Feelworld FW1018SPV1 User manual

10.1" Full HD Field Monitor
Support 4K HDMI Input/ Output
User Manual

1
CONTENTS
1. Product Overview ------------------------------------ 2
2. Cautions ------------------------------------------------- 3
3. Product Features ------------------------------------- 4
4. Product Description --------------------------------- 6
5. Power Supply ----------------------------------------- 10
6. TALLY Indicator Connection --------------------- 12
7. Menu Operation Instruction ---------------------- 13
8. Menu Function Instruction ------------------------ 14
9. Parameters ---------------------------------------------- 18
10.Trouble Shooting ------------------------------------- 20

2
1. Product Overview
Thank you for using our professional broadcasting kits color LCD
monitor. This monitor adopts advanced integrated circuits,
high-quality new HD IPS LCD panel, which makes it low power
consumption, stable performance etc. Advanced features include
Focus Assist, Center Marker, Safe Frames, Color Temp. adjust,
ideal portable lightweight as viewfinder and video monitor
equipment.
Our monitor not only has 3G-SDI (Optional), HDMI, YPbPr, video
input & output and Audio (L/R) input, but also has multi way of
installation which can be easily installed with various hot shoes
mount, bracket and sunshade. To meet different customers’ needs
that use outdoor under high sunlight or outdoor without the power. It
is the best partner of photography. It is widely used in professional
camera video creation, aerial, security and other fields.
To insure best use of the unit, please read the user’s
manual carefully
● Please read this manual before using the product.
● Please keep manual for future reference.
● Please read the cautions to prevent the possible danger and
loss of property.
● Please follow the instruction to use this product.
● Do not use the accessory without authorized by the
Manufacturer. Improper use will cause serious accidents.

3
2. Cautions
● Please avoid the heavy impact and drop onto the ground when
move the product.
● Please do not cover the vents and holes on the enclosure and
do not place the machine on a bed, sofa, and rug to ensure
good ventilation. Otherwise it will lead to overheating and
reduces the service life.
● The screen of this product is made of glass. Please do not
display the screen towards the ground. Keep away from injury if
the screen is broken.
● Keep the product away from the heat source, such as radiator,
water heater, stoves or other heating products.
● Avoid prolonged exposures to the sun as the LCD screen will be
damaged.
● Please use the qualified adapter.
● To avoid damaging the product, please do not take apart or
repair the unit by yourself without adjustable component in the
unit.
● To better maintain the LCD screen, please notice the way as
below to avoid the scratch, discoloration and other damage.
1. Please refrain from using hard objects to hit the screen.
2. Please do not force to wipe the screen.
3. Please do not use chemical solutions to clean the screen.
4. Please do not spray any detergent on the screen.
5. Please do not write on the screen directly.

4
6. Please do not stick on the screen.
7. Please simply wipe with a clean soft cloth and make sure no
water on the screen.
● To better protect the plastic cover, please follow these ways as
below to avoid the damage:
1. Please do not use chemical solutions to clean the cover.
2. Please keep away from the volatile things.
3. Please keep away from the rubber.
4. Please do not clean hard casing.
5. Please simply wipe with a clean soft cloth and make sure no
water on the cover.
3. Product Features
● IPS LCD panel, full HD 1920X1200
●Support 4K UHD signal input and output
3840×2160p (30/29.97/25/24/23.98 Hz) / 4096×2160p (24Hz)
●Histogram is a quantitative tool to inspect the image brightness,
to guide the exposure control (Optional)
●Analog stereo L/R, embedded audio display (Optional)
●Focus Assist
●Zebra and False Color function, convenient to guide the using
light when shooting and the post production (Optional)
●Check Field (Red, Green, Blue, Mono)
●Image Zoom-in function
● Anamorphic Mode

5
●Image Flip (H, V, H/V)
●Image Freeze
●Image Nine Grid, zoom one of the images to realize the full
screen
●Pixel to Pixel
●Marker Types, Safe Frames and Center Marker
●Display and adjust the image Color Temp
●Brightness, Contrast, Tint, Saturation and Color Temp
Adjustment.
●Support a variety of different types of battery brands
(F970, E6, D28S, V Type, Anton)
●A variety of SD HD video interface SDI (Optional), HDMI, YPbPr,
Video inputs and outputs.
●Speaker and earphone output
●External sunshade, sunlight readable

6
4. Product Description
Front Panel Features
1. : Earphone jack
2. Speaker
3. VIDEO: Video signal input selected
4. YPbPr: Ypbpr signal input selected
5. HDMI: HDMI signal input selected
6. SDI: SDI signal input selected (Without SDI model, this button
has no effect)
7. F1, F2, F3, F4, F5, F6: User-definable Function Buttons
8. /MENU: Without enter into the menu, directly rotate this
button, it is for image Saturation adjustment.

7
Press this button to pop up OSD menu, rotate it to select the
secondary menu bar or function menu set and analogue value
adjustment.
9. /ESC : Without enter into the menu, directly rotate this
button, it is for image Brightness adjustment.
Under menu operation, left rotate this button to enter into
function menu and select, press it to exit menu.
10. /FOCUS: Directly rotate this button is for image Contrast
adjustment. Press it directly is the Focus Assist shortcut
button.
11. / : Directly rotate this button is for Volume adjustment.
Press it directly is the Camera Mode shortcut button.
12. Power indicator
13. TALLY indicator

8
Rear Panel Features
1. Signal interfaces
(See below “Signal Interfaces Instruction”)
2. Power switch: ▬:Power on (ON), O: Power off (OFF)
3. TALLY (indicator) signal input
4. 4-PIN（XLR）DC 12V Power input
5. DC power input port
6. USB upgrades port
Remark: There is a hidden upgrade interface behind
the battery plate, please remove the battery plate if you
need to upgrade it.

9
Signal Interfaces Instruction
1. HDMI IN & OUT
2. Y IN & OUT
3. Pb IN & OUT
4. Pr IN & OUT
5. VIDEO IN & OUT
6. AUDIO L/ R IN
7. 3G-SDI IN & OUT (Optional)

10
5. Power Supply
This monitor can be powered with these three ways:
★DC Power Supply:
The power supplied by the adapter. 12V is optional DC voltage
charger, insert DC power input interface directly. You can choose
qualified adapter with output voltage DC 6 ～36V, output
capacity >12W by customers.
Please note the input polarity is Positive with respect to:
Picture:
Otherwise our LCD monitor might be damaged.
If need to use other specifications adapter, please provide the
qualified adapter whose power supply should be not less than 12W
(DC6V-36V).
★This product also can be powered by 4-Pin XLD interface to
use the power supplied from camera：
4-Pin (XLR) power input connection:
★Powered by Battery:
There is a battery plate installed on the back of the monitor, you
could install the battery to it and supply the battery to the monitor.
It is suitable for outdoor use.

11
There are five different types of batteries; customers can choose
the corresponding battery according to the battery plates.
(Standard accessory is F970 if no request).
★Battery Plate:
F970 LP-E6 D28S U60
Anton Plate V-Mount Plate
We assemble the suitable battery plate for the customers according
to the different requirements of the batteries.If the customers have
no requirement on the battery, the factory assembles F970 battery
plate by default.
●Sony F970 battery plate for battery of Sony DV:
Sony F970 F960 F950 F930 F770 F750 F730 F570 F550 F530
QM91D QM91 QM90D QM90 QM71D QM71 QM70D QM70

12
QM51D QM51 FM71 FM70 series
●LP-E6 battery plate for battery of Canon DV:
Canon LP-E6
●D28S battery plate for battery of Panasonic DV:
Panasonic D55 554S D54SE D40 D35 D33 D32 D28 D25 D22
series
●U60 battery plate for battery of Sony DV:
SONY BP-U30/U60/U90, domestic U62/U65/U66/U95/U98 series.
●Sony V-mount camera battery Plate
●Panasonic Anton Bauer battery Plate
6. TALLY Indicator Connection
Indicator Color
Pin connect
Green
1-5
Red
6-5
Yellow
9-5

13
7. Menu Operation Instruction
Follow the instructions mentioned above then plugged into a power
supply and signal, turn on the power, and then follow below
instructions for menu operation:
Menu operation and F1～F6 shortcuts button set
7.1 Press “MENU” to enter “main menu” interface.
7.2 Left/ right rotate “/MENU”button to select, then left rotate
“ /ESC” knob to enter into the secondary menu.
7.3 After enter into secondary menu, then rotate “ /ESC” knob
to enter and select the corresponding set or adjust items (The
cursor moves accordingly).
7.4 When the cursor stay in the corresponding set item, then rotate
“ /MENU” knob to adjust or select the selected item.
7.5 Press “ /MENU” knob to confirm after item adjust.
7.6 Press “ /ESC” knob to exit all Menu.

14
8. Menu Function Instruction
P2P, Zoom ALL, L/R Zoom, U/D Zoom, Aspect Ratio,
Anamorphic Mode, Nine Grid all functions that associated
with the image magnification function are non-supported in
4K Mode.
Image
Pic. Mode
Dynamic, Standard, Mild, User
Select ‘user’ to adjust Brightness, Contrast, Saturation,
Sharpness.
Brightness
0～100
Contrast
10～100
Saturation
0～100
Sharpness
0～100
Color Temp.
6500, 9300, User
When select ‘user’, adjust the Red, Green, Blue to meet
the different user's requirement.
Tint
0～100

15
Setting
Language
English,中文, Español, Português, Français,
Nederlands, Deutsch,日本語
Aspect Ratio
Just Scan, Panorama, Auto., 4:3, 16:9, Zoom 1, Zoom 2
No Signal
White Screen, Blue Screen, Red Screen, Green
Screen, Black Screen
OSD Trans.
Off, Low, Middle, High
OSD H
0～100
OSD V
0～100
Camera Mode
Off, 480P, 1080i
Zoom All
0～100
OSD Time
Off, 10Sec, 20Sec, 30Sec
U/D Zoom
0～100
L/R Zoom
0～100
Backlight
10～100
USB Upgrade
Copy the file to the U disk, connect the USB cable, right
rotate “ /MENU” knob to confirm. After the
upgrade, monitor will automatically restart.
Reset
Right rotate “ /MENU” knob to confirm, back to
original setting.

16
Function (Histogram P Model)
Center Marker
Off, On
Safe Frames
Off, 80%, 85%, 90%, 93%, 96%, 2.35:1
Image Freeze
Off, On
Image Flip
Off, H_V Flip, H Flip, V Flip
Check Field
Off, Mono, Red, Green, Blue
P2P
Off, On
Histogram
Off, On
False Colors
Off, On
Zoom
Off, 4X, 9X, 16X
Anamorphic
Off, 1.3X, 2.0X, 2.0X MAG
Focus Assist
Off, On
Peaking Color
Red, Green, Blue
Over Exposure
Off, On
Exposure Level
1～100 IRE
Embedded Audio
Off, On
Nine Grid
Off, On
Open it to set the image Nine Grid and rotate
“ /MENU” knob to choose a image, and then rotate
“ /ESC” knob to zoom the image to full screen, press
“ /MENU” knob to exit.
Ratio Marker
Off, 4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1
Mark Color
Red, Green, Blue, Black, White
Mark Width
1～7
Modified Mark
0～6

17
Function (Without Histogram Model)
Center Marker
Off, On
Safe Frames
Off, 80%, 85%, 90%, 93%, 96%, 2.35:1
Image Freeze
Off, On
Image Flip
Off, H_V Flip, H Flip, V Flip
Check Field
Off, Mono, Red, Green, Blue
P2P
Off, On
Zoom
Off, 4X, 9X, 16X
Anamorphic
Off, 1.3X, 2.0X, 2.0X MAG
Focus Assist
Off, On
Under signal input, open this function, superimpose red
highlight over parts of the monochrome image in focus.
Nine Grid
Off, On
Open it to set the image Nine Grid and rotate
“ /MENU” knob to choose a image, and then rotate
“ /ESC” knob to zoom the image to full screen, press
“ /MENU” knob to exit.
Ratio Marker
Off, 4:3, 13:9, 14:9, 15:9, 16:9, 1.85:1, 2.35:1
Mark Color
Red, Green, Blue, Black, White
Mark Width
1～7
Modified Mark
0～6

18
Custom Button Setting F1～F6
F1～F6 shortcut buttons set:
1. Press “ /MENU” knob to enter into menu, rotate
“ /MENU” knob to select F menu, and then left rotate
“ /ESC” button to enter F1.
2. Rotate “ /MENU” knob to pop up custom function menu
bar.
3. Left right rotate “ /ESC” to select one of the functions.
4. After selected (The cursor stays position), then press
“ /MENU” button to confirm.
5. After confirm, then rotate “ /ESC” button again to enter the
next shortcut button set.
6. F2～F6 same setting as above step.
9. Parameters
Panel Size
10.1″ Inch
Aspect Ratio
16:10
Resolution
1920×1200 pixels
Dot pitch
0.113(H)×0.113 (W) mm
Brightness
320cd/m2
Contrast
800:1
Viewing Angle
85°/85°(L/R) 85°/85°(U/D)
Backlight
LED

19
Input
3G-SDI (Optional), HDMI, YPbPr, VIDEO, AUDIO (L/R)
Output
3G-SDI (Optional), HDMI, YPbPr, VIDEO
Audio
Stereo Headphone; Speaker (built-in)
TALLY
RS232 D-sub 9pin
SDI Format
480i/ 576i
720p (60/59.94/50/30/29/25/24/23.98)
1080i (60/59.94/50)
1080p (60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
HDMI Format
480i/576i/480p/576p
720p(60/59.94/50/30/29/25/24/23.98）
1080i(60/59.94/50）
1080p(60/59.94/50/30/29.97/25/24/24sF/23.98/23.98sF)
4K UHD 3840×2160p (30/29.97/25/24/23.98Hz)
4096×2160p (24Hz)
4K UHD 3840×2160p (30/29.97/25/24/23.98Hz)
4096×2160p (24Hz)
)
YPbPr Format
480i / 576i / 576p, 720p (60/50), 1080i (60/50)
CVBS (Video)
NTSC 480i; PAL 576i
Input Voltage
DC 7～24V
Power Consumption
≤ 12W
Unit Size
258L×192H×39D (mm)
Unit Weight
810g
Install Way
1/4 inch standard bracket mounting screw holes in left,
right and bottom of the monitor
Working Temperature
-20～55℃
Storage Temperature
-30～65℃
