First Texas Products PinPointer User manual

OWNERS
MANUAL
PINPOINTER
First Texas Products, L.L.C.
5-YR LIMITED
WARRANTY
This product is warranted against defects in
materials and workmanship under normal use
for five years from the date of purchase to the
original owner. Liability in all events is limited to
the purchase price paid. Liability under this
Warranty is limited to replacement or repair, at
our option, of the product returned, shipping cost
prepaid, to First Texas Products, L.L.C. Damage
due to neglect, accidental damage or misuse of
this product is not covered by the warranty.
According to FCC part 15.21 Changes or Modifications made to this
device not expressly approved by the party responsible for
compliance could void the users authority to operate this equipment.
Proof of purchase is required to make a claim under this warranty.
NOTE TO FOREIGN COUNTRY CUSTOMERS
This warranty may vary in other countries, check with
your distributor for details.
Factory warranty follows the channel of distribution.
Warranty does not cover shipping costs.
First Texas Products, L.L.C.
1465-H Henry Brennan
El Paso, TX 79936
800-413-4131
MPP 070610
PinPointer
For Treasure Hunting
and unearthing small
objects
After identifying the presence of a
metal object in the ground,
pinpointing its exact location, and
separating it from the earth, can be
frustrating and time consuming.
With the PinPointer, retrieving
coins and other small metal objects
is easy.
Unearthing
Small Objects
A buried object, especially after
the passage of times, can be
indistinguishable from the soil it is
buried in. In addition, historical
objects will lose value if damaged in
the unearthing process.
It is therefore recommended to
use the PinPointer in a probing or
sifting process. The tip of the
PinPointer will detect a coin-sized
metal object approximately 3/4” to 1”
away from the tip of the probe. Probe
the tip of the PinPointer directly into
the ground; poke around directly on
the surface in different areas until the
internal buzzer activates. If the earth
is loose enough, lift handfuls of soil
out of the ground and probe in the
palm of your hand with the
PinPointer.
OWNERS
MANUAL
PINPOINTER
PinPointer
For Treasure Hunting
and unearthing small
objects
After identifying the presence of a
metal object in the ground,
pinpointing its exact location, and
separating it from the earth, can be
frustrating and time consuming.
With the PinPointer, retrieving
coins and other small metal objects
is easy.
Unearthing
Small Objects
A buried object, especially after
the passage of times, can be
indistinguishable from the soil it is
buried in. In addition, historical
objects will lose value if damaged in
the unearthing process.
It is therefore recommended to
use the PinPointer in a probing or
sifting process. The tip of the
PinPointer will detect a coin-sized
metal object approximately 3/4” to 1”
away from the tip of the probe. Probe
the tip of the PinPointer directly into
the ground; poke around directly on
the surface in different areas until the
internal buzzer activates. If the earth
is loose enough, lift handfuls of soil
out of the ground and probe in the
palm of your hand with the
PinPointer.
First Texas Products, L.L.C.
5-YR LIMITED
WARRANTY
This product is warranted against defects in
materials and workmanship under normal use
for five years from the date of purchase to the
original owner. Liability in all events is limited to
the purchase price paid. Liability under this
Warranty is limited to replacement or repair, at
our option, of the product returned, shipping cost
prepaid, to First Texas Products, L.L.C. Damage
due to neglect, accidental damage or misuse of
this product is not covered by the warranty.
According to FCC part 15.21 Changes or Modifications made to this
device not expressly approved by the party responsible for
compliance could void the users authority to operate this equipment.
Proof of purchase is required to make a claim under this warranty.
NOTE TO FOREIGN COUNTRY CUSTOMERS
This warranty may vary in other countries, check with
your distributor for details.
Factory warranty follows the channel of distribution.
Warranty does not cover shipping costs.
First Texas Products, L.L.C.
1465-H Henry Brennan
El Paso, TX 79936
800-413-4131
MPP 070610
BHpinpointer(printer).qx6 7/6/10 10:59 AM Page 1

Assembly
•No Assembly Required
Operation
1. Click On by rotating the knob clockwise.
2. Battery Check
The PinPointer will buzz immediately,
indicating that the batteries are in good
condition.
If the buzzer does not sound after switching
on, replace the single 9-volt battery.
3. Rotate the knob until the buzzer sound
stops.
4. Set the Sensitivity
A. With the buzzer silent, rotate knob back
counterclockwise to the point where the
device is just silent.
B.You want to position the knob in the most
counterclockwise position at which
the buzzer is still silent. This threshold
setting allows you to always set the
device at maximum sensitivity.
PROBE
ON/OFF KNOB
BATTERY
COMPARTMENT
Assembly
•No Assembly Required
Operation
1. Click On by rotating the knob clockwise.
2. Battery Check
The PinPointer will buzz immediately,
indicating that the batteries are in good
condition.
If the buzzer does not sound after switching
on, replace the single 9-volt battery.
3. Rotate the knob until the buzzer sound
stops.
4. Set the Sensitivity
A. With the buzzer silent, rotate knob back
counterclockwise to the point where the
device is just silent.
B.You want to position the knob in the most
counterclockwise position at which
the buzzer is still silent. This threshold
setting allows you to always set the
device at maximum sensitivity.
PROBE
ON/OFF KNOB
BATTERY
COMPARTMENT
BHpinpointer(printer).qx6 7/6/10 10:59 AM Page 2
