FEHN ASSEMBLY INSTRUCTIONS
•The Assembly and Setup Instructions must be strictly followed. The FEHN should
always be used directly on the floor or other solid, level surface.
•Height and Weight Limits:
- Standard Height Model #s 700S-R, 700L-R, 700E-R:
max weight: 250lbs
max height: 6’1”
- Tall Height Model #s 700S-T, 700L-T, 700E-T:
max weight: 300lbs
max height: 6’5”
*If you are not sure what model chair you have, check the label on the chair
frame. That label includes the model# as well as the height and weight limits.
•Children under the age of 14 should not use the FEHN.
•The seat is designed to move freely. It rocks and swivels 360 degrees. You should
use caution getting in and out of the FEHN; use the handles to stabilize
yourself.
•Always have both feet fully supported by the foot rests or the floor when using
the FEHN.
•Wearing pumps or stiletto heels on the FEHN is not recommended.
•Do not lean sideways on the FEHN.
•Do not sit on the foot rest.
•Always adjust the chair position, height and spring tension as described in the
FEHN Setup Instructions.
•The FEHN is for indoor use only. Do not store the FEHN outdoors, near water, or
at high humidity levels.
Please read this warning carefully before using the FEHN.
The FEHN is different than any other chair on the market,
and requires some time and care when using it.
WARNING

FEHN ASSEMBLY INSTRUCTIONS
In the Box
AB C D
EFG
Step 1:
B
C
•Swing open the arms in the Base Assembly (A)
•Using the Allen Wrench C, screw the Socket Head Bolts (B) into the arms to lock
them in place. Make sure the bolts are well tightened and the heads are flush with
the top of the base. If they are secured correctly, the arms should not move at all.
A
arms
ABase Assembly 1 ea
B5/16" Socket Head Bolt 2 ea
C1/4" Allen Wrench 1 ea
DKnob 1 ea
ESeat 1 ea
FBronze Washer 1 ea
GQuick Release Pin 1 ea

FEHN ASSEMBLY INSTRUCTIONS CONTINUED
D
FEHN ASSEMBLY INSTRUCTIONS CONTINUED
Step 3:
Step 2:
brass piston
seat tube
•Unfold the Seat Tube and Brass Piston. Place the Ball End of the Brass Piston into the
Piston Lock Pocket on the base.
•Pull down on the Seat Tube until the Brass Piston Ball End is securely locked into the
Piston Lock Pocket. You will hear a loud click when it locks securely.
•Caution: Do Not sit on the Fehn unless you are certain that the bottom of the Brass
Piston is securely locked into the Piston Lock Pocket.
•(If you later need to fold the Fehn up for transport, use the Pull Pin to release the
Brass Piston from the Piston Lock Pocket)
piston lock pocket
pull pin
foot rest tube
•Unfold the Foot Rest Tube until the slot at bottom fits over the threaded post on the base.
•Screw the Knob (D) onto the post until it is firmly tightened against the base. You should not
be able to fold the Foot Rest Tube when it is installed properly.
threaded post
brass piston
ball end

FEHN ASSEMBLY INSTRUCTIONS CONTINUEDFEHN ASSEMBLY INSTRUCTIONS CONTINUED
Step 4:
seat mount
block
G
•Install the Seat (E) into the Seat Mount Block placing the Bronze Washer (F) as depicted
above. The Bronze Washer (F) should be placed above the Seat Mount Block.
•Once the seat is in the Seat Mount Block, insert the Quick Release Pin (G) into the lower hole
on the Seat Mount Block to secure the seat in place. DO NOT USE THE FEHN
WITHOUT INSTALLING THE QUICK RELEASE PIN PROPERLY.
•Note: If you need to pack or transport the seat you can move the Quick Release Pin to the
upper hole in the Seat Mount Block to prevent the seat from rotating. You should not use
the FEHN when the Pin is in the upper hole. This is for transport only.
E
IMPORTANT: Before using the FEHN follow the Setup
Instructions on the following pages or watch the video at
www.TheFehn.com/setup to ensure the chair
is adjusted properly for your comfort and body!
