Fellowes 190 User manual

190
200
220
Paper shredder 220 CC
Edition 09/98 1.294.999.110 1
POWERSHRED®
OPERATING INSTRUCTIONS
NOTICE D'UTILISATION
MANUAL DEL PROPIETARIO
BETRIEBSANLEITUNG
1.294.999.110 – Edition 09/98
190
200
220
220CC
ON
POWERSHRED 320

190
200
220
220 CC Paper shredder
2 1.294.999.110 Edition 09/98
Paper shredder Fellowes 190/200/220/220 CC ................................................. 3–8
Déchiqueteuse Fellowes 190/200/220/220 CC ................................................ 9–14
Destructora de documentos Fellowes 190/200/220/220 CC .......................... 15–20
Aktenvernichter Fellowes 190/200/220/220 CC .............................................. 21-26
E
F
D
USA

190
200
220
Paper shredder 220 CC
Edition 09/98 1.294.999.110 3
Contents
Contents Page
1. Important Safety Instructions.................................................................................. 4
2. Parts Identification .................................................................................................. 4
3. Caution ................................................................................................................... 4
4. Technical Specifications ......................................................................................... 5
5. Supplies.................................................................................................................. 6
6. Installation .............................................................................................................. 6
7. Operation................................................................................................................ 6
8. Checklist for Inoperative Machine .......................................................................... 7
9. Malfunctions ........................................................................................................... 7
10. Maintenance ........................................................................................................... 7
11. Warranty ................................................................................................................. 8
12. Customer Service ................................................................................................... 8
USA

190
200
220
220 CC Paper shredder
4 1.294.999.110 Edition 09/98
1. Important Safety Instructions
1. Read all instructions before use.
2. Save these instructions for later use.
3. Follow all warnings and instructions
marked on the proudct.
4. Unplug this product before cleaning.
Clean with a damp cloth using a mild
soap and water solution. (Do not use
abrasives or petroleum products.)
5. Place this product as close as possible to
power source for quick and easy
unplugging.
6. Do not use this product near water.
7. This product should never be placed near
or over a radiator or heat source.
8. Operate from the type power source
indicated on the marking label. If you are
not sure of the type of power available,
consult your dealer or local electric
company.
9. Do not allow anything to rest on the power
cord. Do not place this product where
people may walk on the cord.
10. If an extension cord is used with this
product, make sure that the total of the
ampere ratings on the products plugged
into the extension cord do not exceed the
extension cord ampere rating. Also, make
sure that the total of all products plugged
into the wall outlet does not exceed 15 amps.
11. Do not attempt to service this product
yourself, as opening or removing covers
may expose you to dangerous live parts
or other risks.
12. Unplug this product and refer servicing to
qualified personnel under the following
conditions:
A) When the power cord or plug is damaged
or frayed.
B) If liquid has been spilled on the product.
C) If the product has been exposed to rain.
D) If the product does not operate normally
when the operating instructions are
followed.
E) If the product has been dropped or
the casing has been damaged.
13. Keep out of reach of children.
14. This shredder should be operated only with an
operator in attendance.
2. Parts Identification
1. LED display ( 220 series only)
2. Rocker switch
3. Cover
4. Serial label
5. Caution label
6. Cabinet
7. Waste container
8. Paper feed opening
9. Automatic start stop control ( 190/200 series only)
3. Caution
Never insert hand, fingers or any
foreign objects into the feed
opening.
Serious injury may result.
Keep all loose articles of
clothing, ties, jewelery, long hair
or other loose objects away from
feed opening.
Injury may result.
Always turn off and unplug the
machine before moving,
servicing, cleaning or any other
conduct other than normal
operation.
Serious injury may result.
USA
ON
POWERSHRED 320
7
3
2
1
5
6
4
Fellowes Manufacturing Co.
1789 Norwood Avenue
Itasca, IL 60143 USA
Model:
Serial #:
Voltage: Motor:
Current: Manufactured:
R
R
R
8
9

190
200
220
Paper shredder 220 CC
Edition 09/98 1.294.999.110 5
4. Technical Specifications
Model 190 Model 200 Model 220 Model 220CC
Cutting style Strip cut Strip cut Strip cut Cross cut
Shred size 1/4" 5/32" 5/32" 5/32" x 1"
(5.8 mm) (3.9 mm) (3.9 mm) (3.9 x 30 mm)
Security rating DIN 32757–1 2223
Sheet capacity -
8-1/2" x 11" - 20 lb. 16 12 12 8
A4, 70g/m2(16 lb.) 20 14 14 10
Speed 20FPM 20FPM 20FPM 22FPM
(80 mm/s) (80 mm/s) (80 mm/s) (90 mm/s)
Entry width approx. 93/4" approx. 93/4" approx. 93/4" approx. 93/4"
(240 mm) (240 mm) (240 mm) (240 mm)
Motor power 1/3 H.P. 1/3 H.P. 1/3 H.P. 1/3 H.P.
(0.12 kw) (0.12 kw) (0.12 kw) (0.12 kw)
Input voltage 100V, 50 Hz 100V, 50 Hz 100 V, 50 Hz 100 V, 50 Hz
(Depending on country) 115V, 60 Hz 115V, 60 Hz 115V, 60 Hz 115V, 60 Hz
220/240V, 50 Hz 220/240V, 50 Hz 220/240V, 50 Hz 220/240V, 50 Hz
Dimensions 143/4" x 10" x 211/2" (375 x 250 x 550 mm)
Weight 241/4lbs. (11 kg)
Waste container volume 7.6 gallons (29 liters)
Noise level 53 dB in idle – 59 - 63 dB under load
USA
*Paper DIN 19307 SM 4a – 70

190
200
220
220 CC Paper shredder
6 1.294.999.110 Edition 09/98
Switching equipment ON
(190 & 200 only)
– Press rocker switch to pos. (1)
• Controller switch locks in "on" position.
• Equipment is ready for operation
(standby).
– Feed paper
• The shredding process is started by
automatic start stop control in the paper
feed opening. Insert paper and
shredding begins automatically.
• When the shredding is complete, the
cutting system automatically stops
after approx. 3 seconds.
Switching equipment OFF
(190 & 200 only)
– Press rocker switch to pos. (3)
•switch resets to center position and
stops the cutting system.
Switching equipment ON
(220 series only)
– Press rocker switch to pos. (1)
• Switch locks in "on" position.
• Equipment is ready for operation
(standby).
• Green LED lights.
– Feed paper
• The shredding process is started by
photo–cells in the paper feed opening.
Insert paper and shredding begins
automatically.
• When the shredding is complete, the
cutting system automatically stops
after approx. 3 seconds.
Switching equipment OFF
(220 series only)
– Press rocker switch to pos. (3)
• switch resets to center position and the
machine is turned off.
5. Supplies
– Bags for cut material
(Packed in dispenser carton, 50 or 100 bags
to a roll depending on size. For bag informa-
tion, see label on inside of the waste container.
If label is missing, contact Fellowes or your
local Fellowes dealer for the stock number of
the bag that fits your machine.)
– Cutting block oil for cross-cut units
Stock # 35250.
6. Installation
– The paper shredder is supplied ready for
operation.
– Operate this product only from the type of
power source indicated on the marking label.
– Install the paper shredder so that the plug is
easily accessible.
– Shredder must be operated in upright position
only.
– Set up paper shredder so that the ventilation
slots are unobstructed. To ensure sufficient
ventilation of the shredder a minimum distance
of 4" (10 cm) to the wall or to the furniture must
be maintained.
7. Operation
Read operating instructions before
operating the shredder.
Insert plug in power outlet.
To avoid motor overload, the 190 and
200 model paper shredders may cut
out automatically after approx. 20
minutes of continuous operation.
1
USA
3
1
3

190
200
220
Paper shredder 220 CC
Edition 09/98 1.294.999.110 7
8. Checklist for Inoperative Machine
If the equipment does not work properly, please
check the following points first:
– Is the plug inserted ?
– Is the switch turned on ?
– Is waste container pushed in properly ?
– Is waste container full ?
Empty container
– Is there a paper jam in the shredder ?
See Malfunctions
– Is the motor overheated ?
Switch machine off and allow motor to
cool down for approximately 15–20 min.
If none of the above applies and the equipment still
does not run, please contact the appropriate
customer service department.
9. Malfunctions
Paper jam
• Press rocker switch to center position
(2) to stop the cutting system.
• Press and hold down rocker switch in
pos. (3) to reverse the cutting system
and back out jammed material
(paper is pushed out)
Caution!
Do not press rocker switch alternately
forwards/backwards in pos. (1 and 3)
• Remove excess paper.
• Return switch to pos. (1) and continue
shredding in smaller quantities so as
not to jam the machine further.
2
2
3
3
1
1
1
USA
Door contact interrupted
Red LED lights (220 series only).
No LED on 190 & 200 models.
– Paper shredder switches off automati-
cally. Press rocker switch to center (2)
position.
• Check whether cut material container is
properly pushed into bottom frame.
• Return switch to "on" position (1) and
continue shredding.
Cut material container full
Red LED lights (220 series only).
No LED on 190 & 200 models.
– Paper shredder switches off automati-
cally.
• Press rocker switch to center (2)
position.
• Empty cut material container or
exchange cut material bag.
• Return switch to "on" position (1) and
continue shredding.
10. Maintenance
(Cross cut unit only)
– When tearing capacity drops or the noise
increases:
• Spray special cutting block oil onto
cutting system.
• Run cutting system forward (1) and
backward (3) several times without
feeding paper.
• Continue shredding.
2
1
3
1

190
200
220
220 CC Paper shredder
8 1.294.999.110 Edition 09/98
12. Customer Service
United States
Fellowes Manufacturing Co.
1789 Norwood Avenue
Itasca, IL 60143
Tel.: [phone]
Canada
Fellowes Manufacturing of Canada Ltd.
2750 John Street
Markham, Ontario L3R 2W4
Tel.: [phone]
United Kingdom
Fellowes Manufacturing UK Ltd.
Doncaster Road
Kirk Sandall
Doncaster, South Yorkshire DN3 1HT
Tel.: [phone]
Australia
Fellowes Manufacturing (Australia) Pty.Ltd.
10 Fellowes Court
Tullamarine, Victoria 3043
Tel.: [phone] in Melbourne
1-800-331-177 outside Melbourne
Nederland
Fellowes
P.O. Box 180
4130 Ed Vianen
Nederland
Tel.: [phone]
Germany
Fellowes GmbH
Dieselstraße 27
D-30827 Garbsen
Tel.: [phone]
France
Fellowes Lynx S.A.
194 allée de la Croix des Hormes
69250 Montanay
Tel.: [phone]
11. Warranty
FELLOWES®POWERSHRED LIMITED
WARRANTY
1 year on all parts and labor
5 years parts and labor on cutting cylinders
Fellowes®warrants this product to be free from
defects in material and workmanship for a
period of one year from the date of purchase by
the original consumer. At it's option, Fellowes®
will repair or replace without charge for material
or labor, any component found to be defective
during the warranty period. Additionally, the
cutting cylinders are warranted for 5 years from
the original purchase date and will be replaced
without charge for material or labor if found by
Fellowes®to be defective.
Warranty Exclusions
The parties agree that the buyer's sole and
exclusive remedy against Fellowes®shall be for
the repair or replacement of defective parts as
provided herein. The buyer agrees that no
other remedy (including, but not limited to,
incidental or consequential damages for lost
profits, lost sales, injury to property or any other
incidental or consequential loss) shall be
available to him. This warranty shall NOT apply
and is void under the following circumstances:
1. When this product or any part thereof has been
subjected to accident, alteration, abuse, or
misuse.
2. When the original Model and Serial Number
Plate has been altered, effaced or removed.
3. When repair or service covered under this
warranty (other than routine maintenance
(as described in the Owner's Manual ) has been
performed by personnel without the express
written consent of Fellowes®.
4. When the product has been used pursuant to
any verbal or written rental, lease or loan
agreement.
THIS WARRANTY DESCRIBED HEREIN SHALL
BE IN LIEU OF ANY OTHER WARRANTY,
EXPRESSED OR IMPLIED, INCLUDING, BUT NOT
LIMITED TO, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE. ANY REPRESENTA-
TIONS OR PROMISES INCONSISTENT WITH OR
IN ADDITION TO THIS WARRANTY ARE
UNAUTHORIZED AND SHALL NOT BE BINDING
UPON FELLOWES.
USA
