Federal Signal Corporation 120 Series Installation and operating instructions

120 Series
Loudspeaker, ISMT Loudspeaker,
Powered Loudspeaker, and Sounder
25 Watts
(Model Type ES4 and ES5)
2562192D
REV. D 612
Printed in U.S.A.
Installation, Operation,
and Maintenance

2
Federal Signal Corporation
Integrated Systems
2645 Federal Signal Drive
University Park, IL 60484-3167, U.S.A.
Warranty – Seller warrants all goods for ve years on parts and 2-1/2 years
on labor, under the following conditions and exceptions: Seller warrants that all
goods of Seller's manufacture will conform to any descriptions thereof for speci-
cations which are expressly made a part of this sales contract and at the time
of sale by Seller such goods shall be commercially free from defects in material
or workmanship. Seller reserves the right at the Seller’s discretion to “Repair
and Return” or “Replace” any item deemed defective during the warranty period.
This warranty does not cover travel expenses, the cost of specialized equipment
for gaining access to the product, or labor charges for removal and reinstal-
lation of the product. This warranty shall be ineffective and shall not apply to
goods that have been subjected to misuse, neglect, accident, damage, improper
maintenance, or to goods altered or repaired by anyone other than Seller or its
authorized representative, or if ve years have elapsed from the date of ship-
ment of the goods by Seller with the following exceptions: lamps and strobe
tubes are not covered under this warranty. Outdoor warning sirens and control-
lers manufactured by Federal Warning Systems are warranteed for two years on
parts and one year on labor. No agent, employee, representative or distributor
of Seller has any authority to bind the Seller to any representation, afrmation,
or warranty concerning the goods and any such representation, afrmation or
warranty shall not be deemed to have become a part of the basics of the sales
contract and shall be unenforceable. THE FOREGOING WARRANTIES ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES OR MERCHANT-
ABILITY, FITNESS FOR PURPOSE AND OF ANY OTHER TYPE, WHETHER
EXPRESS OR IMPLIED. These warranties shall not apply unless Seller shall
be given reasonable opportunity to investigate all claims for allegedly defective
goods. Upon Seller's instruction a sample only of allegedly defective goods shall
be returned to Seller for its inspection and approval. The basis of all claims for al-
leged defects in the goods not discoverable upon reasonable inspection thereof
pursuant to paragraph 8 hereof must be fully explained in writing and received
by Seller within thirty days after Buyer learns of the defect or such claim shall be
deemed waived.

3
Contents
Safety Message to Installers, Operators, and
Maintenance Personnel .......................................................................5
An Overview of the 120 Series ............................................................6
Product Detail.........................................................................................7
Special Conditions for Safe Use.............................................................9
Condições especiais para o Uso Seguro: ...........................................10
Installing the Product.........................................................................11
Accessing the Terminals and Glands ................................................... 11
Earthing ................................................................................................12
Greasing Holes for the Mounting Face and Screws.............................13
Wiring the ES4/MS4 Multi-Tone Sounder .........................................14
For 240 Vac Operation .........................................................................14
For 110 Vac Operation..........................................................................14
For 24 Vdc 2-Wire Operation................................................................14
For 24 Vdc 3-to-5-Wire Operation ........................................................16
For AC 4-to-6-Wire Operation...............................................................17
240 Vac Operation: .........................................................................17
110 Vac Operation: .........................................................................17
Routine Maintenance .........................................................................18
Technical Service and Support .........................................................19
Ordering Replacement Parts.............................................................19
Figures
Figure 1 Loudspeaker dimensions........................................................9
Figure 2 Dimensions of mounting bracket ..........................................11
Figure 3 Side and rear views..............................................................12
Figure 4 Tapping .................................................................................12
Figure 5 Speaker wiring diagram........................................................13
Figure 6 Sounder wiring diagram........................................................15
Figure 7 Voltage selector for multi-tone sounder ................................15

4
120 Series Loudspeakers and Sounder
Tables
Table 1 Tone chart for 240 Vac, 110 Vac, and
24 Vdc two-wire operation...................................................... 16
Table 2 Tone chart for 24 Vdc 3-to-5 wire
and AC 4-to-6 wire operation............................................................... 18
Table 3 Replacement parts ................................................................ 19

5
120 Series Loudspeakers and Sounder
Safety Message to Installers, Operators, and
Maintenance Personnel
It is important to follow all instructions shipped with this product. This
device is to be installed by a trained electrician who is thoroughly
familiar with local codes.
The selection of the mounting location for the device, its controls and
the routing of the wiring is to be accomplished under the direction
of the facilities engineer and the safety engineer. In addition, listed
below are some other important safety instructions and precautions
you should follow:
• Read and understand all instructions before installing or
operating this equipment.
• Do not connect this unit to the system while the power is on.
• All effective warning speakers produce loud sounds, which
may cause in certain situations, permanent hearing loss. You
should take appropriate precautions such as wearing hearing
protection.
• All effective warning speakers produce loud sounds, which may
cause, in certain situations, permanent hearing loss. The device
should be installed far enough away from potential listeners to
limit their exposure while still maintaining its effectiveness.
• After installation, test the sound system to ensure that it operates
properly.
• After testing is complete, provide a copy of these instructions to
all operating personnel.
• Establish a procedure to routinely check the speaker installation
for integrity and proper operation. Any maintenance must be
performed by a trained electrician in accordance with NEC
guidelines and local codes.
Failure to follow all safety precautions and instructions may result in
property damage, serious injury, or death.

6
120 Series Loudspeakers and Sounder
An Overview of the 120 Series
The Federal Signal 120 Series Loudspeaker complies with the ATEX
Directive for operation in gaseous hazardous areas classied as
Zone 1 with a temperature classication of –20 °C to +70 °C T4, –20 °C
to +55 °C T5, and –20 °C to +40 °C T6.
The loudspeakers are designed for use in industrial public address
and general alarm applications where ATEX certication is required.
They are available in either an ATEX Zone 1 explosion-proof version
or a CE compliant, marine-grade industrial version.
The Model 120 Series Loudspeaker, including the marine versions
(loudspeaker and MS1), has a main enclosure with dual gland entries
and an FLP end cap. The model is tted with a nose cone, outer and
inner horn, driver, and an adjustable mounting bracket. The compo-
nents within the main enclosure—transformer, transformer and PCB
Assembly, PCB—vary depending on the model.
The 25-watt loudspeakers provide an appropriate amount of sound
for the ambient environment. Each speaker is transformer-coupled to
ne tune the sound output for each application and balance the audio
load. Available audio inputs are 100 Vrms, 70 Vrms, and 8 ohms.
A stainless-steel ratcheted mounting bracket locks the sounder in
position at a specic angle without slipping. The bottom surface of
the mounting bracket also contains three mounting holes, to adapt to
a variety of surfaces.
The loudspeaker is rated for IP66/67 according to EN60529 through
the use of a neoprene O-ring seal. All exterior cast aluminum surfac-
es are nished in powder coat paint and external hardware is manu-
factured from stainless steel to resist corrosion.

7
120 Series Loudspeakers and Sounder
Product Detail
Frequency Range:
Explosion Proof
350–4000 Hz
Marine
300–3700 Hz
Ambient Temperature Range:
T4 Explosion Proof
and Marine
–20 °C to +70 °C
T5 Explosion
Proof
–20 °C to +55 °C
T6 Explosion
Proof
–20 °C to +40 °C
Explosion Proof Rated:
Sound Pressure Level at 1 kHz (full power at 1 meter)
25 W-11B:
123 dBa
Sound Pressure Level at 1 kHz (1 watt at 1 meter)
25 W-11B:
123 dBa
Marine Rated Power:
Sound Pressure Level at 1 kHz (full power at 1 meter)
125 dBa
Sound Pressure Level at 1 kHz (1 watt at 1 meter)
107 dBa
Certications and Approvals:
Nemko 05ATEX1036 II 2 G Ex d IIB T4...T6 Gb
IEC IECEx NEM 04.0002
Marine:
Electromagnetic compatibility to EN 61000-6-1, 2, 3, 4: 2001
ExStandards:
EN 60079-0: 2009
EN 60079-1: 2007
EN 60079-7: 2007

8
120 Series Loudspeakers and Sounder
CE:
EMC to EN 61000-6-1,2,3,4:2001
LVD to EN 60065
Ingress Protection:
Explosion Proof IP66 and IP67-EN60529
Marine IP66 and IP67-EN60529
Specications:
Net Weight Exd Model: 6.4 kg (14.1 lb)
Exde Model: 6.5 kg (14.3 lb)
Shipping Dimensions 32 cm x 30 cm x 38 cm
(12.6 in x 11.8 in x 115.0 in)
Dispersion Angle 120 degrees
Type Dual entry
Gland Entries 2 x M20 x 1.5 mm
Cable Terminations 6A, 1.5 mm conductors
Mounting Unpainted stainless steel bracket
Body and Horn Material Marine grade aluminum alloy
Audio Input 100 volt, 70 volt, and 8 ohms
Power Capacity 25 W
FIRE/EXPLOSION HAZARD
Do not use the 120 Series in ammable atmospheres contain-
ing carbon disulphide (CS2). All units are not certied for use in
ammable atmospheres containing carbon disulphide. Failure
to observe this warning could result in serious injury or death.
AVISO DE PERIGO
PERIGO DE FOGO/EXPLOSÃO
Não use a série 120 em ambientes inamáveis que conte-
nham dissulfeto de carbono (CS2). As unidades não estão
autorizadas para a utilização em ambientes inamáveis
que contenham dissulfeto de carbono. A não observação
deste aviso pode resultar em graves lesões ou morte.

9
120 Series Loudspeakers and Sounder
SHOCK HAZARD
Do not connect this unit to the system while the power is on.
Failure to heed this warning could cause serious injury or
death.
Figure 1 Loudspeaker dimensions
290A6311
2 MOUNTING HOLES
7.0 mm (0.28 in) DIA.
25.0mm
(0.98 in)
315 mm
(12.4 in)
229 mm
(9.02 in)
Special Conditions for Safe Use
To maintain the loudspeaker certication, do not attempt to repair
the ameproof enclosure. Units requiring repair to the ameproof
enclosure must be returned to Federal Signal for service.
The maximum ame path gap for the IIB variants is the same as
for gas group IIC.
All terminal screws, used or unused, must be tightened 0.5 N • m
to 0.7 N • m.
Condições especiais para o Uso Seguro:
Para manter a certicação do auto-falante, não tente restaurar a
cobertura à prova de fogo. As unidades cujas coberturas à prova
de fogo necessitem ser restauradas deverão ser enviadas à em-
presa “Federal Signal” para seu devido conserto.
O intervalo máximo do trajeto da chama para as variantes de ga-
ses IIB é o mesmo que para o grupo de gases IIC.
Todos os parafusos das terminais, estejam as mesmas em uso ou
não, deverão ser apertados à pressão de 0,5 N • m a 0,7 N • m.

10
120 Series Loudspeakers and Sounder
Check label details to ensure the unit is of the correct electrical rat-
ing and hazardous area classication.
For permanently connected equipment located in safe areas, the
equipment supply should be provided via a disconnect device lo-
cated in close proximity to the equipment and within easy reach
of the operator, which is marked as the disconnecting device for
the equipment.
For permanently connected equipment located in a hazardous
area, the equipment supply should be provided via a disconnect
device located in a safe area or via a suitable ATEX approved dis-
connect device located inclose proximity to the equipment, which
is marked as the disconnecting device for the equipment.
Where the disconnect device takes the form of a circuit breaker it
must be properly sized for the required current. The wiring feed-
ing the equipment must be properly sized for the required current.
Recommended cable specication: Elastomeric insulated and
braided armored for xed wiring in ships and offshore units to
BS6883 or IEC92-3.
Maximum core size: 2.5 mm2
Recommended cable gland: Hawke 501/453/univ or equivalent

11
120 Series Loudspeakers and Sounder
Installing the Product
This product must be installed and maintained only by qualied per-
sonnel who have received the relevant training. During installation
ensure that all external screw threads and ameproof faces are suit-
ably greased. Recommended torque on all external xings is 5 N • m.
Check details on the label to ensure the unit is of the correct electrical
rating and hazardous area classication.
Ensure the unit is securely mounted using the supplied bracket. Use
M12 for the center hole and/or 2 x M6 in the outer holes (Figure 2).
You can adjust the angle of the loudspeaker by using the external
ratcheted brackets on each side of the body (Figure 3 on page 12).
Figure 2 Dimensions of mounting bracket
290A6061
MOUNTING
HOLE
7.0 mm DIA.
CABLE HOLE
13.0 mm DIA.
60.0 mm
30.0 mm 30.0 mm
MOUNTING
HOLE
7.0 mm DIA.
Accessing the Terminals and Glands
To access the cable terminals remove the end cap by rst remov-
ing the four M5 socket-head cap screws (Figure 3 on page 12).
The M20 gland entry is located in the main enclosure. Ensure the
cable is terminated in accordance with the gland manufacturer’s
instructions using approved cable glands. Any unused entry must
be sealed with a suitably certied stopper plug.
NOTE: Loudspeakers in close proximity must be connected in the
same phase.

12
120 Series Loudspeakers and Sounder
Figure 3 Side and rear views
290A6313
M20 GLAND
ENTRIES (2)
RACHETED
BRACKET (2)
M5 CAP
SCREW (4)
END
CAP
REAR VIEW SIDE VIEW
Figure 4 Tapping
TRANSFORMER TAPPINGS
STD LOWTERMINALS
1 AND 2 25 W
20 W
15 W
10 W
5 W
2.0 W
1.5 W
1.0 W
0.6 W
0.2 W
1 AND 3
3 AND 4
2 AND 4
1 AND 4
AUDIO IN
SAFETY EARTH
1 2 3 4
STD
LOW
NOTE: ENSURE THE SOUNDER IS
EARTHED USING ONE OF THE
REQUIRED EARTHING POINTS
290A6312B
7
SPEAKER
Earthing
The unit must be correctly connected to earth. Both internal and
external earth terminals are provided.

13
120 Series Loudspeakers and Sounder
Figure 5 Speaker wiring diagram
WIRING DIAGRAM
10-WAY TERMINAL BLOCK
INSIDE SOUNDER
1 2 3 4 5 6 7 8 9 10
+24 Vdc /48 Vdc
0V
TO NEXT SPEAKER
AUDIO SIGNAL
AUDIO SIGNAL
120 Vac /240 Vac
+
−
L
N
FROM ECHO
MODEL OR
PREVIOUS
SPEAKER
2 x M20 GLAND
ENTRIES
INTERNAL
EARTH
IN LID
EXTERNAL
EARTH 290A6314
110060
VOL
VOLUME CONTROL:
TURN CLOCKWISE TO
INCREASE VOLUME
1 2 3 4 5 6 7 8 9 10
REAR VIEW
Greasing Holes for the Mounting Face and Screws
Before the installation you must grease all holes for the O-ring
mounting face and screws.
When you are nished installing the speaker, install the O-ring
and end cap, ensuring that there are no trapped wires. Tighten
the end cap using all four stainless-steel screws to 5 to 7 N • m.

14
120 Series Loudspeakers and Sounder
Wiring the ES4/MS4 Multi-Tone Sounder
This section provides instructions for operating the Multi-Tone Sound-
er at 240 Vac, 110 Vac, and 24 Vdc.
Also included are instructions for 24 Vdc 2-wire operation, 24 Vdc
3-to-5-wire operation, and AC 4-to-6-wire operation. See Figures 6
and 7 on page 15 and the Table 1 on page 16.
For 240 Vac Operation
1. Set the Voltage Selector to 230 V.
2. Insert the 250 mA fuse.
3. Turn the tone selector to the position of the tone you want.
4. Connect the Live wire to the LIVE IN terminal.
5. Connect the Neutral wire to the NEUTRAL IN terminal.
6. Connect the Internal Earth wire to the INTERNAL EARTH
terminal.
For 110 Vac Operation
1. Set the Voltage Selector to 110 Vac.
2. Insert the 500 mA fuse.
3. Turn the tone selector to the position of the tone you want.
4. Connect the Live wire to the LIVE IN terminal.
5. Connect the Neutral wire to the NEUTRAL IN terminal.
6. Connect the Internal Earth wire to the INTERNAL EARTH
terminal.
For 24 Vdc 2-Wire Operation
1. Turn the tone selector to the position of the tone you want.
2. Connect to the 0V common terminal.
3. Connect the +24 Vdc wire to the +24V IN terminal.
4. Connect the Internal Earth wire to the INTERNAL EARTH
terminal.

15
120 Series Loudspeakers and Sounder
Figure 6 Sounder wiring diagram
2 x M20 GLAND
ENTRIES
INTERNAL
EARTH
IN LID
EXTERNAL
EARTH
290A6315
REAR VIEW
LIVE (IN)
NEUTRAL
(OUT)
(IN)
(OUT)
(IN)
(OUT)
(IN)
(OUT)
T. 4 T. 3 T. 2 T. 1
COMMON
+24V
F2
F1
TONE
SELECTOR
DETAIL OF 12-CONNECTOR
TERMINAL BLOCK
Figure 7 Voltage selector for multi-tone sounder
VOLTAGE
SELECTOR
220 V / 240 V 110 V /120 V

16
120 Series Loudspeakers and Sounder
Table 1 Tone chart for 240 Vac, 110 Vac, and
24 Vdc two-wire operation
Position Tone
0 OFF
1Two tones: 588 Hz for 0.25 second, 714 Hz for 0.25 second
2 Swept 600 Hz > 700 Hz in 0.5 second
3 Telephone warble
4 Constant 700 Hz
5 Simulated bell, three rings per second
6Swept 1.2 kHz > 1.6 kHz, swept 1.6 kHz > 1.2 kHz, six
cycles per second
7 Two tones: 1 kHz for 0.4 second, 700 Hz for 0.4 sec.
8 700 Hz for 0.25 second, silence for 0.25 second
9Swept 400 Hz > 1.6 kHz in 1 second, constant 1.2 kHz
for 2 second
A (10) Swept 500 Hz 770 Hz in 0.5 second.
B (11) 1 kHz for 1 second, silence for 1 second
C (12) Constant 1 kHz
D (13) Two tones: 700 Hz for 0.5 second, 500 Hz for 0.5 second
E (14) Warble between 1 kHz and 1.4 kHz approx. 10 cycles
per second
F (15) Swept 1.2 kHz > 400 Hz in 1 second
For 24 Vdc 3-to-5-Wire Operation
See Figures 6 and 7 on page 15 and the Table 2 on page 18.
1. Turn the tone selector to 0.
2. Connect to the 0 V common terminal.
3. Connect the +24 Vdc supply/select wires to the T1, T2, T3,
T4 terminals. These connections enable you to select the four
basic tones remotely.
4. Connect the Internal Earth wire to the INTERNAL EARTH
terminal.

17
120 Series Loudspeakers and Sounder
For AC 4-to-6-Wire Operation
See Figures 6 and 7 on page 15 and the tone chart on page 18.
240 Vac Operation:
1. Set the Voltage Selector to 230 V.
2. Insert the 250 mA fuse,
3. Turn the Tone Selector to the 0 position.
4. Connect the Live wire to the LIVE IN terminal.
5. Connect the Neutral wire to the NEUTRAL IN terminal.
6. Connect the Internal Earth wire to the INTERNAL EARTH ter-
minal.
7. Connect a link between the NEUTRAL OUT and +24V OUT
terminals.
8. In the control panel connect from Neutral return through SE-
LECT LINES. These connections enable you to remotely se-
lect the four basic tones.
9. Connect wires to the T1, T2, T3, and T4 terminals as needed.
110 Vac Operation:
1. Set the Voltage Selector to 110 V.
2. Insert the 500 mA fuse,
3. Turn the Tone Selector to the 0 position.
4. Connect the Live wire to the LIVE IN terminal.
5. Connect the Neutral wire to the NEUTRAL IN terminal.
6. Connect the Internal Earth wire to the INTERNAL EARTH ter-
minal.
7. Connect a link between the NEUTRAL OUT and +24V OUT
terminals.
8. In the control panel connect from Neutral return through SE-
LECT LINES. These connections enable you to remotely se-
lect the four basic tones.
9. Connect wires to the T1, T2, T3, and T4 terminals as needed.

18
120 Series Loudspeakers and Sounder
Table 2
Tone chart for 24 Vdc 3-to-5 wire and AC 4-to-6 wire operation
Terminal Tone
T1 Two tones: 588 Hz for 0.25 second, 714 Hz for 0.25 second
T2 Swept 600 Hz > 700 Hz in 0.5 second
T3 Constant 700 Hz
T4 700 Hz for 0.25 second, silence for 0.25 second
Routine Maintenance
FIRE/EXPLOSION HAZARD
Do not open the loudspeaker and/or sounder, even they are iso-
lated, when a ammable-gas atmosphere is present.
Failure to observe this warning could result in serious injury or
death.
AVISO DE PERIGO
PERIGO DE FOGO/EXPLOSÃO
Não abra a cobertura na presença de gases perigosos.
A não observação deste aviso pode resultar em graves
lesões ou morte.
Ensure that the unit is maintained in line with the regulations in force
and at least once per year.
• Check for external damage and corrosion and repair and replace
as required.
• Check for water ingress and replace the O-rings if necessary.
• Check all earth connections.
• Check ameproof paths and xing screws for damage and corrosion.
• Grease all threads, O-rings, and ameproof paths.

19
120 Series Loudspeakers and Sounder
Technical Service and Support
For technical service and support, please contact:
Federal Signal Corporation
Integrated Systems
Service Department
2645 Federal Signal Drive
University Park, IL 60484-3167, U.S.A.
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Ordering Replacement Parts
To order the replacement parts in Table 3, please contact the Service
Department. When removing any of the subassemblies ensure that
you do not break the two ying leads from the voice coil.
Table 3 Replacement parts
Description Part Number
Mounting Bracket K8597108
Ratchet Fixing Kit K8597225
Cap Screw K7000496-30
O-Ring Kit K8597226
PCB, 100 V ISMT Module, 25 W K2001974
PCB, Sounder Module, 25 W K2005360
PCB, Powered Speaker, 25 W, 24 Vdc K2001975
PCB, Powered Speaker, 25 W, 120 Vdc K2001975-02
PCB, Powered Speaker, 25 W, 240 Vdc K2001975-03
Transformer, 100 V K1461683-01
Transformer, 70 V K1461683
Driver Assembly, 25 W K8597168

20
120 Series Loudspeakers and Sounder
