Fieldmann FZR 3004-B User manual

FZR 3004-B/FZR 3007 BS
FZR 3003-B navodA5_14.indd 1 10.1.12 11:36

brazová příloha
3
4
1
FZR 3003-B navodA5_14.indd 2 10.1.12 11:36
FZR 3004-B/FZR 3007 BS

brazová příloha
5 6
7
8
10 11
9
FZR 3003-B navodA5_14.indd 3 10.1.12 11:36

N
ELF-PROPELLED LAWN MOWER U ER‘ MANUA
nstruction manual 5
SELF-PROPELLED LAWN MOWER
USER‘S MANUAL
Thank you for purchasing this self-propelled garden lawnmower. Before you start using it,
please, carefully read this user‘s manual and save it for possible future use.
CONTENTS
ILLUSTRATED ATTACHMENT .......................................................................................................................... 2–3
1. GENERAL SAFETY INSTRUCTIONS .................................................................................................................. 6
2. EXPLANATION OF INSTRUCTION LABELS ON THE MACHINE ............................................................ 7
3. MACHINE DESCRIPTION AND INCLUDED CONTENTS ......................................................................... 8
4. LAWNMOWER ASSEMBLY ................................................................................................................................. 9
5. PUTTING INTO OPERATION ............................................................................................................................... 9
6. OPERATING INSTRUCTIONS .......................................................................................................................... 12
7. MAINTENANCE AND STORAGE ................................................................................................................... 15
8. TECHNICAL SPECIFICATIONS ........................................................................................................................ 17
9. WHAT TO DO „WHEN...“ ................................................................................................................................... 18
10. DISPOSAL .............................................................................................................................................................. 18
FZR 3003-B navodA5_14.indd 5 10.1.12 11:36

N 6eneral safety instructions
1. GENERAL SAFETY INSTRUCTIONS
Important safety notices
Carefully unpack the product and take care not to throw away any part of the packaging before you find all
the parts of the product.
Store the lawnmower in a dry place out of reach of children.
Read all warnings and instructions. Not following warnings or instructions may lead to injury by electrical
shock, a fire and/or serious injuries.
Packaging
The product is packed in a package that prevents damage during transport. This package is a resource and so
can be handed over for recycling.
User‘s manual
Before you start working with the electric garden lawnmower, read the following safety and usage instructions.
Understand the operating elements and the correct use of the device. Keep the user‘s manual in a safe place
where it can be easily retrieved for future use.
Save the original packaging, including the internal packing material, warranty card and proof of purchase
receipt, at least for the duration of the warranty. If you need to ship this machine, pack it in the original cardboard
box to ensure maximum protection during shipping or transport (e.g. when moving or when you need to send
this product for repair).
Note: If you hand over the machine to somebody else, do so together with the user‘s manual. Following the
instructions in the included user‘s manual is a prerequisite for the proper use of the lawnmower. The user‘s
manual also contains operating, maintenance and repair instructions.
The manufacturer takes no responsibility for accidents or damages resulting from not
following the instructions in this manual.
FZR 3003-B navodA5_14.indd 6 10.1.12 11:36
FZR 3004-B/FZR 3007 BS

N
xplanation of instruction labels onthe machine 7
2. EXPLANATION OF INSTRUCTION LABELS
ON THE MACHINE
General danger warnings.
Attention, rotating blades!
Before putting into operation, carefully read the user‘s manual.
Sharp blade/s. Protect yourself against injury and loss of fingers.
Attention, rotating blades!
Watch out for objects de ected by the rotating blade!
Keep other people away from the work area.
Remove spark plug lead before maintenance.
Make sure that people standing nearby are not injured by de ected foreign objects.
Clear the mowing area. Keep children and others a safe distance from the machine.
Driving and stopping the lawnmower.
ELF-PROPELLED LAWN MOWER U ER‘ MANUA
FZR 3003-B navodA5_14.indd 7 10.1.12 11:36

N 8Machine description and included contents
3. MACHINE DESCRIPTION
AND INCLUDED CONTENTS
MACHINE DESCRIPTION (see pic. 1)
1 Handle 7 Height adjust handle
2 Brake lever 8 Air filter
3 Driver lever 9 Side discharge board
4 Startér 10 Side discharge switch
5 Quick fix handle 11 Spark plug
6 Grass catcher
mWARNING: Sharp blades.
Supplied contents
Carefully take out the lawnmower from the packaging and check whether all the following parts are present:
Self-propelled lawnmower 1 piece
Grass catcher 1 piece
Bearing 4 pieces
Wheels 2 pieces
Wheel center 2 pieces
Nuts 2 pieces
Washer 2 pieces
User’s manual
If there are parts missing or they are damaged, please contact the retailer from whom you bought the machine.
FZR 3003-B navodA5_14.indd 8 10.1.12 11:36
FZR 3004-B/FZR 3007 BS

N
awnmower assembly | Putting into operation 9
4. LAWNMOWER ASSEMBLY
The lawnmower is supplied disassembled. The complete adjustable handle and collection box must be assem-
bled before starting work. Proceed step by step according to the user‘s manual and use the pictures as a guide
so that the assembly process is as easy as possible.
mATTENTION: Do not use any additional equipment, which was not recommended by the manufacturer.
SET UP YOUR LAWNMOWER (see pic. 2)
mIMPORTANT: Unfold handle carefully so as not to pinch or damage control cables.
1. Raise handles until lower handle section locks into place in mowing position.
2. Remove protective padding, raise upper handle section into place on lower handle and tighten both han-
dle knobs.
3. Remove handle padding holding operator presence control bar to upper handle.
WHEEL ASSEMBLY (see pic. 3)
Assemble the wheels on the mower as in the pictures.
Make sure that the star nut strong enough.
Instruction for plastic catcher assembly (see pic. 4)
1. Take plastic catcher out of the package.
2. Take the small cover part from packing bag.
3. Press the cover part into catcher as picture shown
4. Fix the plastic jacket in the metal bracket.
5. PUTTING INTO OPERATION
Your new lawn mower has been assembled and tested at the factory.
mATTENTION: This lawn mower is shipped WITHOUT OIL OR GASOLINE in the engine.
OPERATION
Brake lever –must be held down to the handle to start the engine. Release to stop the engine.
Starter handle - used for starting engine.
Drive control lever (self-propelled lawnmower)- used to engage power-propelled forward motion of lawn mower.
Range of application
Cutting the grass (see pic. 5)
Cutting up and depositing the grass on the lawn
Cutting up and collected in the grass catcher
Cutting up and ejecting backwards
Cutting up and ejecting sidewards.
ELF-PROPELLED LAWN MOWER U ER‘ MANUA
FZR 3003-B navodA5_14.indd 9 10.1.12 11:36

N 10 utting into operation
Mulching
Installation and removal of the accessories must always be take place with switched off engine.
Please make sure the stability of the attached mulching accessories after installing.
For mulching plate, you only allowed use the accessories from original factory
Always avoid to clear away an excessive quantity grass so that the mower mechanism and the engine are
overloaded.
Reducing the speed of self-propelled will help you to pass excessive grass.
Assembly of accessories
Put the baffle plate and raises, aim at the round hole underside, fax up the auto locking hook engage.
Disassembly of accessories
Press the tightly by thumb in the center, then loose and deflect direction take down the mulching plate.
Hang up the grass catcher
Raise the baffle plate and hang up the grass catcher in the illustration shown.
DRIVE CONTROL (see pic. 2)
Self-propelling is controlled by holding the operator presence control bar down to the handle and pushing the
drive control lever forward until it clicks; then releasing the lever.
Forward motion will stop when the operator presence control bar is released. To stop forward motion without
stopping engine, release the operator presence control bar slightly until the drive control disengages. Hold
operator presence control bar down against handle to continue mowing without self-propelling.
ADJUST CUTTING HEIGHT
Raise wheels for low cut and lower wheels for deepcut, adjust cutting height to suit your requirements. Medium
position is best for most lawns.
BEFORE STARTING ENGINE ADD OIL
Your lawnmower is shipped without oil in the engine.
Beforeeachsubsequentusethe oillevelmustbecheck and ifnecessarytoppedupwith500mlSAE30
For type and grade of oil to use, see „ENGINE“ in the Maintenance section of this manual.
mATTENTION: Do not overfill engine with oil, or it will smoke heavily from the muffler on startup.
1. Be sure lawnmower is level.
2. Remove oil dipstick from oil fill spout.
3. Insert and tighten dipstick.
4. Check oil level before each use. Add oil if needed.
5. Fill to full line on dipstick.
6. Change the oil after every 25 hours of operation or each season.
7. You may need to change the oil more often under dusty, dirty conditions. See „TO CHANGE ENGINE OIL“ in the
Maintenance section of this manual.
Note: Check oil level before each use.
FZR 3003-B navodA5_14.indd 10 10.1.12 11:36
FZR 3004-B/FZR 3007 BS
(15W-40) engine oil

N
utting into operation 11
ADD GASOLINE (see pic. 7)
Fill fuel tank to bottom of tank filler neck.
Do not overfill.
Use fresh, clean, regular unleaded gasoline.
Do not mix oil with gasoline.
Recommendation: Purchase fuel in quantities that can be used within 30 days to assure fuel fresh.
mATTENTION: Wipe off any spilled oil or fuel. Do not store, spill or use gasoline near an open flame.
Note: Alcohol blended fuels (called gasohol or using ethanol or methane can attract moisture which leads
to separation and for motion of acids during storage. Acidic gas can damage the fuel system of an engine
while in storage.
To avoid engine problems, the fuel system should be emptied before storage of 30 days or longer.
Empty the gas tank, start the engine and let it run until the fuel lines and carburetor are empty.
Use fresh fuel next season.
See Storage Instructions for additional information.
Never use engine or carburetor cleaner products in the fuel tank or permanent damage may occur.
START ENGINE
mATTENTION: Press or release the start switch carefully according to the manufacturer‘s instructions. Make
sure that feet are at a sufficient distance from the cutting mechanism.
To start the engine, first make sure that the spark plug and that the machine is filled with sufficient oil and petrol.
Note: Due to protective coatings on the engine, a small amount of smoke may be present during the initial
use of the product and should be considered normal.
Hold operator presence control bar down to the handle and pull starter handle quickly. Do not allow starter rope
to snap back.
Note: In cooler weather it may be necessary to repeat priming steps.
STOP ENGINE
To stop engine, release operator presence control bar.
mATTENTION: The blade will continue to rotate for a few seconds after the engine has stopped. Disconnect
the spark plug cap if the lawnmower is to be left unattended.
Under certain conditions, such as very tall grass, it may be necessary to raise the height of cut to reduce push-
ing effort and to keep from overloading the engine and leaving clumps of grass clippings. It may also be nec-
essary to reduce ground speed and/or run the lawnmower over the area a second time.
For extremely heavy cutting, reduce the width of cut by overlap ping previously cut path and mow slowly.
ELF-PROPELLED LAWN MOWER U ER‘ MANUA
