FIELDKING Sub Soiler Installation and maintenance instructions

Operator Manual
† Service Manual † Part Catalogue †
Seeding & Plantation
Post Harvest
Harvest
Crop Protection
Landscaping
Tillage Haulage
Solutions...
01-07-2019
USA
960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA
FIELDKING USA, INC.
[email protected], www.fieldkingusa.com
Sub Soiler

Should you require additional information or assistance, please contact us.
As an authorized “FIELDKING USA” dealer, we stock genuine “FIELDKING USA”
parts which are manufactured with the same precision and skill as our original
equipment. Our trained service persons are well informed on methods required to
service “FIELDKING USA” equipments and are ready to help you.
You have invested in one of the best implements of its type in the market today.
The care you give your “FIELDKING USA” implement will greatly determine your
satisfaction with its performance and its service life. A careful study of this manual
will give you a thorough understanding of your new implement before operating.
If your manual is lost or destroyed, “FIELDKING USA” will be glad to provide you a
new copy. Visit to nearest dealership & get a copy. Most of our manuals can also be
downloaded from our website at www.fieldkingusa.com.
CONGRATULATIONS!
YOUR AUTHORIZED
FIELDKING USA DEALER
BECAUSE “FIELDKING USA” MAINTAINS AN ONGOING PROGRAMME
OF PRODUCT IMPROVEMENT, WE RESERVE THE RIGHT TO MAKE
IMPROVEMENTS IN DESIGN OR CHANGE IN SPECIFICATION
WITHOUT INCURRING ANY OBLIGATION TO INSTALL THEM ON
UNITS PREVIOUSLY SOLD. BECAUSE OF THE POSSIBILITY THAT
SOME PHOTOGRAPHS IN THIS MANUAL WERE TAKEN OF
PROTOTYPE MODELS, PRODUCTION MODELS MAY VARY IN SOME
DETAIL. IN ADDITION, SOME PHOTOGRAPHS MAY SHOW SHIELDS
REMOVED FOR THE PURPOSE OF CLARITY. NEVER OPERATE THIS
IMPLEMENT WITHOUT ALL SHIELDS IN PLACE.

1. Read and understand the information contained in this manual.
3. Inspect the equipment and replace or repair any parts that are damaged or worn
out which under continued operation would cause damage, wear to other parts,
or cause a safety hazard.
4. Return the equipment or parts to the authorized “FIELDKING USA” dealer, from
where it was purchased, for service or replacement of defective parts that are
covered by warranty. (The “FIELDKING USA” Factory may inspect equipment or
parts before warranty claims are honored.)
5. All costs incurred by the dealer for traveling to or transporting the equipment for
warranty inspection and claims will be borne by the customer.
2. Operate, lubricate, assemble and maintain the equipment in accordance with all
instructions and safety procedures in this manual.
PURCHASER / OPERATOR’S RESPONSIBILITY
Serial No. ___________________________________________
Model No. ___________________________________________
Date of Purchase _____________________________________
Sometime in the future your sub soiler may need new parts to replace which are
worn out or broken. If so, go to your dealer and provide him equipment’s detail like
model and part number.
This manual contains valuable information about your new “FIELDKING USA” sub
soiler. It has been carefully prepared to give you helpful suggestions for operating,
adjusting, servicing and ordering spare parts.
Keep this manual in a convenient place for quick and easy reference. Study it
carefully. You have purchased a dependable and sturdy sub soiler but only by proper
care and operation you can expect to receive the service and long life designed and
built into it.
Name ______________________________________________
Purchased From ______________________________________
TO THE PURCHASER
CUSTOMER INFORMATION

2.1 General description
2. TECHNICAL INFORMATION
3. USAGE INSTRUCTIONS
1. INTRODUCTION
2.3 Warranty become void
2.2 Warranty
4. TRACTOR PREPARATION AND WORKING
4.3 Leveling the sub-soiler
4.6 Trouble shooting
5. MAINTENANCE
3.2 Attaching sub-soiler to the tractor
3.1 Overall check -up
4.2 Width of cut adjustment
4.1 Instructions for tractor preparation
4.4 Adjustments for deeper penetration
3.3 Safety Instruction
4.5 Warning for driver
5.2 Storage of Machine after work
6. PICTURES AND PART CODE NO. FOR TRACTOR OPERATOR/DRIVER
5.1 Maintenance Instructions
INDEX

21
1.1 INTRODUCTION
This manual contains the use and maintenance instructions with a list of the
spare parts of the “FIELDKING USA” Sub-Soiler.
FIELDKING USA sub-soiler is used to break-up compacted soil layers and
open the ground up, so that roots and moisture can penetrate more deeply into
the soil. Yields suffer when compaction keeps roots from growing freely
throughout the soil in search of moisture and nutrients. Sub-soiler usage lets
plants to stretch their roots by opening passageways through the hardpan. It
can be used as a primary tillage tool i.e. one used for the first pass over a field
but not normally a part of usual tillage operation.
This implement is useful when a plow pan or hard pan (compacted layer) has
developed because of regular plowing and disking or heavy animal and
equipment traffic. When operated properly in dry soil this implement fractures
and shatters the hard soil.
FEATURES
1. It can go up to 22 inch deep.
4. It is an inexpensive implement & it provides a simple and economical way to
obtain boosting crop yields and profits.
3. It preserves moisture during high rainfall which is very important for the crop to
withstand low rainfall or drought periods.
1. When the implement has been used beyond the specified power limit like
(Tractor Horse Power)
The purchaser may only make the claims under guarantee when he has complied
with the warranty conditions in the supply contract.
Besides the cases specified in the supply agreement, the guarantee shall in any
case become void:
When the machine is delivered, check that it has not been subjected to damage
during transport and that the accessories are in a perfect condition and complete.
Any claims following the receipt of damaged goods shall be presented in writing
within 8 days from the receipt of the goods.
2. It fights drought by increasing the ground storage capacity.
2.2 Warranty
3. It increases soil turnover by reaching deeper organic matter layers.
2.3 WHEN THE WARRANTY BECOMES VOID
2. When repairs made by the customer without authorization from the
manufacturer or owing to installation of spurious spare parts, the machine is
subjected to variations and the damage can be ascribed to these variations.
3. When the user has failed to comply with the instructions in this handbook.
3. USAGE INSTRUCTIONS
3.1. OVERALL CHECK-UP
Before mounting of Sub-Soiler to tractor make sure that all nuts and bolts are
properly secured.
Fig-1 root growth after use of Sub-Soiler
BENEFITS
2. TECHNICAL INFORMATION
1. The sub-soilers are deep tillage implements specially designed for breaking
up hard pan layers and loosening the subsoil allowing better drainage, root
growth and mineral osmosis.
2.1 GENERAL DESCRIPTION
2. The heavy duty chisel pointed share shatters the soil well below the surface,
thus increasing the water holding capacity.

43
3.2. ATTACHING THE SUB-SOILER TO THE TRACTOR
1. Place the sub-soiler duly levelled on the flat piece of land.
6. After attaching the sub-soiler lift it and adjust the control arm parallel to the
ground. When you look from both rear or sideways, the shanks should all be
touching the ground uniformly.
DANGER
2. Reverse the tractor to the sub-soiler ( Do not drag the sub-soiler)
4. Attach the lower right arm, turn the screw until the mounting pin is at the
same level as the hole on the tractor arm. If the gap between hole and
mounting pin is too close or too distant, turn the control arm in or pull it away
to an appropriate distance. You may have to adjust both height and distance
at the same time. When the hole at tractor arm and mounting pin are even,
insert the pin in the hole and lock it with the lynch pin.
5. Attach the central arm to the sub-soiler. To attach, turn the screws on both
sides to an equal length. If the arm is too short or too long, turn the screw to
adjust both at the same time until aligned with the hole on the central arm.
Understanding the Machine Safety Labels
3. Attach the left arm of the tractor to the sub-soiler first.
3.3 SAFETY
Safety-Alert Symbol
Never allow riders on the tractor or implement
unless an additional seat is available.
Be careful when moving around steep gradient to
avoid sharp turn.
Never transport the implement on rough roads
during the night. When operating, avoid sharp
turns that may cause tractor colliding with the
implement.
In order to protect yourself always wear adequate
clothes and shoes during the operations.
The machine safety labels shown in this section are
placed in important areas on your machine to draw
attention to potential safety hazards
On your machine the words DANGER, WARNING, and
CAUTION are used with this safety-alert symbol.
DANGER identifies the most serious hazards.
The operator’s manual also explains any potential
safety hazards whenever necessary.
4.2 Width/Depth adjustment
1. The horsepower of tractor selected should match the implement.
4.1 INSTRUCTION FOR TRACTOR PREPARATION
The following are typical instructions for preparing a tractor for operation:
4. TRACTOR PREPARATION AND WORKING
2. All sub-soiler adjustment should be carried out.
3. Select draft and position control setting according to tractor operators manual.
The width adjustment is available in three arms sub-soiler. Width of shanks could be
adjusted easily with the flexibility provided in the frame. The depth adjustment can
be done by changing the hole position in the shank for both two and three arm sub-
soiler. The single arm sub-soiler has no adjustment.

65
4.3 Leveling the sub-soiler
The level of the sub-soiler is controlled by the tractor top link. Lateral levelling is
controlled by adjusting the length of the tractor right lower link. These
adjustments must be made with the sub-soiler prior to operation.
4.4 Adjustment for deeper penetration
The depth of the penetration can be obtained by the position and draft control
levers of the tractor hydraulic system. Higher the tractor power more is the
depth of operation. However more depth can be obtained by lowering the
shanks.
Fig 2- Soil fracturing pattern
4. Properly mount the three point linkage as mentioned above & lock with lynch
pin.
6. Keep proper distance from sub-soiler when it is in working.
4.5 Warning for driver
3. Never reverse the tractor when the sub-soiler is engaged in the soil.
1. Operate the tractor in low first gear.
4.6 TROUBLING SHOOTING
The “FIELDKING USA” Sub-Soiler Uses a vertical Shank to break- up Hardpan,
trench or aerate the soil. it is a simple and reliable system that requires minimal
maintenance.
2. Lift the sub-soiler completely on every turn.
5. If subs-soiler stuck with tree roots and stones, stop tractor and lift the
subsoiler.
7. Lift the sub-soiler completely during transport.
in the following section, we have listed many of the problems, causes & solutions
to the problems that you may encounter.
if you encounter a problem that is difficult to solve, even after having read
through this trouble shooting section, Please call your local “FIELDKING
USA” Dealer. Before you call, please have this operator's manual & the serial
number from your Sub-Soiler ready.
PROBLEM
Blade won't penetrate
soil
High power required.
CAUSE
Hard ground
condition
1. Wrong Shank
Angle
2. Blade worn
SOLVE
1. Replace blade if badly worn.
2. Be sure 3 point hitch is set in
"float" or "draft" Mode.
3. Set Shank angle
4. Add weight to frame
1. Reset Shank Angle.
2. Replace blade.
2. Replace the worn out nuts and bolts.
These steps will enhance the life of your sub-soiler
If sub-soiler is working on stony land then maintenance goes up. Please follow
these rules to get the best results:
1. If sub-soiler is new then tightened all nuts and bolts after few trials runs.
1. Wash the sub-soiler completely after work.
5.1 MAINTENANCE INSTRUCTIONS
5. MAINTENANCE
3. When the length of the points is reduced by 1 inch, reverse it and use the
other side of the points, when both side of the strip are worn out replace it
with the new one.
5.2 STORAGE OF MACHINE AFTER WORK
2. Constantly check for tightness of nuts and bolts.
3. If sub-soiler has to remain unused for long time then clean it & apply a layer
of un-used oil/grease for rust prevention.

87
6. PART CATALOUGE OF 1, 2 & 3 ARM SUB-SOILER
SUB-SOILER (1-RAM)
TYNE ASEMBLY SUB-SOILER (1-ARM)
OPTIONAL PIPE LAYER
ASSEMBLY SUITABLE FOR
50MM PIPE LAYING
FKSSP-501
SR.NO. PART NO.PART NAME QTY.
1 75200001SUB SOILER TYNE 1
2 75200002SUB SOILER SHOWEL 1
3 75200003SUB SOILER SHOE 1
4 10260080HEX. HEAD BOLT M16x80x2P 2
5 10280005NYLOCK NUT M16x2P 2
6 10260052CSK BOLT M12x40x1.75P 1
7 10260050CSK BOLT M12x50x1.75P 1
8 10280025NYLOCK NUT M12x1.75P 2
9 10270005SPRING WASHER 16MM 2
10 10270003SPRING WASHER 12MM 2
SR. NO. PART NO.PART NAME QTY.
1 75180001FRAME ASSEMBLY 1
2 75190001LINKAGE 1
3 75200004TYNE ASSEMBLY 1
4 75210001STANP PIPE ASSEMBLY 2
5 75180006SIDE LINK SUPPORT 2
6 10020013HITCH PIN 20MM 2
7 10270007SPRING WASHER 25MM 4
8 10280041PLAIN NUT M25 2
9 10260080HEX HEAD BOLT M16x80x2P 2
10 10280005NYLOCK NUT M16x2P 3
11 10280025NYLOCK NUT M12x1.75P 2
12 10260102HEX. HEAD BOLT M12x65x1.75P 2
13 10270003SPRING WASHER 12MM 2
14 10260052HEX HEAD BOLT M12x40x1.75P 1
15 10270005SPRING WASHER 16MM 2
16 10020096R-PIN 6x106MM 2

109
SUB-SOILER (2-ARM) SUB-SOILER TYNE ASSEMBLY (2 & 3 ARM)
3
5
84
10
9
6
2
7
1
11
SR. NO. PART NAME PART NO. QTY.
1 FRAME ASSEMBLY 75270001 1
2 3POINT LINKAGE ASSEMBLY 75380001 1
3 TYNE ASSEMBLY 75300001 2
4 STAND ASSEMBLY 75290001 2
5 HEX HEAD BOLT M16X80X2P 10260080 4
6 NYLOCK NUT M16X2P 10280005 4
7 SPRING WASHER16MM 10270005 4
8 HEX HEAD BOLT M18X60X1.5P 10260082 4
9 SPRING WASHER 18MM 10270006 4
10 NYLOCK NUT M18X1.5P 10280006 4
11 R PIN (6X106MM) 10020096 2
SR.NO.
1
2
3
4
5
6
7
8
PART NO.
75300002
75200002
75200003
10260049
10280025
10260080
10260050
10270003
PART NAME
SUB SOILER TYNE
SUB SOILER SHOWEL
SUB SOILER SHOE
CSK BOLT (M12x40x1.75P)
NYLOCK NUT (M12x1.75P)
HEX. HEAD BOLT (M16x80x2P)
CSK BOLT (M12x50x1.75P)
SPRING WASHER (12MM)
QTY.
1
1
1
2
4
2
2
4

1
6
3
5
4
2
8
7
2
3
10
7
4
5
6
11
12
1
8
9
1211
SUB-SOILER (3-ARM)
10
8
1
TYNE ASSEMBLY-5ARM SUBSOILER
TYNE MOUNTING ASSEMBLY
COMPLETE 5ARM SUBSOILER PART DETAILS
SUB-SOILER (5-ARM)
QTY.
1
1
3
1
1
3
3
6
6
4
12
4
1
4
1
PART NAME
FRAME ASSEMBLY
3 PT. LINKAGE
TYNE ASSEMBLY
FRONT SUPPORT PIPE
STAND PIPE ASSEMBLY
CSK BOLT (M12X50X1.75P)
CSK BOLT (M12X40X1.75P)
HEX HEAD BOLT (M16X60X2P)
HEX HEAD BOLT (M16X80X2P)
HEXHEAD BOLT (M18X60X1.5P)
SPRING WASHER (16MM)
SPRING WASHER (18MM)
R PIN (6X106MM)
NYLOCK NUT (M18X1.5P)
HEX HEAD BOLT (M16X110X2P)
PART NO.
75370001
75380001
75300001
75370002
75290001
10260050
10260049
10260017
10260080
10260082
10270005
10270006
10020096
10280006
10260135
SR.NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

1413
DELIVERY CHECKLIST
Dealer Pre-Delivery (Please Tick)
1. Dealer Pre-Delivery Checklist
3. All safety, operational and maintenance
information have been explained and
demonstrated.
1. The customer or person responsible has
been given the operator’s manual.
4. All greasing and oil points, stickers,
guarding and ID plate have been identified
and physically pointed out.
2. The customer undertakes to read the
co mpl ete ope rat or ’s m anu al a nd
understands all aspects of the manual
before operation of the machine.
5. The customer agrees that it is his
responsibility to read and carry out the
safety, maintenance and operation as per
this operator’s manual.
Customer Delivery (Please Tick)
Please Complete all Dealer information Below
Dealer Information
Dealer’s Name..............................................................................
Address........................................................................................
.......................................................................................................
State........................................... Postcode.................................
Phone.......................................... Fax..........................................
Email.............................................................................................
Service Person..............................................................................
I confirm that the pre-delivery service was performed on this machine.
Signature.......................................................................................
Date..............................................................................................
Comments.....................................................................................
.......................................................................................................
.......................................................................................................
Please Complete all Customer Information Below
Customer Information
Customer’s Name.........................................................................
Address........................................................................................
.......................................................................................................
State........................................... Postcode.................................
Phone.......................................... Fax..........................................
Email.............................................................................................
Delivery Person.............................................................................
I confirm that all of the delivery checks were explained and performed.
Signature.......................................................................................
Delivery Date................................................................................
Comments.....................................................................................
.......................................................................................................
.......................................................................................................
2. Customer Delivery Checklist
1. The customer or person responsible has
been given the operator’s manual.
4. All greasing and oil points, stickers,
guarding and ID plate have been identified
and physically pointed out.
3. All safety, operational and maintenance
information have been explained and
demonstrated.
5. The customer agrees that it is his
responsibility to read and carry out the
safety, maintenance and operation as per
this operator’s manual.
2. The customer undertakes to read the
co mpl ete ope rat or ’s m anu al a nd
understands all aspects of the manual
before operation of the machine.
SUB-SOILER (5-ARM)
TYNE MOUNTING ASSEMBLY PART DETAILS
SL NO. PART NAME PART NO. QTY.
1 TYNE MOUNTING BASE PLATE 75300004 2
2TYNE MOUNTING PLATE 75300005 2
3MOUNTING PLATE RIB 75300006 2
4HEX HEAD BOLT M20X170X2.5P 10260319 4
5SPRING WASHER 20MM 10270016 4
6 NYLOCK NUT M20X2.5P 10280021 4
7 HEX HEAD BOLT M16X85X2MM 10260383 1
8 SPRING WASHER 16MM 10270005 1
9 NYLOCK NUT M16X2MM 10280005 1
10 HEX HEAD BOLT M24X110X3P 10260417 1
11 SPRING WASHER 24MM 10270027 1
12 NYLOCK NUT M24X3P 10280075 1
TYNE ASSEMBLY PART DETAILS
SL NO. PART NAME PART NO. QTY.
1 SUBSOILER TYNE 75300007 1
2SUBSOILER SHOVEL 75200002 1
3SUBSOILER SHOE 75200003 1
4CSK BOLT M12X40X1.75MM 10260049 1
5NYLOCK NUT M12X1.75MM 10280025 2
6HEX HEAD BOLT M16X80X2MM 10260080 2
7CSK BOLT M12X50X1.75MM 10260050 1
8 NYLOCK NUT M16X2MM 10280005 2
COMPLETE 5ARM SUBSOILER PART DETAILS
SL NO. PART NAME PART NO QTY.
1 FRAME ASSEMBLY 76000003 1
2 TYNE MOUNTING ASSEMBLY 75300003 5
3 TYNE ASSEMBLY 75300008 5

15 16
WARRANTY CARD
Customer Copy
Customer`s Signature Dealer`s Signature
CUSTOMER NAME Mr./ Mrs :
ADDRESS :
MOBILE NO. :
Email :
NAME OF IMPLEMENT :
MODEL NO. :
YEAR OF Mfg. :
SERIAL NO. :
REGISTRATION NO. :
DATE OF PURCHASING :
NAME OF DEALER :
USA
960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA
FIELDKING USA, INC.
[email protected], www.fieldkingusa.com

17 18
WARRANTY CARD
Company Copy
Customer`s Signature Dealer`s Signature
CUSTOMER NAME Mr./ Mrs :
ADDRESS :
MOBILE NO. :
Email :
NAME OF IMPLEMENT :
MODEL NO. :
YEAR OF Mfg. :
SERIAL NO. :
REGISTRATION NO. :
DATE OF PURCHASING :
NAME OF DEALER :
USA
960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA
FIELDKING USA, INC.
[email protected], www.fieldkingusa.com

2019
WARRANTY CARD
Dealer Copy
Customer`s Signature Dealer`s Signature
CUSTOMER NAME Mr./ Mrs :
ADDRESS :
MOBILE NO. :
Email :
NAME OF IMPLEMENT :
MODEL NO. :
YEAR OF Mfg. :
SERIAL NO. :
REGISTRATION NO. :
DATE OF PURCHASING :
NAME OF DEALER :
USA
960 Holmdel Road Suite 2-02, Holmdel, NJ 07733, USA
FIELDKING USA, INC.
[email protected], www.fieldkingusa.com
