FeiYu Tech WG2X User manual

3-Axis Wearable Gimbal for Action Camera
Guilin Feiyu Technology Incorporated Company
V1.0E NUser Manual
Instructions

Catalogue
1. WG2X Overview 1
www.feiyu-tech.com
2. Quick Start Guide 3
3. Function operation 4
Working Mode 4
4. Advanced Operation 5
5. Parameters 10
Manual Lock 5
Auto-rotation Mode 6
Connect the camera 8
Firmware Upgrade 8
Function Button - operation 4
Mode Button - operation 5
Shutter Button - operation 5
App - Download and Connecting 7
Gimbal Initialization 9

Micro USB cable
X1
1. WG2X Overview
01
www.feiyu-tech.com
Micro USB Port
(1) It is used for charging the gimbal (input 5V / 2A ),
the gimbal can be used while being charged, but it is
not available for external power supply.
To fix the camera It is used for other accessories expansion, such as 1/4
inch screw tripod, extension bar and so on.
(2) It used for firmware upgrade (computer), please refer
to the firmware upgrade operation steps for details.
Please stuff up this port by the dustproof plug when it is not in use.
Accessories
Introduction of interface and screws
2
1/4-20 Thread MountThumb Screw
1 3
Micro USB Port
Roll Axis Thumb Screw
Charging /WiFi indicator light
Cross Arm
Mounting Plate
Vertical Arm
Shutter
Button
Mode
Button
Knob Ring
Fixing Bar
Function Button
ON / OFF
Tilt Axis
Pan Axis
Mode Indicator Light
1/4 Inch
Thread Hole
Session Mount
X1
Screw
X2
1/2 Inch T-head Connector
X1
2
1
3
5
123
2
3
1
4
4
1
2
3
4

Shutter Button
Introduction of Display and Buttons
Introduction of Axis and Knob
1Mode Button 2
Introduction of Other Components
Function Button
3Charging /WiFi indicator light 4Mode Indicator Light
5
Double click Follow Mode
Four click Auto-rotation Mode
Five click Initialization
Triple click Rotate 180° in horizontal
Panning Mode / Lock Mode Single click
Power on / Power offLong time press
Photo Mode / Recording ModeSingle click
ResetTriple click
Green indicator light is
constantly on
Red Indicator light is
constantly on from flashing
Blue light flashes once
Blue light flashes twice
Blue light constant on
Blue light keeps flashing
Blue light flashes for three
times every 5 seconds
Turn on / Turn off the WiFiLong time press
02
www.feiyu-tech.com
Power on
Power off
Panning Mode
Follow Mode
Lock Mode / Initialization
Initialization failure /
Error
Low battery
It has the highest priority during charging, the red
light is always on when it is not fully charged, and
the green light is always on when it is fully charged.
When it is not being charged, turn on the WiFi and
the blue light blinks, turn off the WiFi and there is
no display.
The green light blinks when controlling the camera
for recording
Single click Photo Capturing / Video Recording
*When the gimbal is in lock mode, triple click the function button can
not be rotated 180° in horizontal
Tilt Axis
Take the camera lens as the base point, and control the
lens to move up or down by tilt axis.
It is used for fixing the cross arm.
1Knob Ring
2
Roll axis
Take the camera lens as the base point, and control
the lens to tilt to the left or tilt to the right by roll axis.
3
4Pan Axis
Take the camera lens as the base point, and control
the lens to turn left or turn right by pan axis.
It is used for fixing the camera.
1
Mounting Plate
2
It is used for adjusting the gravity center position of
roll axis.
3
Cross arm
Vertical arm
It is used for adjusting gravity center position of
pan axis.

2. Quick Start Guide
Charging
1
3
2
Charging with Micro USB cable as shown
below.
Please fully charge the battery before
power on the gimbal for the first time.
TIPS
03
www.feiyu-tech.com
Micro USB
Cable
(Equipped by user)
Output: 5V / 2A
Mount the Camera
Put the camera on mounting plate,then
tighten the camera with retainer bar(or
session mount) and screw.
Use fixing bar to install Use session
holder to install
Balance the Gimbal
Loosen the knob ring, move and adjust the position of
cross arm, tight the knob ring after the gimbal is in
balanced status. Then turn on the gimbal.
( Before power on )
4Power on / off
1
2
Cross Arm
Knob Ring
Power on：long time press function button
until the green light is on.
Power off：long time press function button
until the red light changes from quick flashing
to always on.

The roll and tilt direction are fixed, and the camera moves according to the left-right movements of
the user's hand.
The orientation of the camera is fixed.
The roll direction is fixed, and the camera moves according to the left-right movements, up-down
movements of the user's hand.
Return to panning mode, three axises return to default position.
Panning Mode（Default mode）
Follow Mode
Reset
Lock Mode
Working Mode
3. Operation
04
www.feiyu-tech.com
Panning Mode Default Follow Mode Lock Mode
Function Button - operation
Note: The firmware upgrade may occur manual operation function and the actual product features do not match.
Please find the latest manual on the official website.
Please refer to the chapter "Auto-rotation Mode" in page 06
Please refer to the chapter "Gimbal Initialization" in page 09
Single click
Enter auto-rotation mode
Enter initialization
Make the lens rotate 180°
Panning Mode /
Lock Mode
Double click Follow mode
Triple click
Rotate 180°in
horizontal
Four click Auto-rotation Mode
Five click Initialization
Single click to switch between panning mode
and lock mode
Under all follow, single click to switch to locking
mode
Function
Button
*When the gimbal is in lock mode, triple click the
function button can not be rotated 180° in horizontal

05
www.feiyu-tech.com
Manual Lock
4. Advanced Operation
Shutter Button - operation
After connecting the gimbal to camera via Feiyu On App,
single click it to control the recording of the camera.
Please refer to the chapter "Connecting to camera" in page 08
Single click Capturing / Start recording / Stop recording
Shutter
Button
Mode Button - operation
Long time press Turn on / Turn off the WiFi
Single click Photo Mode / Recording Mode
Triple click Reset
Mode
Button
Camera can be manually positioned while in panning mode ,follow mode or lock mode. Both the pan axis and tilt
axis can be manually set up.
Take the tilt axis setting for example:
Manually move camera to desired position,and hold for half a second. New tilt and/or pan positions are automatically
saved.

06
www.feiyu-tech.comwww.feiyu-tech.com
Auto-rotation Mode
Set rotation speed in Feiyu ON App
The WG2X gimbal can easily create constant speed movements in the auto-rotation mode.
This mode can be used for recording both regular video and motion time-lapse photography.
For better performance, please equip with FeiyuTech tripod or other tripod.
Connect to the Feiyu ON App and select speed from the auto-rotation mode rate option in the settings menu.
WG2X Rotation Speed
18s/ round
12s/ round 24s/ round 30s/ round 1min/ round 2min/ round 15min/ round
8min/ round
4min/ round 4h/ round
1h/ round
(Default) 8h/ round
30min/ round
Record the first position (rotation start position) by manually moving
camera to desired position. Hold in position for half a second. Single
tap the function button to record rotation start position.
Record the second position (rotation end position) by
manuallymoving camera to desired position. Hold in
position for half a second.Single tap the function button
to record rotation end position.
The gimbal automatically restores to the start position, while the
tilt axis and pan axis start rotating at a constant speed according
to pre-set speed to end position, repeat step (2) (3) to start again.
( 2 ) Set rotation start position
( 3 ) Set rotation end position ( 4 ) Start auto rotation movements
( 1 ) Enter auto-rotation mode
Mode Button Exit the auto-rotation mode and reset
Triple clickExit
Tilt
Pan
Pan Axis
Tilt Axis
*When the gimbal is placed in front, it cannot enter the auto-rotation mode.
Both the pan and tilt directions can be rotated.
function button
Four click function button
Single click
function button
Single click

06 07
www.feiyu-tech.com
1 2 3
App - Download and Connecting
Turn on the Bluetooth and run the App on smartphone, follow on the instructions to connect smartphone to gimbal
via bluetooth.
App Store Google play
Connecting App
Or search and download the "Feiyu ON" App on the following application platform:
(1) iOS Version (2) Android Version
* Requires iOS 9.0 or later, Android 5.0 or later
Download and Install Feiyu ON App.

Connecting to Camera
Firmware Upgrade
WG2X gimbal can connect to the camera by Feiyu ON App.
Operations available after connecting to the camera:
(1) Turn on your recording camera's WiFi (2.4GHz)
Steps of connecting to camera:
(2) Successively select "Settings" -- "Parameters Settings" --"WiFi Settings" on Feiyu ON App
(3) Select camera model
(4) Select your camera connection name and enter the correct connection password of your camera
(5) Waiting for connecting
(6) Connect successfully
按键 操作 实现功能
Mode Button Single click Single click to switch between the photo mode and video mode
Shutter Button Single click Capturing / Start recording / Stop recording
Upgrade firmware via App
08
www.feiyu-tech.com
Feiyu ON
Settings Update
Query Update
Later Download
Your Gimbal version is ***,
The latest version is ***,
do you want to upgrade?
If icon appears on the display screen, it means the gimbal failed to connect to the camera, try to
restart gimbal or camera, or reconnect according to above steps.
If the WiFi is not connected for a long time, please restart the camera's WiFi.

Gimbal Initialization
Adjusting Steps
After the initialization is successful, the motor will
automatically start working.
Note:
if the initialization is not successful, long time
press the function button to turn off the gimbal,
restart initialization process.
You can initialize your gimbal when:
（1） camera is not balance
（2） If not use for a long period of time
（3） In case of extreme temperature variations
1
2
3
09
www.feiyu-tech.com
Click the function button for 5 consecutive times,
and the motor will stop working.
Place the gimbal on the table unmoved, and the
gimbal automatically detect whether or not it is
placed on a static flat surface, and then its
initializing will start automatically.

5. Specifications
Parameters
Product Name
Compatible Camera Compatible with GoPro HERO6 / GoPro HERO5 /
GoPro HERO4 / Session and cameras with similar
dimensions
Payload 130g ( In balanced status )
Weight 238 g (Not including the action camera)
Operation Time 2.5Hours
Tilt Axis Mechanical Movement Range 360°
Roll Axis Mechanical Movement Range 310° ( Structure range )
70° ( Limit angle after camera mounted )
Pan Axis Mechanical Movement Range 360°
10
www.feiyu-tech.com
102.5mm
89.3mm 40mm
61.1～78.1mm
WG2X 3-Axis Wearable Gimbal for Action Camera

Guilin Feiyu Technology Incorporated Company
For more information, please visit our official website
Due to software and hardware improvements, your actual product might differ from the descriptions
and pictures in this user manual. You can get the latest user manual from the official website.
[phone]
Prohibit any user for any illegal purpose. Users will be responsible for all behaviors of purchase and use products.
The Company assumes no liability for any risks related to or resulting from the debug and use of this product (including the direct,
indirect or third-party losses).
For any unknown sources of using, we will not be at any services.
The updating and changes of product firmware and program may cause changes in function descriptions in this user manual,
please read the instructions carefully before upgrading the firmware and use the corresponding user manual.
You can get the latest user manual from the official website: www.feiyu-tech.com
FeiyuTech reserves the right to amend this manual and the terms and conditions of use the gimbal at any time.
D I S C L A I M E R
