Fillauer Hosmer 12P User manual

Hosmer
12P & 10P
Hooks
Product Manual

2
Contents
Intended Use................................................................3
Warnings and Precautions ....................................................3
Qualied Provider ...........................................................4
Specications and Preparations BeforeUse
(Risk Management for Installation andCalibration) ...............................4
Compatibility ................................................................5
Disposal/ Waste Handling ....................................................5
Warranty ...................................................................5
User Instructions ............................................................6
Serious Incidents ............................................................6
To see other language options, visit llauer.com.

3
Intended Use
The Models 10P and 12P are pediatric prosthetic terminal devices commonly referred
to as “canted split hooks” and are used to provide for both ne prehension and
gross grasping of objects when controlled through a cable that is operated with body
motions. They are aluminum and have a plastisol-coated surface to provide protection
for the user and other children. These hooks are a voluntary-opening device and
grasping tension is adjusted by the adding of tension bands, rings, or springs (see
catalog for additional information). See llauer.com for information on other sizes of
canted hooks.
Performance Characteristics
Model 12P Model 10P
Size Pediatric Pediatric
Length 2.75 in. (70cm) 3.4 in. (86cm)
Weight 3 oz. (85g) 3 oz. (85g)
Material Aluminum Aluminum
Grip Plastisol Coating Plastisol Coating
Attachment ½-20 Thread ½-20 Thread
These devices are intended for single patient use only.
Storage and Handling
It is recommended that prosthetic hooks (or prosthetic/orthotic components) be
stored in a cool, clean, dry environment away from harsh chemicals (chlorine, acids,
acetone, etc.).
Warnings and Precautions
CAUTION: Aluminum prosthetic hooks are not intended to support partial
or full body weight. For heavy duty applications, steel or titanium hooks
are recommended.
NOTICE: An upper-limb prosthetic device user’s ability to drive should
be determined on a case-by-case basis by a specialist. Contact your local
governing authorities regarding any driving restrictions or limitations.

4
WARNING: Body-powered devices should not rely on cable tension for
grasp control if the user has been cleared to drive with the prosthesis.
Failure to maintain tension while controlling the steering wheel could
cause serious injury or death.
CAUTION: Abnormal or improper environmental conditions will lead
to malfunctioning and damage of the prosthesis and are not covered
under the warranty of the device. This prosthetic component must not
be subjected to dust/debris, liquids other than fresh water, abrasives,
vibration, activities which would damage the biological limb, or prolonged
extreme temperatures (<-5°C or >50°C). Do not allow debris or liquids to
remain in the prosthesis and its components during use. Rinse the device
with fresh water and dry immediately after exposure.
CAUTION: The hook is waterproof to 1 meter. However, if the hook is
submerged, it should be rinsed with fresh water and dried immediately to
remove salt, chlorine, or debris.
Qualied Provider
Attachment, adjustment, alignment, and delivery of this device must be performed by
or under the direct supervision of a qualied prosthetist. Unless stated in this manual,
any such activities should not be attempted by the user and will potentially void the
device warranty.
Specications and Preparations BeforeUse
(Risk Management for Installation
andCalibration)
Installation
The hook may be installed in any Fillauer wrist unit with a ½-20 thread. Follow the
instructions provided with the wrist unit for best results.
Cabling
The hook “thumb” has been designed with a receiver for a ⁹⁄³² inch ball terminal. A
triple swivel with ⁹⁄³² inch ball terminal should be selected with a cable connection that
matches the cable used in the prosthesis. Cable routing should ensure a direct line of

5
pull that minimizes bends in the cable, otherwise excess cable friction or failure could
result.
Adding Tension to Hook Grasp
To add more force to the grasp of the hook, additional tension bands may be applied
using the E-Z Hook Tension Band Applier (55144) or similar device. Additional bands
are included with the hook and are available in beige (53869) or black (53869-BLK) for
the number 10 Hooks or beige (55674) for the number 12 Hook. For greater tension,
hook rings (57500) or stainless-steel tension springs (55363) may be used. Tension
springs are recommended for situations where chemical or heat exposure could cause
band or ring failure.
Compatibility
Fillauer hooks have been tested with and are recommended for use with Fillauer
wrists that have a ½-20 internal thread. They may be used with any equivalent ½-20
threaded wrist units. However, damage caused by other manufacturers wrist units is
not covered under warranty of this device.
Only Fillauer tension bands, hook rings, and tension springs may be used with Fillauer
hooks to adjust the grasping force of the hook.
Disposal/ Waste Handling
The product must be disposed of in accordance with applicable local laws and
regulations. If the product has been exposed to bacteria or other infectious agents,
it must be disposed of in accordance with applicable laws and regulations for the
handling of contaminated material.
All metal components may be removed and recycled at the appropriate recycling
facility.
Warranty
This product has an 18-month warranty against manufacturer defects.

6
User Instructions
The providing health care professional must review the following information directly
with the user.
Care and Maintenance
CAUTION: Aluminum prosthetic hooks are not intended to support partial
or full body weight. For heavy duty applications, steel or titanium hooks
are recommended.
NOTICE: An upper-limb prosthetic device user’s ability to drive should
be determined on a case-by-case basis by a specialist. Contact your local
governing authorities regarding any driving restrictions or limitations.
WARNING: Body-powered devices should not rely on cable tension for
grasp control if the user has been cleared to drive with the prosthesis.
Failure to maintain tension while controlling the steering wheel could
cause serious injury or death.
CAUTION: Abnormal or improper environmental conditions will lead
to malfunctioning and damage of the prosthesis and are not covered
under the warranty of the device. This prosthetic component must not
be subjected to dust/debris, liquids other than fresh water, abrasives,
vibration, activities which would damage the biological limb, or prolonged
extreme temperatures (<-5°C or >50°C). Do not allow debris or liquids to
remain in the prosthesis and its components during use. Rinse the device
with fresh water and dry immediately after exposure.
CAUTION: The hook is waterproof to 1 meter. However, if the hook is
submerged, it should be rinsed with fresh water and dried immediately to
remove salt, chlorine, or debris.
Serious Incidents
In the unlikely event of a serious incident, seek immediate medical help and contact
your prosthetist at your earliest possible convenience. Clinicians should contact their
local Fillauer representative immediately in the event of any device failure.

www.llauer.com
Fillauer LLC
2710 Amnicola Highway
Chattanooga, TN 37406
423.624.0946
Fillauer Europe
Kung Hans väg 2
192 68 Sollentuna, Sweden
[phone]
EC REP
© 2021 Fillauer LLC
M087/10-06-21/Rev.1
