Fein GRIT GHB 15-50 120 V User manual

© C. & E. Fein GmbH. Printed in PRC. Abbildungen unverbindlich. Technische Änderungen vorbehalten. 3 94 10 025 00 0 BY 2017.07 DE.
USA
FEIN Power Tools, Inc.
1000 Omega Drive
Suite 1180
Pittsburgh, PA 15205
Phone: [phone]
www.feinus.com
Canada
FEIN Canadian Power Tool
Company
323 Traders Boulevard East
Mississauga, Ontario L4Z 2E5
Telephone: [phone]
Phone: [phone]
www.fein.com
FEIN Service USA
FEIN Power Tools, Inc.
2735 Hickory Grove Road
Davenport, IA 52804
Phone: [phone]
[e-mail]
Headquarter
C. & E. FEIN GmbH
Hans-Fein-Straße 81
D-73529 Schwäbisch Gmünd-Bargau
www.fein.com
 GHB 15-50 120 V 7 90 32 109 12 4
 GHB 15-50 INOX 120 V 7 90 32 209 12 4

2
Instruction Manual
Mode d'emploi
Instrucciones de uso
en
3
fr
20
es
38

3
en
en
For your safety.
Read all safety warnings and
all instructions. Failure to fol-
low the warnings and instructions may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future-
reference.
Do not use this power tool before you
have thoroughly read and completely
understood this Instruction Manual, including
the figures, specifications, safety regulations
and the signs indicating DANGER, WARNING
and CAUTION.
Only carry out such operations with this
power tool as intended for by GRIT. Only use
application tools and accessories that have
been released by GRIT.
Please also observe the relevant national
industrial safety regulations.
Non-observance of the safety instructions in
the said documentation can lead to an electric
shock, burns and/or severe injuries.
This Instruction Manual should be kept for
later use and enclosed with the power tool,
should it be passed on or sold.
SAVE THESE INSTRUCTIONS.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool
or battery operated (cordless) power tool.
General safety rules.
1) Work area safety
a)Keep work area clean and well lit. Clut-
tered or dark areas invite accidents.
b)Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c) Keep children and bystanders away
while operating a power tool. Distrac-
tion can cause you to lose control.
2) Electrical safety
a)Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b)Avoid body contact with earthed or
grounded surfaces such as pipes, radia-
tors, ranges and refrigerators. There is
an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power
tool will increase the risk of electric
shock.
d)Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for out-
door use. Use of a cord suitable for out-
door use reduces the risk of electric
shock.
f) If operating a power tool in a damp loca-
tion is unavoidable, use a ground fault
circuit interrupter (GFCI) protected sup-
ply. Use of an GFCI reduces the risk of
electric shock.
3) Personal safety
a)Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power tool
while you are tired or under the influ-
ence of drugs, alcohol or medication. A
moment of inattention while operating
power tools may result in serious per-
sonal injury.
b)Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
WARNING

4en
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or bat-
tery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energising
power tools that have the switch on
invites accidents.
d)Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotat-
ing part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose cloth-
ing or jewelery. Keep your hair, clothing
and gloves away from moving parts.
Loose clothes, jewelry or long hair can
be caught in moving parts.
g)If devices are provided for the connec-
tion of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of dust collec-
tion can reduce dust-related hazards.
4) Power tool use and care
a)Do not force the power tool. Use the cor-
rect power tool for your application. The
correct power tool will do the job bet-
ter and safer at the rate for which it was
designed.
b)Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjust-
ments, changing accessories, or storing
power tools. Such preventive safety
measures reduce the risk of starting the
power tool accidentally.
d)Store idle power tools out of the reach of
children and do not allow persons unfa-
miliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for mis-
alignment or binding of moving parts,
breakage of parts and any other condi-
tion that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
g)Use the power tool, accessories and tool
bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those
intended could result in a hazardous sit-
uation.
5) Service
a)Have your power tool serviced by a qual-
ified repair person using only identical
replacement parts. This will ensure that
the safety of the power tool is main-
tained.
Special safety instructions.
Hold power tool by insulated gripping sur-
faces, because the belt may contact its own
cord. Cutting a “live” wire may make exposed
metal parts of the power tool “live” and could
give the operator an electric shock.
Wear personal protective equipment. Depend-
ing on application, use face shield, safety
goggles or safety glasses. Where appropriate,
wear dust mask, hearing protectors, gloves
and workshop apron capable of stopping
small abrasive or workpiece fragments. The
safety glasses must be capable of protecting
against flying particles generated by the vari-
ous operations. Prolonged exposure to high
intensity noise may cause loss of hearing.
While working, do not wear loose clothing,
jewellery or open, long hair. Despite protec-
tive devices, loose objects can be snagged or
caught by moving parts and lead to injury.

5
en
Do not use worn, torn or heavily clogged
grinding belts. Handle grinding belts carefully
and store them according to the manufac-
turer’s instructions. Do not bend or fold grind-
ing belts! Damaged grinding belts can tear, be
flung away and injure someone.
Never touch the running grinding belt and do
not reach under the protective guard. Danger
of injury.
Always use the protective devices attached on
the machine. The protective devices must be
securely mounted to the machine in order to
achieve maximum safety. The protective
devices are supposed to protect the user from
grinding particles thrown from the machine
and from accidental contact with the grinding
belt.
Warning! Danger of fire and explosion! When
grinding metals (e.g., aluminium or magne-
sium), dust develops that may be combustible
or explosive. Do not operate the machine near
flammable materials. Sparks could cause
these materials to ignite.
Pay attention that other persons are not put at
risk from sparking. Remove flammable mate-
rials in close vicinity. Sparking occurs when
grinding metal.
Secure the work piece firmly. A work piece
that is gripped tightly in a clamping device or
vice, is more secure than if held by hand.
Hold the power tool firmly. High reaction
torque can briefly occur.
Never touch the running grinding belt. Danger
of injury.
Do not rivet or screw any name-plates or
signs onto the power tool. If the insulation is
damaged, protection against an electric shock
will be ineffective. Adhesive labels are recom-
mended.
Do not use accessories which are not specifi-
cally designed and recommended by the
power tool manufacturer. Safe operation is
not ensured merely because an accessory fits
your power tool.
Clean the ventilation openings on the power
tool at regular intervals using non-metal
tools. The blower of the motor draws dust
into the housing. An excessive accumulation
of metallic dust can cause an electrical hazard.
Before putting into operation, check the
power connection and the power plug for
damage.
Recommendation: The tool should always be
supplied with power via a ground fault circuit
interrupter (GFCI) with a rated current of
30 mA or less.
Handling hazardous dusts.
When working with power
tools, such as when grinding,
sanding, polishing, sawing or for other work
procedures where material is removed, dusts
develop that are both hazardous to one’s
health and can spontaneously combust or be
explosive.
Contact with or inhaling some dust types can
trigger allergic reactions to the operator or
bystanders and/or lead to respiratory infec-
tions, cancer, birth defects or other reproduc-
tive harm.
Examples of such materials which contain
chemicals that can produce hazardous dusts,
are:
–Asbestos and materials containing asbes-
tos;
–Lead-containing coatings, some wood
types such as beech and oak;
–Minerals and metal;
–Silicate particles from bricks, concrete and
other materials containing stone;
–Solvent from solvent-containing paint/
varnish;
–Arsenic, chromium and other wood pre-
servatives;
–Materials for pesticide treatment on boat
and ship hulls;
–Stainless steel dust, metal dust and non-
ferrous metal dust;
WARNING

6en
To minimize the unwanted intake of these
materials:
–Use dust extraction matched appropriately
for the developing dust.
–Use personal protective equipment, such
as a P2 filter-class dust protection mask.
–Provide for good ventilation of the work-
place.
The risk from inhaling dusts depends on how
often these materials are worked. Materials
containing asbestos may only be worked on
by specialists.
Wood and light-metal dust can
cause spontaneous combus-
tion or explosions.
Hot mixtures of sanding dust and paint/var-
nish remainders or other chemical materials
in the filter bag or the vac filter can self-ignite
under unfavorable conditions, such as spark-
ing from sanding metal, continuous sunlight
or high ambient temperatures. To prevent
this:
–Avoid overheating the material being
sanded and the power tool.
–Empty the dust collector/container in time.
–Observe the material manufacturer’s
working instructions.
–Observe the relevant regulations in your
country for the materials being worked.
Hand/arm vibrations.
While working with this power
tool, hand/arm vibrations
occur. These can lead to health impairments.
The vibration emission value
during actual use of the power
tool can differ from the declared value
depending on the ways in which the tool is
used.
It is necessary to identify safety
measures to protect the oper-
ator that are based on an estimation of expo-
sure in the actual conditions of use.
The vibration emission level given in this
information sheet has been measured in
accordance with a standardised test given in
EN 60745 and may be used to compare one
tool with another. It may be used for a pre-
liminary assessment of exposure.
The declared vibration emission level repre-
sents the main applications of the tool. How-
ever if the tool is used for different
applications, with different accessories or
poorly maintained, the vibration emission
may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to
vibration should also take into account the
times when the tool is switched off or when
it is running but not actually doing the job.
This may significantly reduce the exposure
level over the total working period.
Identify additional safety measures to protect
the operator from the effects of vibration
such as: maintain the tool and the accessories,
keep the hands warm, organisation of work
patterns.
CAUTION
WARNING
WARNING
WARNING

7
en
Emission values for sound and vibration (Two-figure – specifications as per ISO 4871)
Sound emission
A-weighted emission pressure power level measured at the workplace
L
pA
(re 20 μPa), in decibels 100
Measuring uncertainty
K
pA
, in decibels 2.5
Measured A-weighted sound power level
L
wA
(re 1 pW), in decibels 108
Measuring uncertainty
K
wA
, in decibels 3
C-weighted peak sound pressure level measured at the workplace
L
pCpeak
,
in decibels 114
Measuring uncertainty
K
pCpeak
, in decibels 2.5
Vibrations
Mean vibrational value in
–m/s2
–ft/s2< 2.5
< 8.2
Measuring uncertainty
K , in
–m/s2
–ft/s21.5
4.9
REMARK: The sum of the measured emission value and respective measuring inaccuracy
represents the upper limit of the values that can occur during measuring.
Wear hearing protection!
Measured values determined in accordance with the corresponding product standard.

8en
Extension cable.
If the use of an extension cord
is required, its length and con-
ductor cross-section must be adequate for the
application in order to prevent a voltage drop
in the extension cord, power loss and over-
heating of the power tool. Otherwise, the
extension cable and power tool are prone to
electrical danger, and the working efficiency is
decreased.
Recommended dimensions of extension
cables at an operating voltage of 120 V – sin-
gle-phase a. c., with only one power tool
GHB15-50 connected:
Intended use of the power tool:
Hand-guided grinder for belt grinding in
weather-protected environments with the
application tools and accessories recom-
mended by GRIT.
Operation of the power tool off power generators.
This power tool is also suitable for use
with AC generators with sufficient power
output that correspond to the Standard
ISO 8528, design type G2. This Standard is
particularly not complied with when the so-
called distortion factor exceeds 10 %. When
in doubt, please refer to the generator
instruction/specification guide.
Operating the power tool off
power generators whose no-
load speed exceeds the voltage value on the
type plate of the power tool is prohibited.
WARNING
Max. cable length, ft Max. cable length, m
≤ 100 100
–200 200 –300 ≤ 30 30 – 60 60 –100
Min. conductor size
A.W.G. Min. conductorcross- section, mm2
16 14 12 1.5 2.5 4
WARNING

9
en
Symbols.
Symbol, character Explanation
General prohibition sign. This action is prohibited.
Do not touch the rotating parts of the power tool.
Observe the instructions in the text or graphic opposite!
Make sure to read the enclosed documents such as the Instruction
Manual and the General Safety Instructions.
Before commencing this working step, pull the power plug out of
thesocket. Otherwise there will be danger of injury if the power tool
should start unintentionally.
Use eye protection during operation.
Use ear protection during operation.
Use protective gloves during operation.
Use a dust mask during operation.
A surface that can be touched may be very hot and thus hazardous.
This symbol confirms the certification of this product for the USA and
Canada.
This sign warns of a directly imminent, dangerous situation. A false
reaction can cause a severe or fatal injury.
This sign indicates a possible dangerous situation that could cause severe
or fatal injury.
This sign warns of a possible dangerous situation that could cause injury.
Worn out power tools and other electrotechnical and electrical prod-
ucts should be sorted separately for environmentally-friendly recycling.
Product with double or reinforced insulation
Product with build-up of protection class III
~ or a. c. Alternating current
or d. c. Direct current
1~ Alternating current, single-phase
Rotation direction
DANGER
WARNING
CAUTION

10 en
Character Unit of measurement,
national Explanation
n
0
m/min Belt speed
P W Electrical power
°Anglewidth
UV Electric voltage
fHz Frequency
I A Electric current intensity
m kg, lbs Mass
lft, in Length, width, height, depth, diameter or thread
Ø ft, in Diameter of a round part
m, s, kg, A, mm, V, W,
Hz, N, °C, dB, min, m/s2Basic and derived units of measurement from the
international system of units SI.

11
en
Technical description and specifications.
Before mounting or replacing cutting tool or accessories, pull the power plug.
This preventive safety measure rules out the danger of injuries through acciden-
tal starting of the power tool.
All accessories described or shown in this instruction manual will not be included with your-
power tool.
WARNING
Fig. 1
Front handle
Wing bolt for
spark guard
Thumbwheel for speed adjustment
Spark guard
Gripping surface
Rear handle
Lever for changing the grinding belt
On/Off switch

12 en
Fig. 2
Contact disc
Screw for adjustment
of the grinding belt
Screws for adjustment of the gap clearance
Nut for adjustment
of the grinding belt
Support surface for plane grinding
Drive disc
Grinding belt

13
en
Type GHB 15-50 120 V GHB 15-50 INOX 120 V
Order number 7 90 32 109 12 4 7 90 32 209 12 4
Rated power input 1500 W1500 W
Output power 900 W 900 W
Belt speed 45 m/s 13 – 41 m/s
Grinding-belt length 39 3/8 in
1000 mm 39 3/8 in 1000 mm
Grinding-belt width 2 in
50 mm 2 in 50 mm
Weight according to EPTA-Procedure 01 12.3 lbs
(5.6 kg) 12.3 lbs (5.6 kg)
Class of protection /II /II

14 en
Adjustments.
Before mounting or replacing cutting tool or accessories, pull the power plug.
This preventive safety measure rules out the danger of injuries through acci-
dental starting of the power tool.
Adjustment of the gap clearance
(figure 3).
Loosen screws and adjust a max. gap clear-
ance of 4 mm.
Tighten screws again.
WARNING
max. 4 mm
Screws for adjustment of the gap clearance
Drive disc
Fig. 3

15
en
Adjusting the handle (figure 4).
The handle can be fastened in 3 different posi-
tions.
Loosen the handle.
Set the handle to your working position and
retighten it.
Adjusting the belt tracking (figure 5).
Switch the machine on and check the belt
tracking.
If the belt does not run centred, loosen nut
and turn screw using a spanner (size 10 mm)
to the right or left, as required.
Fig. 4
Wing bolt for spark guard
Nut for
adjustment
of the grinding belt
Screw for adjustment
of the grinding belt
Fig. 5

16 en
Adjusting the working position of the
drive motor (figure 6).
Loosen the screw using a 6 mm Allen key and
turn the drive motor to the desired position.
The drive motor can be turned by 360°.
Allen key
Fig. 6

17
en
Changing the tool.
Before mounting or replacing cutting tool or accessories, pull the power plug.
This preventive safety measure rules out the danger of injuries through acciden-
tal starting of the power tool.
Replacing the grinding belt (figure 7).
Pivot lever toward the right. The grinding belt
is now loose and can be removed.
Mount the new grinding belt. Pay attention
that the arrow directions on the inside of the
grinding belt and the housing of the power
tool correspond.
Pivot lever toward the left and check if the
grinding belt is positioned centrally. Check
the belt tracking regularly.
WARNING
Lever for changing the grinding belt
Fig. 7

18 en
Working instructions.
Before mounting or replacing cutting tool or accessories, pull the power plug.
This preventive safety measure rules out the danger of injuries through acciden-
tal starting of the power tool.
For each job, use only the GRIT application tool released and intended for the respective
application.
Switching on and off (figure 8).
Check the power supply cable
and the plug for damage.
Always hold the power tool
firmly. Otherwise, you could
lose control over the power tool.
The self-start lock prevents the belt grinder
from automatically restarting again, even after
a brief interruption of the power supply, e. g.,
from a pulled mains plug.
Switching on:
Push the On/Off switch forward (I).
Switching off:
Press the switch downward ().
Setting the speed (figure 9).
The speed range can be variably adjusted.
Turn the dial control between “1” for the
lowest speed and “6” for the highest speed.
WARNING
WARNING
CAUTION
On/Off switch
Fig. 8
Thumbwheel for speed adjustment
Fig. 9
54321
2
1
3
456
6

19
en
Repair and customer service.
Before mounting or replacing cutting tool or accessories, pull the power plug.
This preventive safety measure rules out the danger of injuries through acciden-
tal starting of the power tool.
Service.
Have maintenance carried out
only through qualified person-
nel. Incorrectly mounted leads and compo-
nents can cause serious injuries. Have the
required service carried out only through a
GRIT customer service agent.
The current spare parts list for this power
tool can be found in the Internet at
www.fein.com.
Cleaning.
Prior to any cleaning or main-
tenance, disconnect the power
tool from the power supply in order to avoid
accidents.
When using in environments
with conductive dust in the air,
such as when working metals, this dust can
settle in the interior of the power tool. This
can impair the total insulation of the power
tool. Therefore, regularly blow out the interior
of the power tool from outside via the venti-
lation openings with dry, oil-free compressed
air; always wear eye protection when doing
this. For additional protection, connect a
residual current device (RCD) on the line side.
Do not attempt to clean
clogged or dirty ventilation
openings of the power tool with pointed
metal objects; use nonmetal tools or objects
if necessary.
Do not use cleaning agents
and solvents that can cause
damage to plastic parts. These include: Gas-
oline, carbon-tetrachloride, chloric solvents,
ammonia and domestic cleaning agents that
contain ammonia.
If the supply cable of this
power tool is damaged, it
must be replaced by a specially prepared cable
available through the GRIT customer service
center.
Warranty and liability.
The warranty for the product is valid in accordance with the legal regulations in the country
where it is marketed. In addition, FEIN also provides a guarantee in accordance with the FEIN
manufacturer’s warranty declaration.
All accessories described or shown in this instruction manual will not be included with your-
power tool.
Environmental protection, disposal.
Packaging, worn out power tools and accessories should be sorted for environmental-friendly
recycling.
For further information, please contact your specialist shop.
WARNING
WARNING
WARNING
WARNING
CAUTION
CAUTION
CAUTION

20 fr
fr
Pour votre sécurité.
Lire tous les avertisse-
ments de sécurité et
toutes les instructions. Ne pas suivre les aver-
tissements et instructions peut donner lieu à
une électrocution, un incendie et/ou une
blessure sérieuse.
Conservez tous les avertissements et toutes
les instructions pour pouvoir vous y reporter
ultérieurement.
Ne pas utiliser cet outil électrique avant
d’avoir soigneusement lu et parfaitement
compris cette notice d’utilisation y compris
les figures, les spécifications, les consignes de
sécurité ainsi que les indications marquées par
DANGER, AVERTISSEMENT et ATTEN-
TION.
N’effectuer avec cet outil électrique que des
travaux pour lesquels il a été conçu par GRIT.
N’utiliser que des outils de travail et accessoi-
res autorisés par GRIT.
De même, respecter les dispositions concer-
nant la prévention des accidents du travail en
vigueur dans le pays en question.
Le non-respect des instructions de sécurité se
trouvant dans la documentation mentionnée
peut entraîner un choc électrique, un incendie
et/ou de graves blessures.
Bien garder cette notice d’utilisation en vue
d’une utilisation ultérieure ; elle doit être
jointe à l’appareil en cas de transmission ou de
vente à une tierce personne.
GARDER SOIGNEUSEMENT CES INSTRUC-
TIONS DE SECURITE.
Le terme « outil électrique » dans les consi-
gnes de sécurité fait référence à votre outil
électrique alimenté par le secteur (avec cor-
don d’alimentation) ou votre outil fonction-
nant sur batterie (sans cordon
d’alimentation).
Instructions générales de
sécurité.
1) Portée
a)Conserver la zone de travail propre et
bien éclairée. Les zones en désordre ou
sombres sont propices aux accidents.
b)Ne pas faire fonctionner les outils élec-
trique en atmosphère explosive, par
exemple en présence de liquides inflam-
mables, de gaz ou de poussières. Les
outils électroportatifs produisent des
étincelles qui peuvent enflammer les
poussières ou les fumées.
c) Maintenir les enfants et les personnes
présentes à l’écart pendant l’utilisation
de l’outil. Les distractions peuvent vous
faire perdre le contrôle de l’outil.
2) Sécurité électrique
a)Il faut que les fiches de l’outil électrique
soient adaptées au socle. Ne jamais
modifier la fiche de quelque façon que
ce soit. Ne pas utiliser d’adaptateurs
avec des outils à branchement de terre.
Des fiches non modifiées et des socles
adaptés réduiront le risque de choc
électrique.
b)Éviter tout contact du corps avec des
surfaces reliées à la terre telles que les
tuyaux, les radiateurs, les cuisinières et
les réfrigérateurs. Il existe un risque
accru de choc électrique si votre corps
est relié à la terre.
c) Ne pas exposer les outils à la pluie ou à
des conditions humides. La pénétration
d’eau à l’intérieur d’un outil augmentera
le risque de choc électrique.
d)Veiller à ne pas endommager le cordon.
Ne jamais utiliser le cordon pour porter,
tirer ou débrancher l’outil. Maintenir le
cordon à l’écart de la chaleur, du lubri-
fiant, des arêtes ou des parties en mou-
vement. Des cordons endommagés ou
emmêlés augmentent le risque de choc
électrique.
e) Lorsqu’on utilise un outil à l’extérieur,
utiliser un prolongateur adapté à l’utili-
sation extérieure. L’utilisation d’un cor-
don adapté à l’utilisation à l’extérieur
réduit le risque d’électrocution.
f) Si l’usage d’un outil dans un emplace-
ment humide est inévitable, utilisez une
alimentation protégée par un dispositif
à courant différentiel résiduel (RCD).
L’usage d’un RCD réduit le risque de
choc électrique.
AVERTISSEMENT
