FB1000
Electrophoresis
Power Supply
7608139 • 9/13/06
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Introduction..........................................................................................................................................................3
Features........................................................................................................................................................3
Safety Information ..............................................................................................................................................4
Alert Signals..................................................................................................................................................4
Specifications ......................................................................................................................................................5
AC Input Power ............................................................................................................................................5
Environmental ..............................................................................................................................................5
DC Output Power..........................................................................................................................................5
Unpacking and Installation ..................................................................................................................................6
Operation ............................................................................................................................................................7
Location ........................................................................................................................................................7
Using the Power Supply ..............................................................................................................................8
Constant Voltage Operations........................................................................................................................9
Constant Current Operations........................................................................................................................9
Constant Power Operations........................................................................................................................10
Timed Operations ......................................................................................................................................10
Volt-Hour Operations ..................................................................................................................................11
Automatic Power-fail Restart ......................................................................................................................11
Programming ..............................................................................................................................................12
Maintenance......................................................................................................................................................14
Cleaning......................................................................................................................................................14
Replacing a Fuse........................................................................................................................................14
Troubleshooting ................................................................................................................................................15
Replacement Parts............................................................................................................................................16
Accessories ................................................................................................................................................16
Replacement Parts ....................................................................................................................................16
Compliance ......................................................................................................................................................17
Warranty ............................................................................................................................................................20
2
Table of Contents
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

The FB1000 power supply is designed to provide con-
stant voltage, current, or power in both Manual and
Programmed modes of operation commonly used in elec-
trophoresis applications. One to four sets of elec-
trophoresis cells can be connected in parallel and run
simultaneously. The FB1000 can deliver up to 250W of
total output power. When operating in any constant
mode, the power supply automatically limits the other
parameters to either the power supply maximum, or a
lower limit if set by the user. If any non-constant limit is
reached, the power supply will automatically switch con-
trol modes, controlling the limit parameter. In this way,
the FB1000 protects your electrophoresis cells from dam-
aging over power conditions. The FB1000 power supply
also provides for timed and volt-hour operation in all con-
trol modes, and allows an automatic completion in the
event of a power loss if enabled.
Features
•5-1000V, adjustable in 1 volt steps
•1-500mA, adjustable in 1mA steps
•1-250W, adjustable in 1W steps
•0-90C, adjustable in 1degree C steps
•Automatic control mode crossover
•0-99 hour 59 minute timed run
•0-9999 volt-hour timed run
•Automatic restart if loss of AC power (if enabled)
•Large LCD display
3
Introduction
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Read and understand this manual completely before
attempting to set up or use this instrument.
This equipment has been designed and tested to conform
to CSA1010 safety standards, as applicable to laboratory
instrumentation. This applies only to the FB1000 when
used as specified in the documentation, in its intended
applications, with Fisher Biotech approved electrophore-
sis apparatus only. Usage in any other manor may not
provide similar performance or safety protection.
This equipment is provided with a 3-conductor, grounded
AC line cord. The protective earth ground is necessary
for safe operation. Do not use any other AC line cord
with this instrument.
The FB1000 is a high voltage power supply capable of
generating dangerous levels of voltage and current during
operation. Exercise caution when working around and
with the electrical connections of this equipment. Always
check electrical connectors, wires, and associated appa-
ratus for any signs of wear or damage before using with
this equipment. Be sure to use only electrophoresis
equipment that is suitably rated for the voltage and cur-
rent capabilities of the FB1000 power supply.
The output of the FB1000 power supply is intended for
connection to electrically isolated electrophoresis appara-
tus only. Use only with electrically isolated electrophore-
sis apparatus with minimum isolation of 1000V. Do not
connect any terminal of the FB1000 output to earth
ground. This may impair the safety protection provided
by the equipment, or cause equipment damage.
The high voltage output of the FB1000 power supply
takes some amount of time to decay when unloaded or
lightly loaded. Wait a minimum of 60 seconds after stop-
ping a run before touching the power supply leads.
This equipment has a protective ground leakage current
of 0.5mA at 120VAC, and 1mA at 230VAC. While signifi-
cantly below the 3.5mA limitation for laboratory instrumen-
tation, some applications and locations require a leakage
current below 0.5mA. Check the specific requirements of
your application before using this equipment.
This equipment is for indoor use only.
4
Safety Information
Warning
Warnings alert you to a possibility of
personal injury.
Caution
Cautions alert you to a possibility of
damage to the equipment.
Note
Notes alert you to pertinent facts and
conditions.
Hot Surface
Hot surfaces alert you to a possibility of
personal injury if you come in contact
with a surface during use or for a period
of time after use.
Alert Signals
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
AC Input Power
95-265VAC, 50-60Hz, 350VA Max
Environmental
Operating temperature: 0-40°C, 0-95% R.H. non-condensing
Altitude: 2000m
Overvoltage category: II, IEC664
Pollution degree: 2, IEC664
DC Output Power
5-1000VDC, 250W Max
1-500mA, 250W Max
Ripple: ± 1%
Drift: ± 1%, after 30-minute warm-up
Specifications
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

When unpacking your FB1000 power supply, be sure you
have received the following items.
•FB1000 unit
•AC line cord
•This manual
Inspect your equipment and packaging material for signs
of damage. Damage to the shipping container may indi-
cate rough handling which could cause internal damage
to the power supply. If you suspect shipping damage to
the power supply, contact your carrier for instructions on
filing a claim. If you are missing any of the above items,
contact your supplier for instructions.
6
Unpacking and Installation
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
Location
Select a location that allows for 3" clearance behind the
power supply, and comfortable reach of the front panel
controls and cell connections. Do not block the vented
area of the case - on the front bottom of the unit, or the
fan area at the rear. Connect the power supply to a 3-
prong grounded AC outlet, using the AC cord provided
with the unit only. Connect the electrophoresis apparatus
to the power supply, making sure to match the red posi-
tive lead to the red positive jack, and the black negative
lead to the black negative jack. Similarly, connect a sec-
ond or more electrophoresis apparatus to the power sup-
ply if you plan to run more than one in parallel. Attach a
temperature probe to the FB1000 rear located connector
and the electrophoresis apparatus if you intend to perform
temperature monitoring for a run. Power the unit on using
the AC power switch located at the rear of the unit, next
to the AC line cord entry.
Operation
Figure 1. Front Panel Controls
Black negative jacks
Function keys Exit key
Black negative jacks
Run key
Red positive jacks Pause key Stop key Gray ON/OFF key Red positive jacks
Clear key
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Using the Power Supply
Press the dark gray key on the front of the unit to enable/dis-
able the control logic. The LCD display will illuminate and allow
selection of MANUAL or PROGRAM mode of operation as well
as enable/disable automatic power-fail restart. Toggle automat-
ic power-fail restart by pressing the topmost function key to the
right of the display. Select MANUAL or PROGRAM mode using
the function keys to the right of the display (see Programming
section for programming mode description). In manual mode,
the FB1000 preserves the constant setpoint each time you start
a run. The constant parameter is saved independently for each
mode; constant voltage, current, and power.
To change the control mode, press the Exit key. From the
resulting screen, select the new constant parameter using the
function keys to the right of the display.
After selecting a control mode and setting the limit and timed
run parameters if desired, press the Run key to energize the
power supply output. The power supply output will ramp up to
the appropriate setpoint, while not allowing any limit parameter
to be exceeded. If any limit parameter should be exceeded,
then the power supply will crossover control modes, making the
limit parameter the new control setpoint. The run mode display
shows the controlled parameter highlighted, and will automati-
cally change if a crossover has occurred.
To stop a run in progress, press the Run key, the Stop key, or
the gray ON/OFF key. The display will change to "STOP" signi-
fying that the output is no longer energized, and display the
conditions just before the stop. To pause a run in progress,
press the Pause key. The display will change to "PAUSE" sig-
nifying that the output is no longer energized, and that the run
can be resumed. Pressing Run or Pause resumes the run from
the previous point (i.e. for a timed run). Only a run that has
been paused can be restarted. After Stopping a run, or to
change parameters of a (paused) run, you must cycle the con-
trol logic off and then back on by pressing the gray ON/OFF
key.
During a run, the display will show the actual values of voltage,
current, power, and temperature. The time value displays
elapsed time for an untimed run, or time left for a timed run.
The volt-hour value displays the accumulated volt-hour value
for the run.
8
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
Constant Voltage Operations
From the mode selection screen, select constant voltage
operation by pressing the appropriate function key located to
the right of the display. To get to the selection screen from an
operating screen, press Exit, or cycle the control logic off and
then back on by pressing the gray ON/OFF key and selecting
MANUAL. The FB1000 will display the last saved values for
constant voltage mode. To switch between
volts/current/power and time/volt-hours, press function key F1.
To change a parameter, press the function key located to the
right of the display, next to the parameter you wish to change.
The FB1000 will allow a new value to be entered using the
keypad numeric keys. Press the function key labeled "Enter"
to complete the new setting. Press Clear to erase previous
keystrokes. Press Exit to cancel entering a new value. The
FB1000 will not accept a voltage setpoint outside of the
allowed range. Press Clear to re-enter an appropriate value.
The limit parameters are normally set to the power supply
maximum values. The FB1000 will not accept a limit parame-
ter outside of the allowed range.
In addition, the FB1000 will never exceed the maximum
power output specification of 250W.
Constant Current Operations
From the mode selection screen, select constant current oper-
ation by pressing the appropriate function key located to the
right of the display. To get to the selection screen from an
operating screen, press Exit, or cycle the control logic off and
then back on by pressing the gray ON/OFF key and selecting
MANUAL. The FB1000 will display the last saved values for
constant current mode. To switch between volts/current/power
and time/volt-hours, press function key F1. To change a
parameter, press the function key located to the right of the
display, next to the parameter you wish to change. The
FB1000 will allow a new value to be entered using the keypad
numeric keys. Press the function key labeled "Enter" to com-
plete the new setting. Press Clear to erase previous key-
strokes. Press Exit to cancel entering a new value. The
FB1000 will not accept a current setpoint outside of the
allowed range. Press Clear to re-enter an appropriate value.
The limit parameters are normally set to the power supply
maximum values. The FB1000 will not accept a limit parame-
ter outside of the allowed range.
In addition, the FB1000 will never exceed the maximum
power output specification of 250W.
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Constant Power Operations
From the mode selection screen, select constant power
operation by pressing the appropriate function key located
to the right of the display. To get to the selection screen
from an operating screen, press Exit, or cycle the control
logic off and then back on by pressing the gray ON/OFF
key and selecting MANUAL. The FB1000 will display the
last saved values for constant power mode. To switch
between volts/current/power and time/volt-hours, press
function key F1. To change a parameter, press the func-
tion key located to the right of the display, next to the
parameter you wish to change. The FB1000 will allow a
new value to be entered using the keypad numeric keys.
Press the function key labeled "Enter" to complete the
new setting. Press Clear to erase previous keystrokes.
Press Exit to cancel entering a new value. The FB1000
will not accept a power setpoint outside of the allowed
range. Press Clear to re-enter an appropriate value.
The limit parameters are normally set to the power supply
maximum values. The FB1000 will not accept a limit
parameter outside of the allowed range.
In addition, the FB1000 will never exceed the maximum
power output specification of 250W.
Timed Operations
It is possible to enter an amount of time for the power
supply to provide power, after which it will automatically
shut off. Use this feature for timed runs.
Set up a constant mode setpoint and limits as described
above. Enter a time duration of 0-99 hours, 59 minutes.
Atime duration of zero effectively disables timed run
mode.
When running a timed run, the time parameter displays
the time remaining in the run. When running a non-timed
run, the time parameter displays the elapsed time during
the run.
10
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Volt-Hour Operations
It is possible to enter an amount of volt-hours for the
power supply to provide power, after which it will automat-
ically shut off. Volt-hours is the integration of voltage over
time. Use volt-hour control to provide consistency
between runs.
Set up a constant mode setpoint and limits as described
above. Enter a volt-hour duration of 0-9999 volt-hours. A
volt-hour duration of zero effectively disables volt-hour run
mode.
During a run, the volt-hour value displays the accumulat-
ed volt-hour value for the run.
Automatic Power-Fail Restart
Automatic power-fail restart capability allows a timed or
volt-hour run which is interrupted by loss of AC power to
be restarted automatically, so that the total time/volt-hour
programmed for the run will be met.
To enable power-fail restart, press the top function key
when in the mode selection screen (MANUAL or PRO-
GRAM). The state of power-fail restart will toggle from off
to on or on to off with each keypress.
When AC power is restored during a run in which power-
fail restart is enabled, the display will show "POWER-FAIL
RESTART" for approximately 10 seconds indicating
power-fail restart pending. During this time the output is
not energized, to allow safely stopping the run (by press-
ing Run). After the power-fail restart pending delay is
completed, the power supply output will ramp up to the
setpoint value and the run will continue from that point.
Any number of power interruptions can occur during the
completion of a single run.
If a power-fail restart occurs during the running of a pro-
gram the FB1000 will complete the interrupted step, and
then advance to the next step in the program.
11
Note
Loss of AC power includes switching
off the unit using the power switch
located at the rear of the unit. When
performing timed or volt-hour runs
with power-fail restart enabled, always
use the front panel controls to stop a
run in progress.
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Programming
The FB1000 can store 9 programs, each containing 9
steps. A program step is a constant voltage, current, or
power setpoint with any associated limit parameters, and
most importantly a time and/or volt-hour setting. When
running a program step, after the time or volt-hour limit is
reached, the FB1000 will automatically run the next pro-
gram step (if there is one). After all program steps are
completed in a program the FB1000 will shut down. Any
sequence of control mode and timed/volt-hour steps can
be contained in a program. Note that a program step can
contain a zero for the time and volt-hour parameters, in
which case the FB1000 will continue to maintain that set-
point indefinitely (just like the setting had been run from
MANUAL mode).
To enter programming mode from an operating screen,
cycle the control logic off and then back on by pressing
the gray ON/OFF key and selecting PROGRAM. The
FB1000 will display the program screen, which shows the
number of steps contained in the selected program. Use
the function keys to the right of the display to move
through the 9 possible programs. To run the program
starting from step 1, press the Run key. To edit a pro-
gram (including adding a first step to an empty program)
press the function key labeled EDIT. The FB1000 will dis-
play the step screen, which shows the parameters for the
selected step (except when the program is empty in
which case the FB1000 automatically starts entering the
first step as follows). Use the function keys to the right of
the display to move through the 9 possible steps. To run
the program starting from the selected step, press the
Run key. To edit a step press the function key labeled
EDIT. The FB1000 displays the mode selection screen.
Select a constant mode of operation by pressing the
appropriate function key located to the right of the display.
To switch between volts/current/power and time/volt-
hours, press function key F1. To change a parameter,
press the function key located to the right of the display,
next to the parameter you wish to change. The FB1000
will allow a new value to be entered using the keypad
numeric keys. Press the function key labeled "Enter" to
complete the new setting. Press Clear to erase previous
keystrokes. Press Exit to cancel entering a new value.
The FB1000 will not accept any parameter outside of the
allowed range. Press Clear to re-enter an appropriate
12
OPERATION
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
OPERATION
value. When all the parameters of the step are as
desired, press Exit to return to the step screen. The
newly entered parameters will be displayed in the select-
ed step. To add a step after the selected step press the
function key labeled ADD. Enter parameters for the step
as for EDIT, pressing Exit when complete.
To delete a program or step, press the Clear key from the
program or step screen as desired. After confirmation the
FB1000 will remove the selected program or step from
memory.
Method 1 Next
2 steps Prev
Edit
Method 1 - 1/2 Next
100V / 200mA Prev
150W Add
0:10 Edit
Number of
steps
Step parameters:
the setpoint is
reverse video
Method number
Navigation and
editing keys
Step 1 of 2
Method number
Navigation and
editing keys
Figure 3. Step screen
Figure 2. Program screen
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Cleaning
Before cleaning the unit, be sure to always turn off AC
power using the switch at the rear of the unit, and then
disconnecting the AC line cord. The front of the unit is
sealed and can be wiped clean with any mild detergent
solution. Avoid harsh cleaners or agents as they may
deteriorate the surface of the tactile membrane keys.
Replacing a Fuse
Before servicing the unit, be sure to always turn off AC
power using the switch at the rear of the unit, and then
disconnecting the AC line cord. The FB1000 power sup-
ply requires no periodic servicing and should provide
years of trouble free operation. Should you need to
replace the fuses proceed as follows:
Turn off AC power using the switch at the rear of the unit,
and then disconnecting the AC line cord. Remove the
fuse holder assembly using a small flat blade screwdriver.
Always replace both fuses with appropriate replacement
fuses: 5A, 250V, 5X20mm, type T fuse (T5A,250V)
(Fisher catalog number FBFUSE3).
14
Maintenance
Caution
The FB1000 uses double pole neutral
fusing.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

15
The FB1000 detects and reports several events and conditions that are considered errors. The FB1000 will
stop any run in process and display "ERROR XX" where XX is one of the below listed errors. When the
FB1000 is displaying an error indication, press the gray ON/OFF key to clear the error and return to setup
mode, or press the Run key to resume the run (after correcting the cause of the error). Note that loss of AC
power during a run is considered an error condition. Always stop a run before turning off AC power to the
FB1000.
'XX' Condition and possible remedy
0020 Minimum load current detected. The output is not connected, or the electrophoresis apparatus is not
set up properly. Check your setup and connections.
0121 Maximum load current exceeded. The output is short circuit, or the electrophoresis apparatus is not
set up properly. Check your setup and connections
02 Step load current change. The FB1000 has detected a large change in load current. Check your
setup and connections
04 Loss of AC power, automatic recovery from power fail disabled, run not completed. The FB1000
detected loss of AC power and didn't complete run.
05 Loss of AC power; run not timed. The FB1000 detected loss of AC power.
06-99 The FB1000 detected an internal error condition. Contact technical support for instructions.
Troubleshooting
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

16
Accessories
Adapter for Cells FBAD1Q
Under Counter Bracket FBUB3000Q
Temperature Probe (0 - 90 C) FBTEMPQ
Replacement Parts
AC line cord FBCORD1
Fuse, T5A, 250V FBFUSE3
For replacement parts contact Fisher Scientific at:
Fisher Scientific
2555 Kerper Blvd.
Dubuque, IA 52003
1-800-926-0505
Replacement Parts
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

CSA 1010
This equipment has been designed and tested to conform
to CSA1010 safety standards, as applicable to laboratory
instrumentation. This applies only to the FB1000 when
used as specified in the documentation, in its intended
applications, with Fisher Biotech approved electrophore-
sis apparatus only. Usage in any other manner may not
provide suitable protection.
17
Compliance
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

18
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

19
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
