Operating Manual
XLT-100
Compact Acoustic Leak Detector
MXLT100 Rev.6 072423
QUALITY
Fisher detectors are renowned for their quality.
Each detector is handcrafted in the USA with pride.
PERFORMANCE
The worldwide underground utility industry relies on Fisher.
Our instruments are durable, dependable and locate deeper.
REPUTATION
Fisher produced the rst patented metal detector in 1931. For
over 85 years, the Fisher logo has been a mark of excellence.
SERVICE
Should you have any questions or problems, contact:
FISHER RESEARCH LABS, INC.
1120 Alza Drive, El Paso, Texas 79907
Tel [phone] Fax [phone]
www.sherlab.com email: info@sherlab.com

OPERATION CHART
OPERATION
To use the XLT-100, power device on, place headphones over ears and
press metal tip to the utility. Before the tip makes contact, mute the
XLT-100 using the button; the tip making contact can produce a
loud sudden bump sound. The XLT-100 amplies vibrations in the
object for listening and displays the average sound/vibration level as a
number between 0 and 99.
2-YEAR LIMITED WARRANTY
This Fisher instrument has been rigorously tested before
shipment. Fisher Research Laboratory (FRL) warrants this
instrument to be free of manufacturing defects for a period
of 2 years after the original date of consumer purchase. This
warranty gives you specic legal rights and you may also
have other rights that may vary from state to state. During the
warranty period, FRL may elect to repair or replace a defective
instrument, free of charge, return postage excluded.
This warranty excludes headphones, all batteries and
damage caused by battery leakage regardless of the type
of battery used. Also excluded is damage caused by wear,
misuse, alterations and negligent handling or any abuse, which
in the opinion of FRL, caused the failure.
This warranty is void in the event any unauthorized person
opens or repairs the instrument.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED. FRL DOES NOT WARRANT
SUITABILITY TO SPECIFIC USE. FRL SHALL IN NO EVENT BE
LIABLE FOR ANY DIRECT, INCIDENTAL, CONSEQUENTIAL
OR INDIRECT DAMAGES.
This warranty is non-transferable.
Maintain proof of purchase. Proof of purchase must
accompany warranty claim. Should warranty service
become necessary, contact FRL for the name of the nearest
authorized Fisher Repair Center or call 915-225-0333 for return
authorization. Please include your dated proof of purchase
and a complete description of the problem.
NOTE TO CUSTOMERS LOCATED OUTSIDE U.S.A .
This warranty may vary in other countries; check with your
distributor for details.
Warranty does not cover shipping costs.
Proof of purchase is required to make a claim under this warranty.
Not to be used with conductive tracing cables longer than 6.5’ ( 1.98 m)
Power On
Press & Hold power button for approx. 2 seconds, then release.
Power O
Press & Hold power button for approx. 2 seconds, then release.
LCD Display Displays vibration level in default setting.
Shows volume when volume is increased or decreased.
Shows lter selection when lter mode is selected.
Shows notch selection when notch mode is selected.
Shows mute state.
Shows battery state.
Volume Increase or decrease volume using up and down buttons
in default mode. Level 99 is max volume, 0 is mute or
min volume. After 1.5 seconds, if neither up nor down
button is pressed, display reverts to vibration level.
Mute Toggle mute using mute button.
Filter Press mode button in default mode to enter lter
selection mode. Use up/down buttons to select lter.
0 --- 40 Hz to 8 kHz, default, (all pass)
1 --- 0.5 kHz center frequency (boost)
2 --- 1 kHz center frequency (boost)
3 --- 2 kHz center frequency (boost)
4 --- 4 kHz center frequency (boost)
5 --- 0.5 kHz center frequency (cut)
6 --- 1 kHz center frequency (cut)
7 --- 2 kHz center frequency (cut)
8 --- 4 kHz center frequency (cut)
Press mode button again to exit lter selection mode,
and enter notch lter mode.
Notch Press mode button in lter mode to enter notch mode.
Use left/right buttons to select lter.
00 --- No notch ltering
50 --- 50 Hz notch ltering
60 --- 60 Hz notch ltering
Back Light
Press to toggle through illumination levels.
C H

POWER
To turn on the device, press-
and-hold for approximately
2 seconds, then release. To
power the device o, press-
and-hold for approximately
2 seconds, then release. When
muted, the XLT-100 will power o
automatically after 5 minutes .
MODES
Level Mode
(Default on power-up)
In this mode, the XLT-100
displays the sound/vibration
level. No mode indicator is
displayed in this mode.
VOLUME MODE
In this mode, the user can
increase or decrease volume
levels.
To enter Volume Mode, press
the or buttons when in
Level Mode. The VOL mode
indicator will be displayed.
The numeric display indicates
the current volume level as a
number between 0 and 99. After
1.5 seconds with no volume
adjustments, the device will
automatically revert to Level
Mode.
FILTER MODE
To enter Filter Mode, press
. The FLT mode indicator will
be displayed.
In Filter Mode, the user can
select from 8 dierent boost/cut
equalization lters with center
frequencies at 500, 1000, 2000
and 4000 Hz. The boost lters
emphasize frequencies around
the center frequency.
The cut lters will de-emphasize
frequencies around the center
frequency. Alternatively, the user
can select the all-pass lter, lter
number zero, which is the default
lter. To exit Filter Mode, and
enter Notch mode, press .
NOTCH MODE
To enter Notch Mode, press
until “NCH” is displayed. In Notch
Mode, the user can select the 50
Hz notch lter, the 60 Hz notch
lter or no notch lter. When
using a notch lter the“notch”
frequency will be ltered out.
MUTE
Turn o the volume by pressing
. Use this mute function to
protect your ears from loud
sounds during set-up.
BACKLIGHT
Press to turn backlight on
or o.
COMPLIANCE
FCC Class B Notice
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Class B Devices
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/ TV technician for help.
ICES-003 Class B Notice
This Class B digital device complies with Canadian ICES-003(B)/NMB-3(B).
EU Declaration of Conformity
Hereby, Fisher Research Labs ®, declares that the XLT-100 Compact Acoustic Leak
Detector complies with the EMC standards under Directive 2014/30/EU.
EN 61000-6-1
EN61000-6-3
G D

BATTERIES
The XLT-100 uses two AA
batteries. Operating life using
2 AA alkaline batteries is
approximately 12-15 hours.
When charge indicator
becomes low, batteries should
be replaced. The XLT-100 will
automatically turn o if the
battery voltage becomes too
low. To replace old batteries,
use a coin or at-head screw
driver to turn the battery cap
counterclockwise until it comes
o. The XLT-100 has special
foam inserts in the battery
compartment; these inserts may
prevent batteries from sliding
out. If this happens, gently tap
the bottom of the XLT-100 on
a at surface, and batteries will
dislodge.
EXTENSION RODS
Included extension rods (2-13”)
May be used in place of standard
probe tip when longer reach for
contact with facility is required.
Extension Rods can also be
inserted into probe holes over
water line in turf areas.
HAND NOISE
Like all accelerometers,
contact microphones, ground
microphones and stethoscopes,
hand movement on the surface
of the housing will induce
vibrations into the sensor which
you will hear as a rubbing noise.
To avoid this, hold housing
securely and do not move hand
over the surface while listening.
SOME POTENTIAL
HAZARDS
As the sensor and extension rods
are “pointed”; caution should
be used when operating or
transporting the device.
Always select the lowest volume
setting that is appropriate for
each leak sound analysis.
It is recommended to set device
to MUTE until positioned to
sample for leak noise, then set to
OFF or MUTE immediately after
each sampling.
For safety reasons, do not
use this device near trac
or where other dangers are
present. This device is to be used
with interconnecting cables/
headphone cables shorter than
three meters.
Fisher Research Laboratory does
not warrant suitability to specic
use. Fisher Research Laboratory
shall in no event be liable for any
direct, incidental, consequential
or indirect damages.
BACK
LIGHT
POWER
MUTE
MODE
LEFT/RIGHT
CONTROL
LCD
DISPLAY
TRANSDUCER TIP
E F

BATTERIES
The XLT-100 uses two AA
batteries. Operating life using
2 AA alkaline batteries is
approximately 12-15 hours.
When charge indicator
becomes low, batteries should
be replaced. The XLT-100 will
automatically turn o if the
battery voltage becomes too
low. To replace old batteries,
use a coin or at-head screw
driver to turn the battery cap
counterclockwise until it comes
o. The XLT-100 has special
foam inserts in the battery
compartment; these inserts may
prevent batteries from sliding
out. If this happens, gently tap
the bottom of the XLT-100 on
a at surface, and batteries will
dislodge.
EXTENSION RODS
Included extension rods (2-13”)
May be used in place of standard
probe tip when longer reach for
contact with facility is required.
Extension Rods can also be
inserted into probe holes over
water line in turf areas.
HAND NOISE
Like all accelerometers,
contact microphones, ground
microphones and stethoscopes,
hand movement on the surface
of the housing will induce
vibrations into the sensor which
you will hear as a rubbing noise.
To avoid this, hold housing
securely and do not move hand
over the surface while listening.
SOME POTENTIAL
HAZARDS
As the sensor and extension rods
are “pointed”; caution should
be used when operating or
transporting the device.
Always select the lowest volume
setting that is appropriate for
each leak sound analysis.
It is recommended to set device
to MUTE until positioned to
sample for leak noise, then set to
OFF or MUTE immediately after
each sampling.
For safety reasons, do not
use this device near trac
or where other dangers are
present. This device is to be used
with interconnecting cables/
headphone cables shorter than
three meters.
Fisher Research Laboratory does
not warrant suitability to specic
use. Fisher Research Laboratory
shall in no event be liable for any
direct, incidental, consequential
or indirect damages.
BACK
LIGHT
POWER
MUTE
MODE
LEFT/RIGHT
CONTROL
LCD
DISPLAY
TRANSDUCER TIP
E F

POWER
To turn on the device, press-
and-hold for approximately
2 seconds, then release. To
power the device o, press-
and-hold for approximately
2 seconds, then release. When
muted, the XLT-100 will power o
automatically after 5 minutes .
MODES
Level Mode
(Default on power-up)
In this mode, the XLT-100
displays the sound/vibration
level. No mode indicator is
displayed in this mode.
VOLUME MODE
In this mode, the user can
increase or decrease volume
levels.
To enter Volume Mode, press
the or buttons when in
Level Mode. The VOL mode
indicator will be displayed.
The numeric display indicates
the current volume level as a
number between 0 and 99. After
1.5 seconds with no volume
adjustments, the device will
automatically revert to Level
Mode.
FILTER MODE
To enter Filter Mode, press
. The FLT mode indicator will
be displayed.
In Filter Mode, the user can
select from 8 dierent boost/cut
equalization lters with center
frequencies at 500, 1000, 2000
and 4000 Hz. The boost lters
emphasize frequencies around
the center frequency.
The cut lters will de-emphasize
frequencies around the center
frequency. Alternatively, the user
can select the all-pass lter, lter
number zero, which is the default
lter. To exit Filter Mode, and
enter Notch mode, press .
NOTCH MODE
To enter Notch Mode, press
until “NCH” is displayed. In Notch
Mode, the user can select the 50
Hz notch lter, the 60 Hz notch
lter or no notch lter. When
using a notch lter the“notch”
frequency will be ltered out.
MUTE
Turn o the volume by pressing
. Use this mute function to
protect your ears from loud
sounds during set-up.
BACKLIGHT
Press to turn backlight on
or o.
COMPLIANCE
FCC Class B Notice
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO
THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
Class B Devices
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/ TV technician for help.
ICES-003 Class B Notice
This Class B digital device complies with Canadian ICES-003(B)/NMB-3(B).
EU Declaration of Conformity
Hereby, Fisher Research Labs ®, declares that the XLT-100 Compact Acoustic Leak
Detector complies with the EMC standards under Directive 2014/30/EU.
EN 61000-6-1
EN61000-6-3
G D

OPERATION CHART
OPERATION
To use the XLT-100, power device on, place headphones over ears and
press metal tip to the utility. Before the tip makes contact, mute the
XLT-100 using the button; the tip making contact can produce a
loud sudden bump sound. The XLT-100 amplies vibrations in the
object for listening and displays the average sound/vibration level as a
number between 0 and 99.
2-YEAR LIMITED WARRANTY
This Fisher instrument has been rigorously tested before
shipment. Fisher Research Laboratory (FRL) warrants this
instrument to be free of manufacturing defects for a period
of 2 years after the original date of consumer purchase. This
warranty gives you specic legal rights and you may also
have other rights that may vary from state to state. During the
warranty period, FRL may elect to repair or replace a defective
instrument, free of charge, return postage excluded.
This warranty excludes headphones, all batteries and
damage caused by battery leakage regardless of the type
of battery used. Also excluded is damage caused by wear,
misuse, alterations and negligent handling or any abuse, which
in the opinion of FRL, caused the failure.
This warranty is void in the event any unauthorized person
opens or repairs the instrument.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED. FRL DOES NOT WARRANT
SUITABILITY TO SPECIFIC USE. FRL SHALL IN NO EVENT BE
LIABLE FOR ANY DIRECT, INCIDENTAL, CONSEQUENTIAL
OR INDIRECT DAMAGES.
This warranty is non-transferable.
Maintain proof of purchase. Proof of purchase must
accompany warranty claim. Should warranty service
become necessary, contact FRL for the name of the nearest
authorized Fisher Repair Center or call 915-225-0333 for return
authorization. Please include your dated proof of purchase
and a complete description of the problem.
NOTE TO CUSTOMERS LOCATED OUTSIDE U.S.A .
This warranty may vary in other countries; check with your
distributor for details.
Warranty does not cover shipping costs.
Proof of purchase is required to make a claim under this warranty.
Not to be used with conductive tracing cables longer than 6.5’ ( 1.98 m)
Power On
Press & Hold power button for approx. 2 seconds, then release.
Power O
Press & Hold power button for approx. 2 seconds, then release.
LCD Display Displays vibration level in default setting.
Shows volume when volume is increased or decreased.
Shows lter selection when lter mode is selected.
Shows notch selection when notch mode is selected.
Shows mute state.
Shows battery state.
Volume Increase or decrease volume using up and down buttons
in default mode. Level 99 is max volume, 0 is mute or
min volume. After 1.5 seconds, if neither up nor down
button is pressed, display reverts to vibration level.
Mute Toggle mute using mute button.
Filter Press mode button in default mode to enter lter
selection mode. Use up/down buttons to select lter.
0 --- 40 Hz to 8 kHz, default, (all pass)
1 --- 0.5 kHz center frequency (boost)
2 --- 1 kHz center frequency (boost)
3 --- 2 kHz center frequency (boost)
4 --- 4 kHz center frequency (boost)
5 --- 0.5 kHz center frequency (cut)
6 --- 1 kHz center frequency (cut)
7 --- 2 kHz center frequency (cut)
8 --- 4 kHz center frequency (cut)
Press mode button again to exit lter selection mode,
and enter notch lter mode.
Notch Press mode button in lter mode to enter notch mode.
Use left/right buttons to select lter.
00 --- No notch ltering
50 --- 50 Hz notch ltering
60 --- 60 Hz notch ltering
Black Light Press to toggle through illumination levels.
C H

Operating Manual
XLT-100
Compact Acoustic Leak Detector
MXLT100 Rev.6 072423
QUALITY
Fisher detectors are renowned for their quality.
Each detector is handcrafted in the USA with pride.
PERFORMANCE
The worldwide underground utility industry relies on Fisher.
Our instruments are durable, dependable and locate deeper.
REPUTATION
Fisher produced the rst patented metal detector in 1931. For
over 85 years, the Fisher logo has been a mark of excellence.
SERVICE
Should you have any questions or problems, contact:
FISHER RESEARCH LABS, INC.
1120 Alza Drive, El Paso, Texas 79907
Tel [phone] Fax [phone]
www.sherlab.com email: info@sherlab.com
