Fischer Panda xControl Series User manual

Panda_xControl_eng.R02 29.9.16
Panda xControl Manual

Fischer Panda
GmbH
Otto-Hahn-Str. 40
D-33104 Paderborn
Germany
Phone:
Fax.:
Hotline
E-mail:
Web
:
:
:
:
:
[phone]
[phone]
[phone]
[email protected]
www.fischerpanda.de
Current revision status
Created by
Fischer Panda GmbH - Head of Technical Documentation
Otto-Hahn-Str. 32-34
33104 Paderborn - Germany
Phone: [phone]
E-mail: [e-mail]
web: www.fischerpanda.de
Copyright
Reproduction of and changes to the manual are permitted only by agreement and with the permission of the
manufacturer!
Fischer Panda GmbH, 33104 Paderborn, reserves all rights regarding text and graphics in this document. Details
are given to the best of our knowledge. No liability is accepted for correctness. Please note: technical modifications
aimed at improving the product may be implemented without prior notice. Therefore, it must be ensured prior to
installation that the pictures, diagrams, and related material are applicable to the equipment supplied. In case of
doubt, verify upon delivery that documentation and equipment match.
Document
Current: Panda_xControl_eng.R02_29.9.16
Replaces: Panda_xControl_eng.R01.5
Revision Page
Manual compiled on the basis of deu R02

29.9.16 Contents Page 3
Table of Contents
Current Revision Status.............................................................................................................................. ....... 2
1 Panda xControl Safety Instructions...................................................................................................... ....... 5
1.1 Personnel........................................................................................................................................ ...... 5
1.2 Safety Precautions.......................................................................................................................... ...... 5
1.3 ........................................................................................................................................................ ...... 6
2 Panda xControl ....................................................................................................................................... ....... 7
2.1 Components of the xControl........................................................................................................... ...... 7
2.1.1 xControl - CP-G .............................................................................................................. ...... 7
2.1.2 xControl - GC-S ............................................................................................................. ...... 7
2.1.3 xControl - CB-G .............................................................................................................. ...... 7
2.2 Installation....................................................................................................................................... ...... 8
2.2.1 Installation of the Electronic Control Unit (ECU) xControl - GC-S .................................. ...... 8
2.2.2 Installation of the Connection Box xControl - CB-G ....................................................... ...... 8
2.2.3 Installation of the xControl - CP-G .................................................................................. ...... 8
2.3 Operation........................................................................................................................................ ...... 9
2.3.1 Switching on the Generator ............................................................................................ ...... 9
2.3.1.1 Overview page with Autostart activated........................................................... .... 10
2.3.2 The Overview Pages ...................................................................................................... .... 10
2.3.3 Symbols used in the Overview Pages ............................................................................ .... 11
2.4 Starting the Generator.................................................................................................................... .... 13
2.4.1 Preparations for starting up / Checks (daily) for marine version ..................................... .... 13
2.4.2 Preparations for starting up / Checks (daily) for vehicle version .................................... .... 13
2.4.3 Starting the Generator .................................................................................................... .... 14
2.4.4 Stopping des Generators ................................................................................................ .... 15
2.5 The Menu........................................................................................................................................ .... 16
2.5.1 Main Menu ...................................................................................................................... .... 16
2.5.2 Sub-menu: "Panel" ......................................................................................................... .... 17
2.5.2.1 Setting the illumination of the CP-G................................................................. .... 17
2.5.2.2 Setting the contrast of the CP-G ...................................................................... .... 18
2.5.2.3 Setting the standby time of the CP-G............................................................... .... 18
2.5.2.4 Setting the standby illumination of the CP-G ................................................... .... 18
2.5.2.5 Setting the display mode of the CP-G overview pages.................................... .... 18
2.5.2.6 Setting the language of the text pages of the CP-G......................................... .... 19
2.5.2.7 Setting the Temperature Unit........................................................................... .... 19
2.5.2.8 Setting the Aural Alarm.................................................................................... .... 19
2.5.2.9 Setting the display to flash in the event of a fault............................................. .... 20
2.5.2.10 Setting the Panel Heating ................................................................................ .... 20
2.5.2.11 Setting the display of the optional measurement data ..................................... .... 20
2.5.2.12 Resetting all values of the Panel sub-menu to default values.......................... .... 21
2.5.2.13 Return to Main Menu........................................................................................ .... 21
2.5.3 Sub-menu: "Generator" .................................................................................................. .... 21
2.5.3.1 Setting the Autostart of the CP-G..................................................................... .... 22
2.5.3.2 Setting the optional DC output of the CP-G ..................................................... .... 23
2.5.3.3 Switching the switching outputs of the CP-G................................................... .... 23
2.5.3.4 Reading out the Event Memory of the CP-G.................................................... .... 24
2.5.3.5 .............Resetting all values of the Generator sub-menu to the default values.... 24
2.5.3.6 Returning to the Main Menu............................................................................. .... 24
2.5.4 Resetting the panel language to the default (English) .................................................... .... 24
2.5.4.1 How to set the panel language after a reset. ................................................... .... 25
2.6 Faults.............................................................................................................................................. .... 25

Page 4 - Table of Contents 29.9.16:
Table of Contents
2.6.1 Symbols and messages on the display .......................................................................... .... 25
2.6.1.1 Example of message - "Sensor defective" ....................................................... .... 25
2.6.1.2 Example of message - "Sensor/Cable break" .................................................. .... 25
2.6.2 Error code ....................................................................................................................... .... 25
2.6.2.1 Table of Faults.................................................................................................. .... 26
2.6.2.2 Description of the Symbols............................................................................... .... 27
2.7 Accessories:.................................................................................................................................... ....28
2.7.1 Dimensional drawing ...................................................................................................... .....30

Panda xControl Safety Instructions
29.9.16 Chapter 1: Panda xControl Safety Instructions - Page 5
1. Panda xControl Safety Instructions
1.1 Personnel
The settings described here can be performed by the operator unless highlighted differently.
The installation should be implemented by specially trained technical personnel or by authorised workshops (Fischer
Panda Service Points), only.
1.2 Safety instructions
Note!Adhere to the safety instructions in the Fischer Panda
generator manual.
If these instructions are not to hand, they can be requested
from Fischer Panda GmbH, 33104 Paderborn, Germany.
WARNING: Automatic start-upAn external signal may trigger an automatic start-up.
Warning!The generator must not be operated with the cover
removed.
If the generator is being installed without a sound insulation
capsule, it must be ensured that all rotating parts (belt pulley,
belts etc.) are covered and protected so that there is no
danger to life and body!
All service, maintenance, or repair work may only be carried
out when the unit is not running.
WARNING: Electrical voltageElectric voltage - Deadly Danger!
Electric voltages of more than 48 V are potentially lethal in
any situation. The rules of the respective regional authority
must be adhered to for installation and maintenance.
For safety reasons, only an electrician may carry out the
installation of the electrical connections of the generator.
Attention!Disconnect battery before working on the generator
The battery must always be disconnected (first the negative
terminal, then the positive terminal) if work on the generator
or electrical system is to be performed, so that the generator
cannot be started inadvertently.
This applies in particular to systems with an automatic start-
up function. The automatic start-up function shall be
deactivated before starting work.
The flooding valve must be closed. (For PMS version only.)

Panda xControl Safety Instructions
Page 6 - Chapter 1: Panda xControl Safety Instructions 29.9.16
Note!Also observe the safety instructions for the other
components of your system.

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 7
2. Panda xControl
The Panda xControl is a generator control system with three main components.
2.1 Components of the xControl
2.1.1 xControl - CP-G
(Control Panel – Generator) - Part No. 21.02.02.204P
Fig. 2.1.1-1: Control Panel - GeneratorDisplay and Control Element of the xControl
The xControl CP-G is the display and control element
Power is supplied via the bus cable. Multiple control
elements can be installed in a single system.
2.1.2 xControl - GC-S
(Generator Control - Servo) - Part.No. 21.02.08.019P
Fig. 2.1.2-1: Generator Control - ServoMain module of the xControl.
The module contains the control electronics
The xControl GC-S is usually installed in the generator
capsule.
The xControl GC-S takes over the monitoring and control of
the diesel engine of the Fischer Panda generator, as well as
the control of the output voltage and frequency of the
generator.
The xControl GC-S is suitable for 12V and 24 V starting systems. The connected actuators are supplied with power
via switching outputs with input voltage.
Current measurement is single-phase and can be done directly.
A voltage sensor is not necessary. Current
measurement takes place via an external current sensor. An additional three-phase module can be used for three-
phase generators.
2.1.3 xControl - CB-G
(Connection Box - Generator)
Fig. 2.1.3-1: Connection Box - GeneratorThe xControl GC-S is usually installed in the generator
capsule (externally).
The xControl CB-G is the external terminal block for the
xControl generator.
The control element and the fuel pump are connected here.

Panda xControl
Page 8 - Chapter 2: Panda xControl 29.9.16
An emergency stop device, auto-start, load relays and
boosters can be connected as options.
Note:Only electricians may work on the xControl CB-G
2.2 Installation
2.2.1 Installation of the Electronic Control Unit (ECU) xControl - GC-S
The ECU xControl - GC-S is pre-installed. The ECU can be exchanged easily. All connections are mechanically
coded and prevent the risk of confusion.
2.2.2 Installation of the Connection Box xControl - CB-G
The connection box is pre-installed. External components are connected in accordance with the installation manual
and the circuit diagram of the xControl generator.
2.2.3 Installation of the xControl - CP-G
The xContol - CP-G is a CAN Bus module. All Fischer Panda CAN bus modules have two RJ45 ports. One for
connection to the module on the CAN bus, the second to relay the CAN bus. The last module on the CAN bus must
have a terminating resistor in the RJ45 port.
Connection by means of the Fischer Panda bus cable is mandatory.
Fig. 2.2-1: xControl CP-G rear
Fig. 2.2-2: Connection Diagram
RJ45

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 9
2.3 Operation
The xControl is operated by means of the xControl CP-G panel.
Fig. 2.3-1: xControl CP-G front
2.3.1 Switching on the generator
Fig. 2.3.1-1: Switching on the generatorPress the "ON/OFF" switch to switch on the control
system of the generator.
The xControl Generator thereby switches to "standby mode".
If automatic starting is activated at the menu, the
generator can henceforth be started by means of an
external signal.
Fig. 2.3.1-2: Home PageThe CP-G Panel displays the home page for two seconds.
Fig. 2.3.1-3: Address PageThe CP-G then displays the address page for one second

Panda xControl
Page 10 - Chapter 2: Panda xControl 29.9.16
Fig. 2.3.1-4: Overview Page 1At the end of the power-on routine, the CP-G displays the
first overview page.
The language as well as the display mode can be set in the
menu.
Overview Page 1 is the same in all display modes/languages.
2.3.1.1 Overview page with Autostart activated
WARNING: AutostartDeadly danger! - The generator can be equipped with an
Autostart function. This means that the generator is
started by an external signal. In order to prevent an
inadvertent start-up, the starter battery must be
disconnected before work on the generator may
commence.
The "Autostart" also remains active if the xControl CP-G
is switched off and then on again.
If a fault should arise when the generator is started or is
already operating, it is stopped and the Autostart is set to
"off".
If the generator is operated by Autostart and is stopped
manually, the Autostart is set to "off".
Once the system has been switched off and then on again,
the Autostart is active once more.
Fig. 2.3.1-1: Overview Page 1 with AutostartThe first overview page shows if the Autostart is active.
Overview Page 1 with Autostart function activated.
2.3.2 The overview pages
The display mode/language of the display can be set in the menu.

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 11
2.3.3 Symbols used in overview pages
Fig. 2.3.3-1: Symbols used in Overview Page 1Overview Page 1:
01. Generator Status (on/off)
02. AC OK
03. Temperature of the generator (OK/Error)
04. Operating hours of the generator
05. Info screen
Overview Page 1 is the same in all languages.
Fig. 2.3.3-2: Overview Page 2 Symbols/EnglishOverview Page 2 (Generator):
06. Output voltage [V]
07. Generator current [A]
08. Generator apparent power [kVA]
Note:In the case of three-phase generators, the voltage, the
current and the electrical power are shown on separate
pages. Each page shows the value of the three phases
one below the other.
Fig. 2.3.3-3: Voltage display 3-P Symbols/EnglishExample of the voltage display of a 3-phase generator.
01
02
03
05
04
06
07
08
06
07
08
06
07
08
06
07
08

Panda xControl
Page 12 - Chapter 2: Panda xControl 29.9.16
Fig. 2.3.3-4: Overview Page 3 Symbols/EnglishOverview Page 3:
09. Frequency of the generator [Hz]
10. Generator speed (r.p.m.)
11. Voltage of the starter battery [V]
Fig. 2.3.3-5: Overview Page 4 Symbols/EnglishOverview Page 4:
12. Temperature of the cylinder head
13. Temperature of the generator winding
14. Temperature at exhaust manifold
Note!:If the information pages of optional components (e.g. fuel
gauge, oil pressure) are available, then these pages are
inserted after Overview Page 4.
Whether these pages are displayed automatically, always or
not at all can be set in the Panel menu.
Fig. 2.3.3-6: Final overview pageFinal Overview Page:
Proceed to this menu by pressing the Start/Stop - Enter key
Overview Page 5 is the same in all display modes/languages.
09
10
11
09
10
11
12
13
14
12
13
14

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 13
2.4 Starting up the generator.
2.4.1 Preparations for starting up / Checks (daily) for marine version
1. Oil level check (ideal level: 2/3 Max).
The level should be about 2/3 of the maximum level when the engine is cold.
Further, if installed, the oil level of the oil-cooled bearing must be checked before each start - see sight glass on
generator front cover!.
2. Check cooling water level.
The external expansion tank should be filled to 1/3 in a cold state. It is very important that there is sufficient
volume for expansion of the coolant.
3. Check if the raw water intake valve is open.
For safety reasons, the raw water intake valve must be shut after the generator has been switched off. It should
be re-opened before starting the generator.
4. Check raw water filter.
The raw water filter must be regularly checked and cleaned. If the raw water intake is restricted by detached
residue, this increases wear on the impeller.
5. Visual inspection
Control fixing bolts, check hose connectors for leaks, check electrical connections. Check electrical lines for
damage/chafing.
6. Switch off loads.
The generator should only be started without a load.
7. Open fuel valve, if installed.
8. Close main battery switch (switch on).
2.4.2 Preparations for starting up / Checks (daily) for vehicle version
1. Oil level check (ideal level: 2/3 Max).
The level should be about 2/3 of the maximum level when the engine is cold.
Further, if installed, the oil level of the oil-cooled bearing must be checked before each start - see sight glass on
generator front cover!.
2. Check cooling water level.
The external expansion tank should be at 1/3 in a cold state. It is very important that there is sufficient volume
available for expansion of the coolant.
3. Visual inspection
Control fixing bolts, check hose connectors for leaks, check electrical connections. Check electrical lines for
damage/chafing.
4. Switch off loads.
The generator should only be started without a load.
5. Open fuel valve, if installed.
6. Close main battery switch (switch on).

Panda xControl
Page 14 - Chapter 2: Panda xControl 29.9.16
2.4.3 Starting up the generator
WARNING: Automatic start-upDeadly danger! - The generator can be equipped with an
Autostart function. This means that the generator is
started by an external signal. In order to prevent an
inadvertent start-up, the starter battery must be
disconnected before work on the generator may
commence.
Fig. 2.4.3-1: Switch on the panel1. Switch on the xControl CP-G
The remote control panel is started by pressing the On/Off
button. The On/Off button must be pressed until the Home
page is displayed.
Fig. 2.4.3-2: Start the generator.2. Press the Start/Stop - Enter key
Fig. 2.4.3-3: Self-test3. The xControl performs a self-test.
Fig. 2.4.3-4: Preheating4. The xControl preheats the diesel engine.
After preheating, the generator is started by the xControl
system.
Fig. 2.4.3-5: Electric starter5. Starter on.
In order to minimise current consumption, preheating is
interrupted briefly when the starter is operated.

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 15
Fig. 2.4.3-6: Preheating6. Starter and preheater
As soon as the high inrush current of the starter has dropped,
preheating is switched on again.
Fig. 2.4.3-7: Increase revolutionsThe engine idles for the first few seconds. Thereafter, the
xControl increases the speed to the operating speed and
indicates this in the display.
Fig. 2.4.3-8: AC OKAs soon as the AC voltage is within the limits (200-250V)
(normal operating mode), the load can be connected.
ATTENTION:Close the raw water intake valve in the event start-up
problems (Panda Marine generators only)
If multiple attempts to start up are required (e.g. to bleed the fuel lines), then the raw water intake valve must
definitely be shut while the attempts are being made. The cooling water impeller turns during the starting process
and feeds cooling water. As long as the engine has not started up, the exhaust gas pressure is insufficient to
discharge the coolant water that has been introduced. This protracted start-up process would flood the exhaust
system with water. This can damage/destroy the generator/engine.
Re-open the raw water intake valve as soon as the generator has started.
2.4.4 Stopping the generator
1. Switch off loads.
2. Recommendation: With turbo engines and under a load
that exceeds 70 % of the rated output, allow the generator
temperature to stabilise for at least 5 minutes with load
switched off.
At higher ambient temperatures (greater than 25 °C) the generator should always run for at least 5 minutes without
load before it is switched off, regardless of the load having been switched off.

Panda xControl
Page 16 - Chapter 2: Panda xControl 29.9.16
Fig. 2.4.4-1: Stopping3. Press "Start/Stop" button (switching off).
ATTENTION:NOTE: Never switch off the main battery until the
generator has stopped, shut the fuel valve if necessary!
2.5 The Menu
Fig. 2.5-1: Menu entry symbolsOne can access the menu from the final overview page.
Switch on the CP-G and scroll down to "Enter Menu Page".
Press the Start/Stop - Enter key to enter the menu.
2.5.1 Main Menu
Fig. 2.5.1-1: Main MenuYou can choose from the following sub-menus in the
main menu:
1. "Panel" sub-menu - The display of the of the panel can be adapted in the "Panel" sub-menu (e.g. brightness,
language, etc.).
2. "Generator" sub-menu - All settings related to the generator can be made in the "Generator" sub-menu, e.g.
bleeding the fuel pump etc.
3. The "Service" sub-menu is blocked and can only be accessed by trained personnel and Fischer Panda
employees.
4. Back - back to the overview pages

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 17
2.5.2 Sub-menu: "Panel"
Fig. 2.5.2-1: Sub-menu: PanelThe following items can be selected in the Panel sub-
menu:
1. Lighting
- changes the brightness of the display in normal mode.
2. Contrast
- changes the contrast of the display.
3. Standby Time
- to set the time until the panel switches to standby mode.
4. Standby Lighting
- changes the brightness of the display in standby mode.
5. Display Mode
- changes the display mode of the overview pages.
6. Language selection
- changes the language of the panel
7. Temperature Unit
- to set the temperature unit to °C or °F
8. Audible alarm
- to activate the audible alarm in the event of a fault
9. Flashing when faulty
- to activate panel flashing in the event of a fault
10.Panel heating
- activates panel heating at temperatures <+10°C
11.Reset to standard
The "Panel" sub-menu
12.is reset to the factory settings
- Switching from the "Panel" sub-menu to the Main Menu
2.5.2.1 Setting the illumination of the CP-G
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.

Panda xControl
Page 18 - Chapter 2: Panda xControl 29.9.16
Fig. 2.5.2.1-1: Sub-menu: IlluminationThe value is changed by using the "Step-up"/"Step-down"
keys and the setting is confirmed with the "Start/Stop - Enter“
key.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.2 Setting the contrast of the CP-G
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.2-1: Sub-menu: ContrastThe value is changed by using the "Step-up"/"Step-down"
keys and the setting is confirmed with the "Start/Stop - Enter“
key.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.3 Setting the standby time of the CP-G
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.3-1: Sub-menu: Standby TimeThe value is changed by using the "Step-up"/"Step-down"
keys and the setting is confirmed with the "Start/Stop - Enter“
key.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.4 Setting the standby illumination of the CP-G
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.4-1: Sub-menu: Standby IlluminationThe value is changed by using the "Step-up"/"Step-down"
keys and the setting is confirmed with the "Start/Stop - Enter“
key.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.5 Setting the display mode of the CP-G overview page
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The

Panda xControl
29.9.16 Chapter 2: Panda xControl - Page 19
respective menu item opens.
Fig. 2.5.2.5-1: Sub-menu: Display Mode"Symbolic View" or "Text View" can be selected by using the
"Step-up"/"Step-down" keys and then confirmed with the
"Start/Stop - Enter“ key.
The "Back" item returns you to the "Panel" sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.6 Setting the language of the text pages of the CP-G
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.6-1: Sub-menu: Language SelectionSelect the corresponding language by using the "Step-up"/
"Step-down" keys and then confirm with the "Start/Stop -
Enter“ key.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.7 Setting the Temperature Unit
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.7-1: Sub-menu: Temperature Unit"°C“ for "degrees Celsius" or "°F" for "degrees Fahrenheit“
can be selected by using the"Step-up"/"Step-down" keys and
then confirmed with the "Start/Stop - Enter“ key.
The "Back" item returns you to the Panel sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.8 Setting the Aural Alarm
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.

Panda xControl
Page 20 - Chapter 2: Panda xControl 29.9.16
Fig. 2.5.2.8-1: Sub-menu: Aural Alarm"Off" or "On" can be selected by using the "Step-up"/"Step-
down" keys and then confirmed with the "Start/Stop - Enter“
key.
The "Back" item returns you to the Panel sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.9 Setting the display to flash in the event of a fault
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.9-1: Sub-menu: Flashing when Faulty"Off" or "Error" or "Warning and Error" can be selected by
using the "Step-up"/"Step-down" keys and then confirmed
with the "Start/Stop - Enter“ key.
The "Back" item returns you to the Panel sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.10 Setting the Panel Heating
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
Fig. 2.5.2.10-1: Sub-menu: Panel Heating"Off" or "On" can be selected by using the "Step-up"/"Step-
down" keys and then confirmed with the "Start/Stop - Enter“
key.
The "Back" item returns you to the Panel sub-menu.
"Cancel" or "Confirm" can be selected by using the "Step-up"/
"Step-down" keys and then confirmed with the "Start/Stop -
Enter“ key.
2.5.2.11 Setting the display of the optional measurement data
The menu item is selected by using the "Step-up"/"Step-down" keys confirmed with the "Start/Stop - Enter“ key. The
respective menu item opens.
