FiveCo CDC11 User manual

CDC11 DISPLAY
User manual
Five srl
Via Cerodolo, 4 - 40138 Bologna

1
Index
1 Product introduction –p.2
2 Functions summary –p.3
3 Technical parameters –p.4
4 Dimensions –p.5
5 Installation instructions –p.6
6 Button definition –p.7
7 Main interface –p.8
8 Board terminal cable sequence schematic diagram –p.9
9 Frequent questions –p.9
10 Error codes –p.10

2
1.Product Instruction
CDC11 display uses the 2.4”LCD color screen features a very clear display interface, with
backlight crepuscular sensor.
Double side printed board, nylon buckle and ABS material shell. Good mechanical performance is
ensured in a temperature range from -20° to 6°. It also features IP65 protection to water infiltration.
The display can match 24V/36V/48V battery; it integrates front light switch function.
Main interface has two background colors, white or black (day/night), switching automatically
between the two themes (thanks to a crepuscular sensor) and always providing a clear visibility for
every external light condition.

3
2. Functions summary
▻Total distance (odometer) / trip distance
▻Maximum speed / average speed
▻Current speed
▻km/miles unit switch
▻Integrated lights on/off indicator on display
▻PAS (pedal assist system) level selection
▻Battery residual capacity
▻Error code definition
▻USB charging function
▻6Km/h walk assistance function
day night

4
3. Technical parameters
- Voltage: 24V / 36V / 48V
- Current: 24V / 35mA, 36V / 27mA, 48V / 24mA
- Ambient temperature limits: -20° / +60°
- Ambient humidity limits: 0-100% RH (relative humidity)
- Ingress Protection: IP65
- Screen viewing angle: 160° Horizontal / 160° Vertical
- Screen brightness: 400~450 lumen (good visibility in sunlight)

5
4. Dimensions

6
5. Installation instruction
- Fix display and button panel on the handlebar
- Adjust the angle of view in a comfortable visible position
- Tighten the screws to finish the installation

7
6. Button definition
Button
Operation
Function
hold 3S
Nothing
click
(In main interface) -> turn on/off usb charging
function
(In setting function) -> confirm
(In passwords interface) -> switch the
passwords digit
hold 3S
Nothing
click
(In main interface) -> Increase the lever
(In setting interface) -> Switch the options
(In passwords interface) -> Increase the numeric
value
hold 3S
(In main interface) -> 6Km/h walk function
click
(In main interface) -> decrease
(In setting interface) -> switch options
(In passwords interface) -> decrease the numeric
value
hold 3S
-> Power off
click
(When off) -> Turn power on
(In main interface) -> Turn lamp on/off
(In passwords input interface) -> Switch the
password digit

8
7. Main interface instructions

9
8. Board terminal cable sequence diagram
9. Q&A
Q
Why the display is not able to start up?
A
Check the connector between display and controller.
Q
How to deal with the error code?
A
Ask the customer care at your local dealer.

10
10. Error codes
Error code
Definition
2
Over current protection (controller)
- Check whether the connectors of 3-phase power cable and the connectors are
badly connected.
- If the problem is still present after re-connect the connectors, there is something
wrong with the controller or motor.
3
Controller cannot properly drive the motor
- Check whether the connectors of 3-phase power cable and the power supply
connectors are badly connected.
- Check if there’s not enough power to drive the system than 2S, such as climbing,
or the wheel is stuck
- If the problem is still present after re-connect the connectors, there is something
wrong with the controller or motor.
4
Undervoltage protection
- Battery voltage is too low.
5
Brake problem
- After turning on, check whether the brake sensor is working properly.
- If the brake signal is less than 0.75V for very a long time, there is something
wrong with the brake.
6
Signal problem
- Check whether the connector of the motor’s cable is well connected.
- if the problem is still present after re-connecting, the motor sensor may be broken.
7
Throttle problem
- After turning on, check whether:
A) the throttle is out of control
B) the throttle signal is less than 0.75V
C) customer turns the throttle before the system works.
- The error can be solved after throttle is reset.
8
Broken controller
A/10
Display / controller communication problem
- yellow cable is disconnected.
D/13
Controller program is wrong / 5V is wrong
- check whether the brake signal short with 5V.
WARNING: any alteration of the ebike electronic system will result in warranty decay.

Thank you for your attention
enjoy the ride!
