Fieryred 93S-FS7S-UFA2 User manual

Thanks for purchasing Fieryred products for your vehicle! This LED light bar is the perfect
choice to compliment your vehicle and increase visibility against heavy fog or extremely dark
conditions. Fieryred's LED lights are constructed with fine materials and tested to meet our
strict criteria to ensure reliable performance. Strict quality control also comes as a testament
to their quality assurance. Before installation, it is highly recommended to read through these
instructions. Failure to follow these instructions may cause damage to your vehicle, serious
injury or even death to you and others.
SAFETY PRECAUTION:
1. Always disconnect any power sources connected to your vehicle before servicing fuses or
electrical systems.
2. Never use a caustic or petroleum based cleaner on any surface of the light bar.
3. Disconnect ground connection from battery (-) to avoid accidental short circuits before
attempting to connect electrical wires.
4. When running wires, avoid areas of excessive heat, vibration, pinch or rotation when securing
harness to vehicle. Also, avoid running the wire through the door over the door seal. Doing that will
create water leak inside your vehicle.
PACKAGE LIST:
2X
4X
2X 2X
4X
2X
2X
2X
For more warranty information, visit https://fieryred.com/pages/warranty-policy
2X
4X

Troubleshooting:
There can be a few different causes as to why your light has stopped working properly. At no stage in troubleshooting your
light do we recommend or encourage disassembling your light as this will void any warranty on the item/items.
If the light has stopped working altogether
1. Establish that the light is not defective by connecting it directly to a 12VDC power source. Unplug the light from the
harness and connect to the vehicles battery or power supply with similar voltage. If the light has light up as it should the
problem will be in the wiring, proceed to the next step;
2. Make sure that the switch is still receiving power (will illuminate once switched to the on position).
3. Check for any loose connections through the harness making sure nothing has loosened over time.
4. Check the ground is still secure and properly mounted
LIKELY CAUSES LEADING TO LOW INPUT SUPPLY POWER
Poor Ground:
A bad ground is generally the number 1 cause of a partially illuminated light. The best way to check whether the ground is at
fault is to move it from chassis ground to the negative terminal of the battery. Keep in mind poor ground cannot be identified
by checking voltage at the connector, as it is possible to have 14v+ at the light connection yet still have bad ground which
ultimately leads to poor input power.
Check the voltage of your vehicle's battery:
Generally, this can occur due to low voltage. Going below what the light requires will either dim the brightness of the light or
you will see an alternating pattern with the LEDs. This can sometimes be solved by charging or replacing the battery. Double-
check all wiring has been connected properly to ensure there are no weak points along the line.
Warranty:
Fieryred warrants that each of its LED light bar that is purchased while this Warranty is in effect will be free from defects in
materials and workmanship for a period of 1 year from the date of receiving the product from Fieryred or its authorized
distributor/dealer. If a product fails to operate during the 1-year Warranty Period as a result of defects in materials or
workmanship, Fieryred will, at its option, repair it, replace it with the same or similar product, or will issue a refund. Fieryred
will pay for the cost of shipping or transportation of a defective component to us.
Any and all warranty coverage does not cover replacement of parts and components damaged by abuse, neglect, improper or
unreasonable use, crash damage, water or excessive moisture, chemical damage, improper or infrequent maintenance,
accident, unauthorized alteration or modification or items that are considered consumable.
For more warranty information, visit https://fieryred.com/pages/warranty-policy
INSTALLATION:
Step 1:
Insert the screw onto the bracket
Step 2:
Tighten washer and nut with screw
Step 3:
Place the bracket to fit the built-i
nuts
Step 4:
Tighten washer and nut with
Hex Key
Step 5:
Finished
