ORIGINAL INSTRUCTIONS
Garden Blower Vacuum
Instruction Manual
FAS3000-A
CAUTION: Read and follow all Safety Rules and Instructions before operating this
equipment
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux – France
Fabrique en PRC

2
CONTENTS
1. SAFETY INSTRUCTIONS 3
2. YOUR PRODUCT 17
3. ASSEMBLY 18
4. OPERATION 19
5. MAINTENANCE AND STORAGE 22
6. DISPOSAL 22
7. DECLARATION OF CONFORMITY 23
8. WARRANTY 24
9. PRODUCT FAILURE 25
10.WARRANTY EXCLUSIONS 26

3
1.SAFETY INSTRUCTIONS
Safe operating practices for hand-held
mains-operated electrical garden vacuums,
and garden blower/vacuums with or without
shredding means and garden blowers
Training
a) Read the instructions carefully. Be familiar
with the controls and the correct use of the
machine.
b) Never allow children or people unfamiliar
with these instructions to use the machine.
Local regulations can restrict the age of the
operator
c) Keep in mind, that the operator or user is
responsible for accidents or hazards occurring
to other people or their property.
Preparation
a) Obtain ear protection and safety glasses.
Wear them at all times while operating the
machine.
b) While operating the machine always wear
substantial footwear and long trousers. Do not
operate the machine when barefoot or
wearing open sandals. Avoid wearing clothing
that is loose fitting or that has hanging cords
or ties.

4
c)Do not wear loose clothing or jewellery that
can be drawn into the air inlet. Keep long hair
away from the air inlets.
d) Operate the machine in a recommended
position and only on a firm, level surface.
e) Do not operate the machine on a paved or
gravel surface where ejected material could
cause injury.
f) Before using, always visually inspect to see,
that the shredding means,shredding
means bolts and other fasteners are secure,
the housing is undamaged and that guards
and screens are in place. Replace worn or
damaged components in sets to preserve
balance. Replace damaged or unreadable
labels.
g) Before use, check the supply and extension
cord for signs of damage or aging. If the cord
becomes damaged during use, disconnect the
cord from the supply immediately. DO NOT
TOUCH THE CORD BEFORE
DISCONNECTING THE SUPPLY. Do not use
the machine if the cord is damaged or worn.
h) Never operate the machine while people,
especially children, or pets are nearby.
Operation
a) Before starting the machine, make certain
that the feeding chamber is empty.

5
b) Keep your face and body away from the
feed intake opening.
c)Do not allow hands or any other part of the
body or clothing inside the feeding chamber,
discharge chute, or near any moving part.
d) Keep proper balance and footing at all times.
Do not overreach. Never stand at a higher
level than the base of the machine when
feeding material into it.
e) Always stand clear of the discharge zone
when operating this machine.
f) When feeding material into the machine be
extremely careful that pieces of metal, rocks,
bottles, cans or other foreign objects are not
included.
g) If the cutting mechanism strikes any foreign
objects or if the machine should start making
any unusual noise or vibration, immediately
shut off the power source and allow the
machine to stop. Disconnect the machine from
the supply and take the following steps before
restarting and operating the machine:
inspect for damage;
replace or repair any damaged parts;
Check for and tighten any loose parts.
h) Do not allow processed material to build up
in the discharge zone; this may prevent proper
discharge and can result in kickback of
material through the intake opening.

6
i) If the machine becomes clogged, shut-off the
power source and disconnect the machine
from supply before cleaning debris.
j) Never operate the machine with defective
guards or shields, or without safety devices,
for example debris collector in place.
k)Keep the power source clean of debris and
other accumulations to prevent damage to the
power source or possible fire.
l) Do not transport this machine while the power
source is running.
m) Stop the machine, and remove plug from the
socket. Make sure that all moving parts have
come to a complete stop
whenever you leave the machine,
before clearing blockages or unclogging
chute,
Before checking, cleaning or working on
the machine.
n) Do not tilt the machine while the power
source is running.
Maintenance and storage
a) When the machine is stopped for servicing,
inspection, or storage, or to change an
accessory, shut off the power source,
disconnect the machine from the supply and
make sure that all moving parts are come to a
complete stop. Allow the machine to cool

7
before making any inspections, adjustments,
etc. Maintain the machine with care and keep
it clean.
b) Store the machine in a dry place out of the
reach of children.
c)Always allow the machine to cool before
storing.
d) When servicing the shredding means be
aware that, even though the power source is
switched off due to the interlock feature of the
guard, the shredding means can still be
moved
e) Replace worn or damaged parts for safety.
Use only genuine replacement parts and
accessorises.
f) Never attempt to override the interlocked
feature of the guard.
Additional safety instructions for units with
bagging attachments
Switch-off the machine before attaching or
removing the bag.
Recommendation
The machine should be supplied via a residual
current device (RCD) with a tripping current of
not more than 30 mA.

8
Additional instructions
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance by
a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Never allow children, persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge or people
unfamiliar with these instructions to use the
machine, local regulations may restrict the age
of the operator.
Never use the machine when people,
especially children, or pets are nearby.
Remember that the operator or user is
responsible for accidents or hazards occurring
to persons or their belongings.
Before connecting, check:
oWhether the tool and cable are not
damaged. If damaged, do not use the
machine and bring it back to your dealer for
inspection and repair.
oThat the voltage on the rating plate of the
tool matches with your electrical installation.

9
Do not use accessories other than those
recommended by the manufacturer; Non-
recommended accessories can damage the
unit and/or cause injuries.
Do not disassemble the tool yourself.
Disassembly, repair or inspection must be
made exclusively by qualified personnel.
Use the tool fully assembled and secure.
Before using, check if the protections and
safety devices are in place.
During the operation of the machine, always
wear protective equipment, including
protective masks, visors or goggles, ear
protection, helmet, gloves, non-slip footwear
and protective clothing.
Always carry the machine by its handle; never
use the cord or any other part of the machine.
Do not use the machine when you are tired,
under the influence of alcohol or drugs or sick.
Use the tool to suck and blow leaves and
similar materials. Do not blow flammable
materials, cigarette butts and materials that
can damage the device.
Do not use the appliance to suck water or wet
debris.
Always use the machine with the collection
bag.

10
Avoid using the machine in bad weather,
especially when there is a risk of
thunderstorms and lightning.
In case of accident, immediately stop using
the machine. Turn off and unplug it and check
the problem. Do not use the machine while the
machine is damaged.
Do not use the tool if you are drunk, tired,
under the influence of drugs or ill. Do not use
the tool if you are not in an adequate physical
condition
Do not use the tool during bad weather
conditions (lighting, rain, storm, big winds, etc.)
Do not use the tool in an area where
ventilation is poor. Gas emissions can cause
injury.
Do not use the tool in damp locations.
Do not use the tool in the presence of
flammable liquids or gases.
Do not operate the product with damaged
guards or shields not in place.
Do not lean. Keep a good balance at all times.
Keep handles dry, clean and free from oil and
grease.
Use and handle the machine carefully.
Do not put your body, clothes or shoes close
to the air opening
Do not lift up the tool when it is in operation.

11
Do not point the tool in front of people; this
can lead to accidents and injuries.
Do not put any objects inside the tube and
inside the tool.
Before using the product and after any shock,
please check it for signs of wear or damage.
Please carry out repairs if necessary.
Inspect and regularly service the product.
Repairs should be carried out only by an
authorized service center or a similarly
qualified specialist.
Children should not play with plastic bags,
sheets and small parts! Keep them out of the
reach of children. There is a danger of
swallowing and suffocation!
Do not use the product on a slippery surface.
Do not use the product on steep, slippery
slopes. If you need to work on slopes, use an
extreme care and be careful about your
footing. Please wear non slippery footwear.
When planning your work schedule, allow
enough time for rest. Limit continuous use of
the device, e.g. use 30 ~ 40 minutes per
session, and take 10 ~ 20 minutes of rest
between work sessions. Work a maximum of
two hours per day.
Do not connect a damaged cord to supply or
touch a damaged cord before it is

12
disconnected from the supply; damaged cords
can lead to contact with live parts.
Keep extension cords away from moving
hazardous parts to avoid damages to the
cords which can lead to contact with live parts.
When a cable is damaged or entangled,
please stop immediately to use the tool.
Switch off the tool, let it cool and unplug it in a
secure way.
When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the
risk of electric shock.
Use extra care when using on stairs.
In dusty conditions, slightly dampen surfaces
or use mister attachment if available
Use the full blower nozzle extension so the air
stream can work closer to the ground
Never use the appliance for spreading
chemicals, fertilizer, or any other substances
that may contain toxic materials. Do not use
appliance as a sprayer of flammable liquids.
Keep all the air intakes and the blower tube
free of dust, lint, hair and other material that
may cause a reduction in air flow.
Do not switch on the tool in enclosed or poorly
ventilated spaces or in the presence of
inflammable and/or explosive substances
such as liquids, gasses, and powders.)

13
Disconnect electrical supply before opening
inlet cover or installing pick up tubes. Never
operate unit without inlet cover secured or
pick-up tubes in place.
Always inspect the area before starting the
appliance to remove debris and hard or sharp
objects that can be blown or cause damaged
during operation
Never operate this appliance when you are
tired, ill or under the influence of alcohol,
drugs or medication.
Always run the appliance with the blower
tubes attached to the unit.
Always work moving away from solid objects
such as walls, large stones, automobiles and
fences.
Clean spaces with corners by starting in
corners and moving outward to straight areas
to prevent an accumulation of debris, which
could fly into face.
Be careful when working near valuable plants.
The force of air could damage tender plants.
Uses for your blowers: sweeping debris or
grass clippings from driveways, sidewalks,
patios, parks, parking lots, barns, etc.
Gathering grass clippings, straw or leaves into
piles. Removing debris from corners, around
joints and between bricks.
Stay alert. Watch what you are doing and use

14
common sense when operating a power tool.
Do not operate tool when you are tired or
under the influence of drugs, alcohol or
medication. A moment of inattention while
operating power tools may result in serious
personal injury.
Residual risks
Even if you use this product in compliance with
all safety requirements, the potential risks of
injury and damage remain. The following
hazards may arise in the structure and design of
this product:
a. There are harmful health consequences
resulting from the emission of vibrations if the
product is used for long periods of time or not
properly managed and properly maintained.
b. Risk of injury to persons and property caused
by flying objects.
c. Prolonged use of this product exposes the
operator to vibration and can produce so-called
"white finger" disease. To reduce the risk, wear
gloves and keep your hands warm.
d. If any of the symptoms of "white finger
syndrome" occur, seek immediate medical
attention. Symptoms of the "white finger" include
numbness, loss of sensitivity, tingling, and pain,
loss of strength, colour changes or skin
condition. These symptoms usually appear on

15
the fingers, hands or wrists. Risk increases at
low temperatures.
e. Inhalation of particles of material
blown/vacuumed
f. Unattended projections
g. Contact with foreign objects
h. Contact with the tool in operation
i. Hearing loss in the absence of correct hearing
protection
Explanation of symbol
a. Description
This product is double insulated electrically
Read instruction manual before operating or attempting any maintenance work
Conforms to all relevant EC Directives
Denotes risk of personal injury, loss of life, or damage to the tool in case of
non-observance
SWITCH OFF: Remove plug from mains before cleaning or maintenance.
Do not use in the rain or leave outdoors while it is raining.

16
Wear an eye protection
Keep bystanders away
Guarantee sound power level
Remove plug from the mains immediately if the cable is damaged or cut.
Intended use
This vacuum blower is intended to be used for the vacuuming and the blowing of
leaves, dust, and similar little materials. It must not to be used for vacuuming and
blowing water, chemical products, flammable material, metal or wood and others
dangerous objects.
This product is intended for private domestic use only. It must be used outdoors.
This product is not intended to be used in a closed room or in places where
exhausted gas and flames can be present.
The use of this product in case of rain or humid environment is prohibited.
Use this vacuum blower only as described in this manual and only for the
intended use as described above.
Any other use might lead to damage of the appliance, property or personal injury.
No liability will be accepted for damage resulting from improper use or non-
compliance with this manual.

17
2. YOUR PRODUCT
a. Description
1. Supply cable
2. Main handle
3. On/off switch
4. Front handle
5. Blower tube
6. Motor housing
7. Function switch (blower/vacuum)
8. Collection bag
9. Wheel
10.Attachment for shoulder
harness
11.Speed control roller
b. Technical specifications
Model
FAS3000-A
Rated input power
3000W
Rated no-load speed
15000/min
Rated Voltage
230-240V~50Hz
Blower velocity
250 km/h
Maximum blower air output
10.7m3/min
Collect bag capacity
40L
Weight
2.8Kg
sound pressure level
87.4dB(A) K=3 dB(A)
sound power level
98.07dB(A) K=0,85 dB(A)
Guarantee sound power level
99dB(A)
vibration
1.66 m/s² K= 1,5 m/s²

18
3. ASSEMBLY
a. Tube assembly
-Slide the upper tube into the motor housing, then tighten the screws and
make sure the tube is firmly fixed with motor housing.
-Insert the 2 lower tubes (one into upper tube and the smaller below) and push
them until they are connected firmly together. Use the provided plate and two
screws to fix the tubes together.
-Assemble the wheels to the lower tube. Add one wheel on each side of the
hole situated on smaller lower tube. Fix the wheels together with the screw
and the nut. Then fix the provided two plates and screws to fix the tubes
together.

19
Caution: In the interests of safety the tubes should not be dismantled after
they have been assembled
-Attach the collect bag to the hook on upper tube and the outlet on the bottom
of motor housing.
4. OPERATION
Before starting the machine, make sure that collect bag is fitted and the shoulder
harness is adjusted to a suitable working position.
a. Extension cable
The tool must be connected to an extension cable. Plug the cable of the tool into
extension cable. Then, attach the extension to the cable holder to hold it.
The extension cable shall not be lighter than the standardised code H05 RN-
F/H05 VV-F. See your retailer or manufacturer for more advice.
b. Switching on and off the tool
Before start the tool, be sure that the speed control knob is on the position 1
(lower position).
-To switch on, press the ON/OFF switch (fig 2a).
-To stop the tool, release the ON/OFF switch (fig 2b).

20
2a 2b
c. Speed Control
You can adjust the power of the air flow with the control knob. The power goes to
1 to 6 (from the lower to the highest power).
Turn the knob to adjust the power of the airflow, according the work performed.
When stop to use the machine, put the knob to the position 1.
d. Blowing mode
Blowing mode can be used for cleaning corners, fences, walls, wooden areas or
beneath cars. Be careful what you point the jet of air as it could move heavy
material and cause injury or damage.
- Inspect the work area before starting. Remove any debris or objects that
could be thrown or those that can get caught or obstruct the device.
- Put the shoulder strap.
- Push down the lever to choose the blowing mode.
- Hold the machine by the handle. Walk and hold the tube just above the
ground and blow the debris.
-Switch on the tool by pushing and holding the ON/OFF switch.
