CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
9
Table of contents
9
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENTable of contents
Cordless Circular Saw
INSTRUCTION MANUAL
Thank you for your purchase of the Cordless circular saw. For your personal safety,
read and understand the Instruction Manual before using. Keep the Instruction Ma-
nual in a safe place for future reference.
TABLE OF CONTENTS
PICTURE ANNEX ................................................................................................................................ 3
GENERAL SAFETY REGULATIONS ........................................................................................... 10
Important safety notices
Packaging
Instructions for use
GENERAL SAFETY INSTRUCTIONS ........................................................................................... 11
SYMBOLS AND PICTOGRAMS ................................................................................................. 15
MACHINE DESCRIPTION AND PACKAGE CONTENT .................................................... 16
SAFETY INSTRUCTIONS ................................................................................................................. 17
USE AND OPERATION .................................................................................................................. 21
ADJUSTMENT AND OPERATION .............................................................................................. 21
CLEANING AND MAINTENANCE ........................................................................................... 23
CLEANING AND MAINTENANCE TIPS ................................................................................. 23
DECLARATION OF CONFORMITY ......................................................................................... 24
TECHNICAL DATA .......................................................................................................................... 25
LIQUIDATION .................................................................................................................................... 26
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.

EN
10
FDUK 50301
General safety instructions
FDK 2001-E
10EN General safety instructions
1. GENERAL SAFETY INSTRUCTIONS
WARNING! Carefully read the instruction manual before use.
Important safety warnings
Unpack the product carefully and be sure not to throw away any part of the package before
having found all components of the product.
Keep the product in a dry place out of reach of children.
Read all cautions and instructions. The failure to adhere to warning cautions and instructions
may result in an accident, fire and/or a serious injury.
Packaging
The product is placed in a package preventing damage during transport. This package is a raw
material therefore it can be handed-over for recycling.
Instructions for use
Before beginning to work with the machine, read the following safety rules and instructions for
use. Familiarize with operating elements and the proper use of the device. Keep the manual in a
safe place for future reference. We recommend keeping the original package including the inner
packaging materials, cash voucher and guarantee card for a period of warranty at minimum.
For a case of transportation, pack the machine into the original box from the manufacturer,
thus ensuring a maximum protection of the product during a possible transport (e.g. moving or
sending into a service station).
Note: If you hand the machine over to next persons, hand it over together with the manual.
Adherence to the attached instructions for use is a precondition for the proper use of the
machine. The operation manual includes also instructions for operation, maintenance and
repairs.
The manufacturer does not take any responsibility for accidents or damages
resulting from the failure to adhere to this manual.

EN
CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
11
General safety instructions
11
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENGeneral safety instructions
2. GENERAL SAFETY INSTRUCTIONS
Carefully read, remember and keep these safety instructions
WARNING! In the use of electric machines and power tools, it is necessary to respect
and follow the following safety instructions for the reasons of protection against electric
shock, personal injury and danger of fire. The term “power tool” in the instructions below
refers both to mains-operated (corded) power tool or battery-operated (cordless) power tool.
Save all warnings and instructions for future reference.
Workplace
Keep the work area clean and well lit. Cluttered or dark areas in the workplace invite
accidents. Store power tools that you don’t currently use.
Do not operate power tools in environments with danger of occurrence of a fire or explosion,
such as in the presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
Keep unauthorised persons, especially children, away from the work area while operating
a power tool! Distractions can cause you to lose control over the performed activity. In no
event leave your power tool unattended. Keep the equipment away from animals.
Electrical Safety
Power tool plugs must match the mains socket outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools. Undamaged plugs and
matching outlets will reduce risk of electric shock. Damaged or fouled supply cables increase
the risk of electric shock. If the power cord is damaged, it must be replaced by a new power
cord which is available at the authorised service centre or the importer.
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, cooking
ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
Do not expose power tools to rain or wet conditions. Never touch the power tool with wet
hands. Never wash the power tool under running water or immerse it in water.
Never use the supply cable for other than intended purposes. Never use the cord for carrying
or pulling the power tool. Never unplug the plug from the outlet by pulling the cable. Keep
electric cables away from sharp or hot objects to prevent mechanical damage.
The power tool was designed to be powered solely by alternating electric current. Always
check if the electric voltage matches the information specified in the type label of the power
tool.
Never use power tool with damaged electric cable or plug or which has been dropped or is in
any way damaged.

EN
12
FDUK 50301
General safety instructions
FDK 2001-E
12EN General safety instructions
If an extension cord is used, always check whether its technical parameters match the
information specified in the type label of the power tool. When operating a power tool
outdoors, use an extension cord suitable for outdoor use. If extension drums are used, these
must be rolled out to prevent overheating of the cord.
If a power tool is operated in a damp location or outdoors, its operation is only permitted if
connected to an electric circuit protected by a residual current device <30 mA. Use of residual
current device (RCD) reduces the risk of electric shock.
Hold the power tool by insulated gripping surfaces only as the cutting or drilling tool may
contact hidden wiring or its own power cord during operation.
Personal Safety
Be careful, stay alert and watch what you are doing when operating a power tool.
Concentrate on your work. Do not use a power tool while you are tired or under the influence
of drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury. Do not eat, drink and smoke while operating a power tool.
Use personal protective equipment. Always wear eye protection. Use protective equipment
corresponding to the type of work you are doing. Protective equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection used in accordance with the working
conditions will reduce the risk of personal injury.
Prevent unintentional starting. Do not carry the power tool while it is energised or with
your finger on the switch or trigger. Ensure the switch or trigger is in the “off” position before
connecting to power source. Carrying power tools with your finger on the switch or energising
power tools that have the switch on may result in serious injuries.
Remove any adjusting key or wrench before turning the power tool on. An adjusting wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
Keep proper footing and balance at all times. Do not overreach. Never overestimate your own
capabilities. Never use power tools while you are tired.
Dress properly. Wear work clothes. Do not wear loose clothing or jewellery. Keep your hair,
clothing, gloves and other part of your body away from moving or hot parts of the power tool.
Connect the equipment to dust exhaustion. If the tools are provided for the connection of dust
collection or exhaustion devices, ensure these are properly connected and used. Use of such
devices can reduce dust-related hazards.
Fix the work-piece tightly. Use a cabinet clamp or a cramp to fix the work-piece you are about
to machine.
Never use power tools if you are under the influence of alcohol, drugs, medication or other
narcotic or addictive substances.
This equipment is not intended for use by persons (including children) with limited physical,
sensual or mental capacities or lack of experience or knowledge unless they are supervised
or instructed about the use of the equipment by a person responsible for their safety. Children
must be supervised to make sure they are not playing with the equipment.

EN
CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
13
General safety instructions
13
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENGeneral safety instructions
Power Tool Use and Maintenance
Always disconnect the power tool from the mains in case of any problem during the work,
before cleaning the power tool or its maintenance, during each transportation and after the
completion of the work! Never operate a power tool if it is damaged in any way.
Immediately stop working if the power tool generates abnormal noise or smell.
Do not overload the power tool. The power tool will operate better and safer if it is used at the
rate for which it was designed. Use correct power tool which is intended for the given activity.
The correct power tool will do the job it was designed for better and safer.
Do not use the power tool if it cannot be safely turned on and off using the control switch.
Use of such power tool is dangerous. Defective switches must be repaired by a certified
service provider.
Disconnect the tool from the power source before making any adjustments, changing
accessories or maintenance. Such preventive safety measure prevents the risk of starting the
power tool accidentally.
Store idle power tools out of the reach of children and unauthorised persons. Power tools can
be dangerous in the hands of untrained users. Store the power tools in a dry and safe place.
Keep the power tool in good condition. Check the adjustment of moving parts and their
mobility. Check for any damage to the protective guards or other parts which could affect
safe operation of the power tool. If damaged, have the power tool properly repaired before
further use. Many accidents are caused by poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges facilitate work, reduce the risk of injury and are easier to control. Use of accessories
other than those specified in the instructions for use could result in damage to the power tool
and cause injuries.
Use the power tool, accessories and tool bits etc. in accordance with these instructions and
in the manner intended for the particular type of power tool taking into account the working
conditions and the work to be performed. Use of the power tool for purposes other than those
the power tool was intended for could result in hazardous situations.
Use of Cordless Power Tools
Before inserting the battery, make sure the switch is in the “0-OFF” position. Inserting a battery
into a switched-on power tool could result in hazardous situations.
Charge batteries only using the chargers prescribed by the manufacturer. Using a charger
intended for other battery type could result in its damage and occurrence of fire.
Use only batteries intended for particular power tool. Use of different batteries could cause
injury or occurrence of fire.
If the battery is not used, keep it separately from metal objects such as clamps, keys, bolts
and other small metal items which could cause connection of one battery contact with the
other. Short-circuiting the battery could result in injury, burns or occurrence of fire.

EN
14
FDUK 50301
General safety instructions
FDK 2001-E
14EN General safety instructions
Handle the batteries with care. Rough handling could result in leak of chemical substance
from the battery. Avoid contact with such substance and if, nonetheless, any contact occurs
wash the affected area under running water. If eyes get into contact with the chemical
substance seek immediately medical aid. Chemical substance from the battery can cause
serious injuries.
Service
Do not replace parts of the power tool, do not make any repairs or interfere in any way with
the construction of the power tool. Have your power tool repaired by qualified repair persons.
Any repair or modification of the product without our company’s authorisation is
impermissible (it could cause injury or damage to the user).
Always have your power tool repaired in a certified service centre. Use only original or
recommended replacement parts. This will ensure that your safety and the safety of your
power tool is maintained.

EN
CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
15
Symbols and pictograms
15
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENSymbols and pictograms
3. SYMBOLS AND PICTOGRAMS
Double insulation.
Before using the machine read
carefully instructions for use.
This product has been manufactured
in accordance with the approved
standards.
Use eye and hearing protection.
Power
Circular-saw blade diameter
Comfortable handle
Copper engine winding
FDV 2001-E, FDV 2002-E
8EN Symbols
2. SYMBOLS
Read the Instruction Manual
attentively prior to use.
The product complies with the
applicable
standards and regulations.
Use eyes protectiveequipment
Use earsprotectiove equipment

EN
16
FDUK 50301
Machine description and package content
FDK 2001-E
16EN Machine description and package content
4. MACHINE DESCRIPTION AND
PACKAGE CONTENT
Machine Description (see Fig. 1.2)
Switch
Handle
Guiding handle
Bevel adjustment knob
Parallel guide adjustment knob
Parallel guide
Circular-saw blade guide
Circular-saw base
Blade stud
Cutting depth adjustment knob
Safety switch
Carbon brush cover
Allen wrench
Flange wrench
2 replacement engine carbon brushes
Bevel angle measuring rod
1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -
10 -
11 -
12 -
13 -
14 -
15 -
16 -
Package Content
Remove the machine carefully from the packaging and check the completeness of the following
parts:
Circular saw
Parallel guide
1 circular-saw blade
Warranty certificate
Operating instructions
Allen wrench
Wrench
2 replacement engine carbon brushes
If some parts are missing or are damaged, please contact the vendor where you purchased the
machine.
FDK 2001-E
16EN Machine description and package content
4. MACHINE DESCRIPTION AND
PACKAGE CONTENT
Machine Description (see Fig. 1.2)
Switch
Handle
Guiding handle
Bevel adjustment knob
Parallel guide adjustment knob
Parallel guide
Circular-saw blade guide
Circular-saw base
Blade stud
Cutting depth adjustment knob
Safety switch
Carbon brush cover
Allen wrench
Flange wrench
2 replacement engine carbon brushes
Bevel angle measuring rod
1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
9 -
10 -
11 -
12 -
13 -
14 -
15 -
16 -
Package Content
Remove the machine carefully from the packaging and check the completeness of the following
parts:
Circular saw
Parallel guide
1 circular-saw blade
Warranty certificate
Operating instructions
Allen wrench
If some parts are missing or are damaged, please contact the vendor where you purchased the
machine.

EN
CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
17
Safety instructions
17
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENSafety instructions
5. SAFETY INSTRUCTIONS
Before use, please read these safety instructions and keep them in a safe place.
ATTENTION! This symbol indicates risk of injury or damage to the equipment.
ATTENTION! Upon failure to follow the instructions specified in this manual, there is a risk
of injury.
ATTENTION! Electric circular saw conforms to applicable technical regulations and
standards.
ATTENTION! Before putting the circular saw aside, make sure all moving parts have
stopped.
Special Safety Instructions for Operation of the Circular Saw
ATTENTION! Risk of Injury! Turn off the saw and unplug the plug from the outlet before
attempting to install or remove the circular-saw blade. This way you prevent the circular saw
from being accidentally started.
The root of the circular-saw blade should always be in tight contact with the cut material.
Keep your hands away from the circular-saw blade.
Never touch the bottom of the material during cutting.
Make sure the circular-saw blade is sharp, undamaged and correctly adjusted. Otherwise, the
cutting edge could break and cause damage to the circular saw or operator’s injury.
Do not touch the circular-saw blade immediately after cutting. It could be hot.
Remove the adjustment key from the saw before starting the work.
Some machined materials may contain preservative substances which could be toxic. Avoid
inhaling saw-dust while machining such materials.
When cutting thin materials, make sure that the cut-off parts do not get into the retractable
guard of the saw.
ATTENTION! Wear dust mask and protective goggles while performing dusty work. Wear
protective goggles conforming to DIN 58214 standard. If the circular saw is used without eye
protection, foreign particles could get lodged in your eyes (such as cuttings or matchwood).
This could permanently damage your eyesight. Using protective goggles that do not conform
to DIN standard could result in serious injury for the reasons of possible shattering of the
protective glass.
ATTENTION! Choose appropriate circular-saw blade for the work you intend to do. Use this
circular saw only for cutting wood, wooden materials and soft metals such as aluminium.
Other materials could tear, rip or spring up, get hitched on the circular-saw blade or cause
other danger.

EN
18
FDUK 50301
Safety instructions
FDK 2001-E
18EN Safety instructions
ATTENTION! Do not use grinding discs
- The arrow on the circular-saw blade indicating the running direction must indicate the same
direction as the arrow on the circular-saw guard. The teeth of the circular-saw blade must
match the running direction of the saw (downwards and forward).
- Keep the circular-saw blade and the clamping surface of the flange clean. The flange of the
circular-saw blade must always fit inwards into the rotating dropping guard (towards the
circular-saw blade).
- Make sure that all clamping devices and locking devices have been tightened and that no
parts shows excessive idle travel.
ATTENTION! Never cut objects while holding them in your hand.
ATTENTION! Make sure that the already cut-off parts cannot get into contact with the
circular-saw blade as they may be caught by the circular-saw blade and sprung up.
ATTENTION! Never cut more than one piece of material at the same time.
ATTENTION! Be especially careful when cutting large, very small or irregular pieces.
ATTENTION! No nails or other foreign objects may be present in the part of the machined
piece to be cut.
ATTENTION! No persons are allowed to stay near or behind the circular saw where saw
dust and cuttings are thrown away.
ATTENTION! Do not use the circular saw for cutting fire wood.
ATTENTION! Do not attempt to stop the circular-saw blade from rotating by exerting
pressure to its lateral face.
ATTENTION! Do not use circular-saw blades which do not conform, in terms of dimensions
and shape, to the requirements of this tool. Before cutting, fix the work-piece firmly e.g. using
clamps (they are not part of the supply).
ATTENTION! Keep your hands away from the cutting area and from the circular-saw blade.
Use your other hand to hold the auxiliary handle or the engine cover. If you hold the circular
saw with your both hands, they cannot be cut by the circular-saw blade.
ATTENTION! Adjust the cutting depth to at least the thickness of the processed material.
ATTENTION! If you carry out work during which the tool could get into contact with hidden
electric wiring or its own cord, hold the power tool by insulated gripping surfaces intended for
holding.
ATTENTION! Maintain a firm grip with both hands on the saw and position your arms to
resist kickback forces. Position your body to either side of the circular-saw blade but not in line
with the circular-saw blade.

EN
CORDLESS CIRCULAR SAW OPERATING INSTRUCTIONS
19
Safety instructions
19
OPERATING INSTRUCTIONSELECTRICAL CIRCULAR SAW
ENSafety instructions
ATTENTION! During longitudinal cutting, always use the longitudinal guide scale or straight
guide rail.
ATTENTION! Never use damaged or incorrect washers or clamping bolts.
ATTENTION! If the circular-saw blade is pinched or when interrupting a cut for other
reason, release the trigger and hold the saw motionless in the material until the blade comes
to a complete stop.
ATTENTION! Never attempt to remove the saw from the work or pull the saw backward
while the blade is in motion. A kickback may occur.
ATTENTION! When restarting the saw in a work-piece, centre the saw blade in the kerf and
check that saw teeth are not engaged into the material.
ATTENTION! Support large panels to minimize the risk of blade pinching or kickback.
ATTENTION! Do not use dull or otherwise damaged blades.
ATTENTION! Blade depth and bevel adjusting locking levers must be tight and secure
before making a cut.
ATTENTION! Use extra caution especially when making a “plunge cut”, e.g. cut into existing
walls or blind areas.
ATTENTION! Never operate the saw without the blade guard attached.
Lower guard
ATTENTION! Check lower guard for proper closing before each use.
ATTENTION! Do not operate the saw if the lower guard does not move freely and close
instantly! Never clamp or tie the lower guard into the open position.
ATTENTION! Check the operation of the lower guard spring. If the guard and the spring are
not operating properly, they must be repaired before use.
ATTENTION! Lower guard should be retracted manually only for special cuts such as
“plunge cuts” or “compound cuts”. Raise the lower guard by the lower guard lift lever and as
soon as the blade enters the material, the lower guard must be released.
ATTENTION! Always observe that the lower guard is covering the blade before placing saw
down on the bench or floor.
Riving knife
ATTENTION! Use appropriate riving knife for the circular-saw blade used.
ATTENTION! Adjust the riving knife as indicated in the instructions for use.

EN
20
FDUK 50301
Safety instructions
FDK 2001-E
20EN Safety instructions
ATTENTION! Except for plunge cuts, always use the riving knife.
ATTENTION! In order for the riving knife to work, it must fit into the cut-out in the processed
piece.
ATTENTION! Do not operate the saw if the riving knife is bent.
ATTENTION! Make sure that the riving knife is so adjusted that the distance between the
riving knife and the blade rim is not greater than 5 mm and the blade rim does not reach out
behind the lower edge of the riving knife by more than 5 mm.
ATTENTION! When replacing the circular-saw blade, make sure that the cut width is not
smaller than the depth of the riving knife.
Avoid the kickback of the saw.
ATTENTION! Kickback occurs when a force is exerted against the saw blade causing a
quick and unexpected lift up of the wood. Kickback is very dangerous but can be minimised if
you identify its causes and avoid them.
The root of the circular-saw blade should always be in tight contact with the cut material
Always hold the saw with your both hands. Support the cut parts by large panels.
Be careful when cutting long parts which can be bent, twisted or pinch the circular-saw blade.
Never cut in the centre of the supported piece of wood. The wood could bend over and pinch
the circular-saw blade.
Never cut overhead.
Do not exert pressure upon the saw. Let the circular-saw blade work at its own rate.
Secure the flange using clamps or cramp to avoid vibrations and irregular cuts.
Do not let the blade leave the cutting line as it could cause the saw jump out of the kerf.
Before cutting, check the wood and remove all bolts, clamps and nails.
Replace the circular-saw blade if it is dull.
Only use circular-saw blades according to EN 847-1 and never use circular-saw blades made
of high speed steel - HSS.
ATTENTION! Wear hearing protection to reduce the risk of impaired hearing! Use protection
against dangerous dust inhaling.
ATTENTION! Wear gloves when working with circular-saw blades and roughly machined
materials - circular-saw blades should be carried in holders, if possible.
ATTENTION! Use means of protection against noise, dust and vibrations !!!
ATTENTION! Keep these safety instructions.
