Felder Hammer A3 31 User manual

IN FH4 10070901 Rev. 1.0
A3 31 Fence Rail
Mounting Instructions
www.hammerusa.com

Table of Contents
Accessories and Tools .... pg 3
Receiving your HAMMER machine .... pg 4
Preparation .... pg 5
Assembly .... pg 6 - 9
Parts List .... pg 10
2
IN H 01061001 Rev. 1.0

Receiving your HAMMER machine
Your Hammer A3-31 woodworking machine is shipped bolted to the pal-
let, shrink-wrapped with a cardboard box placed around it.
Dimensions including the pallet are typically 3 x 4 with an approx. height
of 4 - 5 feet.
When you receive your HAMMER A3-31 Jointer-Planer the rail for the
jointer fence is not attached to the cast iron table.
The fence rail is wrapped
in foam and all necessary
nuts & bolts are shipped in
a clear plastic bag.
Both items are labeled with
a white sticker showing the
machine number.
Start by unwrapping the
aluminum extrusion. Place
the extrusion on top of the
foam to avoid scratches on
your new fence plate.
4
IN H 01061001 Rev. 1.0

Preparation
5
Sometimes it is necessary smoothen the bolt head.Try to sand off the
markings on the bolthead with some sand paper to avoid any scratching
inside the groove of the aluminum extrusion and to ensure a smooth
IN H 01061001 Rev. 1.0
Please check the bolt-heads
for a clean smooth surface or
excess grain residue!
sliding motion.
Scratches caused by
the markings on the
bolthead.

Assembly
Assemble each bolt with metal
T-plate as shown in the picture to
the right.
Now slide both assebled bolts
into the groove of the aluminum
extrusion as shown below.
Put each thick washer onto each black bolt as seen below.
6
IN H 01061001 Rev. 1.0

Assembly
Unwrap your machine until you have full acces to the two precision
machined holes in the cast iron table.
Attach the aluminum extrusion
onto the cast iron table. Insert the
bolts into the machined holes.
If you should run into any kind of
problem or difculties please con-
tact Felder USA Service Depart-
ment immediately either toll free
or at ser[email protected].
NOTE: Make sure that the thick
washers on the bolts line up prop-
erly with the machined round circles
in the cast iron table to avoid that
the rail is mounted in a slight angle.
This would through off the alignment
of the jointer-fence.
7
IN H 01061001 Rev. 1.0
Machined Holes
FOR TECHNICAL
ASSISTANCE
CALL TOLL FREE
866 792 5688
SERVICE
DEPARTMENT

Assembly
8
IN H 01061001 Rev. 1.0

Have the two nuts
for the bolts handy.
Now slide the extru-
sion as far to the
right until the left
side of the extrusion
is ush with the cast
iron table.
Double check align-
ment.
Once the aluminum
extrusion is lined up
properly attach nuts
to bolts from behind
and start fastening
the nuts with the
open wrench.
NOTE:
Do not overtighten.
slide this direction
Assembly
IN H 01061001 Rev. 1.0
9

3
To mount the fence rail you need a 17mm open wrench and possibly
some sandingpaper (see picture).
The content of the accessories bag is shown below.
Please check if you received all. In case that any of the below items
should be missing please contact Felder Group USA immediately at our
toll free number 866-792-5288 !
Assembly
IN H 01061001 Rev. 1.0

Felder Group USA Toll Free:
East 866 - 792 - 5288
West 800 - 572 - 0061
S. CA 866 - 714 - 6005
or shop online:
Description Part No. Price $
Planer Blades 500-07-002 $ 61.49
Handwheel 12.1.311 $ 44.69
Dial Indicators:
in inches 01.2.202 $123.09
in mm 01.1.202 $ 72.69
Grease Gun 12.1.312 $ 25.65
Grease 400g 10.2.001 $ 18.93
Supergleit:
0.13 gal 10.0.010 $ 22.29
0.79 gal 10.0.011 $ 63.73
Tapemeasure
5 m / metric 12.1.313 $ 6.72
16 ft / imperial 12.1.314 $ 6.72
Parts List
IN H 01061001 Rev. 1.0
10
www.hammerusa.com

FOR TECHNICAL ASSISTANCE CALL TOLL FREE
866 792 5688
SERVICE DEPARTMENT FELDER GROUP USA
For more information on the A331
or other Hammer Products please visit our website @
www.hammerusa.com
