Ferno PacRac+ FWEPR+ IT User manual

Model FWEPR+ IT / Model FWEPR+ PX1
Users’ Manual
AUGUST 2021
Pub. No. 00148-AU-V4
Read this Manual and Retain
for Future Reference
PacRac+®
Instrument Table

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
2
Serial Number _________________________
Location: Rear cross tube under tray
USERS’MANUALS
To request additional free users’ manuals,
contact Ferno Customer Relations, your Ferno
distributor, or www.ferno.com.
Disclaimer
This manual contains general instructions for the use, operation
and care of this product. The instructions are not all-inclusive. Safe
and proper use of this product is solely at the discretion of the user.
Safety information is included as a service to the user. All other
safety measures taken by the user should be within and under
consideration of applicable regulations and local protocol. Training
on the proper use of this product must be provided before using
this product in an actual situation.
Retain this manual for future reference. Include it with the product
in the event of transfer to new users. Additional free copies are
available upon request from Customer Relations.
Proprietary Notice
The information disclosed in this manual is the property of Ferno-
Washington, Inc., Wilmington, Ohio, USA. Ferno-Washington, Inc.
reserves all intellectual property rights, proprietary design rights,
manufacturing rights, reproduction use rights, and sales use
rights thereto, and to any article disclosed therein except to the
extent those rights are expressly granted to others or where not
applicable to vendor proprietary parts.
Limited Warranty Statement
The products sold by Ferno are covered by a limited warranty,
which is printed on all Ferno invoices. The complete terms and
conditions of the limited warranty, and the limitations of liability
and disclaimers, are also available upon request by calling Ferno at
1.800.733.3766 or 1.937.382.1451.
Ferno Customer Service
For ordering assistance or general information:
CANADA AND THE U.S.A.
Telephone (Toll-free) 1.877.733.0911
Telephone [phone]
Fax (Toll-free) 1.888.388.1349
Fax [phone]
Internet www.ferno.com
AUSTRALIA
Ferno Australia, 11 Johnstone Road
Brendale, Queensland 4500, Australia
Telephone [phone]
Fax [phone]
Email [e-mail]
Internet www.ferno.com.au
ALL OTHER LOCATIONS
For assistance or information, please contact your Ferno distributor.
If you do not have a Ferno distributor, please contact Ferno
Customer Relations:
Ferno-Washington, Inc., 70 Weil Way
Wilmington, Ohio 45177-9371, U.S.A.
Telephone Country Code +1.937.382.1451
Fax Country Code +1.937.382.6569
Internet www.ferno.com
Ferno Australia Pty Ltd
11 Johnstone Road, Brendale
Queensland 4500, Australia
Ferno S.r.l.
via B. Zallone, n. 26,
40066 Pieve di Cento, Bologna, Italy
[phone]
Ferno (UK) Limited
Stubs Beck Lane, Cleckheaton
West Yorkshire BD19 4T, UK
[phone]

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 3
TABLE OF CONTENTS
Ferno Customer Service ______________________________________ 2
1 - Safety Information ___________________________________ 4
1.1 Warning______________________________________________ 4
1.2 Important ____________________________________________ 4
1.3 Tip __________________________________________________ 4
1.4 Symbol Glossary _______________________________________ 4
1.5 Safety and Instruction Labels _____________________________ 5
1.6 Bloodborne Disease Notice ______________________________ 5
1.7 Terminology Notice ____________________________________ 5
2 - Operator Focus ______________________________________ 5
2.1 Skills_________________________________________________ 5
2.2 Training ______________________________________________ 5
3 - About the PacRac+ ___________________________________ 6
3.1 Description ___________________________________________ 6
3.2 General Specications __________________________________ 6
3.3 Components __________________________________________ 7
4 - Setup_______________________________________________ 8
4.1 Attaching the PacRac+ Mounts to a Mondial® Monobloc ______ 8
4.2 Attaching the PacRac+ Mounts to an iN∫X _________________ 10
4.3 Attaching the PacRac+ Fixing Poles to a POWERX (UK) _______ 11
4.4 Attaching the PacRac+ Mounts to a POWER X1 (US)__________ 12
4.5 Attaching the Straps___________________________________ 13
5 - Using the PacRac+ __________________________________ 14
5.1 Before Placing the PacRac+ in Service _____________________ 14
5.2 General Guidelines for Use______________________________ 14
5.3 Unfolding the PacRac+ for Use___________________________ 15
5.4 Attaching the PacRac+ to a cot or iN∫X ____________________ 16
5.5 Removing the PacRac+ ________________________________ 17
5.6 Using the IV Poles _____________________________________ 18
5.7 Securing Instruments on the PacRac+ ____________________ 19
5.8 Patient Transfer _______________________________________ 21
5.9 Folding and Storing the PacRac+ ________________________ 22
6 - Maintenance _______________________________________ 23
6.1 Maintenance Schedule_________________________________ 23
6.2 Disinfecting the Straps _________________________________ 23
6.3 Cleaning the Straps____________________________________ 23
6.4 Disinfecting the PacRac+ _______________________________ 23
6.5 Cleaning the PacRac+ _________________________________ 23
6.6 Lubricating the PacRac+ _______________________________ 24
6.7 Inspecting the PacRac+ ________________________________ 24
7 - Parts and Service____________________________________ 25
7.1 U.S.A. and Canada_____________________________________ 25
7.2 Worldwide___________________________________________ 25
7.3 Parts List ____________________________________________ 25
Training Record________________________________________ 26
Maintenance Record ___________________________________ 27
Section Page Section Page

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
4
1  SAFETY INFORMATION
1.1 Warning
Warning notices indicate a potentially hazardous situation which, if
not avoided, could result in injury or death.
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to use the PacRac+.
Improper use of the PacRac+ can cause injury. Use the
PacRac+ only for the purpose described in this manual.
Improperly securing the PacRac+ to the cot or iN∫X can
cause injury. Secure the PacRac+ only as instructed in this
manual.
Improperly securing items on the PacRac+ can cause
injury or damage. Use the straps provided, plus additional
straps when needed, to secure items on the PacRac+.
Exceeding the load limit can cause injury or damage.
Include the weight of the IV uid bags when calculating
the load. Observe the 55 lb/25 kg load limit when attaching
items to the PacRac+.
Unlocking both sides of the PacRac+ can cause injury.
Unlock ONLY one PacRac+ side frame at a time. Use the
PacRac+ only for the purpose described in this manual.
Improper maintenance can cause injury. Maintain the
PacRac+ only as described in this manual.
Improper parts and service can cause injury. Use only
Ferno parts and Ferno-approved service on the PacRac+.
Modifying the PacRac+ can cause injury and damage. Use
the PacRac+ only as designed by Ferno.
1.3 Tip
Tips provide recommendations for easier use of the product.
1.4 Symbol Glossary
The symbols dened at right are used on the PacRac+ and/or in this
users’ manual. Ferno uses symbols recognized by the International
Standards Organization (ISO), American National Standards Institute
(ANSI) and the emergency medical services industry.
Acronyms used in this manual are dened below.
One Trained
Operator Required
Read the
Users’Manual
PacRac+ Load Limit
(Safe Working Load)
IV Pole Load Limit
(Safe Working Load)
Do Not
Lubricate
LockedUnlocked
2 kg
4.4 lb
General Warning of
Potential Injury
Product meets
European Union
Standards
Product meets
United Kingdom
Standards
Safety Information
1.2 Notice
Notices emphasize important, but not hazard-related information.
Failure to follow Notices could result in product or property damage.
NOTICE
Acronym Denition
CSK SCS Countersunk Socket Cap Screw
BHCS Button Head Cap Screw
SHCS Socket Head Cap Screw

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 5
1.6 Bloodborne Disease Notice
To reduce the risk of exposure to bloodborne diseases such as HIV-
1 and hepatitis when using the PacRac+, follow the disinfecting and
cleaning instructions in this manual.
1.5 Safety and Instruction Labels
Safety and instruction labels place important information from the
users’ manual on the PacRac+. Read and follow label instructions.
Replace worn or damaged labels immediately. New labels are
available from EMSAR or from your distributor (page 25).
2  OPERATOR FOCUS
2.1 Skills
Operators using the PacRac+ need:
● a working knowledge of emergency patient-handling
procedures.
● the ability to assist the patient.
2.2 Training
Operator trainees need to:
● read and understand this manual.
● be trained on the use of the PacRac+.
● practice with the PacRac+ before using it with a patient.
● record their training information. A sample training record
sheet is provided on page 26.
1.7 Terminology Notice
Terminology varies from region to region. In this manual, the following
term is used:
● Cot – The folding bed on which a patient travels inside an
ambulance. In this manual,“cot” represents any of the following:
ambulance cot, transporter, mobile transporter, stretcher-
transporter, trolley, gurney, etc.
IV Pole Load Limit Label
(axed to the IV pole).The
label species the load
limit for the IV pole.
Side Frame Release Label
(axed near the handle). The
label provides instructions for
using the handle.
1
2
1
2
2 kg
4.4 lb
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to use the PacRac+.
Operator Focus

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
6
3  ABOUT THE PACRAC+
3.1 Description
The PacRac+® Instrument Table (called the PacRac+ in this manual) is
an accessory that mounts to an ambulance cot or iN∫X®. The PacRac+
is designed to secure medical instruments such as a debrillator and/
or heart monitor.
The PacRac+ is for professional use only, by a minimum of one trained
operator. The PacRac+ is designed and tested for use during patient
transport in a ground-based ambulance.
The PacRac+ has been dynamically crash tested and certied to
meet the requirements of SAE J3043. All PacRac+ models meet the
requirements of RoHS-2.
COMPATIBLE COTS
The PacRac+ is compatible with Ferno®Mondial®Monobloc series
cots, POWERX (UK), POWER X1 (US) and with the iN∫X® Integrated
Patient Transport & Loading System™.
Model FWEPR+ PX1 for POWER X1 (US) is 1 in / 25 mm wider than
other models to accommodate the cot’s wider width.
PacRac+
Model Compatible with Additional Mount Kits
required
FWEPR+ IT • iN∫X
• Mondial Monobloc Included with PacRac+
FWEPR+ IT • POWERX (UK) Fixing Kit PacRac+for
POWERX (009010150)
FWEPR+ PX1 • POWER X1 (US) Included with PacRac+
FEATURES
● All-aluminum frame
● Side frames swing open to allow patient to be moved onto or o
from the cot or iN∫X without removing the PacRac+
● Side frames fold for compact storage
● Fast and simple mounting to cot or iN∫X
● 4 straps to secure instruments on the PacRac+
● 2 integrated, telescoping IV poles for hanging intravenous uid
bags
● Hook-and-loop straps secure IV uid bags to the IV poles
● Integrated Ferno iN∫TRAXX system within the tray top
3.2 General Specications
Most general specications are rounded to the nearest whole number.
Metric conversions are calculated before rounding the Imperial
measurements. For more information, contact Ferno Customer
Relations (page 2) or your Ferno distributor.
Ferno reserves the right to change specications without notice.
Load Limit (Safe Working Load)
Include the weight of the IV uid bags when
calculating the load. Inspect the PacRac+
if the load limit has been exceeded (See
Inspecting the PacRac+, page 24).
Specication Imperial Metric
General Specications
Construction Aluminum
Load Limit (Safe Working Load) 55 lb 25 kg
Weight 16 lb 7.2 kg
Unfolded for Use
Height at Tray 17 in. 435 mm
Height at IV Pole button
(pole fully retracted)
22 in. 560 mm
Height at IV Pole button
(pole fully extended)
34 in. 858 mm
Width - FWEPR+ IT 20.9 in. 530 mm
Width - FWEPR+ PX1 21.9 in. 555 mm
Depth 16.5 in. 420 mm
Folded for Storage
Height < 5 in. < 120 mm
Width - FWEPR+ IT 21 in. 530 mm
Width - FWEPR+ PX1 21.8 in. 555 mm
Depth 23 in. 560 mm
WARNING
Improper use of the PacRac+ can cause injury. Use the
PacRac+ only for the purpose described in this manual.
About the PacRac+

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 7
3.3 Components
Front Foot (2)
Equipment Strap (4)
Telescoping IV Pole (2) iN∫TRAXX Track (1)
IV Fluid Bag Strap (2)
IV Fluid Bag Hanger (4)
About the PacRac+
Side Frame Release
Handle (2, Red)
Secondary Catch
(2, Yellow)
IV Pole Release Button (2)
Rear Foot Release
Trigger (2)
Rear Foot (2)
Side Frame
Top Lock (2)
Side Frame Bottom Lock (2)
Tray

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
8
4  SETUP
4.1 Attaching the PacRac+ Mounts to a
Mondial® Monobloc
Attach the PacRac+ mounts (Figure 1, provided) to the cot main
frame to prepare the cot for use with the PacRac+. The PacRac+
attaches to the control end (or foot end) of the cot, above the shock
frame (Figure 2).
ATTACHING THE FRONTFOOT MOUNTS
1. Using a 4 mm hex wrench, remove the screw from the accessory
mounting point on the cot main frame, near the sidearm (Figure
3). Discard this screw.
2. Orient the funnel of the front-foot mount upward and insert an
M6x25 screw (provided) with the head of the screw inside the
funnel.
3. Using a 4 mm hex wrench, attach the front-foot mount to the
cot main frame (Figure 4). Fully tighten the screw.
4. Repeat Steps 1-3 on the opposite side of the cot.
3
4
2
PacRac+Mounts Here
1
Lip
Rear-Foot Mount (2)
and M5x40 CSK SCS (4)
Front-Foot Mount (2)
and M6x25 CSK SCS (2)
M6x45 BHCS for
Shock Frame (4)
Parts Included Qty.
Front-foot mount 2 ea.
Rear-foot mount 2 ea.
M6x25 CSK SCS with nylon patch 2 ea.
M5x40 CSK SCS with nylon patch 4 ea.
M6x45 BHCS with nylon patch 4 ea.
Tools Required Qty.
3 mm Hex wrench 1 ea.
4 mm Hex wrench 1 ea.
#1 Phillips screwdriver 1 ea.
Setup
KIT COMPONENTS  FWEPR+ IT

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 9
7
6
Remove Phillips Screws
ATTACHING THE REARFOOT MOUNTS
1. Using a 4 mm hex wrench, remove the two screws from one
shock-frame mounting block (Figure 5).
Set aside the mounting block. Discard the screws.
2. Using a #1 Phillips screwdriver, remove the two black screws
from the accessory-mounting point on the cot main frame, near
the footrest (Figures 6-7). Discard the screws.
3. Slide the lip of the rear-foot mount block (Figure 1, page 8)
under the edge of the cot main frame extrusion and align the
two holes in the rear-foot mount block with the accessory-
mounting point holes in the cot main frame (Figure 8).
4. Using a 3 mm hex wrench and two M5x40 screws, secure the
rear-foot mount to the cot main frame (Figure 8). Fully tighten
the screws.
5. Repeat Steps 1-4 on the opposite side of the cot.
6. Verify the cot footrest is in position. If it was removed to install
the PacRac+ mounts, position the footrest with the frame facing
upward as shown in Figure 2, page 8.
7. Using a 4 mm hex wrench, reattach the two shock-frame
mounting blocks with four new M6x45 pan-head screws
(provided).
8
5
Shock Frame Screw (2) Shock Frame
Mounting Block
Setup

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
10
Setup
4.2 Attaching the PacRac+ Mounts
To an iN∫X
Attach the PacRac+ mounts (Figure 1 page 8, provided) to the iN∫X
main frame to prepare it for use with the PacRac+. The PacRac+
attaches to the control end (or foot end) of the iN∫X, above the shock
frame (Figure 9).
ATTACHING THE REARFOOT MOUNTS
1. Discard from the kit two front-foot mounts and two M6x25
screws. You will not need them to install the mounting blocks
on an iN∫X.
2. Using a 3 mm hex wrench, remove the two outer screws from
the accessory mounting point on the iN∫X main frame, near the
footrest, leaving the center of three screws in place (Figure 10).
Discard the two screws that you removed.
3. Slide the lip of the rear-foot mount block (Figure 1, page 8)
under the edge of the iN∫X main frame extrusion and align
the two holes in the rear-foot mount block with the accessory-
mounting point holes in the iN∫X main frame (Figure 11).
4. Using a 3 mm hex wrench and two M5x40 screws, secure
the rear-foot mount to the iN∫X main frame (Figure 11). Fully
tighten the screws.
5. Repeat Steps 2-4 on the opposite side of the iN∫X.
9
PacRac+Mounts Here
10
11
Remove Phillips Screw (2x)
Do Not Remove
Center Screw

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 11
Setup
4.3 Attaching the PacRac+ Fixing Poles
to a POWERX (UK)
The PacRac+ is attached to POWERX (UK) using 2 extension poles
which are attached at the foot-end of the cot, tted into the push-
pole storage frame.
1. Remove the trolley push poles from the storage frame at the
foot-end at each side of the cot.
2. Place a PacRac+ xing extension pole into the storage frame
at each side (Figure 13), pushing the pole in far enough so that
the hole in the trolley frame lines up with the xing hole in the
extension pole.
3. Using a 4mm hex wrench and the screws supplied, attach the
foot-mount to the top of the trolley frame, screwing through
the hole into the extension pole that is located inside the
storage frame (Figures 13 and 14).
4. Once the extension poles have been xed tight in place, the
PacRac+ can be attached to the cot (Figures 15 - 17).
Front-foot Mount (2) Extension Poles LH/RH (2)
12
13 14
15
16 17
PacRac Fixing Kit for POWERX (UK) (009010150)
Parts Included Qty.
Front-foot mount 2 ea.
Extension Pole (Left Hand) 1 ea.
Extension Pole (Right Hand) 1 ea.
M6x25 CSK SCS with nylon patch 2 ea.
Tools Required Qty.
4 mm Hex wrench 1 ea.
M6x25 CSK SCS (2)

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
12
Setup
4.4 Attaching the PacRac+ Mounts
to a POWER X1 (US)
Attach the PacRac+ mounts (Figure 18, provided) to the POWER X1
(US) side rail to prepare it for use with the PacRac+. The PacRac+
attaches to the control end (or foot end) of the cot (Figure 19).
ATTACHING THE PACRAC+ FOR POWER X1 US
MOUNTS
Check that all mount kit components are present (Figure 18).
1. Place the cot mount casting on to the POWER X1 (US) side rail,
aligning the casting’s screw hole over the screw hole in the
side rail (Figure 20, q).
2. Using a 5 mm hex wrench and one M6x16 SHCS, secure the
cot mount clamp to the POWER X1 (US)’s side rail (Figure 20,
w).
3. Fit the cot mount clamp to the cot mount casting, ensuring
the mount clamp lip is interlocked with the mount casting
and the screw holes on both the casting and clamp are
aligned (Figure 21).
4. Secure the mount casting to the mount clamp with one
M8x20 SCHS screw and one M8 Nyloc nut (Figure 21). Using a
6 mm hex wrench and 13 mm spanner, fully tighten the screw
and the Nyloc nut.
5. Repeat Steps 1-4 on the opposite side of the POWER X1 (US).
Parts Included Qty.
Cot Mount Clamp 2 ea.
Cot Mount Casting 2 ea.
M8x20 SHCS 2 ea.
M8 Nyloc Nut 2 ea.
M6x16 SHCS with Nylon Patch 2 ea.
Tools Required Qty.
5 mm Hex wrench 1 ea.
6 mm Hex wrench 1 ea.
13 mm Spanner 1 ea.
KIT COMPONENTS  FWEPR+ PX1
18
Cot Mount
Casting (2)
M6x16 SHCS (2)
Cot Mount
Clamp (2)
M8x20 SHCS (2)
M8 Nyloc Nut (2)
19
20
q
w
21

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 13
4.5 Attaching the Straps
Note:Follow your local protocols for the placement and number of
equipment straps needed to properly secure the equipment on the tray.
EQUIPMENT STRAPS
1. Unbuckle the straps and separate the pieces of each equipment
strap.
2. Thread the loop-end of a strap through a slot in the tray, wrap
the strap around the tray and insert the buckle (Figure 22) or
tang through the loop.
3. Pull the buckle (or tang) and webbing through the loop until
the loop is snug around the attachment point.
4. Repeat Steps 2 and 3 to attach the other half of a strap to the
slot on the opposite side of the tray.
5. Repeat Steps 1-4 to attach the remaining three straps (Figure
23). Use additional straps as needed (not supplied). Additional
straps can be purchased from Ferno (see Parts and Service,
page 25).
IV FLUID BAG STRAPS
1. Wrap the loop-side strip of the center (short) hook-and-loop
fastener around the IV pole and secure with the hook-side strip
(Figure 24).
22
23
24
Loop-end of Strap
Buckle
Tray Slot
Equipment Straps
It is easier to attach and remove equipment
straps when the PacRac+ is unfolded for use,
with the side frames locked.
Setup

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
14
5.1 Before Placing the PacRac+
in Service
● Personnel who will work with the PacRac+ need to read this
manual.
● Conrm that the PacRac+ operates properly. See Inspecting the
PacRac+, page 24.
● Conrm that the cot or iN∫X operates properly with the PacRac+
securely attached. Refer to the cot or iN∫X users’ manual for
operating instructions.
● Attach the four tray straps and two IV uid bag straps to the
PacRac+. See Attaching the Straps, page 13. Attach additional
straps if needed, following local protocols.
5.2 General Guidelines for Use
● The PacRac+ is designed and tested for use during patient
transport in a ground-based ambulance. The PacRac+ meets the
crash-test requirements of AS/NZS 4535:1999 and SAE J3043.
● Operation of the PacRac+ requires one trained operator.
● Medical advice is beyond the parameters of this manual.
● It is the users’ responsibility to ensure safe practices for the
patient and themselves.
● The PacRac+ is for professional use only.
● Use the PacRac+ only when it is properly-maintained and in
good working order.
● Always properly secure the PacRac+ to the cot or iN∫X as
instructed in this manual.
● Always properly secure objects on the PacRac+. Use the
equipment straps provided, plus additional straps as needed, to
secure the load on the PacRac+.
5  USING THE PACRAC+
One Trained
Operator Required
Read the Users’
Manual
WARNING
Untrained operators can cause injury or be injured.
Permit only trained personnel to operate the PacRac+.
Improperly securing the PacRac+ to the cot or iN∫X can
cause injury. Secure the PacRac+ only as instructed in this
manual.
Improperly securing items on the PacRac+ can cause
injury or damage. Use the straps provided, plus additional
straps when needed, to secure items on the PacRac+.
Using the PacRac+
Load Limit (Safe Working Load)
Include the weight of the IV uid bags when
calculating the load. Inspect the PacRac+
if the load limit has been exceeded (See
Inspecting the PacRac+, page 24).

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 15
5.3 Unfolding the PacRac+ for Use
1. If an equipment strap was used to secure the legs in the folded
position, unbuckle the strap.
2. Stand the PacRac+ upright, with the rear feet on a at surface.
Raise the tray to horizontal position (Figure 25). Continue to
support the tray as you complete Step 3.
3. Rotate one side frame to the front of the PacRac+ and slide the
side frame top lock into position in the tray (Figure 26).
4. Rotate the side frame handle 90° to the front of the PacRac+ to
engage the side frame top lock (Figure 27).
Side Frame Top Lock
5. Repeat Step 3 and Step 4 to position and lock the second side
frame (Figure 28).
6. Verify that both side frames are securely attached to the tray
and the locks are engaged before continuing.
7. If the straps were removed from the tray for storage, reattach
them to the tray. See Attaching the Straps, page 13.
25
26
27
28
Using the PacRac+

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
16
5.4 Attaching the PacRac+ to a cot or
iN∫X
Locate the accessory mounting points on the cot or iN∫X (Figure 29).
1. Set the PacRac+ on the cot or iN∫X main frame, positioned
slightly toward the loading end of the cot or iN∫X from the
accessory mounting points (Figure 29).
2. Slide the PacRac+ toward the control end of the cot or iN∫X until
the rear feet lock into the accessory mounting points and the
side frame bottom lock castings are seated over the mounting
posts (Figure 29 and Figure 30).
3. Verify the PacRac+ is securely locked in place by attempting to
push it toward the loading end of the cot or iN∫X. If the PacRac+
is locked securely, it will not move.
4. If the PacRac+ slides away from the mounting points, reposition
the PacRac+ and repeat Steps 1-3.
5. The installed PacRac+ on the various cots or iN∫X are pictured
as follows:
• Mondial Monobloc - Figure 30
• iN∫X - Figure 31
• POWERX (UK) - Figure 32
• POWER X1 (US) - Figure 33
Rear Foot Mount Front Foot Mount
29
30
Using the PacRac+
31 PacRac+ installed on iN∫X
PacRac+ installed on Mondial Monobloc
NOTICE
Depending on the size of the patient, the PacRac+ may
prevent the use of the shock frame.

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 17
33
5.5 Removing the PacRac+
1. Standing at the control end of the cot or iN∫X, grasp both rear
feet castings and press the red levers to disengage the locks
(Figure 34).
2. Push the PacRac+ toward the loading end to unseat the
PacRac+ from the mounting posts (approximately 3"/ 75 mm).
3. Lift the PacRac+ o the cot or iN∫X and set it aside. Rear-Foot
Release Levers
Using the PacRac+
34
32 PacRac+ installed on POWERX (UK)
PacRac+ installed
on POWER X1 (US)

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
18
5.6 Using the IV Poles
Two IV poles are integrated into the PacRac+ (Figure 35). The IV poles
are designed to carry bags of intravenous solution. Do not exceed the
4.4 lb/2 kg load limit on each IV pole. Weight attached to the IV poles
must be included when calculating the total load on the PacRac+.
RAISING AN IV POLE
Note:The IV poles are not locked when in the lowered position.
1. Grasp the molded tip of an IV pole and extend the IV pole until
it locks in the raised position (Figure 35).
2. Hang intravenous uid bags on the IV pole hooks. Each hook is
designed to hold a 1-liter/1-quart IV uid bag.
3. Secure each IV uid bag with a hook-and-loop strap (Figure 36).
LOWERING AN IV POLE
1. Remove IV uid bags before lowering the IV poles.
2. Press the red button at the top of the IV pole (Figure 37) and
lower the IV pole.
36
37
35
IV Pole (2)
2 kg
4.4 lb
Using the PacRac+
NOTICE
Include the weight of IV uid bags and/or items attached to
the IV poles when calculating the load on the PacRac+.

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021 19
5.7 Securing Instruments on the
PacRac+
The PacRac+ is designed to carry instruments such as debrillators,
pumps, monitors, and IV uid bags with a combined weight of up to
55 lb/25 kg. Each IV pole has a load limit of 4.4 lb/2 kg, which must be
included when calculating the load on the PacRac+.
Equipment can be secured to the PacRac+ by two methods:
1. Equipment straps (provided).
2. Ferno iN∫TRAXX track system using an iN∫TRAXX mount (not
provided).
WARNING
Improperly securing items on the PacRac+ can cause
injury or damage. Use the straps provided, plus additional
straps when needed, to secure items on the PacRac+.
Exceeding the load limit can cause injury or damage.
Include the weight of the IV uid bags when calculating
the load. Observe the 55 lb/25 kg load limit when
attaching items to the PacRac+.
Using the PacRac+
Load Limit (Safe Working Load)
Include the weight of the IV uid bags when
calculating the load. Inspect the PacRac+
if the load limit has been exceeded (See
Inspecting the PacRac+, page 21).
38
SECURING INSTRUMENTS USING EQUIPMENT STRAPS
Use the straps provided to safely secure all instruments placed on the
PacRac+. Use additional straps if needed. Items with pole-clamps may
be attached to the vertical side tubes of the PacRac+.
Before moving the cot or iN∫X, verify that all items are safely secured to
the PacRac+ (Figure 38).
It is the responsibility of the controlling Emergency Medical Service to
devise the strapping methods for the particular instruments used by
medical service personnel and to train the personnel in using those
methods.

© Ferno-Washington, Inc. / 00148-AU-V4 / AUG 2021
20
39
40
41
Using the PacRac+
SECURING INSTRUMENTS USING IN∫TRAXX
The iN∫TRAXX ambulance system is an integrated approach to
ambulance design that brings equipment and supplies into one
cohesive environment. It is based on a quick-connect track and
mount system which enables equipment to be rapidly attached and
detached.
Tracks are structured with large drop-in zones and a series of locking
holes along the centre of the tracks to allow SafeMounts to lock into
position (Figure 39).
To attach equipment to the track, equipment must rst be secured to
an iN∫TRAXX SafeMount. Instructions are provided in the iN∫TRAXX
User Manual (ERS iNTRAXX User 3637R00) accompanying SafeMount
products.
ATTACHING THE SAFEMOUNT TO THE TRACK
1. Place the SafeMount feet in the track’s drop-in zones (Figure 40)
2. Press the mount into the track.
3. Slide to one side or the other until the SafeMount’s locking pin
locks in place (Figure 41).
4. Rotate the dual purpose lever to the left to tighten the
SafeMount into position (Figure 41).
REPOSITION THE SAFEMOUNT
1. Rotate the dual-purpose lever to the right to loosen the
SafeMount.
2. Pull the dual-purpose lever to retract the locking pin and allow
the SafeMount to be moved or removed from the track.
3. Slide the SafeMount to one side or the other until the locking
pin locks into a new locking position (Figure 41).
4. Rotate the dual-purpose lever to the left to tighten.
REMOVING THE SAFEMOUNT FROM THE TRACK
1. Rotate the dual-purpose lever to the right to loosen.
2. Pull the dual-purpose lever away from the track to retract the
locking pin to release the mount (Figure 41).
3. Slide the SafeMount to a drop-in zone.
4. Remove the SafeMount from the track.
Locking Holes
Drop-in Zones
Slide until
Locking Pin
engages
Rotate lever left
to tighten.
Rotate lever
right to loosen.
