Firegear FPB-G34DBSMT-N User manual

Outdoor Flat Disc Fire Pits
Installation and Operating Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
Warning: For Outdoor Use Only
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
INSTALLATION PRECAUTION:
This re pit requires a minimum 18-square inches (per side) of cross ventilation.
Failure to provide proper ventilation can void the warranty.
Natural Gas Description Propane
Match Light (MT)
FPB-G34DBSMT-N 34” G90 Flat Disc & Spur Kit FPB-G34DBSMT-P
FPB-G44DBSMT-N 44” G90 Flat Disc & Spur Kit FPB-G44DBSTM-P
Thermocouple Manual Safety (TMS)
FPB-G34DBSTMS-N 34” G90 Flat Disc & Spur Kit FPB-G34DBSTMS-P
FPB-G44DBSTMS-N 44” G90 Flat Disc & Spur Kit FPB-G44DBSTMS-P
Thermocouple Flame Sense (TFS)
FPB-G34DBSTFS-N 34” G90 Flat Disc & Spur Kit FPB-G34DBSTFS-P
MODELS
MH# 60069

!
!! !!!"#$%&!
!
"#!$%&!'()**!+,'-!
!
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away
from the appliance and
immediately call your gas
supplier or fire department.
!!'"&#(#$!
!
.%!/%0!'0%1)!%1!&')!+,'%*2/)!%1!%03)1!
#*,((,4*)!5,6%1'!,/7!*28&27'!2/!03)!
5292/20$!%#!032'!%1!%03)1!,66*2,/9):!
!
;/!<=>9$*2/7)1!/%0!9%//)90)7!#%1!&')!
'3,**!/%0!4)!'0%1)7!2/!03)!5292/20$!%#!032'!
%1!,/$!%03)1!,66*2,/9):!
!!!"#$%&! ! ! )"&*+#,-+#+.(!%,/"00"&!,
,
1234,56673589:,958,6;<=>9:,95;?<8,@<8<A3=:,
B2392,254,8<,<=<;C,
,
D438E,3F,38,58,:897<4:=,4659:,958,G377,H<>C,
,
#:I:;,>4:,F234,56673589:,38,58,:897<4:=,4659:,
4>92,54,5,95@6:;J,F:8FJ,95;,<;,2<@:C,
!
'"&#(#$-!!"#!03)!2/#%1(,02%/!2/!03)')!2/'01&902%/'!2'!/%0!#%**%?)7!)@,90*$A!,!#21)!%1!
)@6*%'2%/!(,$!1)'&*0!9,&'2/+!61%6)10$!7,(,+)A!6)1'%/,*!2/B&1$!%1!7),03:!
!
K+&,L+D&,M"K%1L,
.%!/%!'0%1)!%1!&')!+,'%*2/)!%1!%03)1!#*,((,4*)!5,6%1'!,/7!*28&27'!2/!03)!5292/20$!%#!
032'!%1!,/%03)1!,66*2,/9):!
!
!
!! !!'"&#(#$!
"(61%6)1!2/'0,**,02%/A!,7B&'0()/0A!
,*0)1,02%/A!')1529)!%1!(,2/0)/,/9)!9,/!
9,&')!2/B&1$!%1!61%6)10$!7,(,+):!!C),7!
03)!2/'0,**,02%/A!%6)1,02/+!,/7!
(,2/0)/,/9)!2/'01&902%/'!03%1%&+3*$!
4)#%1)!2/'0,**2/+!%1!')15292/+!032'!
)8&26()/0!!!!!!
'"&#(#$,
.%!/%0!*),5)!&/,00)/7)7!7&12/+!&'):!
.%!/%0!&')!#%1!9%%D2/+:!
E%**%?!,**!+,'!*),D!61%9)7&1)'!2/!032'!
(,/&,*!612%1!0%!%6)1,02%/:!
REV. 5-7-14 Page 1
Flat Disc Burning Spur Fire Pits

REV. 5-7-14 Page 2
Specications 3
Preparation for Non-Conbustible Structure 4
Hard Piping to Fire Pit 4
Cross Ventilation Requirements 4
High Elevation 4
Installation into an Approved Enclosure
Section A Match Light (MT) Installation 5-8
Section B Thermocouple Manual Safety (TMS) Installation 9-12
Section C Thermocouple Flame Sense (TFS) Installation 13-17
Operation & Lighting Instructions
Match Light (TM) System 7
Thermocouple Manual Safety (TMS) System 10
Thermocouple Flame Sense (TFS) System 14
Replacement Parts 15
Replacement Parts List 16
Fire Pit Maintenance 17
Trouble Shooting
Match Light & Thermocouple Manual Safety 17
Thermocouple Flame Sense 19-20
Optional Accessories 18
TABLE OF CONTENTS
Flat Disc Burning Spur Fire Pits
Fuels used in gas red appliances, and the products of combustion such as fuels, contain
chemicals known to cause cancer, birth defects and/or other reproductive harm.
This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1
NOTE: This installation instruction covers (3) different ignition systems: Match Light (MT),
Thermocouple Manual Safety (TMS), or Thermocouple Flame Sense (TFS).
Example: FPB-G34DBSMT-N, FPB-G34DBSTMS-N, FPB-G34DBSTFS-N the bold letters provides
the type of ignition system in each model number. The information in this manual provides standard
requirements for all models and ignition systems and provides specic detailed information for each
model in the sections listed below.

SPECIFICATIONS
Table1. Disc Dimensions
Figure 1. Flat Disc Dimensions; refer to Table 1.
REV. 5-7-14 Page 3
Model:
Match Throw NG
NG Factory
Orice
Model:
Match Throw LP
LP Factory
Orice
Btu’s
Natural/Propane
FPB-G34DBSMT-N #29 FPB-G34DBSMT-P #41 65,000 N/A
FPB-G44DBSMT-N #29 FPB-G44DBSMT-P #41 65,000 N/A
FPB-G34DBSTMS-N #29 FPB-G34DBSTMS-P #41 65,000 N/A
FPB-G44DBSTMS-N #29 FPB-G44DBSTMS-P #41 65,000 N/A
FPB-G34DBSTFS-N #7 FPB-G34DBSTFS-P #31 105,000 (High) 51,000 (Low)
FPB-G44DBSTFS-N #7 FPB-G44DBSTFS-P #31 105,000 (High) 51,000 (Low)
Table 2. Btu Specications
Pressure NG LP
Min. Inlet 3.5” WC 8.0” WC
Max. Inlet 10.5” WC 13.0” WC
Normal Inlet 7.0” WC 11.0” WC
Table 3. Gas Pressures
Model:
Natural Gas (NG)
Model:
Propane Gas (LP) A
Disc
Depth
B
Pan
Diameter
C
Min./Max.
Install Opening
D
Ground
Level
E
Side
Wall
F
Combustible
Ceiling
G
Combustible
Floor
FPB-G34DBSMT-N FPB-G34DBSMT-P .0598 34” 24” - 31” 18” 19” 69” 18”
FPB-G44DBSMT-N FPB-G44DBSMT-P .0598 44” 24” - 40” 18” 19” 69” 18”
FPB-G34DBSTMS-N FPB-G34DBSTMS-P .0598 34” 24” - 31” 18” 19” 69” 18”
FPB-G44DBSTMS-N FPB-G44DBSTMS-P .0598 44” 24” - 40” 18” 19” 69” 18”
FPB-G34DBSTFS-N FPB-G34DBSTFS-P .0598 34” 24” - 31” 18” 19” 69” 18”
Disclaimer: Btu listings are based on 7.0”WC for Natural Gas and 11.0”WC
for Liquid Propane (LP) at the burner orice. Flex line size and proper gas
pipe sizing will also affect Btu’s. As a result your Btu’s may vary slightly from
Table 2 specications.
Flat Disc Burning Spur Fire Pits
Figure 2. Clearance to Combustibles
(Not to be used in an enclosed space)
F
E
G
AB
C
*
*
D
Ground Level (Earth)
Valve
Box 10.0”
*( 2.00” minimum overlap per side required to secure disc)

WARNING: Proper clearances from combustible materials must be maintained from all sides, top and bottom of this
appliance. Use the specications listed on page 3 for proper clearance to combustibles.
PREPARING A NON-COMBUSTIBLE STRUCTURE
The re pit can be installed on a at, stable surface, away from any combustible materials. Install re pit on any level,
outdoor non-combustible, at stable surface or a combustible oor according to the clearances specied in this manual.
NOTE: Do not place re pit directly on grass, dirt, or rocks as this may prevent proper ventilation (Fig.1, pg. 3). Ensure
proper water drainage is also incorporated into the re pit enclosure.
HARD PIPING TO FIRE PIT WITHOUT GAS PROXIMITY
NOTE: We recommend using 3/4” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for
proper pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 Btu’s.
1. Turn OFF gas supply system. NOTE: All gas connections (except for brass to brass) require the following. Clean pipe
threads using either a wire brush or steel wool. Apply pipe sealant to the ttings before making any connection.
BE CAREFUL! Ensure all gas connections are snug, but do not over tighten!
2. Extend the gas supply system using minimum of ¾” black iron pipe or an approved exible gas line from existing
house supply. This can be accomplished by teeing off or tapping into a gas line connection. Install necessary pipe
for the distance required and then install a manual shut-off valve at the exterior house wall. If pipe is to pass through a
foundation or house wall, make sure to re-seal the area around the pipe with weather sealant.
3. The primary gas shut-off (not supplied) will require a ½” male ared tting to enable connection of the stainless steel
ex gas line supplied with the re pit.
IMPORTANT
Installation of Natural or LP gas should be done by a qualied installer, service agency or gas supplier.
This appliance must be isolated from the gas supply piping system by closing its manual shutoff valve during any
pressure testing of the gas supply piping system at test pressures equal to or less than ½” psig (3.5kPa)
VENTILATION FOR NON-COMBUSTIBLE ENCLOSURE
Fire pits are subjected to many outdoor elements such as rain,
snow, wind, heat or cold. A minimum of 18 square inches of
cross ventilation (2 sides) is required to keep the
components in good working order. Use gure 3 as guide
to assist to incorporate proper ventilation.
Fire Pit
Enclousure
2”x3”
Fire Pit
Examples of Cross Ventilation
3 - 2”x3” Slots Per Side or
2- 1” x 9” Slots Per Side
Cross Flow Ventilation
(Min. 18 Sq. In. Per Side)
HIGH ELEVATION INSTALLATION
This appliance is listed for elevations from 0-4500 feet in
Canada and the U.S. If elevation exceeds 4500 feet it may be
necessary to decrease the input rating by changing the
existing burner orice to a smaller size. Input should be
reduced 4% for each 1000 feet beyond the 4500 feet above
sea level. Check with your local gas utility for assistance in
determining the proper orice in your location. In some cases
the heating value may already be reduced and downsizing the
orice may not be necessary.
Figure 3. Cross Ventilation Example
REV. 5-7-14 Page 4
Flat Disc Burning Spur Fire Pits

REV. 5-7-14 Page 5
Flat Disc Burning Spur Fire Pits
Section A
Match Light
Installation

REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath area should
be non-combustible or a at level combustible surface according to the clearances specied in this manual..
2. We recommend using 3/4” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for proper
pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 BTU’s.
3. Determine the size of the round re pit you are preparing to install (Refer to page 3).
4. You must provide a round opening out to place the at disc onto the non-combustible enclosure. Do not exceed the
maximum opening from Table 1, dimension B located on page 3.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance. Refer to page 3.
7. CAUTION: A minimum of 18 square inches of cross ventilation (per side) is required to keep the enclosure
dry.
8. These products are designed for outdoor use only. Not approved for any indoor use.
9. This re pit is designed to have lava rock completely covering the spur burner, so that the burner is not visible. Do
not cover more than 1” above the top of the burner. When purchasing lava rock use 1” diameter as a base to cover
the at disc.
10. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak tested
before installation of the re pit. Soapy water leak detection is required before regular use of the re pit.
11. Do not use material that will absorb moisture over time and will not release this moisture quickly. Moisture can boil
in this material and can rapidly break apart and cause damage or personal injury.
12. Never leave any other combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
13 . Ensure proper water drainage is also incorporated into the re pit enclosure.
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
REV. 5-7-14 Page 6
INSTALLING KEY VALVE
The key valve contents: 1- key valve, 1- key and 1- ange. The valve requires a 1” round clearance hole in the non-com-
bustible enclosure wall. See the instructions supplied with the key valve for more specic details. Note: Be sure to leak
test all tting before operation. Figure 6 shows an example of a typical installation.
Flat Disc Burning Spur Fire Pits
SECTION A - MATCH LIGHT (MT) INSTALLATION
Flat disc’s are for use with landscape blocks. The illustrations below show examples of possible installations.
Fig.4 Shows disc secured under stone caps. Fig. 5 Shows disc secured between layer of block.

REV. 5-7-14 Page 7
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Primary Gas
Supply
K
e
y
V
a
l
v
e
S
i
d
e
V
i
e
w
D
e
t
a
i
l
Fig. 6 Typical installation.
NOTE: Key valve and exible gas lines
are supplied. Gas shut-off is not supplied.
Flat Disc Burning Spur Fire Pits
Note: A 1¼” x 2” black iron or galvanized
coupler/nipple (not supplied) can be used
as a spacer between the manual valve
and the valve ange to add additional
support to hold the manual key valve in
place.
Key Valve Flange
Non-
Combustible
Wall Material
Non-
Combustible
Wall Material
Key Valve
Black Iron
Nipple
SECTION A - MATCH LIGHT (MT) INSTALLATION
Landscape/Patio Block Illustration
*
***
*
*
*
*
Shows possible ventilation
*
Illustration depicts at disc (shaded area) under
top course of patio block. Refer to page 3 for
ventilation requirements.
Stone Cap
Flat Disc With Spur
Man Made Stone
Vent
Cement Block Illustration

SECTION A - MATCH LIGHT (MT) INSTALLATION
REV. 5-7-14 Page 8
Flat Disc Burning Spur Fire Pits
CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the re pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
Key
Fig. 8 Inserting Key into Valve
ON
OFF
Fig. 7. Key Valve Face
Butane Lighter
Fig. 9 Lighting re pit with lighter
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE
ATTEMPTING TO LIGHT FIRE PIT
CAUTION: Ensure you have leak tested the re pit before operating.
TURNING ON FIRE PIT
1. Insert key into shut-off valve and secure into square end (see gs 7 & 8).
2. Light a long match or butane lighter and hold it near the burner (see g. 9).
3. Turn the key counter-clockwise in gas valve (until it stops) to allow gas to ow and
simultaneously apply the long burning match or Butane lighter as close to the end
burner as possible to light the re pit.
4. Gas should ignite within 10 seconds or less. If re pit does not light within 10 seconds
turn key clockwise to turn OFF the gas supply. Ensure there is not too much media on
top of the burner that might inhibit gas ow and try again in 5 minutes.
TURNING OFF FIRE PIT
1. Insert key into shut-off valve and secure into square end.
2. Turn key clockwise until it stops.
3. After cooling off install cover.

REV. 5-7-14 Page 9
Flat Disc Burning Spur Fire Pits
Section B
Thermocouple
Manual Safety
Installation

SECTION B THERMOCOUPLE MANUAL SAFETY INSTALLATION
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
INSTALLING GAS VALVE
The gas valve is secured into the mounting plate with a nut.
Figure 12 shows an example of a typical installation.
Fig. 12 Gas valve components.
Mounting Stem
with Securing
Nut
Primary Inlet
Gas Supply
Gas Outlet
to Fire Pit
Thermocouple
Connection
Control
Knob
Valve Mounting
Plate
Fig. 10 Shows disc secured under stone caps. Fig.11 Shows disc secured between layer of block.
Flat disc pans are for use with landscape blocks. The illustrations below show examples of possible installations.
REV. 5-7-14 Page 10
Flat Disc Burning Spur Fire Pits
REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath area should
be non-combustible or a at level combustible surface according to the clearances specied in this manual.
2. We recommend using 3/4” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for proper
pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 BTU’s.
3. Determine the size of the round re pit you are preparing to install (Refer to page 3).
4. You must provide a round opening out to place the at disc onto the non-combustible enclosure. Do not exceed the
maximum opening from Table 1, dimension B located on page 3.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance. Refer to page 3.
7. CAUTION: A minimum of 18 square inches of cross ventilation (per side) is required to keep enclosure dry.
8. These products are designed for outdoor use only. Not approved for any indoor use.
9. This re pit is designed to have lava rock completely covering the spur burner, so that the burner is not visible.
Do not cover more than 1” above the top of the burner. When purchasing lava rock use 1” diameter as a base to ll
the at disc.
10. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak
tested before installation of the re pit. Soapy water leak detection is required before regular use of re pit.
11. Do not use material that will absorb moisture over time and will not release this moisture quickly. Moisture can boil
in this material and can rapidly break apart and cause damage or personal injury.
12. Never leave any other combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under our warranty.
13 . Ensure proper water drainage is also incorporated into the re pit enclosure.

INSTALLATION OF LAVA ROCK/MEDIA INTO BURNER PAN
Install lava rock into the burner pan. Ensure the lava rock is a
1-inch diameter for proper operation. Note: Do not pour Lava
Rock directly from bag. It should be placed naturally and NOT
packed in tight. Loose tting is important to ensure robust ames.
Be sure rocks are free of any excessive dust. This prevents the
burner pan weep holes from being plugged and holding water.
IMPORTANT: Do not place rock over top or under the screen
cover. The screen must be free of any debris to ensure proper
lighting of burner and good ame sense (See g. 15).
Cover the burner completely with media but do not make the
depth greater than 1-inch overtop of the burner portholes.
Do NOT cover the screen mesh with any rock or glass. It must be
free an any debris to operate properly.
Lava Rock Lava Rock
Lava Rock
Ignition Hood
Screen Cover
Fig.15 Keep screen cover exposed
IGNITOR ALIGNMENT
It is important check that the ignitor probes be properly aligned over-
top of the burner port holes and did not move during shipping. Use
the Fig.14 as a guide. Before lighting remove the screen cover of the
ignition hood to burner and ensure the thermocouple is directly over-
top of a burner port hole. The sparking probes and the thermocouple
must be in the path of a ame to ignite the gas for proper ignition of
the ame. Replace the screen cover and follow the operating
instructions.
Fig. 14 Proper alignment of probes and
thermocouple.
Spur Burner Leg
Ignition Hood
Thermocouple
Valve Mounting Plate
Gas Inlet
Gas Outlet
Mounting
Nut
G
a
s
V
a
l
v
e
D
e
t
a
i
l
SECTION B THERMOCOUPLE MANUAL SAFETY INSTALLATION
REV. 5-7-14 Page 11
Flat Disc Burning Spur Fire Pits
Fig. 13 Typical installation
NOTE: Key valve and exible gas lines are
supplied. Gas shut-off is not supplied.
*
***
*
*
*
*
Shows possible ventilation
*
Illustration depicts at disc (shaded area) under
top course of patio block. Refer to page 3 for
ventilation requirements.

CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the re pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
TURNING ON FIRE PIT
CAUTION: Ensure you have leak tested the re pit before operating.
1. Light a long match or Butane lighter and hold it near the burner (see g. 17).
2. Rotate control knob on gas valve in the counter clockwise to ON position. (See Fig 16).
2. Depress control knob inward, push and light the burner at the same time. (See Figures 16 & 17).
3. After the re pits lights continue to depress control knob for 30 seconds then release knob. If re pit does not light
within 30 seconds, release control knob, turn knob clockwise to turn OFF and wait 5 minutes before trying again.
4. Repeat steps 1-3.
Fig. 16. Gas Valve Knob
READ ALL LIGHTING INSTRUCTIONS BEFORE ATTEMPTING TO LIGHT FIRE PIT
TURNING OFF FIRE PIT
1. Slight push inward on control knob and turn clock wise until it stops. Fire pit
will turn OFF.
2. After cooling off install cover.
ON OFF
AT ON POSITION
SLIGHT PUSH TO
TURN OFF
FULL PUSH TO
LIGHT
Butane Lighter
Fig. 17 Lighting with Butane lighter
Flat Disc Burning Spur Fire Pits
SECTION B THERMOCOUPLE MANUAL SAFETY INSTALLATION
REV. 5-7-14 Page 12

Section C
Thermocouple
Flame Sense
Installation
REV. 5-7-14 Page 13
Flat Disc Burning Spur Fire Pits

REQUIREMENTS
1. Only non-combustible materials should come in direct contact with any part of the re pit. Underneath area should be non-
combustible or a at level combustible surface according to the clearances specied in this manual.
2. We recommend using 3/4” black iron pipe; however please refer to the NFPA54 (National Fuel Gas Code) for proper
pipe sizing when exceeding 20-feet in length for re pits rated above 100,000 BTU’s.
3. Determine the size of the round re pit you are preparing to install (Refer to page 3).
4. You must provide a round opening out to place the at disc onto the non-combustible enclosure. Do not exceed the
maximum opening from Table 1, dimension B located on page 3.
5. Follow the local code requirements for the gas type being used. This re pit should be installed in accordance with
local codes and ordinances or in the absence of local codes, with the latest National Fuel Gas Code, ANSI Z223.1
NFPA54 or CSA B149.1, Natural and Propane Installation Code in Canada.
6. Fire pits create high temperatures, it is very important to have any combustibles at a safe distance. Refer to page 3.
7. Normal operation of the re pit is with a battery pack that is supplied with your system (Fig 19). The battery box has
12-feet of black sleeved wire that is to be passed through the junction box provided. This wire should not be cut or
spliced and the junction box can be placed in the facing of the vertical nish of the re pit, if you place the wire under
ground you should install those wires into an approved protective conduit/sleeve material.
8. Fire pit should never be left unattended while in operation. It should always be a safe distance from all trees and
combustible landscape materials.
10. Construction of the nished re pit should be stable and solid. From the bottom of the control box that houses the
gas valve and module, it should be a according to specications on Table #1. NOTE: Proper drainage is critical to
ensure that water does not damage gas valve and components. Never install re pit below grade.
11. CAUTION: The re pit enclosure MUST have a minimum ventilation of 18 square inches on each side of the
nished enclosure.
12. The insulation square pad provided with the re pit is to be placed foil up toward the bottom of pan on top of the
valve box.
13. Never ll the cavity under and around the valve box with any material, this is a provided air space necessary for
ventilation.
14. These products are designed for outdoor use only. Not approved for any indoor use.
15. This re pit is designed to have decorative rock, lava rock/media covering the burner, so the burner is not visible. Optional
concrete logs can be added to consumers taste. Decorative rock is not provided. When purchasing decorative rock use
minimum of 1-inch diameter rock as a base to ll the burner pan. DO NOT COVER THE IGNITION HOOD WITH ANY
ROCK OR MEDIA.
16. Gas lines and ttings must be installed in to the non-combustible structure. All gas connections must be leak tested
before installation of the re pit. Soapy water leak detection is required before regular use of the re pit.
17. Do not use material that will absorb moisture over time and will not release this moisture quickly. Moisture can boil in this
material and can rapidly break apart and cause damage or personal injury.
18. Never leave any other combustible material on top of the re pit. This could cause unsafe operation of this system
and damage to the component that will not be covered under the warranty.
INSTALLATION OF FIRE PIT INTO AN APPROVED ENCLOSURE
NOTE: Gas valve, exible gas lines
and TFS components are supplied.
Gas shut-off is not supplied.
Fig. 18 Typical installation.
Valve
Box
Battery Pack
SECTION C THERMOCOUPLE FLAME SENSE INSTALLATION
REV. 5-7-14 Page 14
Flat Disc Burning Spur Fire Pits

INSTALLATION OF BATTERY PACK
1. During the installation the location of the battery pack should be installed in the location that is easy to service.
The best location is in the vertical enclosure of the re pit. The plastic junction box is provided for the installation
of the battery pack.
Requires 4-AA 1.5V
alkaline batteries
Battery cover slides on/off
Latching Solenoid DC Motor Drive
Slide Switch
to Latching
Solenoid
2. The wiring extending from the valve box is a 12-foot special 4-pin connector that connects to the battery pack and
(2) two additional wires with ¼” female connectors. A complete wiring diagram (Fig.26) is located on page 20.
3. Feed all wires into the plastic junction box and connect special 4-pin plug into back of the battery pack. Connect
¼” female spade connectors to solenoid wires matching color, red-to-red and black-to-black.
4. Install the (4) AA batteries in to the battery compartment shown in gure 19. Double check to ensure the slide
switch is in the latching solenoid position on the battery pack. Then snap cover plate in place as shown in g.20.
Fig. 19. Slide switch on latching solenoid
5. Reinstall the battery pack into the plastic junction box, line up the two holes in the cover and install white screws
provided. Batteries can be changed or installed by removing the two screws that hold the cover plate battery pack
in place. Remove assembly, slide cover away from the cover plate and install the (4) four AA batteries.
6. Be sure the batteries are installed positive-to-positive and negative-to-negative. If one battery is installed wrong
the system will not operate.
7. Once the re pit is installed into the enclosure, the burner and control system should be tested before the media
(lava rock) is installed.
INSTALLATION OF BATTERY INTO TRANSMITTER
You have one handheld transmitter and you will need to install the included (12-volt battery) into the transmitter. On the
backside of the transmitter, push the cover away from the case. Place the battery into the compartment matching positive-
to-positive and negative-to-negative. To ensure the battery is properly installed push any button on the transmitter and
you will see a red LED light at the top of the transmitter glow. The red LED light will only be lit when a button is pushed.
Fig. 20 Cover plate installation
IGNITOR ALIGNMENT
It is important check that the ignitor probes be properly
aligned overtop of the burner port holes and did not move
during shipping. Use the Fig. 21 as a guide. Before lighting
remove the screen cover of the ignition hood to burner and
ensure the spark probes are directly overtop of a burner port
hole. The sparking probes and the thermocouple must be in
the path of a ame to ignite the gas for proper ignition of the
ame. Replace the screen cover and follow the operating
instructions.
Fig. 21 Proper alignment of probes and thermocouple.
Thermocouple
Ignitor Probes
Igniton
Hood
SECTION C THERMOCOUPLE FLAME SENSE INSTALLATION
REV. 5-7-14 Page 15
Flat Disc Burning Spur Fire Pits
Battery Pack
Cover Plate
(Rear View)

INSTALLATION OF LAVA ROCK/MEDIA INTO BURNER PAN
Install lava rock/media into the burner pan. Ensure the media is a minimum of
1-inch diameter for proper operation. Note: Do not pour lava rock directly from
bag. Media should be placed naturally and NOT packed in tight. Loose tting is
important to ensure robust ames. Be sure rocks are free of any excessive dust.
This prevents the burner pan weep holes from being plugged and holding water.
IMPORTANT: Do not place media over top or under the screen cover. The
screen must be free of any debris to ensure proper lighting of burner and to allow
proper heating of the thermocouple.
Cover the burner completely with media but do not make the depth greater than
1-inch overtop of the burner portholes.
Decorative glass may be loosely scattered on top of the lava rock. Do NOT
cover the stainless steel screen cover with any rock or glass. It must be free an
any media/debris to operate properly.
Lava Rock Lava Rock
Lava Rock
Ignition Hood
Screen Cover
Fig. 24 Keep screen cover exposed
Fig. 22 Removing the cover from metal box.
LEARNING THE REMOTE CONTROL TO THE MODULE
The re pit is unique that it comes standard with one remote
controlled transmitter. The handheld remote is shipped with
this system are already learned (programmed) to the module
inside the control box. Additional transmitters can be learned
to this electronic module; up to a total of three transmitters
are available. Contact Firegear to discuss additional
transmitter options or see the accessory page of this
instruction manual.
Learning the new transmitters is simple, but will require
pressing the learn button on the module. You should learn
any new transmitters before the nal installation of the re pit.
Follow the steps below:
1. Remove the two screws securing the cover on the
control box (See g. 22). The cover will slide
down exposing the gas valve and control module.
2. Find the black module attached to the inside of the
control box. Locate the “Learn Button” on the bottom
of the module.
3. Once the Learn button is located, press and release
the button once. You will hear a beep indicating that
the module is ready to receive a transmitter code
(See g. 23)
4. Take the transmitter and press the OFF button. You
will hear a series of rapid beeps indicating the module
has accepted the new code.
NOTE: A maximum of three (3) codes can be programmed to
the module. After a total of three (3) codes have been pro-
grammed the memory is full and will not accept any additional
codes. To clear all codes, press and hold the learn button for
10 seconds. The module will beep three (3) times
indicating the memory is clear of all codes. After codes have
been cleared see to Step #3 above to re-learn transmitter.
Learn Button
AUX
POWER
PEN
MODULE
INSIDE FIRE PIT
METAL BOX
Fire Pit Valve Box
Fig.23 Learn button location
SECTION C THERMOCOUPLE FLAME SENSE INSTALLATION
REV. 5-7-14 Page 16
Flat Disc Burning Spur Fire Pits

CAUTION: Children and adults should be alerted to the hazards on high surface temperatures and should stay away to
avoid burns or clothing ignition. Young children should be carefully supervised when they are in the area of the appliance.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualied service technician
to inspect the appliance and to replace any part of control system and any gas control, which has been under water.
OPERATION
SAFETY WARNINGS
1. Never leave the re pit unattended during operation.
2. Clothing or other ammable materials should not be placed on or near the appliance.
3. Any guard or other protective device removed for servicing the appliance must be replaced prior to operating the
appliance.
4. Installation and repair should be done by a qualied service person. The appliance should be inspected before
use and at least annually by a qualied service person. More frequent cleaning may be required as necessary. It
is imperative the control compartment, burners and circulating air passageways of the appliance be kept clean.
5. Inspect the fuel supply connection before each use of the appliance.
6. Temporary storage of this appliance indoors is permissible only if it has been disconnected from its fuel supply
(Natural or L.P. gas line).
WARNING
1. This appliance is hot when operated and can cause severe burns if contacted.
2. Do not burn any solid fuels in this appliance.
LIGHTING INSTRUCTIONS
NOTE: It may take several cycles of ON/OFF to purge the airow from the gas lines. The direct spark ignition
will turn OFF after 15 seconds if the burner does not light after which you will need to press transmitter OFF button then
back ON to initiate ignition again.
Flame height is HI and LO. By pressing the buttons on the handheld transmitter you can operate ON-OFF-HI-LO. The
transmitter defaults to the HI setting when initially lighting the re pit each time but will remember the last setting used and
change back to that last setting in approximately 5 seconds after lighting.
READ ALL WARNING AND SAFETY INFORMATION ABOVE BEFORE ATTEMPTING TO LIGHT FIRE PIT
L
O
W
H
I
O
F
F
O
N
TURNING OFF FIRE PIT
1. To turn OFF the re pit press the OFF button on the transmitter. Fire pit will turn OFF.
2. After re pit has completely cooled off install cover.
Fig. 25 Transmitter
TURNING ON FIRE PIT
1. Ensure you have leak tested the re pit before operating. Turn main gas supply ON.
2. Ensure batteries are installed in battery pack and switch is on Latching Solenoid.
3. Press the ON button on the transmitter (Fig. 25) You will hear the ignitor probe begin
sparking for 15-seconds and the re pit will turn ON.
4. If the re pit does not light the module will “beep” one time every second indicating an
ignition error. This is a hard lockout. If this occurs press the OFF button on the remote
control and repeat step 1-3.
5. If re pit does not light after second try turn main gas OFF, wait 5 minutes and repeat
steps 1-3.
SECTION C THERMOCOUPLE FLAME SENSE INSTALLATION
REV. 5-7-14 Page 17
Flat Disc Burning Spur Fire Pits

Replacement Parts
Maintenance
Accessories
REV. 5-7-14 Page 18
Flat Disc Burning Spur Fire Pits

FLAT DISC REPLACEMENT PARTS
1
2
8
9
Drawings are not to scale
OUT
PILOT ADJ
IN
MAIN
PILOT
Battery cover slides on/off
Latching Solenoid DC Motor Drive
10 11
12
13
SI
Remote/O ADJ
IPI
POWER
AUX
Learn
Module
17 19
AA Batteries
AA Batteries
AA Batteries
AA Batteries
20
18
57
L
O
W
H
I
O
FF
O
N
25
46
ON
OFF
15
14
16
21
22
23
24
28
29
30
REV. 5-7-14 Page 19
Flat Disc Burning Spur Fire Pits
