Firefly GT200 User manual

1 UserManualforFireflyMicroscopeGT200 Version:1.0
DIGITAL MICROSCOPE
THANKS FOR SELECTING A FIREFLY MICROSCOPE
To take full advantage of this product’s advanced capabilities,
and to properly and safely use this product, please read the manual carefully.
GT200
User Manual

2 UserManualforFireflyMicroscopeGT200 Version:1.0
Copyright 2011 by Firefly Global.
All rights are reserved. No one is permitted to reproduce
or duplicate, in any form, this manual or any part thereof with out permission from Firefly
Global (www.fireflyglobal.com).
Firefly
Global assumes no responsibility for any injury, or for any illega l or impr oper use of
the
product, that may result from failure to use this product in accordance with the
instructions, cautions, warnings, or ind i cati ons for use published i n this manual.
Software in this product is copyright of Firefly Global and its vendors. All rights are reserved.
The software is protected by U.S. and international copyright l a ws and international treaty
provisions applicable worldwide. Under such laws, the licensee is entitled to use the copy
of the
software incorporated w i t h this instrument as intended in the operation of the
product in which it is embe dded . The software may not be cop i ed , decompiled,
reverse-engineered, d
i sass e m ble d or otherwise reduced to human-perceivable form.
This
i s not a sale of the software or any copy of the software; all rights, title, and
ownership of the software remain with Firefly and/or its v e n dors.
Caution:
Changes or mod i fication s not expressly approved by Firefly Global will void the
pu rc haser ’ s autho r i t y to operate the e qui pment and its warranty.

3 UserManualforFireflyMicroscopeGT200 Version:1.0
TABLE OF CONTENTS
Table of Contents.......................................................................................................3
Introduction ..............................................................................................................4
Warnings & Cautions.................................................................................................5
Warning .................................................................................................................................... 5
Caution......................................................................................................................................5
Check List ..................................................................................................................7
Nomenclature............................................................................................................8
Operation...................................................................................................................8
Operation...................................................................................................................9
Setting up the software application：..........................................................................................9
Connect to PC：.........................................................................................................................9
Power the Device On：..............................................................................................................9
recommended holding position: ................................................................................................ 10
low ratio 10-100x:.................................................................................................................... 10
high ratio >100x:..................................................................................................................... 11
Focus：................................................................................................................................... 11
Brightness Adjustment: ............................................................................................................ 12
Using Focus:............................................................................................................................ 12
Using the image capture control: .............................................................................................. 12
Standby and Remove device:.................................................................................................... 13
Launch the Software Application:.............................................................................................. 14
Viewing the Images: ................................................................................................................ 14
Video and Image Settings......................................................................................................... 14
Maintenance and service.........................................................................................16
Cleaning recommendation......................................................................................................... 16
Recycling the system components ............................................................................................. 16
Service policy........................................................................................................................... 17
Specifications ..........................................................................................................18
Limited Warranty ...................................................................................................19
Troubleshooting.......................................................................................................21
Frequently Asked Questions (FAQs): ......................................................................................... 21

4 UserManualforFireflyMicroscopeGT200 Version:1.0
INTRODUCTION
The Firefly Microscope System consists of a digital Microscope and software application. Only a computer
equipped with a free USB port is needed to use the system.
The Firefly Microscope System is designed for effective operation under a variety of conditions and typical
video parameters are set at the factory. The software allows users to adjust most parameters including
Saturation, Hue, Brightness, Contrast and Sharpness for desired applications.
System Requirements
The Firefly Microscope System requires a user PC system running Windows XP Service Pack 2 or later
operating system, a viewing screen, and a PC with an available USB 1.1 or 2.0 port.
Intended use
The Firefly Microscope System is intended to conveniently enable mobile inspection of objects.
User Profile
The Firefly Microscope System is intended for applications such as:
Art / Watches / Jewelry inspection and repairs
Electronic components inspection and repairs
Coin examination for collectors
Schools and Science Education
Medical examinations
Insect dissection and examination
Plant anatomy inspection
Skin test
Textile inspection
Industrial inspection
Print Check

5 UserManualforFireflyMicroscopeGT200 Version:1.0
WARNINGS &CAUTIONS
Please familiarize all operating personnel with the general saf et y
information in this summary. Specific warnings and cautions a r e also found
throughout this manual.
Warning
A warning statement in this manual iden tif i es a condition or pr act i ce which if
not
corrected or discontinued immediately , could lead to injury, illness, or
death.
Do not use in the presence
of f l amma ble anesthetics.
This
product has no user se rv iceable / replaceable parts. Please refer all
service to authorized service personnel.
This
instrument is not intended to be used in the eye.
This
product generates and r e cor d s reference images from inputs
obtained
from the software application FireflyPro . These reference images
are not intended for medical or other diagnostic purposes.
Caution
A caution
statement in this manual identifies condition or practice, which if not
corrected or discontinued immediate l y , could lead to equipment failure,
e
quipment damage, or data loss.

In order to obtain optimum performance and ensure patient safety,
thoroughly read this manual .
Do not use the Firefly Microscope if
y ou notice any signs of damage to the
components of th e system. Contact customer service f o r immediate
assistance
.
Do not attempt to
disinfect the Firefly Microscope System using
glutaraldehyde pro du c t s , ethylene oxide gas, steam or any other liquid or
gas disinfectant.
The signal
output (USB P o r t ) connector is intended for con nect i on of only
devices complying wit h IEC 60601 - 1, or other IEC standards (for
example, IEC 60950), as app r opriate to the device. Conn ecting additional
devices to the Firefly Microscope System is not allowed. You are

6 UserManualforFireflyMicroscopeGT200 Version:1.0
responsible for verifying that the system complies with th e requirements of
the
system standard IEC 60601 - 1 - 1.
This
product complies w i th current re qu ire d standards for
electromagnetic interference and should not present p r oblems to other
equipment or be affected by other devices. As a precaution, avoid using
th is device in close proximity to other e quip ment.
Do not apply alcohol, c h e m icals, or water to the lens. Any liquids entering the
optical
assembly will damage internal comp onents.

7 UserManualforFireflyMicroscopeGT200 Version:1.0
CHECK LIST
Before starting, check that all the following items have been included with your product. If anything is
missing, contact your dealer.
Microscope x 1pc Tripod x 1 pc Tripod Adapter x 1 pc
Stand Holder x 1 pc Clip x 1pc
Software Application CD

8 UserManualforFireflyMicroscopeGT200 Version:1.0
NOMENCLATURE

9 UserManualforFireflyMicroscopeGT200 Version:1.0
OPERATION
To obtain a clear image, please grip the Firefly Microscope; remain still and avoid vibration as much as
possible during observation.
Setting up the software application：
Prior to using the Firefly Microscope for the f i rst t i me, install t he FireflyPro software application following
the
instructions pro v ided with the installation CD .
Connect to PC：
Connect the Firefly Microscope to the PC’s USB port
Power the Device On：
Setting the switch to "ON/LED" will activate the device, and the red indicator will turn on.
*** The first time you open the device, Windows operating system will
automatically install the appropriate device driver, while the
system is installing the drivers, DO NOT TURN OFF THE DEVICE - that is do
not to move switch to the OFF position or pull out the USB connector
Please wait about 2 minutes to complete the driver installation)

… Please wait for about 2 minutes …

… Windows driver installation completed …

10 UserManualforFireflyMicroscopeGT200 Version:1.0
Using the Firefly Microscope System:
recommended holding position:
It is suggested to hold the microscope, transparent cover forward, with the thumb held on
the equipment. This holding position offers relative stability and allows lens control. The index finger is
still free to rotate and adjust the focus wheel (as shown).
low ratio 10-100x:
The digital microscope is placed in the "Base". The open viewing
area at the bottom of the base allows placement of samples under
the microscope for observation.
View Area

11 UserManualforFireflyMicroscopeGT200 Version:1.0
high ratio >100x:
When there is a need to zoom in more than 100 times, maintaining body stability becomes more paramount.
In such instances, a microscope stand is recommended. When a stand is not available, it is suggested that
the digital microscope focus wheel opening should be placed towards the user, and the transparent
cover vertically downward. This enables easy access to the focus wheel and a very stable position. A
smooth desktop may be used as an observation platform. (Shown below)
Device vertically downward (stable observation)
Focus：
Based on the relative height of the observed object, the focus wheel can be turned for a clear image.
When a higher magnification is required, the focus wheel can be turned to the left (see below). If a larger
field of view is required, the microscope can be moved farther away and the wheel turned to the right.

12 UserManualforFireflyMicroscopeGT200 Version:1.0
Brightness Adjustment:
On left rear side of the microscope, a knob allows the user to
control the brightness of the LEDs:
Backward Turn: Decrease Brightness
Forward Turn: Increase Brightness
Using Focus:
Default Position: Match the scale 50 to arrow mark.
Using the image capture control:
Press and release the Capture button to capture image frames. The
system will generate a shutter sound from the PC speaker as
confirmation.
Captur e
Free Focus:
Rotate wheel to fine
tune the ima
g
e.

13 UserManualforFireflyMicroscopeGT200 Version:1.0
Standby and Remove device:
To temporarily turn off or remove the device, slide the power button to the “OFF” position. The
device must also be turned off through the Windows operating system:
•On your Microsoft Windows Desktop, click My Computer in the
left pane. Double-click the USB Video Device (Wireless Digital
Microscope in Windows Vista and Windows 7).
After turning off the device through Windows above, the m can be unplugged from
the PC’s USB port. Using this sequence will avoid transient voltages from potentially
causing hardware damage.

14 UserManualforFireflyMicroscopeGT200 Version:1.0
Launch the Software Application:
Double-click the FireflyView.exe icon on your comp ut er de skto p:
Viewing the Images:
FireflyView software controls your Firefly Microscope. The Microscope communicates with the PC
through a USB cable. The user can configure the video properties, review live images, capture
images, record video clips and store them for further review.
The main features of FireflyView are shown below:
Icon Function Description
Record Video Start and stop video recording
Snapshot Press to capture snapshot images
Preview Press to freeze/unfreeze microscope image
Help Access detailed Users Guide information
Set Change video and image properties as shown below

15 UserManualforFireflyMicroscopeGT200 Version:1.0
Video and Image Settings
Pressing the SET button will provide access to the following capabilities

16 UserManualforFireflyMicroscopeGT200 Version:1.0
MAINTENANCE AND SERVICE
Cleaning recommendation
CAUTION Do not apply alcohol, chemicals, or water to the lens. Any
liquids entering the optical assembly will damage internal components.
Use a dry cloth to
c l ea n the D i git a l Firefly Microscope System on a weekly basis .
Recycling the system components
Within the EU
Do not
dispose of this product as unsorted mun i cipal refuse. Submit for
separate
collection as specified b y Directive 2002/96/EC of the European
Parliament
and th e Council of the European Union on Waste E l ectr on ic and
Ele c t r i cal Equ i pmen t ( W EEE ).
If this product is contaminated, this d i re ct iv e does not ap ply . For more
specific
disposal information contact C ust omer Se rvic e.
Outside the EU
When the
product and its components reach end of life, recycle the product
according to national, state, and loca l regulations .

17 UserManualforFireflyMicroscopeGT200 Version:1.0
Service policy
All repairs on products under warranty must be performed or approved by Firefly or its authorized resellers.
Unauthorized repairs will void the warranty. In addition, whether or not covered under warranty, any
product repair shall exclusively
be performed by Firefly- cer t i f i ed service personnel.
If the product fails to function properly — or if you need assistance, service, or spare parts — contact
your Firefly reseller.
Before contacting your reseller , try to duplicate the problem and check all accessories to ensure that they
are not causing the problem. When calling, please be prepared to provide:

Product name and model number and complete description of the problem.

Serial number of your product (if ap pli c ab le ).

Complete name, address and phone number of your fac ility .

For out-of-warranty repairs or spare parts orders, a purchase order (or credit car d ) nu mbe r .

For parts orders, the required spare or replacement part nu mbe r s .
If your product requires warranty, extended warranty, or non-warranty repair service, please contact
your Firefly reseller. A customer service representative will assist you in troubleshooting the problem
and will make every effort to solve it over the phone, avoiding potential unnecessary returns. In case
a return cannot be avoided, the representative will record all necessary information and will provide a
Return Authorization number, as well as the appropriate shipping address. The Return Authorization
number must be obtained prior to any return.
If you have to return your product for service, follow these recommended packing instructions:
 Disconnect all hoses, cables, sensors, power cords, and ancillary products ( as appropriate) before
packing, unless you suspect they are associated with
the problem.
 Wherever possible use the original shipping carton and packing materials.
 I n c lu de a packing list and the Return Authorization number.
It is recommended that all returned goods be insured. Claims for loss or damage to the product
are the responsibility of
the sen d e r .

18 UserManualforFireflyMicroscopeGT200 Version:1.0
SPECIFICATIONS
Item Specification
Weight Approximately 100 g (0.22 lb)
Length: 13.0 cm (5.2 inches)
Height: 3.6 cm (1.5 inches)
Dimensions (approximate) Width: 4.0 cm (1.6 inches)
Power USB 5VDC, 150mA
Protection against ingress of
water IPXØ
Operating conditions
Temperature +10°C to +40° C (+50°F to +104°F)
Relative humidity 30% to 75% noncondensing
Altitude 700 to 1060 hPa
Shipping and storage conditions
Temperature -20°C to +49°C (-4°F to +120°F)
Relative humidity 95% noncondensing max.
Safety Compliance FCC, CE and RoHS compliant
Patent Patent Pending

19 UserManualforFireflyMicroscopeGT200 Version:1.0
LIMITED W ARRANTY
Limited Hardware Warranty (through distributors & resellers)
FireFly Global hardware products purchased in the U.S. come with a 1-year limited hardware warranty. The warranty is extended
through Firefly Global authorized representatives and resellers. If you have a warranty claim, please contact the store,
distributor, or website through which the product was purchased.
What is covered by this limited hardware warranty?
This limited hardware warranty covers defects in materials and workmanship in your FireFly Global hardware products.
What is not covered by this limited hardware warranty?
This limited hardware warranty does not cover:
•Software, including the operating system and software added to or bundled with the FireFly Global hardware products
•Problems that result from:
•External causes such as accident, abuse, misuse, or problems with electrical power
•Servicing not authorized by FireFly Global
•Usage that is not in accordance with product instructions
•Failure to follow the product instructions
•Problems caused by using accessories, parts, or components not supplied by FireFly Global
•Products with missing or altered serial numbers
•Products for which FireFly Global or its distributors have not received payment
•Normal wear and tear
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE (OR JURISDICTION TO JURISDICTION). FIREFLY GLOBAL'S RESPONSIBILITY FOR MALFUNCTIONS AND DEFECTS IN
HARDWARE IS LIMITED TO REPAIR AND REPLACEMENT AS SET FORTH IN THIS WARRANTY STATEMENT. ALL EXPRESS AND
IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES AND CONDITIONS
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN TIME TO THE TERM OF THE LIMITED
WARRANTY PERIOD REFLECTED ON YOUR PACKING SLIP OR INVOICE. NO WARRANTIES, WHETHER EXPRESS OR IMPLIED,
WILL APPLY AFTER THE LIMITED WARRANTY PERIOD HAS EXPIRED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW
LONG AN IMPLIED WARRANTY LASTS, SO THIS LIMITATION MAY NOT APPLY TO YOU.
WE DO NOT ACCEPT LIABILITY BEYOND THE REMEDIES PROVIDED FOR IN THIS LIMITED HARDWARE WARRANTY OR FOR
CONSEQUENTIAL OR INCIDENTAL DAMAGES, INCLUDING, WITHOUT LIMITATION, ANY LIABILITY FOR THIRD-PARTY CLAIMS
AGAINST YOU FOR DAMAGES, FOR PRODUCTS NOT BEING AVAILABLE FOR USE, OR FOR LOST DATA OR LOST SOFTWARE. OUR

20 UserManualforFireflyMicroscopeGT200 Version:1.0
LIABILITY WILL BE NO MORE THAN THE AMOUNT YOU PAID FOR THE PRODUCT THAT IS THE SUBJECT OF A CLAIM. THIS IS
THE MAXIMUM AMOUNT FOR WHICH WE ARE RESPONSIBLE.
How long does this limited hardware warranty last?
The limited hardware warranty on all FireFly Global products begins on the date of the packing slip, invoice, or receipt. The
warranty period is not extended if a warranted product or any parts are repaired or replaced. FireFly Global may change the
availability of limited hardware warranties, at its discretion, but any changes will not be retroactive.
What do I do if I need warranty service?
Before the warranty expires, please contact the store, distributor, or website through which the product was purchased.
What will FireFly Global do?
FireFly Global or its authorized representative or reseller will repair any FireFly Global hardware products returned that prove to be
defective in materials or workmanship. If FireFly Global or its authorized representativse are not able to repair the product, we will
replace it with a comparable product that is new or refurbished.
When you contact our authorized representatives or resellers via phone or email, they will issue a Return Material Authorization
Number for you to include with your return. You must return the products in their original or equivalent packaging, prepay
shipping charges, and insure the shipment or accept the risk if the product is lost or damaged in shipment. The repaired or
replacement products will be returned to you. The reseller or authorized representative will pay to ship the repaired or replaced
products to you if you use an address in the United States (excluding Puerto Rico and U.S. possessions and territories). Otherwise,
the product will be shipped to you freight collect.
If it is determined that the problem is not covered under this warranty, you will be notified and informed of service alternatives that
are available to you on a fee basis.
How will you fix my product?
We use new and refurbished parts made by various manufacturers in performing warranty repairs and in building replacement
parts and systems. Refurbished parts and systems are parts or systems that have been returned to FireFly Global, some of which
were never used by a customer. All parts and systems are inspected and tested for quality. Replacement parts and systems are
covered for the remaining period of the limited hardware warranty for the product you bought. FireFly Global owns all parts
removed from repaired products.
May I transfer the limited hardware warranty?
Limited hardware warranties are not transferable.
