Fellowes POWERSHRED 99Ms User manual

Quality Office Products Since 1917
POWERSHRED® 99Ms POWERSHRED® 99Ms
Please read these instructions before use.
Do not discard: keep for future reference.

CAPABILITIES
ENGLISH
Model 99Ms
KEY
G. Control Panel and LEDs
1. Overheat (red)
2. Bin open (red)
3. Bin full (red)
4. Remove Paper (red)
5. SafeSense
®
indicator (yellow)
6. Reverse
7. ON/OFF (blue)
8. Forward
A.
B.
C.
F.
D.
E.
G.
Will shred: Paper, credit cards and staples
Will not shred: Adhesive labels, continous form paper, transparencies, newspaper,
cardboard, paper clips, CD/DVDs, laminates, file folders, X-rays or plastic other than noted
above
Paper shred size:
Micro-Cut .......................................................................................................... 2 x 14mm
Maximum:
Sheets per pass ........................................................................................................... 12*
Paper entry width........................................................................................9 in. (230mm)
*8.5 in. x11 in., 20lb., (75g) paper at 120V/60 Hz, 6.5Amps; heavier paper, humidity or other than
rated voltage may reduce capacity. Maximum recommended daily usage rates: 1000 sheets per day,
50 credit cards. 12 sheets per pass to avoid jams.
Fellowes SafeSense®shredders are designed to be operated in home and office environments ranging
between 50 – 80 degrees Fahrenheit (10 – 26 degrees Celsius) and 40 – 80% relative humidity.
BASIC SET UP
CASTER INSTALLATION
17
1
17
2
17
3
17
4
17
5
A. SafeSense
®
Technology
B. Paper entry
C. See safety instructions
D. Pullout bin
E. Casters
F. Disconnect power switch
1. OFF
2. ON
IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!
15
15
• Operation,maintenance,andservicerequirementsarecoveredintheinstruction
manual. Read the entire instruction manual before operating shredders.
• Keepawayfromchildrenandpets.Keephandsawayfrompaperentry.Alwaysset
to off or unplug when not in use.
• Keepforeignobjects–gloves,jewelry,clothing,hair,etc.–awayfromshredder
openings. If object enters top opening, switch to Reverse ( ) to back out object.
• Neveruseaerosolproducts,petroleumbasedlubricantsorotherflammable
products on or near shredder. Do not use canned air on shredder.
• Donotuseifdamagedordefective.Donotdisassembleshredder.
Do not place near or over heat source or water.
• ThisshredderhasaDisconnectPowerSwitch(F)thatmustbeintheON()
position to operate shredder. In case of emergency, move switch to OFF (O)
position. This action will stop shredder immediately.
• Avoidtouchingexposedcuttingbladesundershredderhead.
• Shreddermustbepluggedintoaproperlygroundedwalloutletorsocketofthe
voltage and amperage designated on the label. The grounded outlet or socket
must be installed near the equipment and easily accessible. Energy converters,
transformers, or extension cords should not be used with this product.
• FIREHAZARD–DoNOTshredgreetingcardswithsoundchipsorbatteries.
• Forindooruseonly.
• Unplugshredderbeforecleaningorservicing.
15
15

BASIC SHREDDING OPERATION
Continuous operation:
Up to 15-minutes maximum
NOTE: Shredder runs briefly
after each pass to clear entry.
Continuous operation beyond
15-minutes will trigger
25-minute cool down period.
SafeSense
®
is active and
working properly
SAFESENSE®TECHNOLOGY OPERATION
Stops shredding immediately when hands touch the paper opening.
Touch test area and
look for the SafeSense
®
indicator to illuminate
Turn the shredder ON
( ) to activate SafeSense
®
SET-UP AND TESTING
1
ADVANCED PRODUCT FEATURES
Press ON (I) to
activate (blue)
PAPER OR CARD
Feed paper/card
straight into paper
entry and release
Plug in and put
disconnect power
switch in ON (I) position
SilentShred™Technology
SilentShred™ noise quality
shreds without noisy disruptions.
Patented SafeSense®Technology
Stops shredding immediately when
hands touch the paper opening.
12
12
12
2 43
12
3
2
2
1
When finished
shredding set
to OFF ( )
4
Sleep Mode
Energy saving feature shuts down automatically
after 2 minutes of no shredding activity
SLEEP MODE OPERATION
Energy saving feature shuts down the shredder after
2 minutes of inactivity
WHEN IN SLEEP MODE
In sleep mode To get out of sleep mode
touch control panel
insert paper
or
12
3
2
2
12
1
Press and hold forward ( )
2-3 seconds
2
PRODUCT MAINTENANCE
CLEANING AUTO-START INFRARED SENSORS
Paper detection sensors are designed for maintenance free operation. However, on rare occasions the sensors
may become blocked by paper dust causing the motor to run even if there is no paper present.
(Note: two paper detection sensors are located in the center of the paper entry).
All micro-cut shredders require oil for peak performance. If not oiled, a
machine may experience diminished sheet capacity, intrusive noise when
shredding and could ultimately stop running. To avoid these problems, we
recommend you oil your shredder each time you empty your waste bin.
OILING SHREDDER
15
*Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes 35250
FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE
*Apply oil across entry
12
1
TO CLEAN THE SENSORS
15
1
Turn off and unplug
shredder
Locate Auto-start
infared sensor
Dip cotton swab in
rubbing alcohol
Using cotton swab, wipe
away any contamination
from the paper sensors
12
4
12
23
If hand is held on SafeSense
®
area more than 3 seconds,
shredder will shut off
For more information about all of Fellowes Advanced Product Features go to www.fellowes.com
Overheat Indicator: When the Overheat Indicator is illuminated, the shredder has exceeded its maximum operating temperature and needs to cool down. This indicator will remain
illuminated and the shredder will not operate for the duration of the recovery time. See Basic Shredding Operation for more information about the continuous operation and
recovery time for this shredder.
Bin Full: When illuminated, the shredder waste bin is full and needs to be emptied. Use Fellowes waste bag 36053.
Bin Open: The shredder will not run if the bin is open. When illuminated, close the bin to resume shredding.
Remove Paper: When illuminated, press reverse ( ) and remove paper. Reduce paper quantity to an acceptable amount and refeed into paper entry.
SafeSense
®
Indicator: If hands are too close to the paper entry, the SafeSense
®
indicator will illuminate and the shredder will stop shredding. If SafeSense
®
is active for 3 seconds, the shredder will automatically turn off and the user must press the power button on the control panel to resume shredding.
TROUBLESHOOTING

Quality Office Products Since 1917
POWERSHRED® 99Ms
©2012 Fellowes, Inc. Part No. 407305
LIMITED PRODUCT WARRANTY
Canada [phone]
Mexico +001-800-514-9057
United States [phone]
Questions or Concerns?
www.fellowes.com
Troubleshooting
Registration
Manuals
Customer Service & Support
Troubleshooting
Replacement parts
General questions
Limited Warranty: Fellowes, Inc. (“Fellowes”) warrants the parts of the machine to be free of
defects in material and workmanship and provides service and support for 1 year from the date
of purchase by the original consumer. Fellowes warrants the cutting blades of the machine to
be free from defects in material and workmanship for 7 years from the date of purchase by the
original consumer. If any part is found to be defective during the warranty period, your sole and
exclusive remedy will be repair or replacement, at Fellowes’ option and expense, of the defective
part. This warranty does not apply in cases of abuse, mishandling, failure to comply with product
usage standards, shredder operation using an improper power supply (other than listed on
label), or unauthorized repair. Fellowes reserves the right to charge the consumers for any
additional costs incurred by Fellowes to provide parts or services outside of the country where the
shredder is initially sold by an authorized reseller. ANY IMPLIED WARRANTY, INCLUDING THAT OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION
TO THE APPROPRIATE WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable
for any consequential or incidental damages attributable to this product. This warranty gives you
specific legal rights. The duration, terms, and conditions of this warranty are valid worldwide,
except where different limitations, restrictions, or conditions may be required by local law. For
more details or to obtain service under this warranty, please contact us or your dealer.
