpacking the Kit
Afterunpackingthekit,inspectitfordamagethatmayhaveoccurredintransit.Ifthecontents
havebeendamaged,donotinstallthekit.Fileaclaimimmediatelywiththecarrier,statingthe
extentofthedamage.Carefullycheckallenvelopes,shippinglabels,andtagsbeforeremovingor
destroyingthem.EnsurethatthepartslistedinTable 1areincludedinthepackage.
Table 1: Kit contents
Qty. Description Part No. Qty. Description Part No.
8Bolt,TorxHd.,5/16-18x5/8 7000434-10 4Bolt,Toggle,1/4-20 8422A032
4Bolt,Rd.Hd.Carriage,
3/8-16x3/4
7004A024-12 4Pad,Mounting 8572029
4Nut,Acorn,1/4-20 7054A010 2 Bracket,Mounting 8583089
continued
Installation Instructions for Vi s t a ®Model XAPK-SC,
-SD or XPK-SC, -SD Permanent Mount Kit

2Vista Model XAPK-SC, -SD or XPK-SC, -SD Permanent Mount Kit
Table 1: Kit contents (continued)
Qty. Description Part No. Qty. Description Part No.
4Nut,Jam,1/4-20 7057A049 2 Foot,Mounting,Left 8583084
4Nut,Hex,3/8-16 7059A063 2 Foot,Mounting,Right 8583085
4Lockwasher,Split,3/8 7074A046 2 Screw,Set,#8-32 7008A012-05
8Lockwasher,Split,5/16 7074A020-01 2 Stop,MountingBolt 8583126
8Washer,Flat,5/16 7072234 8Screw,HexHd.,#10 7011A135-10
NOTE:Forelectricalinstallationinstructions,refertothe Installation and Maintenance Instructions
includedwiththeVistalightbar.
Preparing the Lightbar for Installation
1. Turnthelightbarassemblyoversothatthebottomofthelightbarfacesup.Toavoidmarring
theplasticdomes,placethelightbaronsoftragsorcardboard.
290A4113-01
HEX JAM NUTS 1/4-20 (4)
ACORN NUTS 1/4-20 (4)
TOGGLE BOLTS 1/4-20 x 2" (4)
MOUNTING PADS (4)
5/16" SPLIT
LOCKWASHERS (8)
5/16” FLAT
WASHERS
(8)
BOLT, 5/16-18 x 5/8"
SLTD.TORX PAN HEAD (8)
MOUNTING FOOT, BRACKET (4)
SCREW, HEX HEAD,
#10, TYPE B (8)
BOLT, CARRIAGE (4)
A
B
C
Figure 1: Exploded view of mounting foot hardware
2. Usethe5/16-18x5/8Torxheadbolts,5/16atwashers,and5/16lockwasherstosecurea
mountingfootonthemountingbracket:
a. PositiontheTorxheadboltsatthebottomoftheslotsasshowninFigure 1.
b. Tightentheboltsonlyenoughtoholdthemountingfootinplace.
3. Repeatstepwiththeothermountingbracket.
4. InstalltherubbermountingpadsinthemountingfeetasshowninFigure 1.
NOTE FOR MODEL XAPK-SC:Themountingbracketisfactory-mountedonthelightbarfor
ModelXAPK-SC.Donotperformsteps5through8forthismodel.Proceedtothenextsection
Preparing the Mounting Surface tocompletetheinstallation.

3
Vista Model XAPK-SC, -SD or XPK-SC, -SD Permanent Mount Kit
5. SlidethefourcarriageboltsintotheextrusionasshowninFigure 1.Repeatthissteponthe
otherendofthelightbarassembly.
PROPERLY SECURE MOUNTING BOLT STOPS
If the mounting bracket is improperly assembled, the light assembly could y off
the vehicle causing injury or damage. Ensure that the mounting bolt stops are
securely installed in the extrusion.
6. Slideamountingboltstopintotheextrusionandalignitwiththeedgeoftheextrusion.
Securethemountingboltstopinposition,usingasupplied#8-32setscrew.Repeatonthe
otherendofthelightassembly.
NOTE:Wheninstallingthemountingbracketassembly,useholeAandthehole(BorC)
closesttotheendoftheextrusion(Figure 1onpage2).
7. Installamountingbracketassemblyonthelightbarusing3/8-16hexnuts,atwashers,and
splitlockwashersasshowninFigure 1.Tightenthenutsonlyenoughtoholdthemounting
bracketassemblyinplace.Repeatthisstepwiththeothermountingbracketassembly.
290A4114-01
MOUNTING PAD
MOUNTINGFOOT
5/16-18 x 5/8" TORX HEAD BOLTS
MOUNTING BRACKET
Figure 2:Mounting foot secured to mounting bracket
Preparing the Mounting Surface
HEAVY OBJECT
To avoid personal injury and damage to the lightbar, an assistant should help handle
the lightbar assembly.
IMPORTANT: Planallcableroutingbeforecompletingtheinstallation.
1. Placethelightbaronthevehicleroofattheselectedlocation.Thelightbarshouldtypicallybe
installedapproximatelyoverthedriver’shead.
2. Adjustbothmountingbracketassembliesinoroutuntiltherubbermountingpadsrestnear
theedgeoftheroof,orgutter,wheretheroofismostrigid.
3. Centerthelightbarassemblysothattheendoftheassemblyandedgeoftheroofare
equidistantoneachsideofthevehicle(Figure 3onpage4).Tightenthe3/8-16hexnuts
(twooneachmountingbracket)installedinPreparing the Lightbar for Installation,steps2
and3.

4Vista Model XAPK-SC, -SD or XPK-SC, -SD Permanent Mount Kit
4. Tomaximizeaerodynamicefciencyandhigh-speedstability,itisrecommendthatthe
lightbarbemountedwithaone-inchorgreatergapbetweenthebottomedgeofthelightbar
andtheroof.Onahigh-crownedroof,oneinchmaynotbepossible.Inthiscase,adjustthe
lightbarashighaspossible.Adjustthemountingfeetonthemountingbracketasneeded.
5. Checktoensurethatthelightbarislevelfront-to-back.Ifitisnot,adjustthelevelby
rotatingthelightbarinthemountingbracketslots.Tightenalleight5/16Torxheadboltsthat
fastenthemountingfeettothemountingbrackets.
6. Usingthemountingbracketsasatemplate,scribetwodrill-positionmarksoneachsideof
thelightbar.
7. Removethelightbarassemblyfromthevehicleroof.Toavoidmarringtheplasticdomes,
placethelightbaronsoftragsorcardboard.
8. Turnthelightbarassemblyoversothatthebottomoftheassemblyfacesup.Securethe
mountingassemblytothelightbarusingtheeight#10hexheadthread-formingscrews.
9. Tightenthe3/8-16hexnuts(twooneachmountingbracket)installedinstep7ofPreparing
the Lightbar for Installation.Placethelightbarassemblyonthevehicleroofinthepreviously
determinedposition.
THESE DISTANCES SHOULD BE EQUAL
VEHICLE ROOF
VISTA LIGHTBAR ASSEMBLY
290A4115B
1 INCH OR MORE
Figure 3: Distances between the lightbar assembly and the top and end of the roof
Mounting and Securing the Lightbar Assembly
DRILLING PRECAUTIONS
Before drilling holes, check the area you are drilling into to be sure you do not damage
vehicle components while drilling. All drilled holes should be deburred and all sharp
edges should be smoothed. All wire routings going through drilled holes should be
protected by a grommet or convoluted/split loom tubing.
1. Beforedrilling,movethelightbarassemblyoutoftheway.Drillfour1/2-inchdiameterholes
atthescribeddrillpositionmarks.
2. InsertatoggleboltineachofthefourdrilledholesandsealtheholeswithRTV.Slidetwo
rubbermountingpadsovereachboltasyouinsertit(Figure 4onpage5).Usecautionto
avoiddroppingtheboltsthroughtheholesbeforetherubbermountingpadsareinstalled.
3. Placethemountingbracketsdownovertheendsofthetoggleboltsandsecurethemwiththe
jamnuts(Figure 4 on page 5).Tightenthejamnutjustuntiltherubberpadbeginstobulge.
Donotexceedatorqueof60in-lb.

5
Vista Model XAPK-SC, -SD or XPK-SC, -SD Permanent Mount Kit
4. Sawoffthetogglebolts3/16inchabovethejamnutsandscrewonthecapnuts.The
lightbarshouldnowbesolidlyanchoredtotheroof.
5. Ensurethatallfastenersaresecurelytightened.
IMPORTANT:Frequentlyinspectthelightbartoensurethatallfastenersandbracketsare
tight.
VEHICLE ROOF
VISTA LIGHTBAR
ASSEMBLY
ACORN NUT
EXTRUSION
TOGGLE BOLT
UNIVERSAL
MOUNTING FOOT
JAM NUT
FOOT
BRACKET
290A4116-01
MOUNTING
PAD
Figure 4: Mounting hardware
Ordering Replacement Parts
Toorderreplacementparts,callourMobileSystemCustomerSupportat1-800-264-3578,7a m to
5p m ,MondaythroughFriday(CT)orcontactyournearestdistributor.
Returning a Product to Federal Signal
BeforereturningaproducttoFederalSignal,call800-264-3578,800-433-9132,or800-824-0254
toobtainaReturnedMerchandiseAuthorizationnumber(RMAnumber).Toexpeditetheprocess
pleasebepreparedwiththefollowinginformation:
• YourFederalSignalcustomeroraccountnumber.
• Thepurchaseordernumberunderwhichtheitemswerepurchased.
• Theshippingmethod.
• Themodelorpartnumberoftheproductbeingreturned.
• Thequantityofproductsbeingreturned.
• Dropshipinformationasneeded.
• Anyestimaterequired.
WhenyoureceiveyourRMANumber:
• WritetheRMAnumberontheoutsideoftheboxofreturneditems.
• ReferencetheRMAnumberonyourpaperworkinsideofthebox.
• WritetheRMAnumberdown,sothatyoucaneasilycheckonstatusofthereturned
equipment.
