Fiberstars WaterLevV IGW 7000 User manual

Unit Specifications
Sensor Unit: Water Proof Housing
Power operation: 5 - 9 Volt DC
Operating Cycle: Continuous
Operating Range: 40°
°°
°F to 125°
°°
°F / 5°
°°
°C to 55°
°°
°C
Model IGW-7000 Range: 12 ft / 3.65 meters
Installation: Adjustable height
Operation: Pool Service Technicians only
Storage Temperature: 20°
°°
°F to 150°
°°
°F / -5°
°°
°C to +65°
°°
°C
Warranty: 1 Year
Valve control Unit: Water Resistant Housing
Power Supply (Rain tight outdoor type): 120VAC 138mA / 9VDC 1A rating
Operating Cycle: Continuous
Flow rate per minute: Approx. 7 - 8 Gallons / 27 - 30 Liters
Operating Temperature: 40°
°°
°F to 125°
°°
°F / 5°
°°
°C to 55°
°°
°C
Inlet Fitting Type: 3/4” Male Garden Hose Fitting
Outlet Fitting Type: Male 3/4” NPT
Water pressure: 15 – 100 PSI
Warranty: 1 Year
Distributed by ENERGY FOCUS, INC.
32000 Aurora Road
Solon, OH 44139
1-800-327-7877
3172293 FCC ID: W4V-IGW6000
IC: 8173A-IGW6000
This product has been tested to the requirements of CAN/CSA-C22.2 No. 61010-1,
second edition, including amendment 1, or a later version of the same standard
incorporating the same level of testing requirements.
Note: If used in a manner not specified by the manufacturer, the protection
provided by the equipment may be impaired.
Manufactured by WaterLevV Inc.
Montreal, Canada
www.e n e r g y f o c u s i n c .com
WaterLevV
™
Model IGW 7000
Pool Service Kit

Thank you for purchasing the WaterlevV ™ IGW-7000 Pool Service Kit
Pool filling system. This system helps installers in installing, fitting and
replacing Pool Liners.
Please Read before Operation
The WaterLevV ™ Sensor is mounted on a Nylon strap allowing the
Pool Service Technician flexibility in refilling pools at a desired height.
This allows the installer time to adjust and monitor the liner during the
refilling of the Pool.
Step 1
Connect the 90°elbow to Water OUTLET Connection on the Valve Unit.
Step 2
Attach Ground Support Spike to the Valve Control Unit with the Garden
Hose Union Supplied.
Step 3
Attach a short hose to the Outlet 90°elbow and Place Valve Control Unit
at a desired distance from the Pool. ( Grass )
Step 4
Lower the WaterLevV ™ Sensor to the desired level and affix the Nylon
Strap via the Plastic Spike provided or by placing a weighted objet on the
Strap.
Step 5
Attach the WaterLevV ™ Sensor cable and Power Supply cables to the
Valve Control Unit.
Step 6
Connect a water source to the Valve Control Units Water INLET
Connection.
Step 7
When the water level reaches the Sensor the Water Valve will shut off.
Lift Sensor to next desired Level and the Valve will re-activate.
Sensor LED definition as follows:
YELLOW indicates a LOW LEVEL Detect ( Valve On )
RED indicates a Set LEVEL Detect ( Valve Off )
GREEN indicates Send Data
Control Unit LED definition as follows:
LED No. 1 Indicates Power On Status
LED No. 2 Indicates Data Received
LED No. 3 Indicates Valve activation
Control Valve Reset Switch definition:
Press and Hold Reset Button for 3 seconds to turn off valve manually.
Maintenance:
* Keep Probe Sensor Area Clean
If there is a loss of water flow, please check the following:
1. Water Inlet screen may be blocked with dirt or debris.
Solution:
Shut off the water source and remove Inlet connection, and then remove
the ¾” – ¾” adapter. The Dirt screen is located in the Inlet port, remove,
clean and replace. Reconnect the water connection and turn on the
water source.
* If Dirt Screen is not replaced damage to the valve may occur.
2. Loss of Power
Solution: •Verify that the Power Adapter is plugged and functioning
•Power LED of the Valve Unit should be On
•If a problem persists contact service at WaterLevV ™
Rev. 2c 15022010
