Fervi 0048 Operating instructions

USER AND
MAINTENANCE MANUAL
Mini Airbrush Kit
Art. 0048
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
fervi.com

HAR
DWARE
Page
2
of
7
FOREWORD
Read This Manual Before Operation
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
Reading this instruction manual is required before op
erating any of the machinery. The
guarantee of smooth operation and full performance of the product is highly dependent on the
application of all the instructions contained in this manual.
Operator Qualifications
The workers responsible for using th
is tool must have all the necessary information,
education and receive adequate training regarding safety, including:
a)
Conditions of use for the equipment;
b)
Foreseeable abnormal situations;
pursuant to art. 73 of Legislative Decree No. 81/08.
We guarantee
the product's conformity to specifications and technical instructions
described in the Manual on the date of issue, listed on this page; however, the
machine may be subject to potentially major technical changes in the future, without
the Manual being upd
ated.
Therefore, contact FERVI for information regarding modifications that could be
implemented.
REV. 2
July 2013
fervi.com

HARDWARE
Page
3
of
7
Table of Contents
1
COMMISSIONING
................................
................................
......................
3
1.1
How to Use the Airbrush
................................
................................
...............................
4
1.2
Personal Protective Equipment
................................
................................
.....................
5
1.3
Technical Support
................................
................................
................................
.........
5
2
DESCRIPTION AND INTE
NDED USE
................................
...........................
6
2.1
Technical Specifications
................................
................................
................................
7
2.2
Iden
tif
ication
................................
................................
................................
................
7
3
I
MPROPER USES AND PRE
CAUTIONS
................................
........................
7
4
MAINTENANCE AND CLEA
NING
................................
................................
.
7
fervi.com

HAR
DWARE
Page
4
of
7
1
COMMISSIONING
Before using
this mini airbrush, some simple
assembly is required.
To properly assemble the mini airbrush, proceed as follows:
1.
Screw the compressed air tube to the threaded connector (B) on the body of the airbrush
gun, tightening firmly.
2.
Screw the threaded connector
at the other end of the air tube to a can of compressed air
or a compressor with a .25 inch threaded connector.
3.
Insert the connector located on the lid of the paint container into the hole of the body of
the airbrush, applying light pressure to secure the
connection.
1.1
How to Use the Airbrush
Adjust the amount of pai
nt and air released from the
nozzles via the adjusting rings (A)
located on the nozzles themselves.
To begin painting, simply aim the mini airbrush at the element to
be painted, keeping it at a
distance of about 50 mm from the surface and press the trigger (C). While painting, move the
mini airbrush from side to side to distribute the paint as evenly as possible.
Do not point the spray at people or animals.
If the
pain
t is not evenly distributed, adjust the amount of air/paint.
To stop the spray of paint, simply release the trigger.
Turn the dial to adjust the paint output.
Risk of Fire or Explosion

The solvents and paints can be highly flammable.

Use the mini air
brush in well ventilated areas.

Do not smoke or use an open flame when using the mini airbrush.
A
B
C
fervi.com

HARDWARE
Page
5
of
7
1.2
Personal Protective Equipment
When using the mini airbrush, wear protective eye wear, a mask (suitable for painting
operations), gloves and suitable clothing
for the painting operation.
1.3
Technical Support
For any inconvenience and/or concerns please contact the dealer from whom you
purchased
the mini airbrush kit
who will order the spare parts.
fervi.com

HAR
DWARE
Page
6
of
7
2
DESCRIPTION AND INTE
NDED USE
The Mini Airbrush,
Art.
0048
,
is a tool that uses compressed
air
to spray various types of
paints. It is used for precision work, producing very thin lines, creating smooth surfaces with
uniform col
our, and blended tones.
1
Tanks
2
Dropper
3
Tank insert
4
Air outlet nozzle with adjustment ring
5
Paint outlet nozzle with adjustment ring
6
Operating trigger
7
Air connector
8
Air hose
2
3
4
5
6
7
8
1
fervi.com

HARDWARE
Page
7
of
7
2.1
Technical Specifications
Mo
del
Art. 0048
Mass (g)
370
Compressed air connection
1/4”
Pressure (MPa)
1.2
2.2
Identification
The following identification plate is located on the Mini Airbrush,
Art. 0048
:
3
IMPROPER USES AND PR
ECAUTIONS
IT IS STRICTLY FORBIDDEN TO:

Use the mini ai
rbrush for purposes other than those for which it was intended.

Use the mini airbrush in areas that carry a risk of fire or explosion.

Lock the power lever in the open position.

Use the mini airbrush without the proper use of appropriate PPE

Use the airbru
sh in the presence of children;

Point the spray of the mini airbrush at people and/or animals.

Smoke while using the airbrush.
4
MAINTENANCE AND CLEA
NING
The compressed air connection must be kept clean and dry.
The paint outlet nozzle and all moving parts
should be cleaned thoroughly after each time the
airbrush is used.
To clean, we recommend using a solvent and a brush to remove paint residue and thoroughly
clean the nozzle.
Once you have finished cleaning with the solvent, rinse the parts with clean wate
r and dry
thoroughly with a dry cloth.
Used nozzles must be replaced with equivalent nozzles.
Contact the Dealer's Customer Service Centre where you purchased the items to order spare
parts.
